Clevertronics L10 LWP2LIFE-PRO-WPPOD Series Installation and operating instructions

1942122
V1.4
3 March 2020
Clevertest and Clevertest Plus
Refer to the supplementary operation guide supplied with the Product.
After Power ON, the Status LED on a Clevertest Plus enabled fitting will display a rapid Green or
Red flashing for a period up to 2 minutes.
Maintained fittings ((LWP2LIFEM-PRO-WPPOD-xx-yy)) cannot be scanned with a camera using
the CleverSparky App as the maintained light source interferes with the camera scanning function.
To register the fitting manually enter the serial number from the QR code and visually read the test
result and enter manually into CleverSparky.
Zoneworks and DATA Monitored Options
Lifelights with part numbers LWP2LIFE-PRO-WPPOD-ZW, LWP2LIFE-PRO-WPPOD-DATA are
fitted with Zoneworks communications modules (nodes). These fittings are monitored using either
Powerline Carrier Technology that utilising the power cable to provide data communication or a
dedicated data cable to/from data router installed on a dedicated data trunk connected to a central
Server (can also be connected via Ethernet/Internet/Fibre). Zoneworks software on the server is used
to monitor, coordinate testing and collate test data from each Lifelight. Zoneworks Lifelights can be
commissioned by a single push of the test switch, or scanning of the supplied barcode. The LED Test
Switch indicator provides a multifunction indication of the status of the Lifelight during testing and
normal operation:
State
LED Operation
Commissioned LED on Solid (Green)
Un-commissioned LED flashes at 0.5Hz (0.5s Green, 0.5s Yellow)
Emergency Light Test In Progress LED flashes at 3s On (Yellow) & 0.5s Off
In the case of the DATA version a 2-way “figure 8” cable and terminal block facilitates the
connection to the DATA network via a multi-drop bus (daisy chain connection). For further
information of installation of a Zoneworks system, please refer to the Zoneworks Users Guide and
Commissioning Guide (incl. DATA version)
DALI EM Option
Lifelights with part numbers LWP2LIFE-PRO-WPPOD-DALI are fitted with DALI modules (nodes)
that facilitate connection and integration to 3rd Party Lighting Control Systems. Before installing the
LWP2LIFE-PRO-WPPOD-DALI please confirm that the Lighting Control System has the capability
to monitor DALI Emergency Luminaires. The LWP2LIFE-PRO-WPPOD-DALI will be addressed and
configured into the control system by the Lighting Control System Commissioning Technicians and
not Clevertronics.
State LED Operation
Commissioned/ Un-commissioned LED on Solid (Green)
Emergency Light Test in progress LED flashes at 1s On (Yellow) & 1s Off
“IDENTIFY COMMAND” Fitting goes into emergency mode for 10 seconds
A 2-way “figure 8” cable and terminal block facilitates the connection to the DALI network OR a
5/6way “structured wiring system” lead and plug facilitating the power and DALI connection. DALI
connections are marked as Da Da.
Models: LWP2LIFEz-PRO-WPPOD-xx-yy
Testing:
Options:
Manual Test
xx = Blank
Sustained
z = Blank
Zoneworks
xx = ZW
Maintained
z = M
Z/W DATA
xx = DATA
Tamperproof
yy =TP
DALI Comp.
xx = DALI
Clevertest
xx = CT
(NOTE: -CT Products supplied with the Clevertest Plus Symbol are activated with Clevertest PLUS
capability. Please refer to the operation guide supplied with the product for details).
Spare Parts:
1530050
Battery, 3.3 Volt 2.5Ah Li-ion (4)
2750356
LP/L10 WP POD, Gen2, 2 LED, Wht LED, Sub Assy
LLIFE
-PRO-CKIT-NP LifelightPro,Control Only,Batten,L10, NP
Important
:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has
been switched off and isolated. Installation must be carried out in
accordance with the relevant Au
stralian and International Standards.
LWP2LIFE-PRO-WPPOD
Surface Mount Twin Head Emergency Luminaire
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
Website:
www.clevertronics.com.au
Email:
[e-mail]
Phone:
[phone]
Fax:
[phone]
New South Wales
Phone:
[phone]
Fax:
[phone]
Queensland
Phone:
[phone]
Fax:
[phone]
South Australia/Northern Territory
Phone:
[phone]
Fax:
[phone]
Western Australia
Phone:
[phone]
Fax:
[phone]
New Zealand
Phone:
[phone]
Designed in Australia to comply with the
requirements of AS2293.3: 2005 and AS/NZS
CISPR15: 2011
NOTE: Standard product codes with this symbol
are enabled with Clevertest Plus capability. Please
refer to the operation guide supplied with the product for
details.

1942122
V1.4
3 March 2020
Installation:
Note: The fitting is designed to be installed as shown in the image below.
This LWP2LIFE-PRO-WPPOD Surface mount non-maintained Emergency Luminaire can be
installed as either ceiling mount with the PODs facing down or on the wall with the PODs rotated to
face down.
•When wall mounting the fitting must be mounted 32mm off the wall to allow pods to rotate
•Locate the installation position.
•Pre-drill mounting holes per diagram below.
•Removed fitting cover.
•Use suitable fixings to fasten the fitting to the mounting surface.
•Taking note of the terminal block positon, drill a hole in the fitting box to suit the cable gland or
conduit to be used for power entry. Please ensure that the cable entry is appropriately
sealed to maintain the IP65 rating.
•Terminate the supply cables to the L, N & E terminals (in the case of the –DALI or –DATA
fittings terminate the DALI or DATA cable to the terminals marked Da Da or DATA).
•Ensure the Batteries and POD cables are connected.
•To rotate the PODs for the wall mount (WM) position loosen the internal locking nut, rotate
and re-tighten the nut.
•Screw the cover to the base.
Networking:
When installing the product on a monitored network, (ZONEWORKS, DATA, DALI) simply insert
the relevant Smart Node PCA.
Images and Dimensions:
Testing:
When the LWP2PIFE-PRO-WPPOD unit is connected to the un-switched active, it must be allowed to charge
the battery for at least 24 hours. The emergency lamp only illuminates during a power failure. Conduct the
following tests:
•During the first commissioning test the emergency lamp must illuminate for at least 2 hours after
disconnection from the main supply. The results of all tests are required to be recorded in a service
logbook, which is to be kept on-site at all times. If the unit fails to illuminate for the requisite time,
remedial action must be taken to repair the situation and once completed, the unit must pass a
subsequent test.
•Press and hold Test Button in each POD or switch Off Mains Supply, check that the emergency lamp is
On.
•Release the Test Button or Switch on Mains Supply, check that the emergency lamp is Off (Non-
maintained operation).
Below are a list of common problems and their possible causes:
Fault: The Green LED indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected.
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Rated Emergency Lumen Output in accordance with AS2293.1 (refer to
spacing tables for installation positions):
Refer to the Technical Label for classification.
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Lifelight Units, on these circuits, will have their batteries discharged or “cycled”.
The Li-ion battery in the Lifelight has been selected to give excellent long-life performance in a controlled IEC
60598-2-22 testing environment. Excessive battery cycling will reduce through-life performance and may lead
to premature battery failure. Battery warranty claims, as a result of such abuse, are specifically EXCLUDED
from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
Note: The image below shows the
LWP2LIFE-PRO-WPPOD in the wall
mount configuration with the PODs
rotated down. To mount to the ceiling
using the same mounting instructions
but ensure the heads are facing down.
Note: When
rotating the
PODs in WM
position ensure
the PODs are
level with the
bottom of the
main enclosure.
