Clevertronics Argonaut PRO ARGOPRO-1200 Series Installation and operating instructions

1948882
V1.2
28 February 2022
THIS PAGE IS INTENTIONALLY LEFT BLANK
240V Argonaut PRO Weatherproof LED Batten
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
UK OFFICE
Website: www.clevertronics.co.uk
362 Stockley Close
West Drayton UB7 9BL
Phone: [phone]
Models: ARGOPRO-1200-xx-yy
Options:
Microwave Sensor (HI/LO)
xx = SEN
DALI Driver
xx = DD
ZW Inline Filter
yy = FLT
Spare Parts:
8002755
PCA:LED Strip ARGOPRO-1200,HT10540-A1,16P16S,4000K
1330055
LED Driver –Tridonic LC 50w 350-1050mA, 20-50V
1330151
LED Driver - TCI DC MAXI JOLLY SVM 65 DALI SLIM
(SEN version only)
1330056
LED Driver –Tridonic LCA 50w 350-1050mA, one4all Ip PRE
(DD version only)
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Building and Electrical Standards.

1948882
V1.2
28 February 2022
Installation:
This product can be mounted/suspended from any solid surface. Follow the below installation steps:
•Determine the installation and power entry method.
•Undo the Diffuser Clips, remove the Diffuser and Gear Tray. Position the batten base in the desired
location and Mark out the fixing points on the mounting surface.
•If the cable entry is to be via the rear of the body –Drill out a suitable entry-hole in the rear of the
batten body (must be suitably sealed after cable entry using a sealant). If the cable entry is via the
end of the batten - Install the provided cable gland, or bring in conduit, to the base as required for
the intended power access.
Note: Only round cables are to be used with the cable gland for an IP65 seal. Keep cable entry
straight and tension free. Ensure all seals are tight.
min. wire diameter 7mm, max. 12mm.
•For surface mounting, there are 3 extrusions/posts at each end of the base. Drill out the desired
number of fixing points at each end. Fixings must only be through the extrusions/mounting
posts.
oPosition the fitting to the mounting surface and mark the mounting holes.
oCable/Gland entry to be down if mounting vertically.
oDrill the mounting holes.
oFix the base to the surface with appropriate fixings.
oSeal any penetrations/fixing points with appropriate sealant.
•For Surface Mount Clip mounting, measure/mark spacing (see Dimensions image), install
stainless steel clips to surface (use appropriate fixings), then insert batten into clips.
•For Suspension Mounting, measure/mark spacing (see Dimensions image), install suspension
device, E.G chain, and connect chain to batten base.
•Wire mains power cable, 240V 50Hz, to terminals marked L, N & (and DALI Cable to terminals
marked Da Da as applicable)
•Set Switch to the desired Lumen Output (3541lm | 4660lm | 5495lm | 6259lm, Default = 4660lm)
•Attach Gear Tray to lanyards.
•Reinstall the Gear Tray.
•Reinstall the Diffuser, latch the Diffuser using Diffuser Clips and secure with screws provided
NOTE:
•This luminaire (with reinforced insulation between control/LED terminal and AC Supply) contains
non-user replaceable light source –to be replaced (if required) by the manufacturer or his service
agent or a similar qualified person.
Dimensions:
Lumen Setting:
For -SEN products refer to the DIP Switches on
the Driver.
NOTE: Recommended currents are 500mA, 650mA, 750mA & 900mA for this product. Using settings
outside of the recommended will void warranty. Product must be de-energised before switching
Lumen/Current.
Trouble Shooting:
Below are a list of common problems and their possible causes.
Fault: The LED Strip is not illuminated.
Check: A.C. is connected and is turned on.
Wiring connections between the LED Driver & LED Strips
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
https://clevertronics.co.uk/product-warranty-statement/
