Clevertronics LP Supalite CFLLED Series Installation and operating instructions

1949315
V1.0
7 April 2022
Instruction Sheet Template - V1.3 –Updated 20/01/2022
Clevertest Plus
Refer to the supplementary operation guide supplied with the Product.
After Power ON, the Status LED on a Clevertest Plus enabled fitting will display a rapid Green or Red
flashing for a period up to 2 minutes.
4HR: CTP will only test for the 2 hours (first test) and 90 minutes duration. 4 hours testing would only be
facilitated as a Manual Discharge Test.
Zoneworks HIVE Monitored Options
Fittings with part numbers -HV/-HVG are fitted with Zoneworks communications modules (nodes). These
fittings are monitored using RF transceiver modules operating in the ISM band connected to a central
Server (can also be connected via Ethernet/Internet/Fibre). Zoneworks software on the server is used to
monitor, coordinate testing and collate test data from each fitting. Zoneworks Fittings can be
commissioned by scanning the supplied barcode. The LED Test Switch indicator provides a multifunction
indication of the status of the fitting during testing and normal operation:
Option
State
LED Operation
HV, HVG
Commissioned
LED on Solid (Green)
HV, HVG
Un-commissioned
With network connectivity
Batt plugged-in: yellow 1s, green 1s
Batt unplugged: red 1s, off 1s
HV, HVG
Un-commissioned
Without network connectivity
Batt plugged-in: yellow 250mS, green
250mS, yellow 250mS, green 250mS,
green 1s
Batt unplugged: red 250mS, off
250mS, red 250mS,off 250mS, off 1s
HV, HVG
Emergency Light Test In Progress
LED flashes at yellow 1s , 0ff 1s
For further information of installation of a Zoneworks system, please refer to the Zoneworks Users Guide
and Commissioning Guide
DALI EM Option
Luminaires with part numbers having -DALI are fitted with DALI modules (nodes) that facilitate connection
and integration to 3rd Party Lighting Control Systems. Before installing the -DALI luminaire, please confirm
that the Lighting Control System has the capability to monitor DALI Emergency Luminaires. The -DALI
fitting will be addressed and configured into the control system by the Lighting Control System
Commissioning Technicians and not Clevertronics.
State
LED Operation
Commissioned/ Un-commissioned
LED on Solid (Green)
Emergency Light Test in progress
LED flashes at 1s On (Yellow) & 1s Off
“IDENTIFY COMMAND”
Lamp and Status LED Flash for 30 seconds
A 2-way “figure 8” cable and terminal block facilitates the connection to the DALI network. DALI
connections are marked as Da Da.
LP™ Supalite LED Emergency Luminaire
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Designed in Australia to comply with the
requirements of AS2293.3: 2018 and AS/NZS
CISPR15: 2017
NOTE: Standard product codes with this symbol are
enabled with Clevertest Plus capability. Please refer to
the operation guide supplied with the product for details.
Models:
CFLLED-xx-yy-ww-zz
Testing:
Options:
Manual Test
xx = Blank
Black
zz=BLK
Zoneworks HIVE
xx = HV/HVG
15 Minutes Additional ON
time after power resumes
yy=DLY
DALI Registered.
xx = DALI
4 Hour Battery
ww=4HR
Spare Parts:
1550230
Replacement Battery
1100955
Replacement Emergency LED Head –Right
1100954
Replacement Emergency LED Head –Left
1100956
Replacement Emergency LED Head –Left (-BLK option)
1100957
Replacement Emergency LED Board –Right (-BLK option)
8003501
Replacement Emergency Driver
Important:
It is illegal for anyone, exceptfor a licensed electrician toinstall or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.

1949315
V1.0
7 April 2022
Instruction Sheet Template - V1.3 –Updated 20/01/2022
Installation:
This CFLLED Surface Mount Non-maintained Emergency can be installed on PLASTER or solid block
walls.
1. Take off the front external cover by inserting a flat blade screwdriver into the slots along the
bottom edge of the fitting.
2. Mark the mounting hole positions on the wall and drill fixing holes
3. Using the appropriate fixing hardware for the wall surface fix the CFLLED to the wall.
4. If hard wiring, remove the flex and plug after removing the internal cover plate over the terminal
block.
5. If hard wiring terminates the 240V, 50Hz supply to the terminals marked A, N & E. The cable
entry hole through the back of the unit is shown in the image below. Install the internal cover
plate over the top of the terminal block.
6. Re-install the External Front Cover by pushing it back into place until it clicks in top and bottom.
7. If using the flex and plug, plug it into a suitable socket (240V, 50Hz).
8. Adjust the LED heads into position. Two screws are provided for each head to move them into
position. The front screw adjusts the L/R position (roll) and the side screw adjusts the U/D (tilt)
position. There is a standard positioning marker on the body representing a 30° roll out and 30°
tilt down –this is the position that provides the maximum square area coverage when wall
mounted at 3m
9. If the CTP capabilities are activated, please affix the CTP status label to a visible surface and
Four Segment Marking on the product will include an ‘’F’’ in third segment block
Networking:
When installing the product on a monitored network, (HIVE, DALI) simply insert the relevant Smart Node
PCA.
Dimensions:
Testing:
When the CFLLED unit is connected to the un-switched active, it must be allowed to charge the battery
for at least 24hours. The emergencylamp only illuminates during apower fail. Conduct the following tests:
•The emergency lamp must illuminate for at least 2 hours after disconnection from the mains. The
results of all tests are required to be recorded in a service logbook, which is to be kept on-site at all
times. If the unit fails to illuminate for the requisite time, remedial action must be taken to repair the
situation and once completed, the unit must pass a subsequent test.
•Press and hold Test Button or switch Off Mains Supply, check that the emergency lamp is On.
•Release the Test Button or Switch On Mains Supply, check that the emergency lamp is Off (Non-
maintained operation).
Trouble Shooting:
Below are a list of common problems and their possible causes.
Fault: The Green LED Test Switch indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Rated Emergency Lumen Output in accordance with AS2293.1, not applicable
for –TH (theatre) version (refer to spacing tables for installation positions):
Refer to the Technical Label for classification information.
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The battery in this fitting has been selected to give excellent long-life
performance in a controlled AS2293 testing environment. Excessive battery cycling will reduce through-
life performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
