Clevertronics ARGO-1500-EM Series Installation and operating instructions

1948868
V1.1
27 January 2022
Instruction Sheet Template - V1.2 –Updated 06/10/2021
Testing:
Once connected to the 240V mains supply, the unit must be allowed to charge the battery for at least 24
hours. Conduct the following tests:
•For the first test, the emergency lamp must remain illuminated for at least 2 hours after
disconnection from the mains supply.
•Subsequent tests require the unit to illuminate for at least 90 minutes. The results of all tests are
required to be recorded in a service logbook, which is to be kept on-site at all times. If the unit fails
to remain illuminated for the requisite time, remedial action must be taken to repair the situation
and once completed, the unit must pass a subsequent test. For more specific information, please
refer to the current edition of the AS 2293.3 Standard.
•Press and hold Test Button or switch Off Mains Supply, check that the emergency lamp is On.
•Release the Test Button or Switch On Mains Supply, check that the emergency lamp is Off (Non-
maintained operation).
Rated Emergency Lumen Output in accordance with AS2293.1 (refer to
spacing tables for installation positions):
Refer to the Technical Label for classification information.
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The battery in this fitting has been selected to give excellent long-life
performance in a controlled AS2293 testing environment. Excessive battery cycling will reduce through-
life performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
Trouble Shooting:
Below are a list of common problems and their possible causes.
Fault: The Green LED indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Fault: The main LED strip is not illuminated.
Check: A.C. is connected and is turned on.
Wiring connections between the LED driver and LED strip.
Fault: Green LED flashes once every 5 seconds-Battery in disconnected
Check: Battery is connected.
Fault: Green LED blinks off once every 5 seconds- Charging very flat battery
Allow 20min to recover battery then recheck
Fault: Green LED flashes at 2Hz (Fast flash)- Faulty battery
Replace battery
ARGO Weatherproof Emergency LED Batten
Switchable Colour
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Designed in Australia to comply with the requirements of
AS2293.3: 2005 and AS/NZS CISPR15: 2017
Models:
ARGO-1500-EM-xxx
Options:
Microwave Sensor (HI/LO)
xxx = SEN
Spare Parts:
8002851
PCA: LED Strip for ARGO-1500
1330108
LED Driver - Xitanium, 72w, 1.2-1.4A, 51V DS 230V
1330151
LED Driver - TCI DC MAXI JOLLY SVM 65 DALI SLIM (for -SEN only)
AUM03570030001
Lifelight:2LED, Eco, NM, Control Only,3.2Ah, 400mA
1560050
BATT:Eco Lith 3.2V 3.2Ah 70mm lead, no BRKT
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.

1948868
V1.1
27 January 2022
Instruction Sheet Template - V1.2 –Updated 06/10/2021
Installation:
The ARGO-1500-EM-xxx can be mounted to or suspended from any solid surface. Please follow the
below installation steps:
•Determine the installation method (surface/surface with clips) and the power entry method.
•Undo the diffuser clips, remove the diffuser and gear tray. Position the batten base in the desired
location. Mark out the fixing points on the mounting surface.
•If the cable entry is to be via the rear of the body –Drill out a suitable entry-hole in the rear of the
batten body (must be suitably sealed after cable entry using a sealant). If the cable entry is via the
end of the batten - Install the provided cable gland, or bring in conduit, to the base as required for
the intended power access. Note: Only round cables are to be used with the cable gland for an
IP65 seal. Keep cable entry straight and tension free. Ensure all seals are tight.
min. wire diameter 7mm, max. 12mm.
•For surface mounting -, there are 2 extrusions/posts at each end of the base. Drill out the desired
number of fixing points at each end. Fixings must only be through the extrusions/mounting
posts.
oPosition the fitting to the mounting surface and mark the mounting holes.
oDrill the mounting holes.
oFix the base to the surface with appropriate fixings.
oSeal mounting area with appropriate sealant.
•For Surface Mount Clip mounting, measure/mark spacing (see dimensions below), install
stainless steel clips to surface (use appropriate fixings), then snap batten into clips.
•Re-attach battery into Emergency Driver & remove Warning Label from Terminal Block.
•Wire mains power cable, 240V 50Hz, to terminals marked Lsw (Switched Active), Lem
(Emergency/Unswitched Active), N &
•Set Colour Switch to the desired colour (3000K, 4000K, 5700K)
•Attach gear tray to lanyards.
•Reinstall the gear tray, diffuser and latch the diffuser clips.
Wiring:
Sensor Version:
Dimensions:
Colour Setting:
Gear Tray Clip:
Battery Replacement:
1. Prior to any work, isolate power to any Batten that requires battery replacement
2. Open the Diffuser by releasing the Batten Diffuser Clips (remove any screws that may have been
installed into clips)
3. Unlock the Gear Tray by rotating the Gear Tray Clips 90° in an anti-clockwise direction (ensure the
Gear Tray is supported while unlocking clips)
4. Remove Battery connector from the Emergency Driver
5. Remove Battery and Battery Clips from the Gear Tray (release one side of clips to remove battery and
clips together as one)
6. Install replacement Battery & Clips and connect into Emergency Driver
7. Re-Install the Gear Tray and ensure Clips are locked (rotate clips by 90° clockwise)
8. Re-Install the Diffuser and close all clips (re-install any screws that may have been inserted into the
Diffuser Clips)
Note:
This luminaire (with reinforced insulation between control/LED terminal and AC Supply) contains non-user
replaceable light source and battery –to be replaced (if required, refer installation instructions for battery
replacement) by the manufacturer or his service agent or a similar qualified person.
