CommScope OneCell RP5000 Series Manual

DRAFT
Hardware Installation, RP5000 series
Release 4.0
Document Number: M0300A2
OneCell®
Document Revision: 4.0.11
Date: January 2020

ii M0300A2 4.0.11 January 2020
DRAFT
Copyright 2020 CommScope, All rights reserved.
THIS DOCUMENT HAS BEEN DEVELOPED BY COMMSCOPE, AND IS INTENDED FOR THE USE OF ITS
CUSTOMERS AND CUSTOMER SUPPORT PERSONNEL.
THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT
TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS
MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY
PRODUCTS.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET
FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED
HEREIN BY REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED
WARRANTY, CONTACT YOUR COMMSCOPE SALES REPRESENTATIVE FOR A COPY.

OneCell® Installation, RP5000 series, Release 4.0 iii
DRAFT
Contents
Document revision history
About this document
Audience....................................................................................................................xiii
Purpose.......................................................................................................................xiii
What you need to know .............................................................................................xiii
Customer documentation...........................................................................................xiii
Conventions ................................................................................................................xv
Notes, cautions, and warnings ...................................................................................xvi
PART 1 OVERVIEW AND PREPARATION
Chapter 1
CommScope OneCell® overview
Overview....................................................................................................................1-2
CommScope OneCell system ....................................................................................1-2
OneCell hardware components..................................................................................1-3
Baseband Controller physical ports.....................................................................1-3
Chapter 2
Preparing to install the OneCell system
Overview....................................................................................................................2-2
Before installing the OneCell components................................................................2-2
PART 2 ONECELL COMPONENT INSTALLATION
Chapter 3
Baseband Controller installation
Preparing for Baseband Controller installation..........................................................3-2
Installing the Baseband Controller into a rack...........................................................3-2
Chapter 4
RP5100i installation
RP5100i installation overview...................................................................................4-2
Ceiling mount.............................................................................................................4-3
Mounting the Radio Point on the ceiling tile ......................................................4-5

Contents
iv M0300A2 4.0.11 January 2020
DRAFT
Mounting the Radio Point above the ceiling tile...............................................4-15
Flown mount............................................................................................................4-22
Flown mount installation...................................................................................4-24
Pole mount...............................................................................................................4-31
Pole mount installation......................................................................................4-31
Chapter 5
RP5100r installation
Rugged Radio Point installation overview ................................................................5-2
Pole mount installation ..............................................................................................5-4
Vertical pole mount .............................................................................................5-4
Wall mount installation............................................................................................5-10
PART 3 APPENDICES
Appendix A
Safety
Radiation Exposure Statement..................................................................................A-2
FCC Part 15........................................................................................................A-2
EN55032.............................................................................................................A-2
Human exposure limits for OneCell deployments....................................................A-2
Reference documents .........................................................................................A-3
Appendix B
Installation troubleshooting
Baseband Controller LED patterns...........................................................................B-2
Radio Point LED patterns.........................................................................................B-4
Appendix C
Specifications
Electrical ratings and technical data .........................................................................C-2
SPF/SPF+ specifications...........................................................................................C-2
Appendix D
Field Replaceable Units
FRU overview...........................................................................................................D-2
Replacing Baseband Controller modules..................................................................D-2
Prerequisites .......................................................................................................D-2

Contents
OneCell® Installation, RP5000 series, Release 4.0 v
DRAFT
Off-site activities................................................................................................D-3
On-site activities.................................................................................................D-7
Post-Install Verification....................................................................................D-11
Replacing Radio Points...........................................................................................D-13
Prerequisites .....................................................................................................D-13
On-site activities...............................................................................................D-14
Replacing a ceiling RP5100i (above tile).........................................................D-17
Replacing a flown mounted RP5100i...............................................................D-31
Replacing a pole mounted Indoor RP...............................................................D-41
RP post-replacement verification.....................................................................D-46
Replacing RF modules............................................................................................D-49
Appendix E
Cable installation and power separation guidelines
Overview................................................................................................................... E-2
Cable handling.......................................................................................................... E-2
Cable termination...................................................................................................... E-3
Cable splicing..................................................................................................... E-4
Cable termination............................................................................................... E-5
Cable grounding............................................................................................... E-10
Lightning protection................................................................................................ E-12
Important guidelines......................................................................................... E-12
Indoor box ........................................................................................................ E-12
Outdoor protection ........................................................................................... E-13
Ceiling connector.................................................................................................... E-15
Patch panel.............................................................................................................. E-17
Power separation guidelines ................................................................................... E-17

OneCell® Installation, RP5000 series, Release 4.0 vi
DRAFT
List of figures
Figure 1-1 OneCell solution..............................................................................1-3
Figure 1-2 Baseband Controller ports ...............................................................1-4
Figure 4-1 CommScope ceiling mount kit contents..........................................4-3
Figure 4-2 Drop rail, system integrator-provided..............................................4-4
Figure 4-3 CommScope flown mount kit contents..........................................4-23
Figure 4-4 Mounting bracket kit contents.......................................................4-31
Figure 5-1 Hardware provided by CommScope................................................5-2
Figure 5-2 Hardware provided by the systems integrator.................................5-3
Figure 5-3 RJ45, IP67 connector assembly.......................................................5-4
Figure E-1 Unreel cable.................................................................................... E-2
Figure E-2 Cable with sock attached using tie wrap......................................... E-3
Figure E-3 RJ45, IP67 connector...................................................................... E-3
Figure E-4 Assembling the connector on the RP end....................................... E-4
Figure E-5 CAT6-A lightning protector......................................................... E-13
Figure E-6 Remote equipment protection for outdoor devices....................... E-14
Figure E-7 Protector box mounted to pole...................................................... E-15

OneCell® Installation, RP5000 series, Release 4.0 vii
DRAFT
List of tables
Table 1 Customer documentation ...................................................................xiv
Table 2 Conventions ........................................................................................xv
Table 1-1 Baseband Controller physical port assignments.................................1-4
Table A-1 RF exposure for OneCell at maximum power internal antennas ......A-3
Table E-1 CAT-6A protection equipment parts list......................................... E-13

List of tables
viii M0300A2 4.0.11 January 2020
DRAFT

OneCell® Installation, RP5000 series, Release 4.0 ix
DRAFT
Document revision history
The following section lists documentation changes in OneCell® Installation and
Commissioning (M0300A2) for R4.0, the release for RP5000 series devices.
Revision 4.0.11 (January 20, 2020)
• Added Ban12, 14 and 17 content to Table A-1 on page A-3
Revision 4.0.10 (October 22, 2019)
• Removed Commissioning section that included Configuration and Verification
chapters and changed title to OneCell Hardware Installation, RP5000 series
Revision 4.0.09 (October 11, 2019)
• Fixed layout in Chapter 4, RP5100i installation and Appendix D, Field
Replaceable Units
•Chapter 4, RP5100i installation
— Added content to drop rail requirements for Ceiling mount on page 4-3
— Replaced drawings showing updated plastic cover
•Appendix D, Field Replaceable Units
— Replaced drawings showing updated plastic cover
Revision 4.0.08 (October 7, 2019)
•Chapter 4, RP5100i installation
— Replaced drawings that had two Ethernet cable with drawings of one Ethernet
cable
•Chapter 5, RP5100r installation
— Replaced drawings that had two Ethernet cable with drawings of one Ethernet
cable
— Replaced Figure 5-1 on page 5-2
•Appendix A, Safety

Document revision history
xM0300A2 4.0.11 January 2020
DRAFT
— Added notes to Table A-1 on page A-3
•Appendix D, Field Replaceable Units
— Replaced drawings that had two Ethernet cable with drawings of one Ethernet
cable
Revision 4.0.07 (September 16, 2019)
• Chapter 6, Configuring the OneCell system
— Replaced Figure 6-1 on page 6-3 and Table 6-1 on page 6-4
Revision 4.0.06 (August 23, 2019)
• Chapter 6, Configuring the OneCell system
— Removed Cisco switch content
— Revised Configuring aggregate switches on page 6-5 with Ruckus switch
content
Revision 4.0.06 (August 19, 2019)
•Chapter 4, RP5100i installation
— Added SR/MR port information to chapter
•Chapter 5, RP5100r installation
— Added SR/MR port information to chapter
•Appendix A, Safety
— Updated Table A-1 on page A-3
Revision 4.0.05 (July 15, 2019)
• Removed Draft watermark
•AddedChapter 5, RP5100r installation
Revision 4.0.04 (June 6, 2019)
•Appendix D, Field Replaceable Units
— Added topic, Replacing RF modules on page D-49

Document revision history
OneCell® Installation, RP5000 series, Release 4.0 xi
DRAFT
Revision 4.0.03 (May 21, 2019)
•Chapter 1, CommScope OneCell® overview
— Revised Baseband Controller physical ports on page 1-3, including Table 1-1
on page 1-4
• Chapter 6, Configuring the OneCell system
— Revised Timing Source, Boundary Clock Interface Port in Table 6-2 on
page 6-21
— Added GPS Information bullet to Configuring the Baseband Controller
manually on page 6-30
— Revised Whitelist Configuration in Table 6-3 on page 6-30
• Chapter 6, Verifying the OneCell installation
— Revised Verify the OneCell system installation on page 6-2
•AddedAppendix A, Safety and Appendix D, Field Replaceable Units
Revision 4.0.02 (March 27, 2019)
• Revised procedures in Chapter 4, RP5100i installation
Revision 4.0.01 (March 13, 2019)
• Initial document release

Document revision history
xii M0300A2 4.0.11 January 2020
DRAFT

OneCell® Installation, RP5000 series, Release 4.0 xiii
DRAFT
About this document
This document provides the procedures for installing and configuring the Baseband
Controller and Radio Points.
Audience
This document is written for computer hardware installers and administrators,
network architects and business planners who are responsible for the planning and
design of the CommScope OneCell deployment environment.
Purpose
This guide provides the information necessary for installing the OneCell hardware in
the operator’s network.
What you need to know
The reader should have a basic understanding of:
• Data networks
• LTE technology
• General telecommunications practices
Customer documentation
The following table lists available documents in the OneCell documentation suite.

Table 1. Customer documentation
Title Contents
OneCell®Feature Guide
(M0300A0)
Contains a description of anchor features for the
current release, and a system overview, including
CommScope provided components and required
components from other vendors.
OneCell® Network Planning Guide
(M0300A1)
Describes main components of the OneCell system,
high-level view of hardware components, how do you
engineer an in-building system, how do you determine
Radio Point locations, how to design in-building
systems and how to determine Radio Point locations.
Contains best practices for deployment, including
when to use clustering, and how to manage capacity.
OneCell® Installation and
Commissioning (M0300A2)
Includes detailed installation instructions for
Baseband Controller and Radio Points hardware,
planning the installation, physical install, how to
configure the installation, commissioning the
installation to service; verification tests after the
installation.
OM and KPI Reference for
OneCell® Devices (M0300A3)
Describes the operational measurements and key
performance indicators for OneCell devices.
OneCell® Troubleshooting
(M0300A4)
Covers common troubleshooting scenarios in
deployed devices and troubleshooting methods.
OneCell® Administration
(M0300A5)
Describes how to operate, maintain and manage
OneCell devices using the Baseband Controller’s Web
UI.
About this document
xiv M0300A2 4.0.11 January 2020
DRAFT

About this document
OneCell® Installation, RP5000 series, Release 4.0 xv
DRAFT
Conventions
This guide uses the following text conventions, as applicable.
Table 2. Conventions
Convention Description
Syntax symbols
< > Enclose a required parameter or set of parameters. For
example:
>band-class <class>
<class> is a required parameter.
[ ] Enclose an optional parameter or set of parameters. For
example:
>activate image <version> [reboot]
[reboot] is an optional parameter.
|Separates items on a list of parameters, only one of
which can be used. For example:
>channel-included <yes|no>
A valid command is:
>channel-included yes
Font usage
Bold input font Indicates text that must be entered exactly as shown. For
example:
Enter ping 192.23.10.12.
Italic input font Indicates a variable parameter for which you must
provide an actual value. For example:
>authentication key <aukey>
<aukey> is a variable parameter.
A valid command is:
>authentication key 9782503000
Plain output font Indicates system output in a command line or system-
generated file. For example:
IP address 192.23.10.12 is alive.
Italic output font Indicates a variable in system output in a command line
or system-generated file. For example:
Installation of release <release> is
complete.

About this document
xvi M0300A2 4.0.11 January 2020
DRAFT
Notes, cautions, and warnings
NOTE
Notes provide additional information about the subject text.
CAUTION
Cautions indicate that procedures, if performed incorrectly, can cause equipment
damage or data loss.
WARNING
Warnings indicate that procedures, if performed incorrectly, can harm you.
Plain italic font Indicates file names, directory paths, book titles, chapter
titles, and user accounts.
Bold font Indicates text that appears on screen exactly as shown,
for example, names of screens, names of buttons, items
on menus, and items on pull down lists.
blue text Indicates a hypertext link.
Other conventions
>Indicates graphical user interface (GUI) menu path. For
example:
Select Edit > Add Network to open the Add Network
screen.
Table 2. Conventions
Convention Description

DRAFT
Part I: Overview and preparation
Chapter 1 CommScope OneCell® overview
Chapter 2 Preparing to install the OneCell system

DRAFT

OneCell® Installation, RP5000 series, Release 4.0 1-1
DRAFT
Chapter 1
CommScope OneCell®overview
This chapter contains a high level overview of the OneCell deployment and the
OneCell components installed in the OneCell system.
Overview 1-2
CommScope OneCell system 1-2
OneCell hardware components 1-3

Chapter 1 CommScope OneCell® overview
1-2 M0300A2 4.0.11 January 2020
DRAFT
Overview
OneCell is a revolutionary wireless system that can deliver the ultimate in wireless
performance.
• It eliminates cell borders and handovers
• It can cover a large area with consistent user experience without any significant
interference
• It can take advantage of multiple distributed radio points to deliver a stronger
signal on both the downlink and the uplink
• It can deliver greater capacity through distributed (multi-user and single-user)
MIMO and Coordinated Multipoint (CoMP)
• It has the flexibility to neutralize macro interference in co-channel small cell
deployments
• It can be used to deliver unprecedented levels of capacity to hot spot areas by
deploying radio points with overlapping coverage and enabling multi- user MIMO
In addition to these important benefits in user experience and data capacity, OneCell
provides superior economics and investment protection, ease of deployment, support
for multi-operator deployments.
CommScope OneCell system
OneCell is an in-building, enterprise solution for LTE that provides an in-building
consistent signal. It operates as a wireless network with a single cell, called a
Baseband Controller, over distributed Radio Points. Network operators benefit from
the OneCell because they reduce the load on their infrastructure.
