Congatec COM Express conga-MEVAL User manual

COM Express™ conga-MEVAL
Detailed description of the congatec COM Express™ Type 10 evaluation carrier board
User’s Guide (Rev. D or later)
Revision 1.0

Copyright © 2022 congatec GmbH CET0m10 2/58
Revision History
Revision Date (yyyy-mm-dd) Author Changes
1.0 2022-03-11 AEM •Official release

Copyright © 2022 congatec GmbH CET0m10 3/58
Preface
This user’s guide provides information about the components, features and connectors available on the congatec COM Express™ Type 10
evaluation carrier board (revision D or later).
Software Licenses
Notice Regarding Open Source Software
The congatec products contain Open Source software that has been released by programmers under specific licensing requirements such as
the “General Public License“ (GPL) Version 2 or 3, the “Lesser General Public License“ (LGPL), the “ApacheLicense“ or similar licenses.
You can find the specific details at https://www.congatec.com/en/licenses/. Search for the revision of the BIOS/UEFI or Board Controller Software
(as shown in the POST screen or BIOS setup) to get the complete product related license information. To the extent that any accompanying
material such as instruction manuals, handbooks etc. contain copyright notices, conditions of use or licensing requirements that contradict any
applicable Open Source license, these conditions are inapplicable.
The use and distribution of any Open Source software contained in the product is exclusively governed by the respective Open Source
license. The Open Source software is provided by its programmers without ANY WARRANTY, whether implied or expressed, of any fitness for
a particular purpose, and the programmers DECLINE ALL LIABILITY for damages, direct or indirect, that result from the use of this software.
OEM/ CGUTL BIOS
BIOS/UEFI modified by customer via the congatec System Utility (CGUTL) is subject to the same license as the BIOS/UEFI it is based on. You
can find the specific details at https://www.congatec.com/en/licenses/.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
congatec GmbH provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims
any implied warranties of merchantability or fitness for any particular purpose with regard to any of the foregoing. congatec GmbH assumes
no liability for any damages incurred directly or indirectly from any technical or typographical errors or omissions contained herein or for
discrepancies between the product and the user’s guide. In no event shall congatec GmbH be liable for any incidental, consequential,
special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in connection with this user’s guide or any other
information contained herein or the use thereof.

Copyright © 2022 congatec GmbH CET0m10 4/58
Intended Audience
This user’s guide is intended for technically qualified personnel. It is not intended for general audiences.
Lead-Free Designs (RoHS)
All congatec GmbH designs are created from lead-free components and are completely RoHS compliant.
Electrostatic Sensitive Device
All congatec GmbH products are electrostatic sensitive devices. They are enclosed in static shielding bags, and shipped enclosed in secondary
packaging (protective packaging). The secondary packaging does not provide electrostatic protection.
Do not remove the device from the static shielding bag or handle it, except at an electrostatic-free workstation. Also, do not ship or store
electronic devices near strong electrostatic, electromagnetic, magnetic, or radioactive fields unless the device is contained within its original
packaging. Be aware that failure to comply with these guidelines will void the congatec GmbH Limited Warranty.
Copyright Notice
Copyright © 2022, congatec GmbH. All rights reserved. All text, pictures and graphics are protected by copyrights. No copying is permitted
without written permission from congatec GmbH.
congatec GmbH has made every attempt to ensure that the information in this document is accurate yet the information contained within is
supplied “as-is”.
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this user’s guide, or the congatec website, are the property
of their respective trademark holders. These trademark holders are not affiliated with congatec GmbH, our products, or our website.

Copyright © 2022 congatec GmbH CET0m10 5/58
Symbols
The following symbols are used in this user’s guide:
Warning
Warnings indicate conditions that, if not observed, can cause personal injury.
Caution
Cautions warn the user about how to prevent damage to hardware or loss of data.
Note
Notes call attention to important information that should be observed.
Connector Type
Describes the connector that must be used with the conga-MEVAL evaluation carrier board.
Link to connector layout diagram
This link icon is located in the top left corner of each page. It provides a direct link to the conga-MEVAL connector layout diagram.
Certification
congatec GmbH is certified to DIN EN ISO 9001 standard.
C
E
R
T
I
F
I
C
A
T
I
O
N
I
S
O
9
0
0
1
TM

Copyright © 2022 congatec GmbH CET0m10 6/58
Warranty
congatec GmbH makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited
warranty (“Limited Warranty”) per the terms and conditions of the congatec entity, which the product is delivered from. These terms and
conditions can be downloaded from www.congatec.com. congatec GmbH may in its sole discretion modify its Limited Warranty at any time
and from time to time.
The products may include software. Use of the software is subject to the terms and conditions set out in the respective owner’s license
agreements, which are available at www.congatec.com and/or upon request.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, congatec GmbH represents that
the products are new and warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship
or due to non conformance to the agreed upon specifications, will be repaired or exchanged, at congatec’s option and expense.
Customer will obtain a Return Material Authorization (“RMA”) number from congatec GmbH prior to returning the non conforming product
freight prepaid. congatec GmbH will pay for transporting the repaired or exchanged product to the customer.
Repaired, replaced or exchanged product will be warranted for the repair warranty period in effect as of the date the repaired, exchanged
or replaced product is shipped by congatec, or the remainder of the original warranty, whichever is longer. This Limited Warranty extends to
congatec’s direct customer only and is not assignable or transferable.
Except as set forth in writing in the Limited Warranty, congatec makes no performance representations, warranties, or guarantees, either
express or implied, oral or written, with respect to the products, including without limitation any implied warranty (a) of merchantability, (b) of
fitness for a particular purpose, or (c) arising from course of performance, course of dealing, or usage of trade.
congatec GmbH shall in no event be liable to the end user for collateral or consequential damages of any kind. congatec shall not otherwise
be liable for loss, damage or expense directly or indirectly arising from the use of the product or from any other cause. The sole and exclusive
remedy against congatec, whether a claim sound in contract, warranty, tort or any other legal theory, shall be repair or replacement of the
product only.
Technical Support
congatec GmbH technicians and engineers are committed to providing the best possible technical support for our customers so that our
products can be easily used and implemented. We request that you first visit our website at www.congatec.com for the latest documentation,
utilities and drivers, which have been made available to assist you. If you still require assistance after visiting our website then contact our
technical support department by email at [email protected]

Copyright © 2022 congatec GmbH CET0m10 7/58
Terminology
Term Description
DAC Digital Analog Converter
DDC Display Data Channel
eDP Embedded DisplayPort
GbE Gigabit Ethernet
GPIO General Purpose Input/Output
HBR3 High Bit Rate 3
I²C Bus Inter-Integrated Circuit Bus
HDA High Definition Audio
LVDS Low Voltage Differential Signaling
N.A Not available
N.C Not connected
PCIe Peripheral Component Interface Express (PCI Express)
SIO Super I/O
SM Bus System Management Bus
SATA Serial AT Attachment. A serial-interface standard for hard disks
SDIO Secure Digital Input Output
T.B.D To be determined
TPM Trusted Platform Module
USB Universal Serial Bus

Copyright © 2022 congatec GmbH CET0m10 8/58
Contents
1 Introduction ............................................................................. 11
1.1 COM Express™ Concept......................................................... 11
1.2 conga-MEVAL ......................................................................... 11
1.3 Order Number ........................................................................ 12
2 Block Diagram.......................................................................... 13
3 Connector Layout .................................................................... 14
4 Specifications........................................................................... 15
4.1 Feature List .............................................................................. 15
4.2 Mechanical Dimensions ........................................................... 16
4.3 Environmental Specifications................................................... 16
5 Connectors and Features......................................................... 17
5.1 COM Express A - B Connector ................................................ 17
5.2 Power Supply Connectors........................................................ 19
5.2.1 Standard ATX Connector ......................................................... 19
5.2.2 DC Banana Jack....................................................................... 21
5.2.3 Optional DC Banana Jack........................................................ 21
5.2.4 Status LEDs .............................................................................. 22
5.2.5 PWR_OK Signal........................................................................ 23
5.2.6 Power-Up Control .................................................................... 23
5.2.7 Module Type Detection ........................................................... 23
5.3 CMOS Battery.......................................................................... 24
5.4 PCIe Connectors...................................................................... 25
5.4.1 PCIe x4 Slot.............................................................................. 26
5.4.2 PCIe x1 Slot.............................................................................. 26
5.4.3 Mini PCIe Socket...................................................................... 27
5.5 SD Card Slot ............................................................................ 28
5.6 Display Interfaces..................................................................... 28
5.6.1 DP++ ....................................................................................... 28
5.6.2 eDP .......................................................................................... 29
5.6.2.1 Panel Power and Backlight Jumpers........................................ 30
5.6.3 LVDS......................................................................................... 31
5.6.3.1 Panel Power and Backlight Jumpers........................................ 33
5.6.3.2 Panel and Backlight Power Supply .......................................... 33
5.6.3.3 Backlight Enable Polarity ......................................................... 34
5.6.3.4 Flat Panel Configuration Data.................................................. 34
5.6.3.5 Flat Panel and Backlight Power Supply Connection................ 35
5.7 Universal Serial Bus (USB) ........................................................ 36
5.7.1 Dual Stacked USB 3.1 Gen 2 Type-A ...................................... 37
5.7.2 Dual Stacked USB 2.0 Type-A.................................................. 37
5.7.3 USB Type-B .............................................................................. 38
5.8 SATA™........................................................................................... 38
5.8.1 Disk Drive Power Connector.................................................... 39
5.9 Gigabit Ethernet ...................................................................... 39
5.10 Audio Interfaces....................................................................... 40
5.10.1 Audio Jacks.............................................................................. 41
5.10.2 Optical S/PDIF-Out.................................................................. 42
5.10.3 HDA Adapter/Debug Header.................................................. 42
5.10.4 Digital MIC............................................................................... 43
5.11 I2C Bus...................................................................................... 43
5.12 SM Bus..................................................................................... 44
5.12.1 I2C Digital I/O........................................................................... 44
5.13 SPI Flash Header...................................................................... 45
5.14 LPC Interfaces .......................................................................... 46
5.15 LPC Header.............................................................................. 46
5.16 Super I/O Configuration .......................................................... 47
5.17 Serial Ports ............................................................................... 48
5.17.1 COM Ports 0-3 ........................................................................ 48
5.17.2 Module Serial Port 0-1/CAN Bus ............................................. 49
5.18 CPU Fan Header ...................................................................... 50
5.19 Smart Battery Header .............................................................. 51
5.20 Programming Header - Internal Use Only ............................... 51
5.21 Module Detection - Internal Use Only..................................... 52
5.22 Feature Connector................................................................... 52
6 Additional Features.................................................................. 54
6.1 Buttons..................................................................................... 54

Copyright © 2022 congatec GmbH CET0m10 9/58
6.1.1 Power....................................................................................... 54
6.1.2 Reset ........................................................................................ 54
6.1.3 LID............................................................................................ 54
6.1.4 Sleep........................................................................................ 55
6.1.5 Fast Standby Discharge ........................................................... 55
6.2 Beeper ..................................................................................... 55
6.3 Debug Display ......................................................................... 56
6.4 Ground Test Points................................................................... 56
6.5 External Power LED ................................................................. 57
6.6 Wireless Disable....................................................................... 57
7 Mechanical Dimensions ........................................................... 58

Copyright © 2022 congatec GmbH CET0m10 10/58
List of Tables
Table 1 Order Description .................................................................... 12
Table 2 Feature Summary..................................................................... 15
Table 3 Module Type 10 Connector Pinout—Rows A and B ................ 17
Table 4 X58 - ATX PSU Control Description ......................................... 19
Table 5 X60 - ATX 5V Standby Connection .......................................... 19
Table 6 X59 - ATX Pinout...................................................................... 20
Table 7 X128 - ATX (4-pin).................................................................... 20
Table 8 M22/M23 - DC Banana Jack.................................................... 21
Table 9 M29/M30 - Optional DC Banana Jack..................................... 21
Table 10 X76 - Voltage Regulator Control.............................................. 21
Table 11 Power LEDs Status ................................................................... 22
Table 12 X57 - Module PWR_OK Signal................................................. 23
Table 13 Module Type Detection Pinout Description............................. 23
Table 14 X75 - PCIe x4 Slot Configuration ............................................. 26
Table 15 PCIe x1 Lane Routing............................................................... 26
Table 16 X107 - USB Port 5 Routing....................................................... 27
Table 17 D4-D6 - Mini PCIe LEDs Description ....................................... 27
Table 18 X22 - SDIO/GPIO Connection ................................................. 28
Table 19 X82 - eDP Pinout Description .................................................. 29
Table 20 X87 - eDP/LVDS Selection ....................................................... 30
Table 21 X122 - eDP Panel Power .......................................................... 30
Table 22 X34 - Backlight Voltage Selection............................................ 30
Table 23 X87 - eDP/LVDS Selection ....................................................... 31
Table 24 X65 - LVDS Connector (Top side)............................................. 31
Table 25 CN6 - LVDS Connector (Bottom side)...................................... 32
Table 26 X33 - LVDS Panel Power .......................................................... 33
Table 27 X34 - Backlight Voltage Selection............................................ 33
Table 28 X35 - LVDS Power Pinout Description...................................... 33
Table 29 X36 - Backlight Enable Polarity................................................ 34
Table 30 X107 - USB5 Route Configuration ........................................... 38
Table 31 X21 - External LED Header ...................................................... 38
Table 32 X5 Status LEDs......................................................................... 39
Table 33 D1 - Onboard GbE Link LED ................................................... 39
Table 34 X6 - Ethernet LEDs Power Configuration................................. 40
Table 35 CN2 Pinout Description ........................................................... 41
Table 36 X38 Pinout Description ............................................................ 42
Table 37 X123 Pinout ............................................................................. 43
Table 38 X50/X51 Pinout Description .................................................... 44
Table 39 X20 - SPI Flash Header ............................................................ 45
Table 40 SW M13 - BIOS Boot Device Selection ................................... 45
Table 41 CN7 - LPC Header .................................................................. 46
Table 42 X104 - Onboard TPM Activation ............................................. 46
Table 43 X105 - Super I/O Activation .................................................... 47
Table 44 X78 - SIO Upper Byte ............................................................. 47
Table 45 X79 - SIO Lower Byte .............................................................. 47
Table 46 X10,X11 - COM Port 0-3 Pinout Description ........................... 48
Table 47 X115, X116 - Module Serial Port 0-1 ...................................... 49
Table 48 X111 - SER1/CAN Bus Selection.............................................. 49
Table 49 X109 - CAN Bus....................................................................... 49
Table 50 X110 - CAN Bus Mode ............................................................ 49
Table 51 X56 - CPU Fan Header............................................................. 50
Table 52 X55 - CPU Fan Voltage Selection............................................. 50
Table 53 X52 - SBM Header Pinout........................................................ 51
Table 54 X80/X81 - Bus Selection .......................................................... 51
Table 55 X53 - Feature Connector ......................................................... 52
Table 56 X83 - Beeper Configuration .................................................... 55
Table 57 X63 - POST Code Decoder...................................................... 56
Table 58 X54 - External Power LED........................................................ 57
Table 59 X103 - Mini PCIe Wireless Disable Signal................................ 57

Copyright © 2022 congatec GmbH CET0m10 11/58
1 Introduction
1.1 COM Express™ Concept
COM Express™ is an open industry standard defined specifically for COMs (computer on modules). Its creation makes it possible to smoothly
transition from legacy interfaces to the newest technologies available today.
A Computer On Module integrates all the core components and standard I/O interfaces of a common PC onto an application specific carrier
board. The key advantage of the COM in the embedded computer industries is that all the highly integrated, high speed components such as
CPU, chipsets and memory are combined on a small module form factor for easy adaptation into different applications across multiple market
segments.
COM Express™ modules have standardized form factors and specified pinouts on the two system connectors that remain the same regardless
of the vendor. The COM Express™ module reflects the functional requirements for a wide range of embedded applications. These functions
include, but are not limited to, PCI Express, PCI, Graphics, High Definition Audio, serial ATA, Gigabit Ethernet and USB ports. One ruggedized,
shielded connector provide the carrier board interface and carry all the I/O signals to and from the COM Express™ module.
Carrier board designers can use as little or as many of the I/O interfaces as deemed necessary. The carrier board can therefore provide all
the interface connectors required to attach the system to the application specific peripherals. This versatility allows the designer to create a
dense and optimized package, which results in a more reliable product while simplifying system integration. Most importantly, COM Express™
modules are scalable, which means once an application has been created there is the ability to diversify the product range through the use
of different performance class or form factor size modules. Simply unplug one module and replace it with another; no redesign is necessary.
1.2 conga-MEVAL
The conga-MEVAL carrier board is designed based on the Type 10 pinout definition and it complies with COM Express Specification 3.0. The
conga-MEVAL provides most of the functional requirements for any embedded PC application. These functions include, but are not limited to
a rich complement of contemporary high bandwidth serial interfaces such as PCI Express, Serial ATA, USB 2.0, and Gigabit Ethernet. To ensure
stable data throughput, the carrier board is equipped with a high performance connector in accordance with the COM Express specification.
By combining the scalability of COM Express modules, the conga-MEVAL carrier board provides manufacturers and developers with a platform
to jump-start the development of systems and applications based on COM Express specification. This helps to reduce product design cycle
and encourages rapid innovation in system design, to meet the ever-changing needs of the market.
The various features and capabilities offered by the conga-MEVAL makes it ideal for integrating mini form factor modules.

Copyright © 2022 congatec GmbH CET0m10 12/58
1.3 Order Number
Table 1 Order Description
Part Number Product Name Description
065400 conga-MEVAL Evaluation carrier board for COM Express Type 10 modules, rev. 3.0 (mini form factor)

Copyright © 2022 congatec GmbH CET0m10 13/58
2 Block Diagram
USB2
PCIe 3
+3V
COM Express
Type 10
SATA 0
SD card
USB 2.0
BR2032
PCIe 1
Feature
PCIe 2
SATA 1
SDIO / GPIO
FAN
USB 4
ATX
24pin
USB3
PCIe 0
PCIe Clock
Buffer
HDA codec
MUX
MUX
MUX
PCIe Clock
mini PCIe
full / half
PCIe X1
PCIe X1
PCIe X4
MUX
USB 3.2
Redrivers
RS232
Transceivers
Super IO
TPMUART 0*Optional
COM 0
COM 1
COM 2
COM 3
LPC
USB 5
USB 6
HDAUSB 0USB 1
HP OUT
MIC IN
LINE IN
LINE OUT 1
LINE OUT 2
DMIC
SPDIF OUT
SPDIF IN
Optional
GbE
Transf.
USB 2.0
USB 3.1
RS232
Transceiver
SW
UART 1*
* COMe UARTs
(TX/RX)
MUX
USB 2.0USB 2.0 Type B
USB 7 (Host/Client)
UART
0-3
DisplayPort
Redriver
DDI 0
BC JTAG
GbE
SDP
DP++
SIM
MUX
LVDS / eDP
DisplayPort
Redriver
MUX
LVDS
Backlight
Power
Jumper
Switch
5V / 12V
SDIO
GPIO 8x
I2C
Battery
Support
BATLOW, WAKE, WD, THRM ...
I/O Expander
GPIO 8x
GPIO 8x
PWR,RST,SLP,LID
CPLD
POST CODE DISPLAY
CAN
Transceiver
CAN
Buttons
eDP
SPI
BATLOW, PWR ...
I2C
PWM & TACHO
12V DC
Input
Module DC Input
PS
12V
5V SBY
4.75 - 20V
Power Switch
BEEP

Copyright © 2022 congatec GmbH CET0m10 14/58
COM1
C6
C1 C5
C9
COM0
C6
C1 C5
C9
COM2
C6
C1 C5
C9
COM3
C6
C1 C5
C9
GND GND
I2C Digital I/O
+12V +4.75-
20V
M9 M8
M19
X9
M30 M29
X65
X82
X85
D40,D42
LEDs
M15
Beeper
X83
Beeper Enable/Disable
X103
MPCIe Wireless Disable
D7
SATA LED
M2
GND
M4
GND
M3
GND
M1
GND
X20
SPI Flash Header
X126
Ethernet SDP Header
U32
EPI EEPROM
U42
I2C EEPROM
X35
M14
X58
Power Supply Mode
X81 & X80
Battery Bus Config
X55
Fan Control
X60
Standby Voltage Control
X105
Super IO Activationl
X78
SIO Upper Bytel
X79
SIO Lower Byte
CN7
LPC Header
X57
Power_OK Config
X76
Module Power Control
X56
CPU Fan
X36
Bklt Polarity Config
X34
Bklt PWR Config
X122
eDP Voltage Selection
X87
eDP/LVDS Selection
X33
LCD Power Config
X50
X51
X52
SBM
X10X11
X38
X63
POST Code Decoder
DIP Switch M13
X22
GPIO/SDIO Config
X75
PCIe Config
X107
USB Port 5 Routing
X73
Programming Header - Internal Use Only
X59
D33-D36, D64
LEDs
X69
(Upper)
(Upper)
(Upper)
(Middle)
(Lower)
(Lower)
CN2
X6
LAN Power Rail
D1
LAN LED
CN1
X3
X5
X4
X106 X39
X68
X74
X8
X84
X15
M17
LID
M16
RESET
M18
SLEEP
Pwr On
USB Port 5/6
(DC Power) (Variable Power)
ATX
LVDS eDP
LCD Power
SD Card Slot
SATA0
SATA1
7.1 Channel Audio
Output
SPDIF
OUT
USB
Client
LAN
DisplayPort
USB 2.0 Port 4
Port 3 Port 1
USB 3.0/2.0
USB 2.0
Port 0
Port 2
Mini PCIE
CMOS Battery
PCIE(0-3)
HDA Header
X53
COM Express Connector
PCIE1 PCIE3
DEBUG Display
X21
Remote HDD LED
X109
CAN Bus
X116
Module SER1
X54
External Power LED
M39
SV_Standby Manual Discharge
X111
UART/CAN Select
X116
Module SER0
X88
SIM Card Slot
Feature Connector
D4 - D6
Mini PCIE LEDs
HDD Power
3 Connector Layout
The connector layout
picture shows each
connector and its name
designator. Jumpers are
also shown.
Select the Adobe ‘Zoom-
In-Tool’ and zoom in on a
given component to see
its designator. Hover over
the component and the
‘Zoom-In-Tool’ will change,
indicating that there is a
link.
Click on the link to
navigate to the area in
the document where the
component is described.
Use the mouse icon in the
top left hand corner of the
destination page to return
to the connector layout
picture.

Copyright © 2022 congatec GmbH CET0m10 15/58
4 Specifications
4.1 Feature List
Table 2 Feature Summary
Form Factor Based on COM Express standard pinout Type 10, rev. 3.0
Supported Modules COM Express™ Type 10 mini module form factor (55 x 85 mm)
Power 1x standard 24-pin ATX connector
1x DC power input (4 mm banana connectors)
1x BR2032 CMOS battery
Back Panel I/O
Connectors
1x DP
2x USB 3.1 ports
4x USB 2.0 host ports
1x Gigabit Ethernet RJ45 port
1x USB Type B (USB device functionality)
2x Line-Out jacks
1x Line-In jack
1x Microphone jack
1x Headphone jack
1x Optical S/PDIF-Out
Onboard I/O
Connectors
1x PCIe x4 slot
2x PCIe x1 slots
1x mini PCIe socket
1x SIM card socket
1x SD card socket (full-size)
2x LVDS connectors
1x LVDS/Backlight power supply header
2x SATA connectors
1x Disk drive 4-pin connector
1x HDA adapter/debug header
4x COM ports
2x COM port headers (module serial ports)
1x I2C digital IO expansion header
1x CPU fan header
1x SBM header
1x I2C EEPROM socket
1x SPI flash header
1x LPC header
1x EPI EEPROM Socket
1x Feature connector
2x USB 2.0 host ports
1x DMIC header
Other Features 5x Buttons (power, reset, sleep, lid, 5 V standby power discharge)
1x Beeper
4x Debug displays for post code information
4x Ground test points
1x Voltage test point for COM Express module
Onboard Super I/O
Optional discrete TPM
Note
The module must also support these features for them to function. Refer to the module’s user’s guide for information about supported features.

Copyright © 2022 congatec GmbH CET0m10 16/58
4.2 Mechanical Dimensions
•294 mm x 244 mm
•Height approximately 36 mm (top side)
4.3 Environmental Specifications
Temperature Operation: -40° to +85°C Storage: -40° to +85°C
Humidity Operation: 10% to 90% Storage: 5% to 95%
Note
1. The above operating temperatures must be strictly adhered to at all times. The maximum operating temperature refers to any measurable
spot on the carrier board’s surface.
2. Humidity specifications are for non-condensing conditions.

Copyright © 2022 congatec GmbH CET0m10 17/58
5 Connectors and Features
5.1 COM Express A - B Connector
Table 3 Module Type 10 Connector Pinout—Rows A and B
Pin Row A Pin Row B Pin Row A Pin Row B
A1 GND(FIXED) B1 GND(FIXED) A56 RSVD B56 RSVD
A2 GBE0_MDI3- B2 GBE0_ACT# A57 GND B57 GPO2
A3 GBE0_MDI3+ B3 LPC_FRAME# A58 PCIE_TX3+ B58 PCIE_RX3+
A4 GBE0_LINK100# B4 LPC_AD0 A59 PCIE_TX3- B59 PCIE_RX3-
A5 GBE0_LINK1000# B5 LPC_AD1 A60 GND(FIXED) B60 GND(FIXED)
A6 GBE0_MDI2- B6 LPC_AD2 A61 PCIE_TX2+ B61 PCIE_RX2+
A7 GBE0_MDI2+ B7 LPC_AD3 A62 PCIE_TX2- B62 PCIE_RX2-
A8 GBE0_LINK# B8 LPC_DRQ0# A63 GPI1 B63 GPO3
A9 GBE0_MDI1- B9 LPC_DRQ1# A64 PCIE_TX1+ B64 PCIE_RX1+
A10 GBE0_MDI1+ B10 LPC_CLK A65 PCIE_TX1- B65 PCIE_RX1-
A11 GND(FIXED) B11 GND(FIXED) A66 GND B66 WAKE0#
A12 GBE0_MDI0- B12 PWRBTN# A67 GPI2 B67 WAKE1#
A13 GBE0_MDI0+ B13 SMB_CK A68 PCIE_TX0+ B68 PCIE_RX0+
A14 GBE0_CTREF B14 SMB_DAT A69 PCIE_TX0- B69 PCIE_RX0-
A15 SUS_S3# B15 SMB_ALERT# A70 GND(FIXED) B70 GND(FIXED)
A16 SATA0_TX+ B16 SATA1_TX+ A71 eDP_TX2+/LVDS_A0+ B71 DDI0_PAIR0+
A17 SATA0_TX- B17 SATA1_TX- A72 eDP_TX2-/LVDS_A0- B72 DDI0_PAIR0-
A18 SUS_S4# B18 SUS_STAT# A73 eDP_TX1+/LVDS_A1+ B73 DDI0_PAIR1+
A19 SATA0_RX+ B19 SATA1_RX+ A74 eDP_TX1-/LVDS_A1- B74 DDI0_PAIR1-
A20 SATA0_RX- B20 SATA1_RX- A75 eDP_TX0+/LVDS_A2+ B75 DDI0_PAIR2+
A21 GND(FIXED) B21 GND(FIXED) A76 eDP_TX0-/LVDS_A2- B76 DDI0_PAIR2-
A22 USB_SSRX0- B22 USB_SSTX0- A77 eDP/LVDS_VDD_EN B77 DDI0_PAIR4+ 1
A23 USB_SSRX0+ B23 USB_SSTX0+ A78 LVDS_A3+ B78 DDI0_PAIR4- 1
A24 SUS_S5# B24 PWR_OK A79 LVDS_A3- B79 eDP/LVDS_BKLT_EN
A25 USB_SSRX1- B25 USB_SSTX1- A80 GND(FIXED) B80 GND(FIXED)
A26 USB_SSRX1+ B26 USB_SSTX1+ A81 eDP_TX3+/LVDS_A_CK+ B81 DDI0_PAIR3+
A27 BATLOW# B27 WDT A82 eDP_TX3-/LVDS_A_CK- B82 DDI0_PAIR3-

Copyright © 2022 congatec GmbH CET0m10 18/58
Pin Row A Pin Row B Pin Row A Pin Row B
A28 (S)ATA_ACT# B28 HDA_SDIN2 A83 eDP_AUX+/LVDS_I2C_CK B83 eDP/LVDS_BKLT_CTRL
A29 HDA_SYNC B29 HDA_SDIN1 2A84 eDP_AUX-/LVDS_I2C_DAT B84 VCC_5V_SBY
A30 HDA_RST# B30 HDA_SDIN0 2A85 GPI3 B85 VCC_5V_SBY
A31 GND(FIXED) B31 GND(FIXED) A86 RSVD B86 VCC_5V_SBY
A32 HDA_BITCLK B32 SPKR A87 eDP_HPD B87 VCC_5V_SBY
A33 HDA_SDOUT B33 I2C_CK A88 PCIE_CLK_REF+ B88 BIOS_DIS1#
A34 BIOS_DIS0# B34 I2C_DAT A89 PCIE_CLK_REF- B89 DD0_HPD
A35 THRMTRIP# B35 THRM# A90 GND(FIXED) B90 GND(FIXED)
A36 USB6- B36 USB7- A91 SPI_POWER B91 DDI0_PAIR5+ 1
A37 USB6+ B37 USB7+ A92 SPI_MISO B92 DDI0_PAIR5- 1
A38 USB_6_7_OC# B38 USB_4_5_OC# A93 GPO0 B93 DDI0_PAIR6+ 1
A39 USB4- B39 USB5- A94 SPI_CLK B94 DDI0_PAIR6- 1
A40 USB4+ B40 USB5+ A95 SPI_MOSI B95 DDI0_DDC_AUX_SEL
A41 GND(FIXED) B41 GND(FIXED) A96 TPM_PP B96 USB7_HOST_PRSNT
A42 USB2- B42 USB3- A97 TYPE10# B97 SPI_CS#
A43 USB2+ B43 USB3+ A98 SER0_TX B98 DDI0_CTRLCLK_AUX+
A44 USB_2_3_OC# B44 USB_0_1_OC# A99 SER0_RX B99 DDI0_CTRLDATA_AUX-
A45 USB0- B45 USB1- A100 GND(FIXED) B100 GND(FIXED)
A46 USB0+ B46 USB1+ A101 SER1_TX/CAN_TX B101 FAN_PWMOUT
A47 VCC_RTC B47 ESPI_EN# A102 SER1_RX/CAN_RX B102 FAN_TACHIN
A48 RSVD B48 USB0_HOST_PRSNT A103 LID# B103 SLEEP#
A49 GBE0_SDP B49 SYS_RESET# A104 VCC_12V B104 VCC_12V
A50 LPC_SERIRQ B50 CB_RESET# A105 VCC_12V B105 VCC_12V
A51 GND(FIXED) B51 GND(FIXED) A106 VCC_12V B106 VCC_12V
A52 RSVD B52 RSVD A107 VCC_12V B107 VCC_12V
A53 RSVD B53 RSVD A108 VCC_12V B108 VCC_12V
A54 GPI0 B54 GPO1 A109 VCC_12V B109 VCC_12V
A55 RSVD B55 RSVD A110 GND(FIXED) B110 GND(FIXED)
Note
1. Not supported
2. Assembly option

Copyright © 2022 congatec GmbH CET0m10 19/58
5.2 Power Supply Connectors
The conga-MEVAL provides the following connectors for power supply:
•standard 24-pin ATX conector (X59)
•12 V DC banana jack (M22 and M23)
•optional DC banana jack for supplying power to the module (M29 and M30)
Note
In ATX mode, the +3.3 V, +5 V and +12 V are derived from the ATX power supply. If 12 V DC power is supplied via the DC banana jack, the
onboard DC/DC regulators will generate 3.3 V and 5 V.
Caution
1. Do not exceed the voltage rating of the COM Express module. Doing so will damage the module.
2. Do not supply power to both the DC banana jack and the ATX connector at the same time.
5.2.1 Standard ATX Connector
The conga-MEVAL provides a 24-pin ATX connector (X59). Use jumper X58 to select ATX or AT power supply mode. Use jumper X60 to
disconnect the 5 V standby voltage from the whole system.
The conga-MEVAL also provides a 4-pin ATX connector (X128). This connector can be used together with connector X59 if higher current is
expected.
Table 4 X58 - ATX PSU Control Description
Pin Configuration Description
1-2 ATX mode (default) Module starts after pressing power-on button M19
2-3 AT mode Module starts after switching on the power supply
Table 5 X60 - ATX 5V Standby Connection
Pin Description
1-2 5V standby connected (default)
2-3 5V standby disconnected
2 31
X58
M19
2 31
X60

Copyright © 2022 congatec GmbH CET0m10 20/58
Table 6 X59 - ATX Pinout
Pin Signal Description Pin Signal
1 +3.3 V Power supply +3.3 VDC 13 +3.3V Power supply +3.3 VDC
2 +3.3 V Power supply +3.3 VDC 14 -12V Power supply -12 VDC
3 GND Power ground 15 GND Power ground
4 +5 V Power supply +5 VDC 16 PS_ON# Power supply on (active low). Short this pin to GND to switch on
power supply; disconnect from GND to switch off.
5 GND Power ground 17 GND Power ground
6 +5V Power supply +5 VDC 18 GND Power ground
7 GND Power ground 19 GND Power ground
8 PWR_OK Power Ok 20 N.C Not connected
9 5V_SB Standby power supply +5 VDC 21 +5V Power supply +5 VDC
10 +12 V Power supply +12 VDC 22 +5V Power supply +5 VDC
11 +12 V Power supply +12 VDC 23 +5V Power supply +5 VDC
12 +3.3 V Power supply +3.3 VDC 24 GND Power ground
Note
The -12 V power output of the ATX power supply is not used.
Table 7 X128 - ATX (4-pin)
Pin Signal Description Pin Signal Description
1 GND Ground 2 GND Ground
3 +12 V Power supply +12 VDC 4 +12 V Power supply +12 VDC
Connector Type
X58, X60: 2.54 mm grid jumper
X59: 24-pin ATX 2.0 power connector
X128: 4-pin ATX connector
X59
X128
1
2
3
4
