Congatec conga-IA5 User manual

conga-IA5 Thin Mini-ITX SBC
Detailed Description Of The congatec Thin Mini-ITX Based On Intel® Apollo Lake SoCs
User's Guide
Revision 0.1 (Preliminary)

Copyright © 2017 congatec AG IA50m01 2/59
Revision History
Revision Date (yyyy.mm.dd) Author Changes
0.1 2017.07.19 BEU •Preliminary release

Copyright © 2017 congatec AG IA50m01 3/59
Preface
This user's guide provides information about the components, features and connectors available on the conga-IA5 Thin Mini-ITX Single Board
Computer.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
congatec AG provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims
any implied warranties of merchantability or fitness for any particular purpose with regard to any of the foregoing. congatec AG assumes
no liability for any damages incurred directly or indirectly from any technical or typographical errors or omissions contained herein or for
discrepancies between the product and the user’s guide. In no event shall congatec AG be liable for any incidental, consequential, special, or
exemplary damages, whether based on tort, contract or otherwise, arising out of or in connection with this user’s guide or any other information
contained herein or the use thereof.
Intended Audience
This user's guide is intended for technically qualified personnel. It is not intended for general audiences.
Lead-Free Designs (RoHS)
All congatec AG products are created from lead-free components and are completely RoHS compliant.
Electrostatic Sensitive Device
All electronic parts described in this user’s guide are electrostatic sensitive devices and are packaged accordingly. Do not open or handle
a carrier board, module or SBC except at an electrostatic-free workstation. Additionally, do not ship or store electronic devices near strong
electrostatic, electromagnetic, magnetic, or radioactive fields unless the device is contained within its original manufacturer’s packaging.

Copyright © 2017 congatec AG IA50m01 4/59
Symbols
The following symbols are used in this user's guide:
Warning
Warnings indicate conditions that, if not observed, can cause personal injury.
Caution
Cautions warn the user about how to prevent damage to hardware or loss of data.
Note
Notes call attention to important information that should be observed.
Connector Type
Describes the connector used on the Single Board Computer.
Copyright Notice
Copyright © 2017, congatec AG. All rights reserved. All text, pictures and graphics are protected by copyrights. No copying is permitted
without written permission from congatec AG.
congatec AG has made every attempt to ensure that the information in this document is accurate, yet the information contained within is
supplied “as-is”.

Copyright © 2017 congatec AG IA50m01 5/59
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this user’s guide, or the congatec website, are the property
of their respective trademark holders. These trademark holders are not affiliated with congatec AG, our products, or our website.
Warranty
congatec AG makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited
warranty (“Limited Warranty”) per the terms and conditions of the congatec entity, which the product is delivered from. These terms and
conditions can be downloaded from www.congatec.com. congatec AG may in its sole discretion modify its Limited Warranty at any time and
from time to time.
The products may include software. Use of the software is subject to the terms and conditions set out in the respective owner’s license
agreements, which are available at www.congatec.com and/or upon request.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, congatec AG represents that the
products are new and warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or
due to non conformance to the agreed upon specifications, will be repaired or exchanged, at congatec’s option and expense.
Customer will obtain a Return Material Authorization (“RMA”) number from congatec AG prior to returning the non conforming product freight
prepaid. congatec AG will pay for transporting the repaired or exchanged product to the customer.
Repaired, replaced or exchanged product will be warranted for the repair warranty period in effect as of the date the repaired, exchanged
or replaced product is shipped by congatec, or the remainder of the original warranty, whichever is longer. This Limited Warranty extends to
congatec’s direct customer only and is not assignable or transferable.
Except as set forth in writing in the Limited Warranty, congatec makes no performance representations, warranties, or guarantees, either
express or implied, oral or written, with respect to the products, including without limitation any implied warranty (a) of merchantability, (b) of
fitness for a particular purpose, or (c) arising from course of performance, course of dealing, or usage of trade.
congatec AG shall in no event be liable to the end user for collateral or consequential damages of any kind. congatec shall not otherwise be
liable for loss, damage or expense directly or indirectly arising from the use of the product or from any other cause. The sole and exclusive
remedy against congatec, whether a claim sound in contract, warranty, tort or any other legal theory, shall be repair or replacement of the
product only.

Copyright © 2017 congatec AG IA50m01 6/59
Certification
congatec AG is certified to DIN EN ISO 9001 standard.
Technical Support
congatec AG technicians and engineers are committed to providing the best possible technical support for our customers so that our products
can be easily used and implemented. We request that you first visit our website at www.congatec.com for the latest documentation, utilities
and drivers, which have been made available to assist you. If you still require assistance after visiting our website then contact our technical
support department by email at [email protected]
Terminology
Term Description
PCIe Peripheral Component Interface Express
cBC congatec Board Controller
SDIO Secure Digital Input Output
USB Universal Serial Bus
SATA Serial AT Attachment: serial-interface standard for hard disks
HDA High Definition Audio
S/PDIF Sony/Philips Digital Interconnect Format
HDMI High Definition Multimedia Interface
TMDS Transition Minimized Differential Signaling
DVI Digital Visual Interface
LPC Low Pin-Count
I²C Bus Inter-Integrated Circuit Bus
SM Bus System Management Bus
CAN Controller Area Network
SPI Serial Peripheral Interface
GbE Gigabit Ethernet
LVDS Low-Voltage Differential Signaling
DDC Display Data Channel
PN Part Number — the part number for placing orders.
N.C Not connected
N.A Not available
T.B.D To be determined
C
E
R
T
I
F
I
C
A
T
I
O
N
I
S
O
9
0
0
1
TM

Copyright © 2017 congatec AG IA50m01 7/59
Contents
1 Introduction ............................................................................. 10
1.1 Mini-ITX Concept..................................................................... 10
1.2 conga-IA5 ................................................................................ 10
1.2.1 Options Information................................................................. 11
1.2.2 Optional Accessories ............................................................... 12
2 Specification ............................................................................ 13
2.1 Feature List .............................................................................. 13
2.2 Supported Operating Systems ................................................ 14
2.3 Mechanical Dimensions ........................................................... 15
2.4 Supply Voltage Power.............................................................. 15
2.5 Power Consumption ................................................................ 15
2.6 Supply Voltage Battery Power ................................................. 16
2.7 Environmental Specifications................................................... 17
3 Block Diagram.......................................................................... 18
4 Cooling Solution ...................................................................... 19
4.1 Cooling Installation.................................................................. 20
4.2 CSP Dimensions....................................................................... 21
5 Connector Description............................................................. 23
5.1 Power Supply ........................................................................... 23
5.1.1 DC Power Jack (Rear I/O) ........................................................ 23
5.1.2 Power Supply (Internal Connector) .......................................... 24
5.1.3 Optional SBM3Power Connector (Internal Connector) ........... 25
5.1.3.1 Optional SBM3Signal Connector............................................. 25
5.1.4 PWR_OK Signal........................................................................ 26
5.1.5 Power Status LEDs ................................................................... 26
5.2 CMOS Battery/RTC.................................................................. 27
5.3 Audio Interfaces....................................................................... 27
5.3.1 Rear Audio Connectors............................................................ 28
5.3.2 Internal Audio Connectors....................................................... 28
5.3.2.1 Stereo Speaker Header............................................................ 29
5.3.2.2 Digital Microphone/SPDIF ....................................................... 29
5.3.2.3 Front Panel HD Audio.............................................................. 30
5.4 Communication Bus................................................................. 30
5.4.1 SMBus...................................................................................... 30
5.4.2 I²C Bus .................................................................................... 30
5.4.3 SPI Bus ..................................................................................... 31
5.5 LPC Super I/O Device.............................................................. 31
5.5.1 Serial Ports (COM) ................................................................... 31
5.5.2 CPU/System Fan Connector & Power Configuration............... 32
5.6 Universal Serial Bus (USB) ........................................................ 33
5.6.1 Rear USB Connectors............................................................... 34
5.6.2 Internal USB 3.0 Connector ..................................................... 34
5.6.3 Internal USB 2.0 Connector ..................................................... 35
5.7 Ethernet 10/100/1000.............................................................. 35
5.8 SATA Interfaces........................................................................ 36
5.8.1 SATA / SATADOM Ports........................................................... 36
5.8.2 SATA Power ............................................................................. 37
5.8.3 4-Pin Power.............................................................................. 37
5.8.4 M.2 Slot.................................................................................... 38
5.9 Display Interfaces..................................................................... 39
5.9.1 Display Port Interface DP++ .................................................... 39
5.9.2 LVDS......................................................................................... 40
5.9.3 Embedded Display Port (eDP) ................................................. 41
5.9.3.1 Backlight Power Connector ..................................................... 42
5.9.3.2 Backlight/Panel Power Selection ............................................. 43
5.9.3.3 Monitor OFF connector ........................................................... 44
5.10 PCI Express ............................................................................. 44
5.10.1 x1 PCIe Slot.............................................................................. 44
5.10.2 Mini PCIe (Half Size) ................................................................ 45
5.10.3 Mini PCIe (Full Size).................................................................. 47
5.11 Micro-SIM Slot ......................................................................... 48
5.12 Micro-SD Slot........................................................................... 48
5.12.1 PCI Express Routing................................................................. 49
6 Additional Features.................................................................. 50
6.1 Front Panel Connector............................................................. 50
6.2 Case Open Intrusion Connector .............................................. 51
6.3 Trusted Platform Module – TPM (Optional) ............................. 51

Copyright © 2017 congatec AG IA50m01 8/59
6.4 congatec Board Controller (cBC) ............................................. 51
6.4.1 Fan Control .............................................................................. 51
6.4.2 Power Loss Control.................................................................. 52
6.4.3 Board Information.................................................................... 52
6.4.4 GPIOs....................................................................................... 52
6.5 OEM BIOS Customization........................................................ 52
6.5.1 OEM Default Settings .............................................................. 52
6.5.2 OEM Boot Logo....................................................................... 52
6.5.3 OEM POST Logo ..................................................................... 53
6.5.4 OEM BIOS Code / Data........................................................... 53
6.5.5 OEM DXE Driver...................................................................... 53
6.6 congatec Battery Management Interface ................................ 53
6.7 API Support (CGOS) ................................................................ 54
6.8 Thermal/Voltage Monitoring.................................................... 54
6.9 Beeper ..................................................................................... 54
6.10 External System Wake Event ................................................... 54
6.11 Feature Connector................................................................... 55
7 conga-IA5 Mechanical Drawing............................................... 56
8 BIOS Setup Description........................................................... 57
9 Additional BIOS Features ........................................................ 58
10 Industry Specifications ............................................................. 59

Copyright © 2017 congatec AG IA50m01 9/59
List of Tables
Table 1 conga-IA5 Commercial Variants............................................... 12
Table 2 conga-IA5 Industrial Variants ................................................... 12
Table 3 Cooling/IO Shield .................................................................... 13
Table 4 Memory Modules..................................................................... 13
Table 5 Cables...................................................................................... 13
Table 6 Adapters .................................................................................. 13
Table 7 Feature Summary..................................................................... 14
Table 8 Measurement Description........................................................ 16
Table 9 Power Consumption Values ..................................................... 17
Table 10 CMOS Battery Power Consumption ........................................ 17
Table 11 DC Power Jack (X43 Connector) Pinout Description ............... 24
Table 12 Straight Internal Power (X44 Connector) Pinout Description... 25
Table 13 Right Angle Internal Power (X44 Connector) Pinout
Description............................................................................... 25
Table 14 SBM3Power (X46 Connector) Pinout Description.................... 26
Table 15 SBM3Signal (X45 Connector) Pinout Description.................... 27
Table 16 Double-Color Power LED ........................................................ 27
Table 17 Single-Color Power LED .......................................................... 28
Table 18 MIC-IN (X20 Connector) Pinout Description............................ 29
Table 19 Line-OUT (X22 Connector) Pinout Description........................ 29
Table 20 Stereo Speaker (X21 Connector) Pinout Description............... 30
Table 21 Internal Digital Microphone/SPDIF (X19 Connector) Pinout
Description............................................................................... 30
Table 22 Front Panel HD Audio (Connector X18) Pinout Description .... 31
Table 23 Serial Ports (Connectors X24/X25) Pinout Description ............ 32
Table 24 CPU Fan (X36 Connector) Pinout Description ........................ 33
Table 25 System Fan (X38 Connector) Pinout Description..................... 33
Table 26 Jumper (X34, X37 Jumper) Pinout Description........................ 33
Table 27 LED Descriptions ..................................................................... 37
Table 28 M.2 Slot (Connector X12) Pinout Description.......................... 39
Table 29 LVDS (Connector X33) Pinout Description .............................. 41
Table 30 eDP (Connector X29) Pinout Description................................. 42
Table 31 Backlight Power (Connector X32) Pinout Description.............. 43
Table 32 Backlight Voltage Selector (Connector X30) Pinout ....................
Description............................................................................... 44
Table 33 Panel Voltage Selector (Connector X31) Pinout Description ... 44
Table 34 Monitor OFF (Connector X28) Pinout Description................... 45
Table 35 x1 PCIe Slot (Connector X8) Pinout Description...................... 45
Table 36 mPCIe (Connector X9) Pinout Description............................... 46
Table 37 Micro-SIM Slot (Connector X10) Pinout Description................ 49
Table 38 Front Panel (Connector X39) Pinout Description..................... 51
Table 39 Case Open Intrusion (Connector X23) Pinout Description ...... 52
Table 40 Feature Connector (Connector X35) Pinout Description ......... 56

Copyright © 2017 congatec AG IA50m01 10/59
1 Introduction
1.1 Mini-ITX Concept
The Mini-ITX form factor provides engineers and manufacturers with a standardized ultra compact platform for development. With a footprint
of 170mm x 170mm, this scalable platform promotes the design of highly integrated, energy efficient systems. Due to its small size, the Mini-
ITX form factor enables PC appliance designers not only to design attractive low cost devices but also allows them to explore a huge variety of
product development options — from compact space-saving designs to fully functional Information Station and Value PC systems. This helps
to reduce product design cycle and encourages rapid innovation in system design, to meet the ever-changing needs of the market.
Additionally, the boards can also be passively cooled, presenting opportunities for fanless designs. The Mini-ITX boards are equipped with
various interfaces such as PCI Express, SATA, USB 3.0/2.0, Ethernet, Displays and Audio.
1.2 conga-IA5
The conga-IA5 is a Single Board Computer design based on the Thin Mini-ITX specification. The conga-IA5 SBC features the Intel®Apollo Lake
processors. With maximum 12 W TDP processors, the SBC offers Ultra-Low-Power boards with high computing performance and outstanding
graphics. Additionally, the SBC supports dual channel DDR3L up to 1866 MT/s for a maximum system memory capacity of 8 GB, multiple I/O
interfaces, up to three independent displays and various congatec embedded features.
With smaller board size and lower height keep-out zones, the conga-IA5 SBC provides manufacturers and enthusiasts with the opportunity to
design compact systems for space restricted areas. With appropriate I/O shield, the same conga-IA5 SBC can be used in either a Thin Mini-ITX
or a Mini-ITX design.
The various features and capabilities offered by the conga-IA5 makes it ideal for the design of compact, energy efficient, performance-oriented
embedded systems.

Copyright © 2017 congatec AG IA50m01 11/59
1.2.1 Options Information
The conga-IA5 is currently available in six variants. This user’s guide describes all of these variants. The tables below show the different
configurations available. Check for the Part No. that applies to your product. This will tell you what options described in this user’s guide are
available on your particular module.
Table 1 conga-IA5 Commercial Variants
Part-No. 052801 052802 052803 052820 052821
Processor Intel®Atom™ x7 E3950
Quad Core 1.6 GHz
Intel®Atom™ x5 E3940
Quad Core 1.6 GHz
Intel®Atom™ x5 E3930
Dual Core 1.3 GHz
Intel®Pentium®N4200
Quad Core 1.1 GHz
Intel®Celeron®N3350
Dual Core 1.1 GHz
Burst Frequency 2.0 GHz 1.8 GHz 1.8 GHz 2.5 GHz 2.4 GHz
L2 Cache 2 MB 2 MB 2 MB 2 MB 2 MB
Memory (DDR3L) 1866 MT/s dual channel 1866 MT/s dual channel 1866 MT/s dual channel 1866 MT/s dual channel 1866 MT/s dual channel
Processor Graphics Intel®HD Graphics 505 Intel®HD Graphics 500 Intel®HD Graphics 500 Intel®HD Graphics 505 Intel®HD Graphics 500
Graphics Base/Burst Freq. 500/650 MHz 400/600 MHz 400/550 MHz 200/750 MHz 200/650 MHz
VGA No No No No No
LVDS Single/Dual 18/24-bit Single/Dual 18/24-bit Single/Dual 18/24-bit Single/Dual 18/24-bit Single/Dual 18/24-bit
DDI DP/HDMI/DVI DP/HDMI/DVI DP/HDMI/DVI DP/HDMI/DVI DP/HDMI/DVI
Processor TDP 12 W 9.5 W 6.5 W 6 W 6 W
Table 2 conga-IA5 Industrial Variants
Part-No. 052811
Processor Intel®Atom™ x7 E3950
Quad Core 1.6 GHz
Burst Frequency 2.0 GHz
L2 Cache 2 MB
Memory (DDR3L) 1866 MT/s dual channel
Processor Graphics Intel®HD Graphics 505
Graphics Base/Burst Freq. 500/650 MHz
VGA No
LVDS Single/Dual 18/24-bit
DDI DP/HDMI/DVI
Processor TDP 12 W

Copyright © 2017 congatec AG IA50m01 12/59
1.2.2 Optional Accessories
Table 3 Cooling/IO Shield
Article Part No. Description
conga-IA50/CSP 052830 Passive cooling solution with Thin Mini-ITX height for open die variants (Celeron® and Pentium®)
conga-IA50/i-CSP 052831 Passive cooling solution with Thin Mini-ITX height for lidded die variants (Atom™)
conga-IC87/97- CSA Retention Frame 052254 Retention frame for conga-IC87/97/170/IA5 standard cooling
Table 4 Memory Modules
Article Part No. Description
DDR3L-SODIMM-1600 (2 GB) 068755 Certified 2 GB DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S)
DDR3L-SODIMM-1600 (4 GB) 068756 Certified 4 GB DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S)
DDR3L-SODIMM-1600 (8 GB) 068757 Certified 8 GB DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S)
Table 5 Cables
Article Part No. Description
cab-ThinMini-ITX-SATA-Power 14000120 Power cable for SATA and micro-SATA devices.
cab-ThinMini-ITX-UART 14000121 UART cable with 2x5 pin female housing and D-Sub male connector.
cab-ThinMini-ITX-USB2.0-Single 14000122 20cm USB 2.0 cable with 1x5 pin female housing and one USB 2.0 Type A female connector.
cab-ThinMini-ITX-USB20-Twin 14000123 20cm USB 2.0 cable — Twin with 2x5pin female header and two USB 2.0 Type A female connectors.
cab-ThinMini-ITX-USB30-Twin 14000124 25cm USB 3.0 cable — Twin with 2x10pin female header and two USB 3.0 Type A female connectors.
cab-ThinMini-ITX-LVDS-Open End 14000125 ACES 40 pin LVDS cable with open end.
cab-ThinMini-ITX-BKLT 14000127 CHYAO SHIUNN 8 pin backlight cable with open end.
cab-DP to HDMI 14000128 20 pin male DP to 19 pin female HDMI
cab-ThinMini-ITX-SATA-Power (50cm lenght) 14000135 50cm SATA power cable with 2x15 pin female connectors.
cab-ThinMini-ITX-SATA-Power (30cm length) 14000136 30cm SATA power cable with 2x15 pin female connectors.
cab-ThinMini-ITX-USB30-Micro B 14000198 30cm USB 3.0 cable with 2x10 pin female housing and one USB 3.0 Micro B female connector.
SATA III cable 30 cm, straight/straight 48000029 30cm SATA III cable with straight connectors on both ends.
SATA III cable 30 cm, down/straight 48000030 30cm SATA III cable with down and straight connector.
Table 6 Adapters
Article Part No. Description
conga-Thin MITX/eDP to DP Adapter 052231 eDP to standard DisplayPort evaluation adapter for congatec Thin Mini-ITX boards
conga-Thin MITX/eDP to HDMI Adapter 052232 eDP to standard HDMI evaluation adapter for congatec Thin Mini-ITX boards

Copyright © 2017 congatec AG IA50m01 13/59
2 Specification
2.1 Feature List
Table 7 Feature Summary
Form Factor Based on Thin Mini-ITX form factor (170mm x 170mm)
Processor Intel®Apollo Lake Atom™, Pentium®and Celeron®
Memory Two memory sockets (located on the top side of the conga-IA5) with support for:
-SO-DIMM non-ECC DDR3L modules
-Data rates up to 1866 MT/s
-Maximum 8 GB system memory capacity
cBC Multi-stage watchdog, manufacturing and board information, board statistics, I2C bus, Power loss control
Chipset Integrated in the SoC
Audio High Definition Audio codec Cirrus Logic CS4207
Ethernet 2x Gigabit Ethernet Intel®I211 (commercial variants) or Intel®I210 (industrial variants)
Graphics Intel®HD Graphics Gen9-LP supporting DirectX12, OpenGL 4.3, OpenGL ES 3.0, OpenCL 1.2, PAVP 2.0 and HDCP 1.4/2.0. HEVC (H.265), AVC
(H.264), MVC, VP8, VP9 (software encode only), and JPEG/MJPEG format decode and encode. MPEG2, VC-1, and WMV9 format decode.
Graphic Interfaces 2x DisplayPort++ (DP, HDMI/DVI) and 1x LVDS shared with 1x eDP 1.4
Back Panel I/O
Connectors
1x DC-IN (for commercial variants only)
2x DisplayPort ++ support:
-DP
-DVI/HDMI 1.4 (requires external passive cable adapter)
2x Gigabit Ethernet
2x USB 2.0
2x USB 3.0/2.0
1x Line OUT
1x Mic IN
Onboard I/O
Connectors
1x LVDS (top side)
1x eDP (bottom side)
1x Backlight with selectable voltage
1x Monitor OFF
SATA Interfaces:
-2x SATA III (6.0 Gb/s) — one featuring SATADOM
-1x SATA power (3.3V, 5V or 12V)
-1x 4-pin power header (5V or 12V)
PCI Express Interfaces:
-1x M.2 slot (shared with SATA1 connector)
-1x Half size/Full size mini PCIe/mSATA card slot
-1x PCIe x1 card slot (shared with mini PCIe/mSATA card slot)
1x Double USB 3.0 header (only supports one port)
1x Single USB 2.0 header
1x Front panel HD audio
1x SPDIF/Digital microphone
1x SD card
1x Internal stereo speaker
Connectors supported via Super IO:
-2x COM ports
-1x HSUART
-1x CPU fan power with selectable voltage
-1x System fan power with selectable voltage
-1x Case Open Intrusion Detection header
-GPIOs on feature connector
Feature connector (GPIOs, I2C, SPI, SMB, LPC, LID/SLEEP etc.)
1x Front panel header (Power button, reset, LEDs etc.)
1x Internal power header (12 - 24V)
Optional Interfaces (not populated by default):
-SBM3signal and power support
-ccTALK (shared with COM port)
-SIM card slot (routed to Full Size mini PCIe)
BIOS AMI Aptio®UEFI 5.x firmware, 8 MByte serial SPI with congatec Embedded BIOS features.

Copyright © 2017 congatec AG IA50m01 14/59
Power
Management
ACPI 4.0 compliant with battery support. Also supports Suspend to RAM (S3)
Configurable TDP
Ultra low standby power consumption, Deep Sx
Other Features Thermal and voltage monitoring, CMOS Battery, Beeper
congatec Standard BIOS (also possible to boot from an external BIOS by triggering the BIOS_DISABLE# signal on the feature connector)
Security Optional discrete Trusted Platform Module “TPM 1.2/2.0”, new AES Instructions for faster and better encryption
Note
Some of the features mentioned above are optional. Check the part number of your module and compare it to the options information table
in section 1.2.1 to determine what options are available on your particular module.
2.2 Supported Operating Systems
The conga-IA5 supports the following operating systems:
• Microsoft®Windows® 10 IoT Enterprise (64-bit)
• Microsoft®Windows® 10 IoT Core (32/64-bit)
• Microsoft®Windows® 10 (64-bit)
• Linux 3.x/4.x
• Android 6.x
• Yocto
Note
To install Microsoft® Windows®10 (64-bit), we recommend a minimum storage capacity of 20 GB. congatec will not offer support for systems
with less than 20 GB storage space.

Copyright © 2017 congatec AG IA50m01 15/59
2.3 Mechanical Dimensions
• 170mm x 170mm
• Maximum Height: 20mm
2.4 Supply Voltage Power
• 12V - 24V DC ± 10%
2.5 Power Consumption
The power consumption values were measured with the following setup:
• conga-IA5
• conga-IA5 cooling solution
• Microsoft®Windows®10 (64-bit)
Note
The CPU was stressed to its maximum workload with the Intel®Thermal Analysis Tool
Table 8 Measurement Description
The power consumption values were recorded during the following system states:
System State Description Comment
S0: Minimum value Lowest frequency mode (LFM) with minimum core voltage during
desktop idle.
S0: Maximum value Highest frequency mode (HFM/Turbo Boost). The CPU was stressed to its maximum frequency.
S0: Peak value Highest current spike during the measurement of “S0: Maximum
value”. This state shows the peak value during runtime.
Consider this value when designing the system’s power supply to
ensure that sufficient power is supplied during worst case scenarios.
S3 SBC is powered by VCC_5V_SBY.
S5 SBC is powered by VCC_5V_SBY.
Note
The fan and SATA drives were powered externally. All other peripherals, except the LCD monitor, were disconnected before measurement.

Copyright © 2017 congatec AG IA50m01 16/59
Table 9 Power Consumption Values
The tables below provide additional information about the power consumption data for each of the conga-IA5 variants offered. The values are
recorded at various operating modes.
Part
No.
Memory
Size
H.W
Rev.
BIOS
Rev.
OS
(64-bit)
CPU Current (Amp.)
Variant Cores Base/Burst
Freq. (GHz)
S0:
Min
S0:
Max
S0:
Peak
S3 S5
052801 T.B.D T.B.D T.B.D Windows®10 Intel®Atom™ x7 E3950 4 1.6/2.0 T.B.D T.B.D T.B.D T.B.D T.B.D
052802 T.B.D T.B.D T.B.D Windows®10 Intel®Atom™ x5 E3940 4 1.6/1.8 T.B.D T.B.D T.B.D T.B.D T.B.D
052803 T.B.D T.B.D T.B.D Windows®10 Intel®Atom™ x5 E3930 2 1.3/1.8 T.B.D T.B.D T.B.D T.B.D T.B.D
052820 T.B.D T.B.D T.B.D Windows®10 Intel®Pentium®N4200 4 1.1/2.5 T.B.D T.B.D T.B.D T.B.D T.B.D
052821 T.B.D T.B.D T.B.D Windows®10 Intel®Celeron®N3350 2 1.1/2.4 T.B.D T.B.D T.B.D T.B.D T.B.D
052811 T.B.D T.B.D T.B.D Windows®10 Intel®Atom™ x7 E3950 4 1.6/2.0 T.B.D T.B.D T.B.D T.B.D T.B.D
Note
With fast input voltage rise time, the inrush current may exceed the measured peak current.
2.6 Supply Voltage Battery Power
Table 10 CMOS Battery Power Consumption
RTC @ Voltage Current
-10oC 3V DC T.B.D µA
20oC 3V DC T.B.D µA
70oC 3V DC T.B.D µA
Note
1. Do not use the CMOS battery power consumption values listed above to calculate CMOS battery lifetime.
2. Measure the CMOS battery power consumption in your customer specific application in worst case conditions (for example, during high
temperature and high battery voltage).
3. Consider also the self-discharge of the battery when calculating the lifetime of the CMOS battery. For more information, refer to application
note AN9_RTC_Battery_Lifetime.pdf on congatec AG website at www.congatec.com/support/application-notes.
4. We recommend to always have a CMOS battery present when operating the conga-IA5.

Copyright © 2017 congatec AG IA50m01 17/59
2.7 Environmental Specifications
Temperature (commercial variants) Operation: 0° to 60°C Storage: -20° to +80°C
Temperature (industrial variants) Operation: -40° to 85°C Storage: -40° to +85°C
Humidity Operation: 10% to 90% Storage: 5% to 95%
Caution
The above operating temperatures must be strictly adhered to at all times. When using a congatec heatspreader, the maximum operating
temperature refers to any measurable spot on the heatspreader’s surface.
Humidity specifications are for non-condensing conditions.

Copyright © 2017 congatec AG IA50m01 18/59
3 Block Diagram
*
1
Located at the bottom side.
*
2
Optional feature.
2x SO-DIMM DDR3L
LPC
GPO
SMB
HDA
Speaker
HD Audio
CS4207
congatec
Board Controller
Battery
BR2032
Front Panel
HD Audio
Intrusion
Header
2x FAN
SBM
3
Batt. Mgmt *
2
Feature
Connector
COM Port 2
COM Port 1
ccTALK
Super I/O
NCT6102D
2x TTL
to RS232
Reverse Polarity
Protection
External I/O
Power IN
Internal I/O optional
SPI Flash
SATA /
SATA DOM
mPCIe
M2 socket
SATA
PCIe
PCIe
i210 / i211
i210 / i211
uSim
Card
uSim
Card
TPM
eDP to LVDS
Ethernet
Ethernet
DP++
Audio HeadPh
Audio MIC
Buzzer
Internal
stereo speaker
Digital Mic,
(SPDIF)
USB 3.0 ICC A
Header
USB 2.0 Header USB2.0
USB3.0
SPI
SD3
MIPI
eDP
LVDS
eDP
DDI1
DP++ DDI0
2x USB 2.0 USB2.0
2x USB 3.0 USB3.0
SATA0
RTC
PCIe2
PCIe2 PCIe 2
SATA1
PCIe4/
USB3.0
USB2.0
PCIe5
USB2.0
Front Panel
Micro SD Card
MIPI 2xCAMS
2x SATA Power
Power IN
Backlight
Power
Panel
Power
Monitor
Off
PCIe x1
Intel Apollo Lake oC
Memory Controller
Tri-gate 3D 14nm Single/Dual/Quad Core
1MB L2 Cache Shared By 2 Cores
64 Architecture
SSE4.2 AES-NI Thermal Mgmt.
Virtualization (VT-x)
3D
DisplayPort 1.2
Dual Channel Low Power
HDMI 1.4 (3D, 4k)
embedded DP VGA
Display Interfaces
COMPUTE UNIT
SoC TRANSACTION ROUTER
OCL 1.2
MPEG-2 OpenCL 1.2
H.264 OpenGL 3.0
WMV9 OpenGLES 2.0
MJPEG DirectX 11
INTEGRATED I/O
SATA
High Definition Audio
USB 2.0
LPC BusPCIe
I/O Interfaces
GPIOs
USB 3.0
Multimedia Features

Copyright © 2017 congatec AG IA50m01 19/59
4 Cooling Solution
The conga-IA5 SBC offers Ultra Low Power boards with high computing performance and outstanding graphics. Due to its low power
consumption, the SBC generates less heat and therefore requires less active cooling, allowing the use of quieter, lower profile coolers that are
better suited to small form factor systems.
Nonetheless, all electronics contain semiconductor devices which have operating temperature ranges that should be adhered to. This means
that for reliable operation, the thermal design of the conga-IA5 must be carefully considered. For this reason, it is imperative to provide
sufficient air flow to each of the components, to ensure the specified operating temperature of the conga-IA5 is maintained.
congatec AG offers two cooling options for the conga-IA5:
• A congatec passive cooling solution for open die Celeron®and Pentium®(PN: 052830 — conga-IA5/CSP) or lidded die Atom™
(PN: 052831 — conga-IA5/i-CSP) variants in combination with the conga-IA5 retention frame (PN: 052254 — conga-IC87/Retention Frame).
The CSP complies with the Thin Mini-ITX height specification and features a Hi-Flow 225UT pressure sensitive, phase change thermal
interface. Refer to section 4.2 “CSP Dimensions” for the dimensions of the congatec heatspreaders.
• The use of a custom cooling solution in combination with the conga-IA5 retention frame (PN: 052254 — conga-IC87/Retention Frame).
Note
When a passive cooling is used, the end user must ensure that adequate air flow is maintained.
See section 1.2.2 “Optional Accessories” for the part numbers of the cooling accessories.
Passive Cooling Solution Retention Frame

Copyright © 2017 congatec AG IA50m01 20/59
4.1 Cooling Installation
Assembly Instruction:
• Flip over the SBC and locate the position of the CPU.
• Place retention frame on the bottom side of the board with insulating foil facing the PCB and standoffs inserted to PCB's mounting holes.
• Remove the CSP's protection pull tab foil from the phase changer and carefully place the CSP to the CPU.
• Hold the CSP with one hand so that it does not tilt while tightening the screws.
• Slightly tighten each of the 4 screws so that they hold the CSP in place. To do so, start with one screw and then slightly tighten the other
screws in a crossover pattern. All the while keep holding the cooling adapter straight with one hand.
• Now you can fully tighten the screws. Once again start with one and then continue to tighten the other screws in a crossover pattern. All
the while keep holding the cooling adapter straight with one hand.
Caution
For adequate heat dissipation, follow the assembly instruction above. Apply thread-locking fluid on the screws if the CSP is used in a high
shock and/or vibration environment.
For applications that require vertically-mounted CSP, use only cooling solution that secure the thermal stacks with fixing post. Without the
fixing post feature, the thermal stacks may move.
Also, do not exceed the maximum torque specification for the cooling solution screws. Doing so may damage the SBC.
