Product Manual
Pump Display & Control Panel
J1939 and Mechanical Engines
Part Number: MVP-702
Revision: 3.0
CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
2
TABLE OF CONTENTS
INSTALLATION INFORMATION……...........………………………………...……………………………………………………………....2
MODULE CONNECTOR ……..........................………………………………...………………………………………………………………….4
ENGINE ALARMS, CODES AND MESSAGES………………………………………………………………………….…...……..5
ALARM ANNUNCIATION AND CODE READER
PANEL INDICATION LAMPS
CONTROL PANEL ANALOG AND DIGITAL INPUTS………………………………………………………..……………..…7
MENU SYSTEM……………………………………………………………………………………………..……………………………..……….…..…9
MENU ACCESS, EXIT AND NAVIGATION
MENUS TO VIEW INFORMATION
MENUS TO CONFIGUREMODULE SETTINGS
CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
3
INSTALLATION INFORMATION
CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
4
MODULE CONNECTOR INFORMATION
BATTERY +
CAN HIGH
CAN LOW
SPEED INPUT
FUEL LEVEL INPUT
BATTERY -
BATTERY -
DIGITAL INPUT #1
FUEL/RUN
TEMP INPUT
OIL PRESS INPUT
PREHEAT
OUTPUT #3
1
2
3
4
5
6
1
2
3
4
5
6
CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
5
CONTROL PANEL SPECIFIC ALARMS AND SHUT DOWNS
The panel has its own engine safety alarms and shut downs that can be enabled. These alarms and
shut downs are managed by the control panel. The available options are listed below and can be
accessed via the Engine Safety Configuration menu.
Each alarm must be enabled in the Engine Safety Configuration menu to activate.
Heading
Default
Range
Units
Sender Check Bypass
0:10
0:05 –1:00
Min:Sec
Fuel Level Check
Off
Off / Always / Run
Low Fuel Pre Alarm
20
0 - 100
%
Low Fuel Alarm
1
0 - 100
%
Fuel Alarm Delay
0:05
0:01 –1:40
Sec
Fuel Level Alarm Action
Shutdown
Oil Pressure Check
Run
Off / Always / Run
Low Oil Press Pre Alarm
15
0 - 100
PSI
Low Oil Press Alarm
10
0 - 100
PSI
Oil Pressure Alarm Action
Shutdown
Oil Press Alarm Delay
0:05
0:01 –1:40
Sec
Temperature Check
Run
Off / Always / Run
High Temp Pre Alarm
220
150 - 300
Deg F
High Temp Alarm
230
150 - 300
Deg F
Temperature Alarm Action
Shutdown
Temp Alarm Delay
0:05
0:01 –1:40
Min:Sec
Battery Volts Check
Off
Off / Always / Run
Low Battery Pre Alarm
12.0
0.0 –40.0
Volts
Hi Battery Pre Alarm
15.0
0.0 –40.0
Volts
Over Speed Check
Off
Off / Always / Run
Over Speed Alarm
3000
650 - 5000
RPM
Over Speed Alarm Delay
0:05
0:01 –1:40
Min:Sec
1) Off / Always / Run –Describes when the parameter will be monitored for alarm conditions. Run
refers to when the engine is running. Off disables the alarm conditions. Always enables the alarm
constantly regardless of engine state.
2) Alarm Delay –The time period, after Sender Check Bypass, that the parameter must be on the
alarm condition before the alarm becomes latched.
CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
6
Indicator Lamps
.
Engine
Fault
Lamp
Low
DEF
Lamp
Engine
Pre Alarm
Lamp
Emissions
Fault
Lamp
Regen
Active
Lamp
Engine
DPF
Lamp
Engine
MIL
Lamp
Regen
Inhibit
Lamp
CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
7
CONTROL PANEL ANALOG AND DIGITAL INPUTS
The panel has one analog input and up to one digital input (close to ground) available to monitor
other components, senders or signals. These inputs can be used for a number of purposes
including alarms and shut downs.
Input
Heading
Default
Options
Connector
Pin
Digital 1
Normally
Open
Open / Closed
B
1
Function
None
Message
None
Check
Off
Off / Always / Run
Digital Outputs
1) Alarm –Engine shutdown when active with display message as assigned. A red lamp will also
be illuminated.
2) Pre Alarm –Warning message will be displayed along with a yellow lamp when active.
3) Pre Alarm & Alarm - Energizes an external audible alarm when a pre alarm or alarm condition
is present. Pressing the ENTER button will silence.
4) Alarm Horn - Energizes an external audible alarm when an alarm condition is present.
Pressing the ENTER button will silence.
5) Engine Run - Relay will be active when engine RPM is greater than 600. Typically used to
drive an auxiliary circuit such as louvers or send a signal to a monitoring station.
6) Low Oil Press Alarm - Relay closes if a low oil pressure shutdown is detected.
7) High Coolant Temp Alarm - Relay closes if a high engine temperature shutdown is detected.
8) Over Speed Alarm - Relay closes if an over speed shutdown is detected.
9) Over Crank Alarm - Relay closes if an over crank alarm is detected.
10) Low Fuel Level Alarm - Relay closes if a low fuel level shutdown is detected.
11) Fuel / Run - Relay will be active during an engine start request and while the engine is
running.
12) Custom 1 - Reserved for OEM applications.
13) Preheat - Relay will be active during programmed preheat period. Used to drive a preheat
relay.
CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
8
Digital Function Activation
1) Off / Always / Run –Describes when the parameter will be monitored for alarmconditions.
Run refers to when the engineis running. Off disables the alarmconditions. Always enables
the alarm constantly regardless of engine state.
2) AlarmDelay –The time period, after Sender Check Bypass, that the parameter must be on
the alarmcondition before the alarmbecomes latched.
CONTROL PANEL OUTPUTS
The panel has three relay outputs available to signal other devices based on predefined events.
These Outputs can be used for a number of purposes including engine operation or driving an
audible alarm.
Input
Heading
Default
Connector
Pin
Relay 1
B
2
Function
Fuel Run
Polarity
Positive
Initial State
On
Input
Heading
Default
Connector
Pin
Relay 2
B
5
Function
Preheat
Polarity
Positive
Initial State
Off
Input
Heading
Default
Connector
Pin
Relay 3
B
6
Function
None
Polarity
Positive
Initial State
Off
CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
9
MENU SYSTEM
To Enter Menu System
Hold MENU button and press ENTER button.
Menu Navigation
Press MENU button to scroll menu options.
Press UP arrow button to enter menu.
Press DOWN arrow button to reverse.
Exit Menu System
Hold MENU button and press ENTER button.
To Change a Setting
Press ENTER button to bring up brackets [ ].
Press UP arrow button and DOWN arrow button to change setting.
Press ENTER button to make selection, brackets disappear.
Recycle key to the OFF position after changing a setting.
CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
10
Main Menus
Main Menus
Sub Menus
Active Engine Fault Codes
View/Scroll Active Fault Codes
Stored Engine Fault Codes
View/Scroll Stored Fault Codes
Engine Parameters
View ECU Engine Information
(% Load, Torque, Oil Temp, etc.)
Emissions Parameters
Regen Options (Auto, Inhibit, Request)
DEF Level
Regen Active/Not Active View
Regen Inhibited/Not Inhibited View
DPF Out Gas Temperature View
DPF Differential Pressure View
Engine Identification
Engine Model # View
Engine Serial # View
Module Information
Control Unit Part# View
Control Unit Software Version View
Controller Setup
Quick Setup
(1)
(PASSWORD PROTECTED)
Engine Parameter Configuration
(2)
Input Configuration
(3)
Output Configuration
(4)
Throttle Configuration
(5)
Engine Safety Configuration
(6)
Module Configuration
(7)
Display Configuration
(8)
CAN Configuration
(9)
Maintenance Configuration
(10)
Emissions Configuration
(11)
Clutch Configuration
(12)
To access the controller setup menus, a password is required. The password is 4345.
Configuration
Menus
Viewing Menus
CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
11
Configuration Menus
(1)
Quick Setup
Engine Type –Default = Mechanical
Flywheel Teeth
Preheat Time
Performance Display Off/On
(2)
Eng. Parameter Configuration
Engine Type
Parameter Selection (Speed, Coolant Temp., Oil Pressure, Fuel Level,
Voltage, Hour Meter)
Parameter Setup (Varies based on parameter)
(3)
Input Configuration
Configure Selection (Channels/Message)
Digital 1 Setup
(4)
Output Configuration
Configure Selection (Channels/Message)
Relay 1 Function (Default to Fuel/Run)
Relay 2 Function (Default to Preheat)
Relay 3 Function
(5)
Throttle Configuration
Throttle Type
Cooperative TSC Mode
TSC Minimum Speed
TSC Maximum Speed
TSC Bump Speed
TSC Ramp Rate
Throttle Curve
Multi State Speeds 1-4
(6)
Engine Safety Configuration
Sender Check By-Pass (Default = 0:10)
Parameter Selection (Fuel Level, Oil Pressure, Temperature, Battery,
Overspeed, Speed Limit, Derate to Shutdown)
Parameter Settings (vary based on selection)
CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
12
(7)
Module Configuration
Preheat Time
Low Power Mode
Power Save Delay
Pre-Alarms Displayed (Default = 4)
Check Run Criteria
Clear Operation Log (Default = No)
Clear Alarm Log (Default = No)
Clear # of Starts
Engine Run Criteria
Engine Stop Criteria
(8)
Display Configuration
English/Metric Selection
Performance Display Off/On
Fuel Display
(9)
CAN Configuration
Engine Manufacturer
TSC1 Address (Default = 3) Others available
Source Address (Default = 44) Others available
Engine Address (Default = 0) Others available
Speed Transmit On/Off
Temperature Transmit On/Off
Oil Pressure Transmit On/Off
Fuel Level Transmit On/Off
Voltage Transmit On/Off
Hours Transmit On/Off
Faults Transmit
JDLINK Auto Accept
(10)
Maintenance Configuration
Service Messages
Schedule Selection
Schedule Reset
Schedule Interval
Schedule Warning
Schedule Trip
Schedule Message
CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
13
(11)
Emissions Configuration
DEF Level Check (Default = Off)
Low DEF Pre Alarm (Default = 16%)
Low DEF Alarm (Default = 0%)
DEF Alarm Delay (Default = 5 Sec.)
HC Burn off (Default = On)
HC Burn off Speed (Default = 1500 RPM)
Urea Burn off (Default = On)
Urea Burn off Speed (2000 RPM)
DPF Inhibit Lamp Source (Default = ECU)
DPF Message Delay (Default = 0 Sec.)
Neutral Switch (Default = Off)
Parking Brake (Default = Off)
(11)
Clutch Configuration
Clutch #1 Engage Trip (Default = None)
Clutch #1 Engage Speed (Default = 800 rpm)
Clutch #1 Engage Load (Default = 0%)
Clutch #1 Engage Coolant Temperature (Default = 150°F)
Clutch #1 Engage Delay (Default = 0:00)
Clutch #1 Engage Interval (Default = 0:00)
Clutch #1 Release Trip (Default = None)
Clutch #1 Release Speed (Default = 800 rpm)
Clutch #1 Release Load (Default = 0%)
Clutch #1 Release Coolant Temperature (Default = 150°F)
Clutch #1 Release Delay (Default = 0:00)
Clutch #1 Release Interval (Default = 0:00)

Other Controls Control Panel manuals

Controls HARLO MVP-902 User manual

Controls

Controls HARLO MVP-902 User manual

Controls MVP-62350 User manual

Controls

Controls MVP-62350 User manual

Controls MVP-G142 User manual

Controls

Controls MVP-G142 User manual

Controls J1939 User manual

Controls

Controls J1939 User manual

Controls MVP-L6100 User manual

Controls

Controls MVP-L6100 User manual

Controls C4F-F10198 User manual

Controls

Controls C4F-F10198 User manual

Controls MVP-903 User manual

Controls

Controls MVP-903 User manual

Controls J1939 User manual

Controls

Controls J1939 User manual

Controls XE-9501-AS User manual

Controls

Controls XE-9501-AS User manual

Controls MVP-A3702 User manual

Controls

Controls MVP-A3702 User manual

Controls MVP-62110 User manual

Controls

Controls MVP-62110 User manual

Controls C3-G8386 User manual

Controls

Controls C3-G8386 User manual

Controls J1939 User manual

Controls

Controls J1939 User manual

Controls MVP-A3413-FT4 User manual

Controls

Controls MVP-A3413-FT4 User manual

Controls C3M-G7230-AS User manual

Controls

Controls C3M-G7230-AS User manual

Controls C3-C10186 User manual

Controls

Controls C3-C10186 User manual

Controls MVP-A6307 User manual

Controls

Controls MVP-A6307 User manual

Controls MVP-L3100 User manual

Controls

Controls MVP-L3100 User manual

Controls C3-G7230-AS User manual

Controls

Controls C3-G7230-AS User manual

Controls J1939 User manual

Controls

Controls J1939 User manual

Controls MVP-410 User manual

Controls

Controls MVP-410 User manual

Popular Control Panel manuals by other brands

Nederman 591 Series user manual

Nederman

Nederman 591 Series user manual

Ness D8X Installation & programming manual

Ness

Ness D8X Installation & programming manual

Arlight Sens SR-2831-RF-IN manual

Arlight

Arlight Sens SR-2831-RF-IN manual

Texecom Premier 832 master user manual

Texecom

Texecom Premier 832 master user manual

Philips RC9800I/00 Specification sheet

Philips

Philips RC9800I/00 Specification sheet

RGBlink CP 3072 user manual

RGBlink

RGBlink CP 3072 user manual

Blue Whale Spa spaTouch instruction manual

Blue Whale Spa

Blue Whale Spa spaTouch instruction manual

DALGAKIRAN L-8 user manual

DALGAKIRAN

DALGAKIRAN L-8 user manual

Siemens MKB-1 operating instructions

Siemens

Siemens MKB-1 operating instructions

Frick QUANTUM Series Setup

Frick

Frick QUANTUM Series Setup

UTC interlogix NX-8V2 installation manual

UTC

UTC interlogix NX-8V2 installation manual

Belden Grass Valley NV9000 user guide

Belden

Belden Grass Valley NV9000 user guide

Infinite ZI250C user manual

Infinite

Infinite ZI250C user manual

Gewiss Chorus GW 10 746 manual

Gewiss

Gewiss Chorus GW 10 746 manual

Ravel RE -102 Installation, commissioning & operating  manual

Ravel

Ravel RE -102 Installation, commissioning & operating manual

Advanced MxPro4 Series manual

Advanced

Advanced MxPro4 Series manual

Satel Integra 24 manual

Satel

Satel Integra 24 manual

Frymaster M2000 Operation manual

Frymaster

Frymaster M2000 Operation manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
