Contura C i4 FS User manual

Installation
Instructions
C i4 FS
www.contura.eu
For use in GB and IE only

GB
2CERTIFICATE
DECLARATION OF PERFORMANCE
No. Ci4FS-CPR-130619-SE-1
DECLARED PERFORMANCE
Essential characteristics Performance Harmonised technical
specification
Reaction to fire A1 WT
Minimum distance to combustible material 100 mm to rear
300 mm to side
According to the given conditions in the installa-
tion instructions
Risk of falling embers Approved
Emissions from combustion
Wood / (Coal briquettes)
CO 0.10% / (0.21%)
NOx 108 mg/m3 / (NPD)
OGC 107 mg/m3 / (NPD)
PM 36 mg/m3 / (10 mg/m3 )
Surface temperatures Approved
Cleaning options Approved
Mechanical durability Approved
Emissions of hazardous substances Approved
Nominal output 4 kW / (4 kW)
Efficiency 78% / (76%)
Flue gas temperature in connector at nominal
output
310°C / (270°C)
EN 13240:2001 / A2:2004
PRODUCT
Product type Stove lit with solid biofuels
Type designation Contura i4 FS
Manufacturing number See rating plate on the stove
Intended area of use Heating of rooms in residential buildings
Fuel Wood / (Coal briquettes)
MANUFACTURER
Name NIBE AB / Contura
Address Box 134, Skulptörvägen 10
SE-285 23 Markaryd, Sweden
CHECKS
According to AVCP System 3
European standard EN 13240:2001 / A2:2004
Test institute Rein-Ruhr Feuerstätten Prüfstelle, NB 1625,
has checked declared performance and issued test report no. RRF-29 11 2751
The undersigned is responsible for the manufacture and conformity with the declared performance.
Niklas Gunnarsson, Business area manager NIBE STOVES
Markaryd, 1st July 2013

GB
3
A warm welcome to Contura.
A warm welcome to the Contura family. We hope
you will get a great deal of pleasure from your new
stove. As a new owner of a Contura stove you have
secured a product with timeless design and long
service life. Contura also has combustion that is both
environmentally friendly and efficient for the best heat
production.
Read through these installation instructions carefully
before installation. Read how to best light your stove
in the lighting instructions.
The stove becomes very hot
During operation, certain surfaces of the stove become
very hot and can cause burn injury if touched. Be aware
of the strong heat radiated through the door glass.
Placing flammable material closer than the safe distance
indicated may cause a fire. Smouldering can cause quick
gas ignition with the risk of damage to property and
personal injury.
NOTE! WARNING!
Report the installation of a stove to your
local authority.
The owner of the house is personally responsible
for ensuring compliance with the mandatory safety
requirements and must have the installation approved by
a qualified inspector. Your local chimney sweep must also
be informed about the installation as this will affect the
routines for regular chimney-sweeping services.
CONTENTS
Table of contents
Technical data 4
Installation distance to walls Classic 5
Installation distance to walls Modern 6
Prior to installation 7
Supply of combustion air 8
Heat retaining – Powerstone 8
Smoke control area 9
Adjusting and connecting 10
Removing the loose components 11

GB
4
WOOD COAL
Handle
(removable on modern)
FACTS
Building application
Before installing a stove or erecting a
chimney it is necessary for you to apply
for planning permission from your local
authority. Ask your local authority for
advice regarding building regulations and
the application.
Technical data
Output 3-5 kW
Nominal output 4 kW
Efficiency level Up to 80%
Model Classic
Weight (kg) 85
Width (mm) 479
Depth (mm) 408
Height (mm) 642
Model Modern
Weight (kg) 81
Width (mm) 492
Depth (mm) 368
Height (mm) 660
The connector’s inner diameter is Ø126 mm
Type approved in accordance with:
European standard EN-13240
DEFRA exempted
The stove can be used in
Smoke Control Areas.
Fire-box insulation panels
Grate
Ash-pan
Log guard
Type plate
Primary air
inlet control
Secondary air
inlet control
Chimney
Note! The stove installation and connection
to a chimney must be accomplished with
the current edition of Building Regulations.
We recommend that you consult a local
chimney sweep before the installation
to make sure that the chimney is in good
condition.
The stove is type approved and must be
connected to a chimney dimensioned
for at least 350°C. The connector on
the appliance is suitable for pipes with
diameter of 125 mm. The stove can be
loaded with maximum 100 kg of chimney.
A flexible flue liner or steel flue
certified for use with solid fuel is highly
recommended. The stove requires a
draught in the chimney of at least –12
Pa. The draught is affected both by the
length and area of the chimney, and by how
well sealed it is. Minimum recommended
chimney length is 3.5 m and a suitable
cross section area is 120-175 cm² (125-
150 mm in diameter). Carefully check that
the chimney is sealed and that there is
no leakage around soot hatches and flue
connections.
Note that a flue with sharp bends and
horizontal routing reduces the draught in
the chimney. Maximum horizontal flue is 1
m, on the condition that the vertical flue
length is at least 5 m. It must be possible
to sweep the full length of the flue and the
soot hatches must be easily accessible.
General
In this manual you will find instructions
about how your Contura i4 FS shall be
installed. Before you start the installation
it is important that you read this
instruction carefully and fully understand
the requirements. All European, national
and local standards and regulations
needs to be fulfilled when the appliance is
installed.
To guarantee the function and safety of
the stove we recommend that it is installed
by a professional. Our Contura agents can
recommend a suitable installer.
The room or space containing a stove shall
have a permanent air supply sufficent to
ensure proper combustion, to determine
correct amount of air supply use current
edition of Building Regulations.
Remember to use only for the appliance
recommended fuel as wood logs
or smokeless fuel as anthracite or
manufactured smokeless fuel briquettes.
Do not ever burn bituminous coal, “petro-
coke” or other petroleum based fuels!

GB
5
Installation distance to walls
INSTALLATION DISTANCES
Ci4 FS Classic
Move the stove in position and check that the minimum installation
distances given in the diagrams are met. The minimum distance in
front of the stove opening to combustible parts of the building or
interior decoration must be at least 1 m. The appliance must stand on
a constructional hearth which meet the building regulations and has
minimum dimension as shown in the diagram. Always check that the
building has enough bearing capacity for the hearth, stove and chimney.
When top connecting a steel flue please refer to the relevant
manufacturer’s installation instructions. Observe the safety distances to
combustible material that steel flues require.
Permitted area for
combustible parts
of the building
* To prevent discolouration of painted non-flammable walls we recommend that the same side distance as to combustible walls is used.
125
Ø125
98
42
598
450
Constructional
Hearth Combustible floor
Flue connector
479
642
408
304
100
673
740
779
450
Combustible wall
Constructional
Hearth
198
100
300
150 150
307
540
307
100
450
Combustible wall
Constructional
Hearth
254
50*
623
670 450
Constructional
Hearth
Fire-retardant wall of
brick or concrete
148
50*
50*
290
450
Constructional
Hearth
Fire-retardant wall of
brick or concrete

GB
6
Installation distance to walls
INSTALLATION DISTANCES
Ci4 FS Modern
492
660
125
Ø125
98
42
616
450
Constructional
Hearth Combustible floor
Flue connector
368 419
Move the stove in position and check that the minimum installation
distances given in the diagrams are met. The minimum distance in
front of the stove opening to combustible parts of the building or
interior decoration must be at least 1 m. The appliance must stand on
a constructional hearth which meet the building regulations and has
minimum dimension as shown in the diagram. Always check that the
building has enough bearing capacity for the hearth, stove and chimney.
When top connecting a steel flue please refer to the relevant
manufacturer’s installation instructions. Observe the safety distances
to combustible material that steel flues require.
309
100
662
708
779
450
Combustible wall
Constructional
Hearth
197
100
300
150 150
540
450
307
307
100
Combustible wall
Constructional
Hearth
259
50*
612
670 450
Constructional
Hearth
Fire-retardant wall of
brick or concrete
147
50*
50*
297
450
Constructional
Hearth
Fire-retardant wall of
brick or concrete
* To prevent discolouration of painted non-flammable walls we recommend that the same side distance as to combustible walls is used.
Permitted area for
combustible parts
of the building

GB
7
PREINSTALLATION
Prior to installation
10
10
VANADIUM
No. 7
CHROME
LEK
10
10
VANADIUM
No. 7
CHROME
!

GB
8
Supply of combustion air
When a stove is installed in a room, the demand for air supply to
the room increases. Air can be provided indirectly via a vent in the
outer wall or via a duct from the outside that is connected to the
stove. The amount of air needed for combustion is approximatly
20m³/h.
Install supply air connector (accessory) and outside air-supply kit
(accessory) before chimney installation.
Assembly instruction is found together with the accessory.
Outside air-supply kit (accessory)Supply air connector (accessory)
COMBUSTION AIR / ACCESSORY
Heat retaining – Powerstone
Place heat retaining Powerstone, before chimney installation
(accessory).
Assembly instruction is found together with the accessory.

GB
9
SMOKE CONTROL AREA
1 1
2 2
In smoke control areas it is mandatory to stop the damper from
closing completely. In other areas it´s optional.
Smoke control area
Ci4 FS Classic Ci4 FS Modern

GB
10 INSTALLATION
Final inspection of the installation
It is very important that the installation is inspected by an authorised chimney sweep before the
stove is used. Also read the ”Operating instructions”, before lighting for the first time.
Adjusting the stove
• Positionthestoveonthehearthplate.
• Adjusttheheightofthefouradjustablefeetuntil
the stove is horizontal.
Adjusting and connecting
After the stove has been adjusted and positioned according
to the installation distances, connection to the chimney is
carried out.
Put stove cement inside the flue connection and press the pipe
into the connection.
Continue the chimney installation according to the chimney
installation instructions.
max Ø125

GB
11
Removing the loose components
Smoke baffle
REMOVAL
Fire box surround
When sweeping, the smoke baffle must be lifted out, this can be
done when one side has been dismantled.
Fire bars
Lift the fire bars straight up, clean the ash from the guide groove
in the stove base plate before repositioning it in position.

811191 IAV Ci4 FS GB-2
2014-05-07
Contura reserves the right to change dimensions and
procedures described in these instructions at any
time without special notice. The current edition can be
downloaded from www.contura.eu
NIBE AB · Box 134 · 285 23 Markaryd · Sweden
www.contura.eu
