Courtyard Creations TLS41TP-WM User manual

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
PAGE 1 OF 2
TLS41TP
PARTS LIST
PART
NO.
MATERIAL
CODE PART Q’TY
1
2
3
4
1
4
1
4
6
5
7
8
9
12
8
4
8
1
TLS40TP-CS01
TLS41TP-CS01
62TLS40TPY101
17C33A0706001Y4
17C01A0706001Y4
17FA05040301-Y4
18000337004
18000337001
17KAA0101----Y4
TABLE TOP
LEG
CENTER
CONNECTOR WITH RING
BOLT M6*16
BOLT M6*16
BOLT CAP
BOLT CAP M6
HEX.KEY WRENCH 4MM
WASHER d6.5*D13*1.0
FIGURE 1
16
#4 BOLT M6*16
Attention:
Make sure that each bolt needed for all steps
matches the corresponding figure to ensure proper
assembly.
Step 1:
Place the table top (#1) onto a non-abrasive surface,
such as a carpet, with the underside facing upwards.
Fasten the legs (#2) to the table top (#1) by using
bolts (#4) and washers (#6). Keep the bolts loose.
See Figure 1.
2
2
2
2
1
6
4
7
-WM
COURTYARD CREATIONS INC.
STOP DON’T RETURN TO STORE!
Use the correct bolts as indicated. Do not tighten any of the bolts until the table is completely
assembled.
Do not sit or stand on this table.
Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
Quote the following FQC NO. when contacting the service center.
"
"
"
"
"
"
SERVICE CENTER TOLL FREE NO.
TEL: [phone]
FAX: [phone]

2
2
2
2
3
FIGURE 2 FIGURE 3
#5 BOLT M6*16
16
Step 2:
Fasten the center connector with ring (#3) to the
middle of the legs (#2) by using bolts (#5) and
washers (#6). Make sure that all of the bolts have
been tightened completely and cover them with
bolt caps (#7 and #8). See Figure 2.
Step 3:
Turn the table to its upright position. See Figure 3.
PAGE 2 OF 2
Note:
To use an umbrella with this table, Remove the
plastic center plug and put the umbrella pole
through the table top and center connector ring.
2
2
2
2
3
Cleaning and Maintenance

acid, or other solvents on the frame parts.

safety of your table.
When moving the table, remove the umbrella and lift. Do not drag this table.


protected area during off season periods.

STOP DON’T RETURN TO STORE!
The store where you made your purchase
does not stock parts for this item.
If you need parts,
whether they are missing or damaged,
STOP!
Missing A Part?
No Need To Go Back To
The Store
Call us between 9:00 AM and 4:30 PM
Eastern Time Monday through Friday
Call Toll Free:
TEL: [phone]
FAX: [phone]
READ THESE INSTRUCTIONS COMPLETELY BEFORE STARTING ASSEMBLY
SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU
HAVE ALL OF THE PARTS LISTED.
IF YOU DO NOT LOCATE ALL OF THE PARTS LISTED, INSPECT THE
PACKING MATERIAL FOR SMALL PARTS THAT MAY HAVE BECOME
SEPARATED DURING SHIPMENT.
IF YOU EXPERIENCE ANY DIFFICULTY DURING ASSEMBLY OR IF ANY
PARTS ARE MISSING OR DAMAGED, CALL THE HELP LINE AT
1-877-539-7436 BEFORE RETURNING THIS ITEM TO THE STORE.
PROVIDE THE FOLLOWING INFORMATION WHEN CALLING:
1-MODEL NUMBER OF THE PRODUCT.
2-PART NUMBER AND MATERIAL CODE OF THE PART FROM THE PARTS
LIST.
MOST PROBLEMS CAN BE RESOLVED WITHOUT RETURNING THIS
PRODUCT TO THE RETAILER.
