Coway CHP-6200N User manual

Water Purier CHP-6200N
• This product cannot be used if the voltage is dierent from that mentioned in the rating plate.
• For your safety and proper use of the product, please read this User’s Manual before use.

1
2
6
3
4
5
Direct water purication system
Nanotrap™ Filter removes particulates in drinking water, waterborne microorganisms,
bacteria and virus.
Plus Inno-Sense Filter(D) improves the taste of water by removing pollutants,
such as odor-causing substances, soluble contaminant, chlorine and volatile organic
compounds (VOC’s).
Direct water purication system has been applied for more hygienic use.
Electronic Cooling System
Our cooling system does not use a coolant and is an environmental friendly
water purier. In addition, as the unit uses an electrical based cooling function,
external noise is reduced.
Easy Filter Replacement
Unlike the existing dicult water purier lter replacement method that takes a
long time, you can now easily replace the lter.
Small, Slim, Sophisticated Design
The sophisticated slim design makes it easy to use even in small spaces.
Smart LED Display
Through the LED display on the control panel & indicator,
you can check the operating status of the product.
Instant Water Heating
Instant water heating function enables you to have more hygienic water than
stored hot water. Also it helps to save energy as heating function is activated
only when needed.
FEATURES

2
1
COWAY
DEAR CUSTOMERS
- Please keep the user manual in easily accessible areas. -
CONTENTS
FEATURES / CONTENTS
Thank you for using Coway Water Purier.
Please read this User Manual to learn about proper usage and maintenance of the product.
When a problem occurs while using the product, it can be solved by referring to the instructions in this manual.
Product Information How to use
Maintenance Others
| 03 | Safety Information
Power
Installation
During Use
Others
| 07 | Parts Name
| 08 | Water Purication Process
| 09 | Please Check Before Use
| 10 | Buttons and Indicators
| 14 | How to Get the Desired Water
How to Get Hot Water
How to Get Ambient Water
How to Get Cold Water
| 16 | How to Install
| 19 | How to Clean
| 23 | Filter Replacement
| 24 | How to Replace the Filter
| 26 | Troubleshooting
| 27 | Specications
| 28 | Water Flow Diagram

Danger : Indicates an imminently hazardous situation which,
if not avoided, will result in death or serious injury.
• Do not use a damaged power plug or loose power outlet.
• Do not pull on the power cord.
• Do not pull on the power cord to move the product.
• Do not touch the power plug with wet hands.
• Do not bend the power cord excessively or put it under a heavy
object to avoid damage or deformation.
• Do not plug and unplug the power cord repeatedly.
• When the power area comes into contact with water, unplug the
power plug and completely dry it prior to use.
• Make sure to unplug the power cord when repairing, inspecting
the product or changing its parts.
• Completely wipe o dust, water, etc. on the power plug’s pins
and areas of contact with the pins.
• Do not connect multiple products to one power outlet.
Use a separate socket for the product.
• Lock the tap water supply valve and disconnect power when not
using the product for an extended period of time.
• Do not modify the power cord on your own.
• If the power cord is damaged, do not attempt to replace the
cord. Instead, contact the service center to replace it.
• Do not install near sources of heat.
Be careful to keep this safety information.
Please read this information to prevent property loss and
ensure your safety. for 220 V - 240 V , 50 Hz use only
SAFETY INFORMATION

4
3
Product Information
• Connect the tap water to the cold water tubing.
• Please lock the tap water valve and disconnect the power plug
and contact the service center if there is water leakage from
inside the product or if water is puddling around the product.
• Immediately disconnect the power plug and contact the service
center if there is any burning smell or smoke or strange noises
from the product.
• Do not place candles or cigarettes on top of the product.
• Do not place bowls lled with water, chemicals, food, small
metals, or ammable substances on top of the product.
• Anyone who has insucient physical, sensory or mental ability
(including children) must be supervised or instructed to use the
product.
• It is recommended to keep eyes on children to make sure they
do not play with the product.
• Disconnect the power plug prior to cleaning.
• Do not arbitrarily open, repair, or remodel the product.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
SAFETY INFORMATION
for 220 V - 240 V , 50 Hz use only

Warning : Indicates a potentially hazardous situation which,
if not avoided, could result in death or serious injury.
• Do not apply excessive force or impact to the product.
• Do not install the product on a tilted surface. Do not apply
excessive force or impact to the product.
• Do not install in a location with too much humidity or dust or in
a location exposed to water or rain.
• Do not directly spray water on product for cleaning or use
benzene or thinner to wipe the product.
SAFETY INFORMATION

6
5
Product Information
SAFETY INFORMATION
Caution : Indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate
injury or damage to the product or other properties.
• Use tap water as source water.
① Use tap water that is suitable for drinking as source water.
②Do not use in places of high temperatures such as a bathroom.
③Do not use in places of high humidity or temperature.
• Drain the stored water as well as newly ltered water one more
time completely prior to use when not using the product for an
extended period of time.
• Hot water is very hot, so avoid direct contact with your body.
• Please replace the lter according to the lter replacement cycle
for clean water.
• Make sure to use the new hose set provided with the product. Do
not use an old hose set.
• Do not use the ltered water for replacing water in sh tanks and
aquariums.

User Manual
WaterFiltrationDevice
CHP-6200N
•Foryoursafetyandproperuseoftheproduct,pleasereadthisUser’sManualbeforeuse.
•Thisproductcannotbeusedifthevoltageisdierentfromthatmentionedintheratingplate.
Fitting Clips Distance Keeping GuideDistance Keeping Pole
PARTS NAME
Front/Rear
Accessories
Tray
Control Panel
/Indicators
Radiator Grill
Power Cord
Faucet
Extraction Button
Top Cover
Tips
- Tools for cleaning the product and for lter replacement are not provided along with the product.
- Product servicing by specialists is provided to rental and membership customers.

8
7
WATER PURIFICATION PROCESS
The essence of the water purication system lies in the lters.
Using an uncertied lter; or even using a certied yet expired lter may reduce lter performance.
2-Step Water Purication System (CHP-6200N)
Plus Inno-Sense Filter(D)Nanotrap™ Filter
21
PARTS NAME / WATER PURIFICATION PROCESS
Product Information
Step 1
: Nanotrap™ Filter
Nanotrap™ Filter removes particulates in drinking water, waterborne microorganisms, bacteria and virus.
Step 2
: Plus Inno-Sense Filter(D)
Plus Inno-Sense Filter(D) improves the taste of water by removing pollutants, such as odor-causing
substances, soluble contaminant, chlorine and volatile organic compounds (VOC’s).
Uses of the disposed water
- The disposed water should be used only for cleaning house, cloths,
or purposes other than drinking.
- Never use the disposed water for drinking or for cooking.
Tips

CHECK BEFORE USE
Please check before use!

Open the tap water supply valve.
The water purier can work properly only when the
tap water is supplied.

When indicator light on the display is
turned o
When the indicator light is o, check if there is a
blackout or if the power supply is cut o for other
reasons.

When the product has not been used
for a long time
If you stored water or have not used the system for
a long time, run continuous extraction for 1 cup of
hot water before use.

After installing the water purier
After installing the product, run continuous extraction
of ambient water for 3 minutes and continuous
extraction of cold water for 5 minutes before use.
After installation, make sure to run continuous
extraction for 1 cup of hot water before use.

Regular lter replacement
Regular lter replacement is crucial for clean
drinking water. Using expired lters decreases
water purier performance, so please replace the
lters on time.
This product is for 220 V - 240 V~, 50 Hz.
Make sure to connect the power plug to a grounded 220 V - 240 V~, 50 Hz outlet.
It requires a power supply to operate.
- Turn o the tap water valve when the product is not in use for a long time.
Tips

10
9
CHECK BEFORE USE / BUTTONS AND INDICATORS
How to use
1Hot Water Indicator
The indicator lights up when
hot water is selected.
3Cold Water Indicator
The indicator lights up when
cold water function is selected.
2Ambient Water Indicator
The indicator lights up when
ambient water function is selected.
4Cold Water Temperature
Indicator
The indicator lights up according to
the temperature of the cold water.
When the light indicator turns blue,
the water is at its coldest.
5Extraction Amount Indicator
The amount of selected extract is displayed.
∗4 Stages(1 CUP 250 ml / 2 C
UP 500 ml /
POT 1 000 ml / Continuous Extraction(CON).
5Extraction
Amount
Indicator
1Hot Water
Indicator
2Ambient Water
Indicator
3Cold Water
Indicator
4Cold Water
Temperature
Indicator
BUTTONS AND INDICATORS
Indicators
7
Low Water Indicator
It is displayed when the extraction
ow rate is lowered and the extraction
stops until the indicator turns o.
∗
The indicator turns on and hot water extraction
is limited for 10 seconds if you do not comply
with the lter replacement cycle or the
installation conditions. Follow the installation
conditions and lter replacement cycle.
6
Hot Water Lock Indicator
The indicator lights up when
hot water lock mode is selected.
7Low Water
Indicator
6Hot Water Lock
Indicator

Buttons
1Hot Water Button
Use when you wish to extract hot water.
Each time you press the button, you can
set the hot water temperature(COFFEE,
TEA, BABY MILK).
3Cold Water Button
Use when you wish to extract cold
water(Press for more than 2 seconds to
select, press for more than 5 seconds to
release).
2Ambient Water Button
Press it when you wish to extract
ambient water.
4Extraction Amount Button
Use when you wish to select desired
extraction amount.
∗
1 CUP 250 ml / 2 CUP 500 ml / POT 1 000 ml /
Con (Continuous Extraction) will be selected
in order.
5Extraction Button
Press it when you wish to extract water.
1Hot Water
Button
3Cold Water
Button
2Ambient
Water
Button
4Extraction
Amount Button
5Extraction Button
BUTTONS AND INDICATORS

12
11
BUTTONS AND INDICATORS
How to use
2 sec.
 If you wish to use the xed amount extraction function
You can touch the xed amount extraction button in succession to switch
between 4 options : 1 cup (250 ml), 2 cups (500 ml), POT (1 000 ml) and
Con(Continuous extraction for about 3 minutes).
∗During extraction, press the extraction button again to stop extraction.
∗The initial setting is set to 1 cup. If you wish to change the default setting,
press the desired extraction volume button for 2 seconds
(continuous extraction cannot be set as the default setting).
 Using the cold water function
Touch the cold water button for at least 2 seconds and check if the cold water
indicator on the display lights up. To turn o the cold water function, touch
the cold water button for more than 5 seconds.
∗After turning on the cold water function, you can drink cold water after about 3 hours.
∗
When you use the product for the rst time after the product is installed, select the cold water
mode and extract water using the continuous water extract feature until water comes out.
∗
When cooling is completed, the LED on the upper right changes in color from white to blue.
∗According to the ambient temperature, it can take 3 to 5 hours to complete the cooling
process.
∗
To maintain performance, make sure to separate the mesh from the back of the product and
clean it every two months if possible.
 Using the hot water function
Press hot water button and check that the hot water indicator is turned on.
∗When extracting hot water, pay special attention to avoid burns.
∗When using the hot water function once after the power is turned on, drain 1 cup of
hot water rst and it will take approximately 20 to 30 seconds and the progress will be
displayed at 0 to 100 %.
∗If you use hot water excessively for a certain duration, its use may be limited for
5 minutes to protect the product.

BUTTONS AND INDICATORS
5 sec.
2 sec.
 To use the mute function
If you touch the ambient water button and the xed amount extraction
button for more than 5 seconds, the mute function is activated. When the
mute function is activated, the alarm does not ring even when you touch the
lock/clean/cold/hot extract button or when the extraction is completed or
switched to the continuous extraction.
∗To release the mute function, touch the ambient water button and the xed amount
extraction button for more than 5 seconds.
 To use the hot water lock function
Press and hold the hot water button for more than 5 seconds to generate the
setting sound and turn on the lock LED.
To turn o the hot water lock function, press the hot water button for more
than 5 seconds.
 To use the all-lock function
Press and hold the hot water button and the the ambient water button
simultaneously for more than 2 seconds to set the all-lock function. To turn o
the all-lock function, press the hot water button for more than 2 seconds.
∗When all-lock function is set, all indicators turn o and
only the hot water lock indicator light up.
∗
If you set the all-lock function and then canceled it while using the hot water lock
function, the hot water lock function will be maintained and the lock button will light up.
5 sec.

14
13
How to use BUTTONS AND INDICATORS / HOW TO GET THE DESIRED WATER
How to Get Hot Water
- When extracting hot water, pay special attention to avoid burns.
- When extracting hot water, keep the cup close to the faucet as the water may splash.
(However, in case of inconvenience, use the faucet extension adapter).
- If you do not use hot water for a long time, the temperature of the rst glass of hot water may
be slightly lower.
To prevent hot water burns, the system automatically switches to cold water if the button is not
pressed within a certain amount time (about 7 seconds) after the hot water button was selected.
(When the cold water function is not selected, the state is changed to the ambient state.)
- If you hear only warning sounds with no hot water coming out, check the lock button LED (see p.16).
- Instant hot water heating method takes some time to extract.
(Hot water temperature 25°C, 0.5 L/min, standby time 4 seconds)
- When hot water is extracted, white debris (lime) may occur depending on the conditions of use.
If you nd a white foreign substance, please contact our service sta and ask for a Plus Service
(Scale Removal Service).
∗White foreign substance is limescale, which is produced by heating of the minerals in water.
- If you use hot water excessively for a certain duration, its use may be limited for 5 minutes to
protect the product.
Tips
- The xed amount extraction method
Touch the hot water button and select the desired extraction amount with the extraction amount button.
Press the extraction button, and hot water is extracted according to the selected quantity.
During extraction, if you press the extraction button again, then extraction is stopped (250 ml, 500 ml,
1 000 ml, and continuous extraction can be selected, in that order).
- Continuous extraction method
Press the extraction button after the extraction amount display has changed to Con by pressing the xed
amount extraction button, or press the extraction button for 2 seconds or longer. During extraction, if you
press the extraction button again, then extraction is stopped.
-Hot water temperature selection method
Select the desired temperature with the hot water button(Coee, tea, and baby milk can be selected,
in that order).
▶
HOW TO GET THE DESIRED WATER

HOW TO GET THE DESIRED WATER
- Fixed Amount Extraction Method
After checking the cold water temperature indicator, touch the cold water button and press the extraction
amount button to select the desired extraction amount. Press the extraction button, and cold water is extracted
according to the selected quantity. During extraction, if you press the extraction button again,
then extraction is stopped (250 ml, 500 ml, 1 000 ml, and continuous extraction can be selected, in that order).
- Continuous Extraction Method
Press the extraction button after the extraction amount display has changed to Con by pressing the xed
amount extraction button, or press the extraction button for
2 seconds or longer for continuous extraction.
During extraction, if you press the extraction button again,
then extraction is stopped.
∗Cold water mode is set as the default
during stand-by.
How to Get Ambient Water
How to Get Cold Water
- If cold water is not being dispensed, please check to see whether the cold water indicator on
the display unit is turned on (see p.13).
Tips
- Fixed Amount Extraction Method
Touch the ambient water button and select the desired extraction amount with the extraction amount button.
Press the extraction button, and ambient water is extracted according to the selected quantity.
During extraction, if you press the extraction button again, then extraction is stopped (250 ml, 500 ml,
1 000 ml, and continuous extraction can be selected, in that order).
- Continuous Extraction Method
Press the extraction button after the extraction amount display has changed to Con by pressing the xed
amount extraction button, or press the extraction button for
2 seconds or longer. During extraction, if you press the
extraction button again, then extraction is stopped.
▶
▶

16
15
HOW TO GET THE DESIRED WATER / HOW TO INSTALL
HOW TO INSTALL
Installation Guide
▶Feed water supply condition : 20 psi, 3 LPM or higher
Tap Water
Supply Valve
Connect the orange inlet for the tap water supply hose 1 to
the tap water pipe. Connect the drain connection 2 .
(COLD OUT 3 )
INLET : Tap water supplying hose (Orange) tubing
COLD WATER OUTLET : Fitting
HOT WATER OUTLET : Drain (Grey) Connection
Only for
220 V - 240 V~, 50 Hz
Maintenance
1
32

HOW TO INSTALL
Tips
If the components above are not installed, it may compromise on cooling performance.
Installation Guide

18
17
HOW TO INSTALL
Maintenance
Caution!
Place for Installing Water Purier I
Avoid installing the water purier in an area with uneven surface, extreme humidity, extreme light
exposure, extreme dust exposure, and water exposure, etc.
Place for Installing Water Purier II
Keep the radiator grill at the rear of the product at least 10 cm away from the wall and make sure that the
installation oor is rm.
Relocation and installation
When moving between locations, wait at least 30 minutes after installation to connect the power.
Cold Water Tubing
Make sure to connect it to the cold water tubing
(If connected to the hot water tubing, the lters can get damaged).
After Installation
After power-up, when FL is displayed, select the ambient water button and press the extract button
to ush the lter.
- Prepare a large container to contain all the water as the ushing process takes 3 minutes.
- The process is displayed at 0 to 100% on the indicator.
Cold water is not extracted at rst use since it takes some time to ll the cold water tank.
The hot water may not be available immediately after the product is turned on.
It takes some time to set the hot water feature.
Tips
Some residual water used during post-manufacturing inspection may be present in the lter.
Do not be alarmed as it is not a used product.
Do not reuse the previously used tap water supply valve and hose when installing the purier.

1. How to take out the tray
The front of the tray can be easily separated by lifting it up slightly.
Separate the tray and wipe the inside and outside with a cloth.
2. How to assemble tray
Slide the tray into the bottom of the product and
then place the cover in place.
HOW TO CLEAN
How to Clean the Tray
Wipe the product with a clean towel.
∗For thicker layers of dust, use a wet towel to wipe
(Do not use an abrasive.)
How to clean the product body (once every 2~4 weeks)
- Do not directly spray water to the product body to clean it.
- Do not use thinner, benzene or agent containing abrasives or rough cloths to clean it.
Tips
