Coway Aquamega 200C User manual
USER MANUAL
Water Purier 200C
- Sediment + Carbon-block filter.
-
Reduction of chlorine, taste & odor, chloramine, lead, mercury, cyst, VOCs,
turbidity, Bisphenol A, Estrone, Ibuprofen, Naproxen, and Nonylphenol.
See performance data sheet for individual contaminants and
reduction performance.
Wi-Fi connectivity and Coway IoCare® Mobile App for smarter use of
water purifier.
Our cooling system does not use coolant, so it is an environmentally
friendly water purifier system. In addition, noise due to the existing
cooling function is reduced by use of an electrical energy based cooling
function.
Unlike the existing difficult water purifier filter replacement method
that takes a long time, you can now easily replace the filter.
The sophisticated slim design makes it easy to use even in small spaces.
The controller/indicator's LED can show you the operational status of
the product including filter replacement information.
The following features are available for our Aquamega Water Purifier
01 BEFORE USE
02 HOW TO USE
03 MAINTENANCE
04 OTHERS
EN
The following symbols are used in this manual to explain procedures, restrictions, handling precautions, and
instructions that should be observed for safety.
WARNING
Warning indicates a potentially hazardous situation that may result in death or severe injury to the user or others.
CAUTION
Caution indicates a potentially hazardous situation that may result in injury to the user or others, or the loss of property.
NOTE
Note indicates useful tips or additional information for procedures and product use.
Read and follow all the safety tips and warnings before using the product.
WARNING
• Do not use damaged power plugs or loose fitting
outlets.
• Do not pull on the power cord.
• Do not pull on the power cord to move the product.
• Do not touch the power plug with wet hands.
• Do not bend the power cord excessively or put it under
heavy objects.
• Don't repeatedly plug and unplug the power cord.
• When the power supply comes into contact with water,
unplug the power plug and completely dry it prior to
use.
• Make sure to unplug the power cord when repairing,
inspecting the product or changing parts.
• Completely wipe off dust and water at the contact of
the power plug's pins.
• Do not connect multiple products to one power outlet.
Always use a separate socket for the product.
• Lock the raw water valve and disconnect power when
not using the product for an extended period of time.
• Do not modify the power cord arbitrarily.
• Do not arbitrarily replace damaged power cords and
contact the service center to replace the power cord.
• Do not install near sources of heat.
• Connect the feed water to the cold water pipe.
• Please lock water supply valve and disconnect the
power plug and contact the service center if there is
water leakage from inside the product or if water is
puddling around the product.
01 BEFORE USE
• Immediately disconnect the power plug and contact
the service center if there is any burning smell or
smoke or strange noises from the product.
• Do not place candles or cigarettes on the top of the
product.
• Do not place bowls filled with water, chemicals, food,
small metals, or flammable substances on the top of
the product.
• Disconnect the power plug prior to cleaning.
• Do not arbitrarily open, repair, or remodel the product.
CAUTION
• Don't apply excessive force or impacts to the product.
• Don't install on slopes. Do not apply excessive force or
shock to the product.
• Do not install in a location with too much humidity or
dust or in a location exposed to water or rain.
• Completely drain the stored water as well as newly
filtered water one more time prior to use when using
the product after an extended period of time.
• Do not directly spray water on the product for cleaning
or use benzene or thinner to wipe the product.
• Please replace the filter according to the filter
replacement cycle to drink clean water.
• Do not use the filtered water for replacing water in fish
tanks and aquariums.
• Use tap water as feed water.
(1) The water used should meet the drinkable criteria
of tap water.
(2) Do not use in places of high temperatures such as a
bathroom.
(3) Do not use in places of high humidity or
temperature.
• The end user has to be informed to keep at least 20 cm
separation with the antenna while this end product is
installed and operated.
• Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
EN
01 BEFORE USE
Check the parts of the product (exterior in the front and top view and control panel) and how they function.
X
5
X
3
X
3
The heart of a water filtration device is its filters.
If filters are not authorized or if authorized filters are used past
their life expectancy, their performance may decrease.
Carbon block Filter (B-I)
Sediment Filter (B-N)
12
EN
This product is for 120 V~, 60 Hz.
Please connect the power plug to grounded 120 V~, 60 Hz outlet. The water filtration
device requires a power supply to operate.
Tap water must be supplied for operation.
Please check for power failure or power stoppage for other various reasons when indicators of the display unit
are turned off.
Completely drain the stored water as well as newly filtered water one more time prior to use when using the
product after an extended period of time.
After installing the product, dispense the ambient water for 3 minutes before using the cold water.
Make sure that you run the ambient water to flush the filters properly before using the cold water.
Regular filter replacement is crucial for drinking clean water. Using expired filter decreases water filtration device
performance so please replace the filter on time.
Using the water drain cap at the rear of the product, you can completely drain the water from the inside of the
cold water tank.
NOTE
Lock the tap water valve and disconnect power when not using the product for an extended period of time.
02 HOW TO USE
1
It is lit when ambient water is
selected.
2
It is lit when cold water is selected.
* Cold water temperature displays
- Blue : Very Cold
- White : Cold
3
It will lit and indicate the selected
amount of dispensing water.
5
It is lit differently depending on
the Wi-Fi connection.
4
It is lit differently depending on the
remaining level of the filter.
1
3
5
4
2
Reference
EN
02 HOW TO USE
3
2
1
Use when you wish to dispense
filtered water (short tap).
2
Use when you want to use/cancel the
cold water function. (ON/OFF 5 sec).
Use when you wish to dispense cold
water (short tap).
3
Use when you wish to select the
desired dispensing amount.
(4 oz → 8 oz → 16 oz).
4
Press to dispense water.
* If you hold the button for 3 seconds,
it will dispense water for 3 minutes
continuously.
1
4
If you press the cold water button for more than 5 sec,
the cooler will be turned on/off. Touch it and see if the cold
water temperature display lamp is lit.
If you press the ambient water button for more than 5 sec,
it will be turned on/off.
If you press the ambient water button and the amount
button together for more than 2 sec, LED will be turned
on/off.
If you press the ambient water selection button and the
extraction amount button together for more than 2 sec,
Wi-Fi function will be turned on/off.
EN
02 HOW TO USE
Very Cold Cold
On :Connected
Blink :Disconnected
O :Wi-Fi O
-
(When the temperature of the water in the cold tank is
lower than 50~55 ℉)
-
(When the temperature of the water in the cold tank is
higher than 50~55 ℉)
- Filter Good : The remaining filter capacity is 100% ~ 1%
- Filter Change : The remaining filter capacity is 0%
Depending on the Wi-Fi status, the LED will be on, off,
or blinking.
Go to www.cowaymega.com/instructions for Wi-Fi pairing instruction
and other video instructions.
Set Wi-Fi for
the Coway IoCare® application
Press and hold the Ambient and Cold water buttons together
to activate the Wi-Fi pairing mode and follow the instruction.
NOTE
- If cold water is not being dispensed, please check if the
cooler is turned on. (Refer to P.11 - Cooler on/off)
- Vibration and chattering of a valve may occur during
the initial use of the water purifier and it will disappear
naturally.
NOTE
- Vibration and chattering of a valve may occur during
the initial use of the water purifier and it will disappear
naturally.
EN
02 HOW TO USE
*Howtochangethedefaultvalueofamount
NOTE
When dispensing cold/ambient water, the dispensing
display lamp will be lit in sequential order.
03 Maintenance
1/4" Tubing (White)
T-valve
HOT COLD
1/4" Tubing (White)
EN
03 Maintenance
CAUTION
- The T-valve must be connected to the cold water
supply only.
- Do not over tighten, it may cause a break or leak.
CAUTION
Depending on the installation environment, use L-fittings
and the T-fitting supplied to arrange the tubes.
CAUTION
When inserting the tubing, insert up to the black line.
CAUTION
- For continuous dispensing, use a drain hose.
- Make sure that you run the ambient water to flush
the filters before using the cold water.
NOTE
You can drink cold water after about two hours from the installing the product.
EN
Install the product in a cool part of the room, on an even surface, out of direct sunlight and away from
humidity, dust, and dripping water.
Keep the condenser part at the rear of the product at least 4 inches away from the wall and make sure that
the installation floor is firm.
Connect power 30 minutes after installation if the device has been moved.
The tubing and the product must be connected to the cold water pipe.
(If connected to the hot water pipe, it can damage the water filter.)
After installing the product, dispense the ambient water for 3 minutes before using the cold water.
03 Maintenance
NOTE
Some of the water used for the inspection process during production may remain inside the filter.
This product is not a secondhand product, so do not worry.
Do not reuse previously used connection valves or tubes when installing the product.
NOTE
In order to keep the tank clean, drain the cold water
from the tank every time you change the water filters
or every 3 months.
EN
1
2
Remove the cover before you lift up the tray.
After reinserting the cleaned tray back to the product,
place cover on top of the tray.
03 Maintenance
Table of contents
Languages:
Other Coway Water Filtration System manuals
Coway
Coway CHP-06DL User manual
Coway
Coway P-300L User manual
Coway
Coway CHP-264L User manual
Coway
Coway P-220R User manual
Coway
Coway CHP-18AR User manual
Coway
Coway CHP-03ARL User manual
Coway
Coway CHP-06DL User manual
Coway
Coway AQUAMEGA 100 User manual
Coway
Coway CHP/CP-6310L User manual
Coway
Coway CHP-7310R User manual
Coway
Coway CHPI-620L User manual
Coway
Coway CHP-671R/L User manual
Coway
Coway p-210n User manual
Coway
Coway CHP-250L User manual
Coway
Coway P-6320R User manual
Coway
Coway CHP-6200N User manual
Coway
Coway CHP-08AR User manual
Coway
Coway CHP-260L User manual
Coway
Coway CHP-240N User manual
Coway
Coway P-08L User manual
Popular Water Filtration System manuals by other brands
Wrekin Water
Wrekin Water SS15 Installation and operating instructions
EcoWater
EcoWater ess1000x series user manual
Antunes
Antunes VZN-420H owner's manual
HYDAC International
HYDAC International OLF-5 Series Operating and maintenance instructions
Thermo
Thermo 50132121 TII 3 operating instructions
Jandy
Jandy JEF-IN installation instructions
