Coway P-07CL User manual

P-07CL
Water Filtration Device
• Foryoursafetyandproperuseoftheproduct,pleasereadthis
User’sManualbeforeuse.
• WarrantycardisincludedinthisUser’sManual.

1
FEATURES
1. Continuous extraction function
Ifyouletthecokeleverdown,asyoucanextractthewater
continuouslyinastateofstoppedlever,itisconvenient.
2. Uniform water pressure keeping function
Intheareawiththehighwaterpressure,itprotectstheinsideof
theproductfromthehighwaterpressurebyprovidingamain
waterwithanuniformedwaterpressure.
3. Closed tank for preventing the secondary
pollution
Itisthehygienicbyapplyingtheextraclosedstructure
totheinnertanktopreventingthesecondarypollutiondueto
theintrusionofadust,worm,andotherforeignbody.
4. Compact, Slim Design
Thecompact,slimdesigntsanysmallspaceinyourkitchen.
Uninformed water
pressure keeping
Uninformed water
pressure keeping
Continuous
extraction
Continuous
extraction
Secondary
pollution
prevention
Secondary
pollution
prevention

ThankyouforusingCoway Water Filtration Device.
PleasereadthisUsers’Manualtouseandmaintaintheproductcorrectly.Ifyouencountera
problemwhileusingtheproduct,youmaysolvetheproblemreferringtotheUser’sManual.
Asthismanualcontainstheproductwarrantycard,pleasekeepitinasafeplace.
ThissystemconformstoNSF/ANSI42foraestheticchlorinereductionandNSF/ANSI53forVOC
reductionasveriedandsubstantiatedbytestdata.
ThissystemconformstoNSF/ANSI58forthereductionofpentavalentarsenic,barium,cadmium,
selenium,radium226/228,trivalentchromium,hexavalentchromium,lead,nitrate/nitriteas
veriedandsubstantiatedbytestdata.
Seeperformancedatasheetforindividualcontaminantsandreductionperformance.
Thissystemisacceptablefortreatmentforinuentconcentrationsofnomorethan27mg/
Lnitrateand3mg/LnitriteincombinationmeasuredasNandiscertiedfornitrate/nitrite
reductiononlyforwatersupplieswithapressureof280kPa(40psi)orgreater.
2
Coway
FEATURES / CONTENTS
DEAR CUSTOMERS
- Please keep the User’s Manual where it can be readily reached or found -
CONTENTS
FOR INFORMATION
SAFETY INFORMATION...................3
Installationsafety...................... 3
Operationsafety....................... 3
Others................................. 4
PARTS NAME ............................5
WATER FILTRATION PROCESS.............6
HOW TO USE
INSTALLATION PRECAUTIONS ............7
HOW TO USE.............................9
Todrinktheroomwater ............... 9
Toextractcontinuously. . . . . . . . . . . . . . . . 9
MAINTENANCE
INSTALLATION ..........................10
CLEANING METHOD ....................12
Storagetank..........................12
FILTER REPLACEMENT...................15
FILTER REPLACEMENT METHOD .........16
OTHERS
TROUBLESHOOTING ....................18
SPECIFICATIONS ........................19
WATER FLOW DIAGRAM.................20
PERFORMANCE DATA SHEET ............21
WARRANTY CARD.......................25

3
SAFETY INFORMATION
Ifnotobserved,
seriousinjuryor
evendeathcould
occur.
Ifnotobserved,
seriousinjuryor
propertydamage
couldoccur.
Ifnotobserved,slight
injuryorproperty
damagecouldoccur.
Danger Warning Caution
Installation safety
Do not install near a
heating device.
Otherwise,remayoccuras
aresult.
Do not install the
product on a sloped
oor.
Injurytotheuserordamage
totheunitmayresult.
Do not press the product
by constraint or impact.
Injurytodamagetotheunit
mayresult.
The ltration device installation shall
comply with applicable state and local
regulations.
Operation safety
When the water is
coming inside of the
product or there is a
puddle on the product,
call Service Center after
closing the supplying
valve and unplugging.
Otherwise,electricshockmay
occurasaresult.
If our product produces a
strange noise or odd
smell, immediately
unplug from the
electrical outlet and call
our Service Center.
Otherwise,electricshockor
remayoccurasaresult.
Be careful to keep this safety information.
Pleasereadthissafetyinformationcarefullytoensureyoursafetyandtopreventpossible
propertydamageorloss.

4
For Information
SAFETY INFORMATION |Installation safety |Operation safety |Others
Do not put the candle, a
light for cigarette on the
products.
Otherwise,remayoccuras
aresult.
Do not place any
containers with water,
medicine, food, small
metallic objects, or any
ammable material on
the top of the product.
Inthecaseforeignmaterial
getsinsidetheproduct,
electricshock,re,product
damagemayoccurasaresult.
To drink the ltered,
change the lter
according to the lter
replacement cycle.
Ifyouusetheexpiredlter,
thelterperformanceis
lowered.
Use after closing the
water tank cover
completely inside of the
product.
Thebuckortheforeignbody
canbeentered.
Others
Do not clean by spraying
the water directly or
don’t wipe the product
using the benzene and
thinner.
Otherwise,electricshockor
remayoccurasaresult.
Do not repair,
disassemble, or modify.
Otherwise,electricshockor
productdamagemayoccur
asaresult.
Do not use ltered water
for the water exchange
of an aquarium or a
shbowl.
Theroomwaterthroughthe
membraneisn’tsuitablefor
thesh’slifeenvironmentas
itremovedtheionicmaterial.
Insomecases,shesmight
evendie.
After moving the product
or replacing the inno-
sense lter, the black
powder can be remained
in the inner bottom of
the water tank.
Itisquietharmlessasthe
powderoftheactivated
carbonusedintheinno-sense
lterwasowedoutfor
improvingthewatertastes.
Rotate with grasping the
ltered water extraction
faucet or don’t raise the
product using the faucet.
Otherwise,theleakagemay
beoccurredorproductmay
break.
Do not use with water
that is microbiologically
unsafe or of unknown
quality without adequate
disinfection before or after
the system.

PARTS NAME
Front
Rear
Top Cover
Inlet(Orange)
Outlet(Blue)
Extraction Lever
Room water Extraction Faucet
Front Cover
5

WATER FILTRATION PROCESS
The 5-step Water Filtering System
Step 1, 2 : NEO-SENSE FILTER
Thisneo-senselterhasthefunctiontoreduceaestheticchlorine,odor,volatileorganic
compounds(VOC’s).
Step 3 : RO MEMBRANE FILTER
ROmembranelterhasthefunctiontoreducewatercontaminantssuchaspentavalentarsenic,
barium,cadmium,selenium,radium226/228,trivalentchromium,hexavalentchromium,lead,
nitrate/nitrite.
Step 4 : INNO-SENSE FILTER
Thisinno-senselterhasthefunctionstoreducesmellinductionmaterialandtoimprovetasteof
water.Italsohasthefunctiontoreduceaestheticchlorine,volatileorganiccompounds(VOC’s).
Step 5 : CERAMIC FILTER
Thelteristhecoretechnologyoftheltrationsystem.
Ifyoudon’tusequalifyinglterorifyouuseanoldlterthathasexpired,
thesystemperformancemaydegrade.
Uses of reject water
- Therejectwatershouldbeusedforcleaningtherestroom,thehouse,clothes,or
purposesotherthandrinking.
- Neverusetherejectwaterforadrinkingorcooking.
Tips
Reject
Water
Outlet CERAMIC
FILTER
NEO-SENSE
FILTER
ROMEMBRANE
FILTER
INNO-SENSE
FILTER
CERAMIC
FILTER
6
For Information
PARTS NAME / WATER FILTRATION PROCESS

INSTALLATION PRECAUTIONS
The summary for the proper installation of the water ltration device
1. Close main water supply valve to separate the faucet.
2. Apply the teon tape on the adaptor and t it to the
pipe.
3. Connect the faucet with the adaptor.
4. Connect 1/4 inch orange tubing with the connector
on the adaptor.
5. Open the feed valve to supply water to the ltration
system.
Do not tum the water pipe.
Install the adaptor with connector to the cold water pipe.
Flush water through each lter at least 5 minutes before
Connection.
7

Please check before use!
• Openthemainwatersupplyvalve.
Themainwatermustbesuppliedtooperatethewaterltrationdevicenormally.
• Afterinstallingtheproduct
Getridofthesavedwaterabovethefullwaterintheinnerwatertank2timesormoretouse.
• Whenyoudidn’tuseforalongtime
Ifyousavedthewaterforalongtimeoryoudidn’tuse,drainthewaterinsideofthewater
ltrationdevicecompletelyandremovethenewlylteredwateronetimetouse.
• Regularlterreplacement
Itisimportanttoreplacethelterregularlytomaintainwaterqualityasitisdesigned.Ifthelter
isoverusedbeyonditsservicelife,theperformanceofthewaterltrationdevicedeteriorate.Do
notmissthelterreplacementcycle.
Whenyoudon’tuseforalongtime,closethemainwatersupplyvalve.
Tips
8
How to Use
INSTALLATION PRECAUTIONS

HOW TO USE
To drink the room water
Ifyoupulltheextractionleverdownward,youcandrink
thelteredwater.
To extract continuously
Pleasextheleverbylettingextractionleverdown
about90˚.
9

INSTALLATION
Follow the instruction for installation
Connecttheorangecolorinlettubing 1 to the tap water
supplying pipe. Connect the outlet tubing 2.
Outlettubing
(Blue)
Inlettubing
(Orange)
2
1
Mainwater
supplyvalve
10
Maintenance
HOW TO USE |To drink the room water |To extract continuously / INSTALLATION

INSTALLATION
Be cautious!
Water ltration device installation place 1
Pleaseinstallthewaterltrationsystemnotataroughplace,adamp
place,aplacewheretheunitisexposedtothedirectsunlight,a
placewheredustispresent,oraplacethatthewaterdrops.
Water ltration device installation place 2
Pleaseinstallattheplacewhereitis10cmormoreofromthewall
andthebottomisatandrm.
After installing the water ltration system
Pleaseemptythewatertanklledwithlteredwatertwotimesafter
theproductinstallation.
Cold water plumbing
Pleaseconnectthesourcewater.Makesurethatthesourcewateris
notfromhotwaterline.Ifyouusehotwaterassourcewater,then
itwillcausepermanentdamagestoROmembraneandseverely
degradetheproductperformance.
Hot water Pipe
1O Cm
Tomaintainoptimalproductperformance,consultaCowayengineerforthedetailed
installationmethods.
Theremaybesomewaterremaininginsideofthelterwhichwasusedtotestthe
productduringinspectionprocessatthefactory.
Pleasefeelateasyanduseasitisn’ttheusedproduct.
Don’treusethemainwatersupplyvalveandhosethatwaspreviously
usedwhenyoure-installtheproduct.
Tips
11

CLEANING METHOD
Storage tank
1. Close the main water supply valve.
2. Please empty the water tank completely using
the continuous extraction method (See P.9).
3. Please remove the top cover, and then un-hook the xed clip holding the
top cover of the water tank. Now open the tank cover.
1
21
12
Maintenance
INSTALLATION / CLEANING METHOD |Storage tank

CLEANING METHOD
4. Please install again after separating the ceramic lter from the water tank
cover and shaking and cleansing in the drained water.
5. Please wipe the surface of the storage tank with
soft clothes.
6. Use the storage tank after cleaning it with the drained water, and empty
the water tank using the continuous extraction method.
7. Close the water tank cover and assemble the xing clip.
2
2
1
1
13

8. Close the upper cover, and open the main water supply valve.
Closethestoragetankcovercompletely.
Insectsorotherforeignparticlescanbeentered.
Whenyoucleanthestoragetank,don’tuseanychemicalsor
detergent.
Ifyoudon’tcleanchemicalsordetergentcleanly,itcanbe
harmfultothebody.
- Keepthesurroundingscleanandcleanthestoragetankonce
pertwomonths.
Tips
14
Maintenance
CLEANING METHOD |Storage tank

FILTER REPLACEMENT
Filter
Filterisacriticalcomponentforawaterltrationsystem.Replacing
authorizedltersataspeciedreplacementcycleisimportanttomaintain
thewaterquality,andapropersystemoperation.Pleasereplaceltersata
speciedreplacementcycle.Forreplacementlters,pleasecontactCoway
authorizeddealersanddistributors.
Filter replacement cycle
Ifthelterisnotregularlyreplaced,itmaydegradethewaterqualityfrom
theproduct.Thesourcewaterqualitycanshortenthelterreplacement
period.
Theperiodforthelterexchangeismadebasedon10Luseinadayfor
houseuse(4peoplebased)useforbusiness.
P-07CL
Part No. Names of Filter Replacement Cycle
WJNF8-S Neo-senselter 6months
WJMF8-20-S Romembranelter 20months
WJIF8-S Inno-senselter 18months
WJCC-02 Ceramiclter 12months
About lter replacement cycle
Thelterreplacementcycledescribedaboveisnotthelterquality
warrantyperiodbuttheexpectedcycle(life)thattheltershowsits
originalperformance.
Therefore,thelterreplacementcyclemaybereducedfortheareawith
thepoorwaterqualityormorewaterconsumption.
15

FILTER REPLACEMENT METHOD
1. Close the main water supply valve and drain the water inside of the water
ltration device (See P.12).
2. Separate the top cover and the front cover.
(Remove the 2 xing screws at the top of the product and then separate
the front cover.)
Don’tpulltheCup-touchLeverwiththeexcesspower.
Otherwise,theproductmaybreak.
Tips
1
1
2
16
Maintenance
FILTER REPLACEMENT / FILTER REPLACEMENT METHOD

FILTER REPLACEMENT METHOD
3. After separating the tting connected to the lter trying to replace, please
replace the lter. (Separate the tting using the proper tool.)
4. Close the front cover aligning the grooves and then fasten the 2 screws
xing the front cover.
Close the top cover.
Whenyouarereplacinglters,pleasemakesurethatacorrespondinglteranda
hosearermlyconnectedandthatthereisnoleakage.Itisrecommendedtoempty
thewatertanklledwiththelteredwateratleastonetimerightafterthelter
replacement.
Tips
Beforeinstallinganewlter,pleasedotheltercleansingrstasdirectedbelow:
Tips
Filter Name Cleansing Time Comment
Neo-senselter 30seconds
Inno-senselter 3minutes PleaseuseNeo-senselteredwaterforcleansing
Romembranelter 3minutes PleaseuseNeo-senselteredwaterforcleansing
17

TROUBLESHOOTING
Symptom Check Measures to take
Thewatertastes
weird.
• Didyoucleanthestoragetank? Cleanthestoragetank.
• Youdidn’tusethewaterltrationdevice
foralongtime.
Getridofthesavedwaterandcleanthe
storagetank.
• Isn’titabouttimetochangethelter? Requestthelterreplacement.
Thewaterdoesn’t
come.
• Isthewatersupplycutorisn’tthewater
supplyvalveclosed? Openthemainwatersupplyvalve.
• Thewaterextractionfaucetisoutof
order. Inthiscase,pleasecontactaservicecenter.
• Didyoumissthelterreplacementtimes? Requestthelterreplacement.
Thewateris
owingslower.
• Isn’titabouttimetochangethelter? Requestthelterreplacement.
• Didn’tyouclosethemainwatersupply
valve? Openthemainwatersupplyvalve.
• Didn’tthetemperatureofthemainwater
dropsuddenly?
Ifthewatertemperatureislowered,the
wateramountisdecreased.
Aleakagewas
occurred.
• Doesn’tthewaterinsideofthestorage
tankcoverorthewaterltrationdevice
owout?
Checkbyopeningtheuppercoverand
requesttheserviceafterclosingthemain
watervalve.

ThewaterFiltrationdevicemayoperateabnormallyduetominorcausesnotbecauseofthe
productmalfunctionbutbecauseofthefactthattheuserisnotfamiliarwiththeproductuse.
Insuchacase,problemscanbesolvedeasilyevenwithoutthehelpfromtheServiceCenterby
checkingthefollowingitems.Ifyoucan’tsolvetheproblemaftercheckingthefollowingitems,
pleasecalltheServiceCenter.
18
Others
FILTER REPLACEMENT METHOD / TROUBLESHOOTING

19
SPECIFICATION
Product Water Filtration Device
Model P-07CL
FiltrationMethod RO(ReverseOsmosis)
TankCapacity 3.9L
Dimension 200mm(W)×390mm(D)×370mm(H)
WorkingTemperature 5°C-35°C
ProductionRate 76.8L/d(25°C,138kPa)
WorkingPressure 138kPa–827kPa
NetWeight 4.5kg
• Thewateramountcanbedierentiatedaccordingtothewaterpressureandthewater
temperature.
• Thewatertankcapacityistheamountbythesizeandcanbedierentfromtheextraction
capacity.
• Withoutanypriornotice,allorpartsoftheproductaresubjecttochangeforthepurposeof
improvingtheperformanceoftheproduct.
• RefertoPerformancedatasheetforindividualcontaminants,reductionperformanceandgeneral
operatinginformation.
