Coway CHPI-620L User manual
CHPI-620L
This product is for domestic use only. It cannot be used in overseas
countries where the power voltage is dierent.
Warranty card is included in this user’s manual.
Read and save these instructions.
FEATURES
01
DEAR CUSTOMERS COWAY
02
SAFETY INFORMATION
Do not use a damaged power plug or loose electric outlet.
Please connect the power plug to a dedicated grounded electrical outlet for
220 V - 240 V~ 50 Hz.
Do not move the product by pulling only the power cord.
Do not handle the power plug with wet hands.
Do not forcefully bend the power cord or place it under a heavy object to
prevent it from being damaged or deformed.
Do not repeatedly connect and disconnect the power plug.
If the electric outlet is wet, carefully unplug the product and let the electric
outlet dry completely before subsequent use.
Make sure to unplug the product before repairing, inspecting or replacing a part.
Remove any dust or water from the power plug.
Do not plug the product into an electrical outlet or power strip that is being used
by several other appliances. Use an electrical outlet dedicated to the product.
Unplug the system if it is not used for a long time.
Do not attempt to repair or modify the power cord yourself.
If the power cord is damaged, do not replace the cord yourself.
Call a service center to have it replaced.
Do not install the product near a heating device.
Do not install the product in locations exposed to moisture or water (rainwater).
Do not use the product in areas where ammable gases or combustible
materials are used or stored.
If the product produces a strange noise, burning smell or smoke, unplug it
from the electrical outlet immediately and call our service center.
03
For Information
Never place the product in water.
Do not disassemble, repair, or modify the product at your own discretion.
Do not place any containers with water, medicine, food, metallic objects or
ammable material on top of the product.
Unplug the system before cleaning it.
Clean by spraying water directly and do not clean the product using
benzene or thinner.
Avoid external impacts to the water tank. A strong impact may damage the
water tank.
Empty the water tray and the water tank before moving the product.
04
SAFETY INFORMATION
Do not let children hang on to the product or climb on it.
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
Children shall not play with the appliance.
Children should be supervised to ensure that they do not play with the
appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or
appliances. Arrange cord away from trac area and where it will not be
tripped over.
Cleaning and user-maintenance, such as lubrication, may result in re,
electric shock, or injury to persons.
Unplug or disconnect the appliance from the power supply before servicing.
05
Please use a dedicated electrical outlet/socket.
Multiple outlet or extension is not allowed as it may cause electric shock or re.
Please use single-socket extension cord only.
Installation Precaution.
READ AND SAVE THESE INSTRUCTIONS
Do not install the product on a sloped surface.
Do not apply force or impact to the product.
When the product is in use, maintain a distance of at least 4 inch from the
walls.
Replace the lters according to the lter replacement cycles.
Drain all the water from the product before moving it. And move the unit
using handle.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
The new hose-sets supplied with the appliance are to be used and that old
hose-sets should not be reused.
For Information
06
PARTS NAME
07
WATER FILTRATION PROCESSES
First lter : Neo-Sense lter
2nd lter : Membrane lter (RO)
3rd lter : Plus Inno-Sense lter
4th lter : Antibacterial lter
For Information
08
PLEASE CHECK BEFORE USE
The main water supply must be turned on for the product to run normally.
When the indicator in the indication part is turned off, check if the power supply was
shut off due to power failure or other causes.
When the user has saved water for a long time or has not used water for a while, drain
the water inside the water ltration device completely, and rinse the water tank with the
newly ltered water one time before use.
Following the product installation, make sure the water tank is emptied or the water is ltered for
50 minutes or longer. (Empty the water tank lled with ltered water two times or more.)
It is very important to replace the lter regularly to maintain the intended water quality.
If the lter is used beyond its service life, the performance of the water ltration device will
deteriorate. Take note of the lter replacement cycle.
Close the main water supply valve and unplug the power cord.
09
BUTTONS AND INDICATORS
Ice Lock Indicator
Ice Full Indicator
Ice On Indicator
Lock indicator
Continuous dispense indicator
Power Saving indicator
Hot Water Temperature Indicator
Hot Water Indicator
Ambient Water indicator
Cold Water Indicator
Cold Water Temperature Indicator
Light Sensor
Service check lights
How to use
1
12
13
4
5
6
7
8
9
10
11
2
3
10
BUTTONS AND INDICATORS
1
4
5
6
7
8
2
3
Ice Lock Button
Ice On Button
Hot Water Lock Button
Continuous Dispense Button
Power Saving Button
Hot Water Button
Ambient Water Button
Cold Water Button
11
*
*
12
HOW TO GET THE DESIRED WATER
- If the unit does not dispense cold water, check if the Cold Water indicator
is on (refer to P.10).
- If the Continuous dispense button is pressed before or during dispensing,
cold water will be dispensed continuously.
- If the unit does not dispense hot water, check if the Hot Water indicator
is on (refer to P.10).
- The hot water feature will be deactivated after some time, and the cold
water feature will be activated automatically. (If the Cold Water feature
was selected previously, or if none was selected, the Ambient Water
feature will be activated)
- If the Continuous dispense button is pressed before or during dispensing,
hot water will be dispensed continuously.
13
How to use
- If the unit does not dispense ambient water, check if the Ambient Water
indicator is on (refer to P.10).
- If the Continuous dispense button is pressed before or during dispensing,
ambient water will be dispensed continuously.
*
*
- If the unit does not dispense ice, check if the Ice indicator is on (refer to P.10).
- Ice will be dispensed only when the ice dispenser lever is pressed.
Have the ice dispenser lever pressed continually while getting ice.
- When ice cubes are dumped into the storage tank, a clattering noise may
be heard.
14
HOW TO INSTALL
15
Maintenance
Install the product in a cool part of the room, on an even surface, avoid direct sunlight and
away from humidity, dust, and dripping water.
Allow a clearance of 10 cm or more behind the product, and level the water ltration unit.
Filter the water for more than 50 minutes or ll and drain once before using the unit.
(Drain the ltered water more than twice.)
If the unit is relocated, do not plug in the power cord until 30 minutes after the unit has been
installed.
Make sure the unit is connected to the cold water supply line.
(If connected to the hot water supply line, the ltration unit may be damaged.)
16
HOW TO CLEAN
*
*
17
*
Maintenance
18
HOW TO CLEAN
19
