Crestron UC-M130-T User manual

Quick Start
The Crestron®UC-M130-T Tabletop UC Video Conference System for Microsoft Teams™
delivers a powerful, professional solution for knowledge workers who want the Microsoft Teams
software experience in small to midsize meeting and conference rooms.
To use the UC-M130-T system you must have the following:
• A Microsoft Teams or Skype® for Business software account
• An environment running Microsoft Exchange (2013 SP1 or later for on-premises installation
or M365 for cloud) for scheduling and/or Skype for Business 2015 (on-premises installation
or M365 for cloud)
Display
UC-BRKT-100
CAT5e
UCENGINE HDMI
USB 2.0
CCSCAMUSBF100
Check the Box
Item Qty
UC-M130-T 1
CBL-CAT5E-7, 7 ft (2.1 m) CAT5e Cable (P/N 6509924) 1
CBL-USB-A-EXT-15, 15 ft (4.57 m) USB Extension Cable, Type A Male-to-Female,
(P/N 6508260)
1
CCS-CAM-USB-F-100 Logitech®Webcam C930e (P/N 6506442) 1
CCS-UC-1-T-V, Crestron Mercury®Tabletop UC Conference Console for Microsoft
Teams (P/N 6510716)
1
PW-2420RU, Desktop Power Pack, 24VDC, 2.5A (P/N 6500187) 1
UC-BRKT-100-ASSY Wall Bracket Assembly (includes HD-CONV-USB-200,
CBL-MDP-HD-0.5, UC-CONN-HD, and UC-ENGINE, Connector Cover Screws with
Tools, and Mounting Hardware) (P/N 6510636)
1
NOTE: Your system will be provided with the UC-ENGINE mounted on the UC-BRKT-100-ASSY.
Future packages will include the UC-ENGINE-SD mounted on the UC-BRKT-100-SD-ASSY.
Additional Requirements
The following items (not included) are required to build the system.
• A video display, connected to the UC-ENGINE
• USB keyboard and mouse to configure the system
• HDMI® cable to connect a display device
• HDMI cable to connect an HDMI source
• Ethernet cable to connect the PoE injector to the network
• #1 Phillips screwdriver
• Drill with a 5/16 in. bit (required for use with mounting anchors)
NOTE: Crestron recommends using Crestron cables only. For optimum performance, Crestron
offers the UC-M-ACCY KIT which includes all of the required hookup cables and a wireless
keyboard with integrated touchpad.
Optional Items
The following can be added to a Flex system.
• CCS-UCA-SMK Swivel Mount Kit
• CCS-UCA-MIC Microphone Pods
Install the Wall Bracket Assembly
The wall bracket assembly can be installed on a wall behind a display device, or attached to
the rear of the display device. The wall bracket assembly includes mounting slots on both side
edges, spaced 100, 200, and 300 mm vertically, to allow for attachment to either side of the
display mounting plate. Additional mounting holes are provided on each side for other mounting
locations. Centerline mounting holes are also provided for attachment to the building structure.
Integrated, reusable cable tie wraps manage cable runs between the wall bracket and peripheral
devices.
Dimensions and Callouts
14.00 in.
(356 mm)
UC-ENGINE
Connector Cover
Connector Cover
Wall Plate Opening
Power Pack
Reusable Cable Tie Wrap (x4)
7.00 in.
(178 mm)
16.00 in.
(406 mm)
6.70 in.
(170 mm)
15.44 in.
(392 mm)
5.00 in.
(127 mm)
14.92 in.
(378 mm)
13.42 in.
(341 mm)
13.45 in.
(342 mm)
HD-CONV-USB-200
NOTES:
• The integrated cable tie wraps are reusable. Take care to avoid damage to the cable tie
wraps.
• The wall bracket assembly has an opening and pass through screw holes for placement
over a US electrical wall box that can be covered by a decorative wall plate. If the wall
plate opening will be positioned over an electrical wall box, longer screws will be needed
to secure the decorative wall plate to the electrical box. Do not secure the wall bracket
assembly with the wall plate opening screws.
When mounting on a wall, the wall bracket assembly should be anchored to the wall. The screws
and anchors included with the assembly are best suited for surfaces with 3/8 in. to 3/4 in.
thickness. To use the included anchors, perform the following procedure.
1. Drill a 5/16 in. pilot hole.
2. Fold the anchor in the middle and pinch
the ends together.
3. Insert the anchor in the hole and tap flush
with the wall.
4. Insert the included anchor key to pop the
anchor open and lock it.
WARNING: Do not force or hammer key.
5. Drive the screw partially into the anchor,
leaving 1/4 in. of the screw exposed.
6. Repeat steps 1 - 5 for the other anchor.
7. Place the wall bracket assembly on the
screws and hand tighten the screws until
the wall bracket is secured to the wall.
Install the Wall Bracket Assembly On a Wall
UC-M130-T
Crestron Flex M130 Tabletop UC Video Conference System for Microsoft Teams™

Prepare for Hardware Hookup
On the wall bracket assembly, open the connector covers located above and below the
UC-ENGINE to reveal the UC-ENGINE’s connectors.
NOTE: Each connector cover is secured to the wall bracket with a 6-32 Phillips screw. Use a #1
Phillips screwdriver to remove or install the screws. For additional security, replace the screws
with the spanner screws included with the UC-BRKT-100-ASSY. A 1/4 in. driver bit is supplied to
install the spanner screws.
Connect the System
UC-ENGINE
Connect the CCS-UCA-KB-USB (sold separately), CCS-UC-1-T-V, display, camera, and LAN to the
UC-ENGINE. Connections are made to the top and bottom of the UC-ENGINE.
UC-ENGINE, Bottom (as mounted)
CCS-UCA-KB-USB
(sold separately)
HD-CONV-USB-200
UC-ENGINE
• Keyboard: Connect a CCS-UCA-KB-USB keyboard (sold separately) to a port on the
UC-ENGINE for local keyboard and mouse control.
• CCS-UC-1-T-V: For connection details, refer to “CCS-UC-1-T-V.”
• HD-CONV-USB-200: The HD-CONV-USB-200 is already installed on the wall bracket
assembly and connected to the UC-ENGINE.
UC-ENGINE, Top (as mounted)
LAN
CCS-CAM-USB-F-100
UC-ENGINE
Display
UC-CONN-HD
(Do not remove)
• LAN: Connect the CBL-CAT5E-7 cable to the port on the UC-ENGINE and to the
corporate LAN.
NOTE: The UC-ENGINE and CCS-UC-1-T-V must be on the same network switch.
• CCS-CAM-USB-F-100: Connect the CCS-CAM-USB-F-100 camera to the port on the
UC-ENGINE with the cable that is attached to the camera.
• Display: Connect an HDMI cable (sold separately) to the HDMI port on the UC-ENGINE and
to the display.
• UC-CONN-HD: The UC-CONN-HD is already connected to the UC-ENGINE with the
CBL-MDP-HD-0.5 on the UC-BRKT-100-ASSY. Do not remove the UC-CONN-HD.
CCS-UC-1-T-V
LANLAN
Ground
UC-ENGINE
PW-2420-RU
CCS-UC-1-T-V Rear Panel
• USB B: Connect the CBL-USB-A-BMICRO-6 cable (supplied with CCS-UC-1-T-V) to the
USB B port on the CCS-UC-1-T-V and a USB port on the UC-ENGINE. If additional cable is
required, use the CBL-USB-A-EXT-15 to extend the length of the CBL-USB-A-BMICRO-6.
NOTE: Make this connection only when the CCS-UC-1-T-V is to be used as an audio device.
• LAN: Connect a 12 ft (3.6 m) CAT5e cable (included with the CCS-UC-1-T-V) to the LAN
port on the CCS-UC-1-T-V and to the corporate LAN.
NOTE: The CCS-UC-1-T-V and UC-ENGINE must be on the same network switch.
• Ground: Connect the CCS-UC-1-T-V to earth ground.
• Power: Connect the PW-2420RU power pack to an AC receptacle and to the 24V 2.5A port
on the CCS-UC-1-T-V.
NOTE: The CCS-UC-1-T-V can also be powered by PoE+. However, if the CCS-UCA-MIC is to be
used, the CCS-UC-1-T-V must be powered by the PW-2420-RU.
HD-CONV-USB-200
HDMI Source
HD-CONV-USB-200
The HD-CONV-USB-200 is already installed on the wall bracket assembly and connected to the
UC-ENGINE. Connect an HDMI source to the HDMI port on the HD-CONV-USB-200 with an
HDMI cable (sold separately).
Complete the Installation
1. Bundle the cables with the integrated cable tie wraps. The cable tie wraps are reusable.
2. Secure the connector covers with the spanner screws or the Phillips screws removed earlier
from the wall bracket assembly.
3. Connect the wall bracket assembly’s power pack cord to a wall outlet.
Apply Power
When all connections are made, press the power button on the bottom of the UC-ENGINE and
apply power to all of the other devices in the system. The CCS-UC-1-T-V will start and the display
will show its IP address.
Configure the System
Configure the CCS-UC-1-T-V
1. On a computer, open a web browser to the IP address of the CCS-UC-1-T-V (displayed when
power was applied) to configure the device to operate in Teams Video mode.
NOTES:
• The CCS-UC-1-T-V and computer must be on the same network switch.
• A login with administrative rights for the CCS-UC-1-TV is required.
2. Log in to the CCS-UC-1-T-V and navigate to DEVICE > Applications.
3. Select Teams Video from the Application Mode drop-down menu.
4. Reboot the device. The Microsoft Teams user interface is displayed on the device following
the reboot.
5. On a computer, open a web browser to the IP address of the CCS-UC-1-T-V. Log in and
navigate to DEVICE > Applications.
6. Enter the following information in the appropriate fields:
• Teams Video PC Address: Enter the IP address or hostname of the UC-ENGINE.
NOTE: The hostname is printed on a label affixed to the UC-ENGINE (mounted on the
UC-BRKT-100-ASSY).
• Teams Video PC Port: By default, port number 49500 is used. If a different port number
has been configured on the UC-ENGINE, enter that port number instead.
• Teams Video Username: Enter the login username for the UC-ENGINE. (The default
username is “admin”.)
• Teams Video Password: Enter the login password for the UC-ENGINE. (The default
password is “sfb”.)
7. Click Save Changes.
Refer to the CCS-UC-1 Supplemental Guide (Doc. 7927) at www.crestron.com/manuals for
details.
Configure the UC-ENGINE:
Use the CCS-UCA-KB-USB keyboard (sold separately) and your Microsoft Teams or Skype
account credentials to configure the UC-ENGINE. Refer to the UC Video Conference Systems for
Microsoft Teams Supplemental Guide (Doc. 8360) at www.crestron.com/manuals.
For Additional Information
Scan or click the QR code for detailed product information.
UC-M130-T
