Crestron UC-MM30-T User manual

The UC-MM30-T(-I) Crestron Flex tabletop conferencing system
provides small room video conference solution for use with Microsoft
Teams® Rooms software. It supports single or dual video displays and
features a Crestron Flex tabletop conference device, a UC bracket
assembly, and a collaboration camera.
Minimum Requirements:
lA video display (not included) connected to the UC Engine. A second
display is optional.
lA Microsoft Teams Rooms provisioned or Skype® for Business
account (not included)
lAn environment running Microsoft Exchange Server® software (2013
SP1 or later for on-premises installation or Microsoft 365® software
for Cloud) for scheduling and/or Skype for Business 2015 (on-
premises installation or Microsoft 365 software for Cloud) (not
included)
In the Box
Tabletop Conference Device
1 Flex MM Tabletop Conference Device, Microsoft Teams
video (6511613 or 6511614)
1 PoE+ Injector (2055605)
2 Cable, CAT5e, RJ-45 - RJ-45, 11.8 ft (3.6 m) (2056204)
1 Cable, USB 2.0, A - Micro B, 5.8 ft (1.8 m) (2055579)
UC Bracket Assembly
1 UC Bracket Assembly with UC Engine and HDMI® content
ingest (UC-BRKT-200-S-T-ASSY,6512689)
2 Anchor, Drywall, Plastic, 3/8 in. x 1/2 in. (9.5mm x
12.7mm) (2052565)
1 Key, Anchor (4529654)
2 Screw, 8-AB x 1-1/2 in. (38.1 mm), Pan Head, Combo
(2052567)
4 Tie Wrap (2047935)
Additional Items
1 Collaboration camera (6510482)
1 Camera wall mount kit (6510998)
1 Cable, CAT6a, RJ-45 - RJ-45, 20 ft (6.1 m) (6507640)
1 Cable, CAT5e, RJ-45 - RJ-45, 7 ft (2.1 m) (6509924)
1 Cable, DisplayPort™ to HDMI, 6 ft (1.8 m) (6508282)
1 Cable, HDMI, 20 ft (6.1 m) (6503567)
1 Cable, HDMI, 6 ft (1.8 m) (6503565)
1 Cable, USB 3.0, Right angle USB-C® to A, 6 ft (1.8 m)
(6511591)
1 Cable, USB Extension, USB Type A Male-to-Female, 15 ft
(4.6m) (6508260)
1
UC-MM30-T(-I) QuickStart
Crestron Flex Tabletop Small Room Video Conference System for Microsoft Teams® Rooms

Mount Devices
Mount the UC Bracket Assembly
Mount the UC Bracket Assembly to VESA® compliant display devices, a
wall, or other building structure. Anchors and screws are supplied for
installation on walls 3/8 in. (9.5mm) to 3/4 in. (19mm) thickness.
CAUTION: Preinstalled screws may protrude from the back of the
UC Bracket Assembly. Exercise caution when handling the UC
Bracket Assembly to avoid scratching or damaging surfaces.
NOTE: The integrated cable tie wraps are reusable. Avoid damaging
the cable tie wraps.
Mount the Camera
Mount the included camera according to the UC-CAM-WMK Quick Start
(Doc. 8257).
2
UC-MM30-T(-I) QuickStart
Crestron Flex Tabletop Small Room Video Conference System for Microsoft Teams® Rooms

Connect
System Overview
When connections are complete, the system appears as shown below. Refer to Make Connections for detailed connection instructions.
3
UC-MM30-T(-I) QuickStart
Crestron Flex Tabletop Small Room Video Conference System for Microsoft Teams® Rooms

Make Connections
1. Make UC Engine connections as shown in the following illustrations. The conference device can communicate with the UC Engine over a direct
connection or a network connection. Select one of the connection types as described below.
lMake a direct connection for simple installation and setup. Only use the direct connect adapter to connect the conference device to the UC
Engine. Do not use the direct connect adapter to connect the UC Engine to the network.
Direct Connection
4
UC-MM30-T(-I) QuickStart
Crestron Flex Tabletop Small Room Video Conference System for Microsoft Teams® Rooms

lMake a network connection if the system is to be managed by the XiO Cloud® service.
NOTE: When a network connection is used, disconnect the direct connect adapter from the UC Engine.
Network Connection
5
UC-MM30-T(-I) QuickStart
Crestron Flex Tabletop Small Room Video Conference System for Microsoft Teams® Rooms

2. Connect displays to the UC Engine.
6
UC-MM30-T(-I) QuickStart
Crestron Flex Tabletop Small Room Video Conference System for Microsoft Teams® Rooms

3. Connect the camera to the UC Engine as shown in the image below. Do not connect the camera to any of the other USB ports.
7
UC-MM30-T(-I) QuickStart
Crestron Flex Tabletop Small Room Video Conference System for Microsoft Teams® Rooms

4. Connect a laptop to the content ingest device (HD-CONV-USB-200).
5. Bundle the cables to the bracket assembly with the integrated cable tie wraps. The cable tie wraps are reusable.
8
UC-MM30-T(-I) QuickStart
Crestron Flex Tabletop Small Room Video Conference System for Microsoft Teams® Rooms

Configure
Apply Power
Press the power button on the bottom of the UC Engine and apply
power to all of the other devices in the system.
Configure the Conference Device
NOTE:If a Direct Connection was made between the conference
device and the UC Engine, skip to Configure the System.
1. On a computer, open a web browser to the IP address found in the
conference device's settings.
NOTES:
lThe device and computer must be on the same network switch
and VLAN.
lA login with administrative rights for the device is required.
2. Log in to the device and navigate to DEVICE >Applications.
3. Enter the following information in the appropriate fields:
lTeams Video PC Address: Enter the IP address or hostname of the
UC Engine.
NOTE: The hostname is printed on a label affixed to the UC
Engine.
lTeams Video PC Port: By default, port number 49500 is used. If a
different port number has been configured on the UC Engine,
enter that port number instead.
lTeams Video Username: Enter the login username for the UC
Engine. (The default username is “admin”.)
lTeams Video Password: Enter the login password for the UC
Engine. (The default password is “sfb”.)
4. Click Save Changes.
Configure the System
Use the conference device and your Microsoft Teams or Skype account
credentials to configure the UC Engine. For detailed information on
deploying Microsoft Teams Rooms, refer to the Microsoft Teams Rooms
documentation.
NOTE: Microsoft Teams does not support emergency calling in
Japan. For more information on emergency calling from Microsoft
Teams, refer to Manage emergency calling.
9
UC-MM30-T(-I) QuickStart
Crestron Flex Tabletop Small Room Video Conference System for Microsoft Teams® Rooms

Factory Reset
A factory reset may be performed when troubleshooting the conference
device.
To perform a factory reset on the conference device:
1. Power cycle the device by disconnecting and reconnecting the CAT5e
cable from the conference device.
2. When the device powers on and the LEDs flash green, tap the button
below the Crestron® logo 10 times. A factory reset confirmation
screen appears.
3. Tap one of the mute buttons to move the selector on the factory
reset confirmation screen to Yes. Tap the button below the Crestron
logo to confirm the factory reset.
4. The device will reboot. Configure the device as described in Configure.
Visit the Product Page
Scan the QR code to visit the product page.
UC-MM30-T
www.crestron.com/model/6511339
UC-MM30-T-I
www.crestron.com/model/6511340
10
