Crestron CGDMX-512BI DMX512 Controller
Operations & Installation Guide – DOC. 0003 Contents
•
i
Contents
DMX512 Controller: CGDMX-512BI 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................1
Applications.................................................................................................................1
Specifications ..............................................................................................................1
Physical Description....................................................................................................2
Industry Compliance ...................................................................................................5
Setup..........................................................................................................................................6
Supplied Hardware......................................................................................................6
Hardware Hookup .......................................................................................................6
Programming Software..............................................................................................................7
Earliest Version Software Requirements for the PC ...................................................7
Programming with Crestron SystemBuilder................................................................7
Programming with D3 Pro...........................................................................................7
Programming with SIMPL Windows..........................................................................8
Example Program........................................................................................................8
Uploading ..................................................................................................................................9
Programs......................................................................................................................9
Operation.................................................................................................................................10
S1 Values...................................................................................................................10
S2 Values...................................................................................................................10
S3 Values...................................................................................................................11
Problem Solving ......................................................................................................................13
Troubleshooting.........................................................................................................13
Reference Documents................................................................................................13
Further Inquiries........................................................................................................13
Future Updates ..........................................................................................................13
Software License Agreement...................................................................................................14
Return and Warranty Policies..................................................................................................16
Merchandise Returns / Repair Service ......................................................................16
CRESTRON Limited Warranty.................................................................................16

Crestron CGDMX-512BI DMX512 Controller
Operations & Installation Guide – DOC. 0003 DMX512 Controller: CGDMX-512BI
•
1
•System integration via RS232
•512 DMX inputs
•512 DMX outputs
•Optimal and standard-compliant DMX512 timing
DMX512 Controller:
CGDMX-512BI
Introduction
The CGDMX-512BI is a serial DMX512 interface which makes easy interfacing
possible between a Crestron control system and lighting product using the DMX512
protocol.
Only one serial RS-232/422 port on the Crestron control system is required to
communicate with the DMX512 interface.
The DMX512 interface has two separate DMX Ports, one DMX Out to send data to
the DMX lighting products and one DMX In to receive and/or control data from a
DMX512 Lighting console or other lighting control units.
Features and Functions
N
Applications
Control of any lighting systems that is compatible with the DMX512 protocol.
Specifications
Specifications for the CGDMX-512BI are listed in the following table.

DMX512 Controller Crestron CGDMX-512BI
2
•
DMX512 Controller: CGDMX-512BI Operations & Installation Guide – DOC. 0003
CGDMX-512BI Specifications
SPECIFICATION DETAILS
Fuse Slow, 0,63mA – Type TR5
I/O 1 RS232/422 (selectable)
I/O 2 DMX512-A, terminated, 120 ohm automatic
switch after power on
Timing (adjustable)
Break
Mark
B2B
179µ
14µ
22,8ms (S2=0)
Power
Supply voltage
Power Consumption 85 - 265V~, 47 – 83Hz approx. 5W
Default Net ID N/A
Minimum 2-Series Control
System Update File1, 2Version 2 or later
Environmental
Temperature 41º to 104º F (5º to 40º C)
Humidity 10% to 90% RH (non-condensing)
Enclosure
Chassis UL-94-V-0, heavily inflammable
Isolation All I/O (DIN3 56930-2/4.2.3
Dimensions
Height 2,24 in (5,7 cm)
Width 4,33 in (11 cm)
Depth 7,87 in (20 cm)
Weight 1,06 lbs (0,480 kg)
1. The latest software versions can be obtained from the Crestron website. Refer to the NOTE following
these footnotes.
2. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product
Catalog for a complete list of 2-Series control systems.
NOTE: Crestron software and any files on the website are for authorized Crestron
dealers and Crestron Authorized Independent Programmers (CAIP) only. New users
may be required to register to obtain access to certain areas of the site (including the
FTP site).
Physical Description
This section provides information on the connections, controls and indicators
available on your CGDMX-512BI.

Crestron CGDMX-512BI DMX512 Controller
Operations & Installation Guide – DOC. 0003 DMX512 Controller: CGDMX-512BI
•
3
CGDMX-512BI Physical View
CGDMX-512BI Overall Dimensions

DMX512 Controller Crestron CGDMX-512BI
4
•
DMX512 Controller: CGDMX-512BI Operations & Installation Guide – DOC. 0003
S1 S3
S2
Connectors, Controls & Indicators
# CONNECTORS,
CONTROLS &
INDICATORS
DESCRIPTION
1 DMX512 Output [+Data(3), GND2(1), -Data(2)]
2 DMX512 Input [+Data(3), GND1(1), -Data(2)]
3 Status LED’s:
Power
CN COM
DMX512
Indicates that the device is powered.
Indicates traffic between the Crestron
processor and CGDMX-512BI.
Indicates a valid DMX512 input signal.
4 RS232/422 Interface-
connector to the
Crestron processor
S1 Rotary code switch Set Baud rate, factory 7
S2 Rotary code switch Set DMX512 speed, factory 1
S3 Rotary code switch Set interface mode, factory 1
100 – 240V ~2.4A 50/60
Hz
(1) IEC Socket, mates with removable power
cord (included)
