Crestron DM-RMC-4K-SCALER-C User manual

DO GUIDE
Mounting onto a Rack Rail
The DM-RMC-4K-SCALER-C mounts onto
the front or rear rail of a rack. Position
either the left or right mounting ange of the
device so that the holes align with the holes
in the rack. Then, secure the device to the
rack using two rack mounting screws (not
included).
DO Check the Box
QTY PRODUCT PART NUM.
1 Power Pack, 24 Vdc 1.25 A, 100-240 Vac 2043102
2Interface Connector, Plug, 4-Pin 2003576
2Interface Connector, Plug, 5-Pin 2003577
Not Included: Cables, Mounting Screws
DO Make Connections to the Device
Make connections to the DM-RMC-4K-SCALER-C as required for the application.
The DM IN port is a PoDM+ (Power over DM) PD (Powered Device) port. To receive PoDM+, the
DM-RMC-4K-SCALER-C requires a connection to a DigitalMedia™ switcher or other equipment
that has a PoDM+ PSE (Power Sourcing Equipment) port. Any wiring that is connected to a
PoDM+ PSE port is for intra-building use only and should not be connected to a line that runs
outside of the building in which the PSE is located.
NOTE: Connection of the CEN-SWPOE-16 to the POE IN ports of DMC-4K-CO-HD output
cards in a DigitalMedia switcher can provide PoDM+ power to up to eight
DM-RMC-4K-SCALER-C devices.
NOTE: Connection of the DM-RMC-4K-SCALER-C to the included power pack is not required
when PoDM+ is used to power the device.
DM-RMC-4K-SCALER-C/DM-RMC-4K-SCALER-C-DSP
4K DigitalMedia 8G+®Receiver and Room Controller with Scaler
The Crestron® DM-RMC-4K-SCALER-C and DM-RMC-4K-SCALER-C-DSP are generally
identical. For simplicity within this guide, the term “DM-RMC-4K-SCALER-C” is used except
where noted.
DO Install the Device
The DM-RMC-4K-SCALER-C can be mounted onto a at surface or onto a rack rail.
Mounting onto a Flat Surface
Using four mounting screws (not included),
mount the device onto a at surface such as
a wall or a ceiling.
To/From
RS-232 Device
To IR Controllable
Devices
Balanced Stereo Line
Level Audio Output
To Relay Controllable
Devices
Ground
10BASE-T/100BASE-TX
Ethernet to Local Network
Device
HDMI®Digital Video and
Audio Output
From DM®Switcher,
Transmitter, or Other
DM Device or to
HDBaseT®Device
From Power Pack
(Included)

DO GUIDE DOC. 7708B (2042253) 04.15
Specications subject to change without notice.
DO Set the IP Address
The conguration of the receiver within the DigitalMedia 8G+®system determines how the IP
address of the receiver is set:
• If the receiver connects to a DigitalMedia switcher, the receiver is congured by the
switcher automatically.
• If the receiver connects to a DigitalMedia 8G+ transmitter, the receiver uses its own
conguration settings. By default, DHCP (Dynamic Host Conguration Protocol) is
enabled. If desired, you can assign the default IP address to the receiver by holding down
the SETUP button while the unit boots up. The default IP address overwrites the current
setting. The default IP address of the DM-RMC-4K-SCALER-C is 192.168.1.201, and the
default IP address of the DM-RMC-4K-SCALER-C-DSP is 192.168.1.202. To manually set a
different IP address, use Crestron Toolbox™.
DO Learn More
Visit the website for additional information
and the latest rmware updates.
Crestron Electronics
15 Volvo Drive, Rockleigh, NJ 07647
888.CRESTRON | www.crestron.com
As of the date of manufacture, the product has been tested and found to comply with specications for CE marking.
Federal Communications Commission (FCC) Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions:
(1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Caution: Changes or modications not expressly approved by the manufacturer responsible for compliance could void the user’s
authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Industry Canada (IC) Compliance Statement
CAN ICES-3(B)/NMB-3(B)
The specic patents that cover Crestron products are listed at patents.crestron.com. Product warranty can be found at www.crestron.com/warranty.
Crestron, the Crestron logo, Crestron Toolbox, DigitalMedia, DigitalMedia 8G+, and DM are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/
or other countries. HDBaseT and the HDBaseT Alliance logo are either trademarks or registered trademarks of the HDBaseT Alliance in the United States and/or other countries. HDMI and the
HDMI logo are either trademarks or registered trademarks of HDMI Licensing LLC in the United States and/or other countries. Other trademarks, registered trademarks, and trade names may
be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron
is not responsible for errors in typography or photography.
This document was written by the Technical Publications department at Crestron.
©2015 Crestron Electronics, Inc.
DM-RMC-4K-SCALER-C
DM-RMC-4K-SCALER-C-DSP
