Crestron 4 Channel Motor Control Module CLX-1MC4 User manual

Buttons
SETUP: Used for TSID
LED Indicators
PWR: (green) Indicates line power is applied to the LINE terminal
NET: (yellow) Indicates communication with the control system
1 – 4: (red x8) Indicates open or closed state of each channel
SETUP: (red) Indicates unit is in setup/manual mode
Environmental
Temperature: 32° to 104°F (0° to 40°C)
Humidity: 10% to 90% RH (non-condensing)
Heat Dissipation: 15 BTU/Hr + (0.44 BTU/Hr x Load Current in Amps), 22 BTU/Hr at
maximum load
Enclosure
Gray metal with black heat sink, surface mount module with (2) integral mounting flanges.
occupies 1 module space in any CAEN enclosure
Dimensions
Height: 7.59 in (19.27 cm)
Width: 6.92 in (17.57 cm)
Depth: 3.43 in (8.70 cm)
Weight
3.00 lb (1.36 kg)
AVAILABLE ACCESSORIES
CAEN Automation Enclosures
CLT-1MC4 Terminal Block
www.crestron.com
|
800.237.2041
> 4 channels of bidirectional motor control
> Up/down and open/close control for drapes, blinds, projection
screens, lifts, and more
> Single 120 Volt feed
> Occupies 1 module space in a CAEN automation enclosure
> Easy termination using CLT-Series terminal block
As part of a complete Crestron lighting system, the CLX-1MC4 motor control
module provides control of up to 4 bidirectional motors for drapes, blinds,
projection screens, lifts, etc. Each channel is rated for 10 Amps or 1/2 HP, with a
total module rating of 16 Amps.
The CLX-1MC4 occupies a single module space in any CAEN automation enclosure.
Termination of high-voltage wiring to the module is facilitated by a CLT-1MC4
terminal block, sold separately to enable termination of the wiring anytime prior to
installing the module. CLX modules are controlled by the PAC2 and PAC2M
professional automation control systems via the Cresnet network. A 5-wire link
provides bussing of the Cresnet and override signals between modules within an
enclosure (interconnect jumpers included).
SPECIFICATIONS
Load Ratings
Motor Control Channels: 4
Per Channel: 10 Amps, 1/2 HP
Module Total: 16 Amps
Load Types: 3-Wire bidirectional motors
Power Requirements
120 Volts AC, 60Hz, single-phase
Connections on module
Module Interconnect: (2) 5-pin 0.156 inch headers, Cresnet/Override interconnect ports
Connect to PAC2, PAC2M, CAEN-BLOCK, or adjacent CLX-Series module using interconnect
cable provided
Connections via CLT terminal block (sold separately)
LINE: (1) DIN rail terminal block, black, line power input
OPEN 1 - 4: (4) DIN rail terminal blocks, red
Channel outputs, “open” terminals
CLOSE 1 - 4: (4) DIN rail terminal blocks, blue
Channel outputs, “close” terminals
N IN: (1) DIN rail terminal block, white, line input neutral
N OUT 1 - 4: (4) DIN rail terminal blocks, white, channel output neutrals
Specifications subject to change without notice. Doc.4844 12/07
©2007 Crestron Electronics, Inc. All brand names, product names and trademarks are the property of their respective owners.
Crestron Electronics, Inc. 15 Volvo Drive
l
Rockleigh, NJ 07647
Tel: [phone]
l
Fax: [phone]
Crestron CLX-1MC4
4 Channel Motor Control
Module
Shown with CLT-1MC4 Terminal Block
