Crestron TSW-1050-FMKT User manual

Crestron TSW-1050-FMKT
TSW-1050 Flush Mount Kit
Installation guide
Further inquiries
To locate specific information or resolve questions after reviewing this guide contact Crestron’s
True Blue support or refer to the listing of Crestron worldwide offices on the Crestron Web site
(http://www.crestron.eu/?q=en/contact/global_offices) for assistance within a particular geograph-
ic region.
To post questions about Crestron products log onto the Online help section of the Crestron Web
site (www.crestron.com/onlinehelp). First-time users must establish a user account to fully benefit
from all available features.
NOTES: Observe the following points.
• Use caution when installing the TSW-1050-FMKT, not to plunge into a pipe or electrical
conduit.
• For Low voltage use only.
• Pay attention up /down orientation of the adapter according to the arrows marked on the
back sides of the adapter.
• Pay attention, avoid plugging the microphone and speaker grills with excessive paint also do
not paint the internal surface.
Crestron International
Oude Keerbergesebaan 2 Rijmenam, 2820
Tel: [phone]
Fax: [phone]
www.crestron.eu
Installation Guide
Specifications subject to
change without notice
DESCRIPTION
The TSW-1050-FMKT flush mount kit is an optional accessory for use with a Crestron® TSW-1050
10.1” touch screen. It is designed for a in-wall flush installation of a TSW-1050 touch screen onto a
concrete/brick wall and drywall. The TSW-1050-FMKT securely mounts the touch screen while al-
lowing easy access, insertion and exertion by manual push and magnet detachment of the touch
screen tray. When installing the TSW-1050-FMKT onto a concrete/brick wall first install the TSW-
1050-FMKT-BBI brick wall back box for a professional installation. The mounting kit is configured for
installation in 12.7mm (1/2 inch) thick clad constructions, shimming may be required if adjacent ma-
terial is not 12.7 mm drywall (1/2 inch). Installations and finishes are in the same manner as drywall.
Specications Details
Material MDF
Dimensions
Height
Width
Depth
234.7 mm (9.2”)
327 mm (12.9”)
16.6 mm (0.65”)
Weight 0.54 kg (1.2 pounds)
Available Models
TSW-750-FMKT TSW-1050 Flush Mount Kit
Physical View - Front side and Rear
INSTALLATION
Cut and Place
First determine where the TSW-1050-FMKT mount will be located, keeping in mind that the
TSW-1050-FMKT mounts need to fit between two studs. To locate these studs use a stud finder (We
suggest using a high quality stud finder that can detect studs, AC cables and water pipes so that you
can avoid these in-wall obstacles).
When a favourable installation position is determined, drill a pilot hole in the middle. USE CAUTION
when drilling, not to plunge into a pipe or electrical conduit. When the hole is drilled, explore the
surrounding area, making sure there are no obstacles present and that there’s enough room for
the mount. While using the mount, a level and a pencil, mark the top and bottom horizontal edges
of the mount on the drywall. Continue each line to the closest stud centre. Cut the drywall accord-
ing the top and bottom marked lines and stud centres using a utility knife or saw. After cutting the
drywall chamfer the rim of the opening using a coarse rasp.
Route adequate cabling to the installation point in accordance with your local electric regulations.
The TSW-1050-FMKT needs to fit between two studs and be installed on two horizontal supports
that are secured to the studs.
It is proffered that the TSW-1050-FMKT is mounted on two horizontal supports and at least
one stud. A good choice for horizontal supports are telescoping box mounting brackets that are
installed on stud face without bending their fixing plates. Horizontal supports may be made on site
of the drywall U tracks. When performing a retrofit work, insert the horizontal supports half way
under the top and bottom drywall edges of the opening. PAY ATTENTION UP / DOWN ORIENTATION
OF THE ADAPTER ACCORDING TO THE ARROWS MARKED ON THE BACK SIDES OF THE ADAPTER.
SETUP
Installation Tools and Materials
Safety goggles
Dust mask
Screwdriver
Measuring tape
Utility knife/saw
Leveller
Brush / sponge roller
Pencil
Spatula
Spackle tray
Coarse Rasp
Drywall T-square
Taping or joint knife
Sandpaper
Pole Sander
#6 bugle head screws
Setting-type compound
Drywall mud or joint compound
Drywall Paper tape
Paint
Drywall
Safety
• Use a dust mask to avoid getting dust particles in you lungs
• Wear eye protection to avoid getting dust particles in your eyes.
• Turn off the power in areas you’ll be drilling to avoid electric shock.
• Use plastic or canvas drop cloths to prevent the sanding dust from damaging nearby
furniture or spreading beyond you immediate work area.
Future Updates
As Crestron improves functions, adds new features and extends the capabilities of the TSW-1050-
FMKT, additional information may be made available as manual updates. These updates are solely
electronic and serve as intermediary supplements prior to the release of a complete technical
documentation revision.
Check the Crestron Web site periodically for manual update availability and its relevance. Updates
are identified as an “Addendum” in the Download column.

Removal
Push the left edge of the TSW-1050 inwards to eject the unit.
Painting
Before painting, remove the protective tape from de microphone and speaker grills. PAY ATTRI-
TION, AVOID PLUGGING THE MICROPHONE AND SPEAKER GRILLS WITH EXCESSIVE PAINT ALSO
DO NOT PAINT THE INTERNAL SURFACE. Paint and painting procedure are in the same manner
as drywall painting but avoid spray painting. Paint the number of coats necessary to achieve the
desired coverage and texture. After painting remove protective plug.
Insertion
Before insertion of the TSW-1050 verify that the internal adaptor surfaces are clear of putty and
paint. Attach the Crestron Mounting Bracket to the TSW-1050 and connect the cable. Insert the
touch screen into the adapter.
Fit the TSW-1050-FMKT into the opening, ensuring it is positioned square. When positioned cor-
rectly and levelled, secure the TSW-1050-FMKT through the holes located on its perimeter using
#6 bugle head screws.
Cut the appropriate drywall pieces and plug voids on the mount sides. Where the panels meet, cut
a V-groove into the short untampered ends with a utility knife, as this will make hiding the joint
easier when you’re taping. Secure all drywall edges to the studs and the horizontal supports.
Mud and tape
Before applying mud and tape and performing a standard mud, ensure that the front surface of
the mount is aligned with the drywall and that all the screws are flushed with the surface of the
drywall. Fill the gaps with setting-type compound and apply tape. Perform a standard mud and
tape drywall joining procedure. Do not apply drywall compound to the front surface. Apply drywall
compound to external grooves only. Sand the excess drywall compound to level with the front
surface.
