Crestron Isys i/O™
TPMC-15/17 Tilt Series
Touchpanel Media Centers
Operations Guide

This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
All brand names, product names and trademarks are the property of their respective owners.
Windows®and Windows®XP are registered trademarks of Microsoft Corporation in the United States and other countries.
©2005 Crestron Electronics, Inc.

Crestron Isys i/O™TPMC-15/17 Tilt Series Touchpanel Media Centers
Contents
Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................1
Specifications ..............................................................................................................8
Physical Description..................................................................................................11
Tilt Angle Tension Adjustment .................................................................................20
Industry Compliance .................................................................................................21
Setup ........................................................................................................................................21
Network Wiring.........................................................................................................21
CAT5 Wiring (CH Versions Only) ...........................................................................23
QM Network Wiring (QM Versions Only) ...............................................................23
QuickMedia Transport System..................................................................................24
Identity Code ............................................................................................................. 25
Configuring the Touchpanel......................................................................................25
Cable Management.................................................................................................... 48
Hardware Hookup ..................................................................................................... 48
Recommended Cleaning............................................................................................49
Programming ...........................................................................................................................49
Uploading and Upgrading........................................................................................................ 50
Establishing Communications ...................................................................................50
Troubleshooting Communications ............................................................................59
Uploading a SIMPL Windows Program.................................................................... 60
Uploading a VT Pro-e Project ...................................................................................61
Firmware Upgrade..................................................................................................... 64
Operation .................................................................................................................................66
MediaMarker ............................................................................................................. 66
Security Infrastructure...............................................................................................66
Problem Solving ......................................................................................................................68
Troubleshooting......................................................................................................... 68
Further Inquiries ........................................................................................................69
Future Updates .......................................................................................................... 69
Software License Agreement................................................................................................... 70
Return and Warranty Policies .................................................................................................. 72
Merchandise Returns / Repair Service ...................................................................... 72
CRESTRON Limited Warranty.................................................................................72
Microsoft®Windows XP®Embedded End User License Agreement .....................................73
Operations Guide - DOC. 6344 Contents •i

Crestron Isys i/O™TPMC-15/17 Tilt Series Touchpanel Media Centers
Touchpanel Media Centers:
Crestron Isys i/O™ TPMC-15/17
Tilt Series
Introduction
Features and Functions
The Crestron®Isys i/O™ TPMC-15 and TPMC-17 series of Touchpanel Media
Centers fuse a touchpanel with computer-based digital media technology to provide a
unified multimedia presentation and control solution. Incorporating thoroughly
modern styling in a versatile tilt design, the TPMC-15 series of Touchpanel Media
Centers feature a 15” XGA standard (4:3 ratio) display, high-resolution images,
embedded PC applications, annotation, and full-motion video. The TPMC-17-series
of Touchpanel Media Centers feature a 17” WXGA widescreen (15:9 ratio) display,
in addition to all of the features of the TPMC-15 series.
Both the TPMC-17 and TPMC-15 are available in QuickMedia™ (hereinafter
referred to as QM) and Crestron Home (hereinafter referred to as CH) versions.
TPMC-15 & TPMC-17 Series Functional Summary
• Microsoft®Windows®XP Embedded operating system with integrated
applications such as Internet Explorer, Windows Media®Player,
Netmeeting, Remote Desktop, and viewers for Word, Excel,
PowerPoint®, and Adobe®Acrobat®
• MediaMarker™ video annotation utility allows presenters to write or
draw electronically on the touchscreen using a finger or stylus
• 15” (38.1 cm) diagonal active matrix color display (TPMC-15) or
17” (43.2 cm) diagonal active matrix color display (TPMC-17)
• 4:3 aspect ratio (TPMC-15) or 15:9 widescreen aspect ration
(TPMC-17)
• 16.7 million colors
• 1024 x 768 screen resolution (TPMC-15)
1280 x 768 screen resolution (TPMC-17)
(continued on following page)
Operations Guide - DOC. 6344 Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series •1

Touchpanel Media Centers Crestron Isys i/O™TPMC-15/17 Tilt Series
TPMC-15 & TPMC-17 Series Functional Summary
•24 Bit non-palette graphics
• Fast graphics performance: imported photographs, drawings, and icons
• Two scalable video windows (up to full screen), enable the
simultaneous display of any two full-motion video or RGB computer
images (RGB on QM versions only)
• Two balanced video inputs can receive component, composite, and
S-video inputs; supports NTSC/PAL formats from any Crestron CAT5
balanced video source (CH versions only)
• Two QM inputs can receive audio, microphone, NTSC/PAL composite
video, S-video, component video and non-interlaced RGB computer
signals over Crescat-QM (or equivalent) cable (QM versions only)
• Built-in time-base correction for stable video & graphics
• Balanced input for audio that can be connected to a Crestron
CNX-BIPAD8 or any Crestron CAT5 balanced audio source (CH
versions only)
• Balanced output for microphone audio that can be connected to a
Crestron CNX-BIPAD8 or any Crestron CAT5 balanced audio device
(CH versions only)
• QM output at native touchpanel resolution act as transmitter for
connection to a QM receiver or switcher (QM versions only)
• Built-in microphone & two speakers (half duplex intercom capable)
• Built-in mixer mixes PC audio with selected audio input to speakers
• Stereo headphone jack
• Auto compensation automatically recalls microphone EQ settings,
source compensation settings and peak and boost preset values of
multiple QM origination points when acting as an endpoint (QM
versions only)
• Stores and transmits audio parameters for recall by a QM receiver when
acting as a QM origination point (QM versions only)
• Two USB ports for connecting with USB peripherals
• One RS-232 port for project upload, firmware upgrade, and diagnostics
• Two PCMCIA card slots for further expansion including installation of
wireless network card
• One 10BaseT/100BaseT Ethernet port
• Up to 4,000 digital and 4,000 analog signals; up to 4000 serial signals
• Support for downloadable fonts – proportional* and non-proportional
• Foreign language text
• Display can be tilted between 45 and 90 degrees for optimum viewing
* Proportional fonts: the width of each character differs with the character shape, for example, the letter M
is wider than the letter I. All characters in non-proportional fonts are spaced equally.
QM versions feature two QM inputs that can receive audio, microphone, NTSC/PAL
composite video, S-video, component video (including interlaced and progressive
scan HDTV), and non-interlaced RGB computer signals from any of Crestron’s
MediaManager line of FlipTop Boxes, Wall Plates, or Distribution Centers. The QM
versions also have a QM output for connection to a QM receiver or switcher.
CH versions feature two balanced video inputs for receiving component, S-video,
and NTSC/PAL composite sources, including HDTV signals from a Crestron
CNX-PVID device (or similar Crestron CAT5 video source) and one balanced audio
input for receiving audio signals from a Crestron CNX-BIPAD8 (or similar Crestron
2 •Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series Operations Guide - DOC. 6344

Crestron Isys i/O™TPMC-15/17 Tilt Series Touchpanel Media Centers
CAT5 audio source). The CH version is also equipped with balanced output for
microphone audio that can be connected to a Crestron CNX-BIPAD8 or similar
Crestron CAT5 audio receiver.
With either a 15-inch (38.1 cm) (TPMC-15) or a 17-inch (43.2 cm) widescreen (15:9
aspect ratio) active matrix color display (TPMC-17), these media centers can display
up 16.7 million colors at up to 1280 x 768 resolution (TPMC-17 series only),
allowing all graphics to be displayed with incredible brightness and depth.
Multiple graphics can be displayed on the TPMC-15 & TPMC-17 without any shift
in color depth or quality. CH versions of the TPMC-15 & TPMC-17 series can
display two real-time video signals from any Crestron balanced video distribution
product or any balanced video, S-video or composite video source. QM versions can
display two real-time video/RGB signals from two QM transmitters.
For information on programming the TPMC-15 or TPMC-17 touchpanels, refer to
the latest version of the Crestron Isys i/O™ TPMC-15 & TPMC-17 Series
Programming Guide (Doc. 6350) which can be downloaded from the Crestron
website (http://www.crestron.com/manuals).
The purpose of these touchpanels is to provide a complete presentation solution
integrating conventional AV control with embedded PC applications for browsing
the Internet and presenting a full range of multimedia content.
Sound & Video
The TPMC-15 and TPMC-17 feature a built-in, biamplified speaker system and a
headphone jack. Sound can be generated by the touchpanel using downloaded wave
files (.WAV), a PC application, or can be mixed in from an external line level audio
source (CH versions) or a QM input (QM versions only). The audio amplifiers
output 5 Watts to a biamplified 2-way speaker system (mono). Refer to the latest
version of the Crestron Isys i/O™ TPMC-15 & TPMC-17 Series Programming
Guide (Doc. 6350) for WAV file details.
CH versions amplify the built-in microphone to produce a line level differential
output. QM versions transmit the microphone output and PC audio for transmission
through the QM output.
All versions of the TPMC-15 and TPMC-17 can display up to two scaleable video
windows, enabling the simultaneous display of any two full motion video. QM
versions can also send RGB computer images to the video windows. Discrete video
scalers are employed with motion adaptive deinterlacing to bring out the highest
detail by minimizing visible scan lines and motion artifacts. Automatic source
identification assigns the optimum deinterlacing algorithm and applies 3:2 (NTSC)
and 2:2 (PAL) reverse pulldown based upon the input signal.
Operations Guide - DOC. 6344 Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series •3

Touchpanel Media Centers Crestron Isys i/O™TPMC-15/17 Tilt Series
Refer to the following functional diagrams for more information.
TPMC-15/17-CH Functional Diagram
TPMC-15/17-QM Functional Diagram
QuickMedia
While acting as a QM receiver, QM versions of the TPMC-15/17 can be connected
to any combination of QM switching devices and/or QM transmitters to expand the
number of available QM inputs as shown in the following diagrams.
TPMC-15/17-QM Connected with Other QM-Switching Devices
4 •Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series Operations Guide - DOC. 6344

Crestron Isys i/O™TPMC-15/17 Tilt Series Touchpanel Media Centers
For more information on QM networks, refer to “QM Network Wiring (QM
Versions Only)” on page 23.
Applications
The TPMC-15-QM and TPMC-17-QM are part of the Crestron MediaManager line
of integrated presentation solutions. It is ideally suited to work with Crestron’s
MediaManager wall plate media centers, FlipTop media centers, receivers and
control processors to allow quick switching of multiple A/V sources in a presentation
system. MediaManager devices are designed for conference room, auditorium, and
lecture hall applications, or anywhere else where audio, video, or computer
equipment needs to be easily connected and disconnected from a presentation system
or room control system.
The following diagram shows a TPMC-17-QM in a lecture hall application.
TPMC-15/17-QM in Lectern Application
The TPMC-15-CH and TPMC-17-CH are integral to managing a residential
audio/video distribution system. With built-in audio and video connectivity as well
as Ethernet communications, the touchpanel can be used to control complex
audio/video systems.
Operations Guide - DOC. 6344 Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series •5

Touchpanel Media Centers Crestron Isys i/O™TPMC-15/17 Tilt Series
The following diagram shows a TPMC-17-CH in a residential audio/video
distribution application.
TPMC-17-CH in Residential Audio/Video Distribution Application
MediaMarker™
Crestron’s MediaMarker software is used to create, organize and save presentations.
A presenter can devise an entire lecture or demonstration and save it to a PC,
compact flash, or network drive. At the presenter’s discretion, the audience may
view the presentation complete with annotation in real-time (audience view feature is
available on QM versions only).
MediaMarker can be used with the TPMC-15, TPMC-17, or a personal computer.
In addition to containing the tools required for object creation, MediaMarker can
import graphics and text from many other applications. Importable objects include:
HTML, JPG, BMP, PNG, and TIF.
MediaMarker projects can be saved and retrieved to compact flash or a mapped
network drive.
Refer to page 66 for additional MediaMarker information.
Annotation
MediaMarker software’s video annotation utility allows the presenter to
electronically draw on a touchpanel display using a finger. Whether drawing
freehand on a blank screen, highlighting points on a spreadsheet, or making notes
6 •Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series Operations Guide - DOC. 6344

Crestron Isys i/O™TPMC-15/17 Tilt Series Touchpanel Media Centers
over motion video or still images, the annotation utility allows text and line attributes
to be selected on the fly to facilitate crystal clear visual communications.
Annotations and notes (without video freeze) can be saved to a file on the network or
a USB drive for later review.
Embedded PC Applications
With a host of embedded applications, the TPMC-15 and TPMC-17 provide a truly
integrated digital media asset management solution. Applications include:
• MS Internet Explorer
• Windows Media®Player
• MS WordPad
• NetMeeting
• Remote Desktop
• Viewers: Word, PowerPoint®, Excel, and Adobe®Acrobat®
Future PC applications and features may be added, as they become available,
through Crestron updates.
PC Card Memory and USB
The TPMC-15 and TPMC-17 feature built-in PCMCIA slots that allow memory
expansion to 4 GB or installation of a wireless network adapter. Two built-in USB
ports can be used to connect to mass storage devices or other USB peripherals.
Program loading can be accomplished via any mass storage device or through
Compact Flash.
A USB drive (connected to one of the USB ports) or a PCMCIA Flash Card adaptor
card and flash memory card can be used for the Word, Excel, and other files that can
be read by the embedded applications. The flash card can also be used to save the
MediaMarker presentations created with the TPMC-15 or TPMC-17.
NOTE: USB devices requiring custom drivers are not supported.
Connectivity
The TPMC-15 and TPMC-17 feature Cresnet and high-speed Ethernet ports for
seamless communication with Crestron control systems, computers, digital media
servers, and other IP-based devices. Wireless networking and memory expansion are
easily added through the two PCMCIA card slots. Two USB ports enable the
connection of an optional mouse or keyboard as well as USB drives, CD ROM
drives, memory devices or wireless network adapters.
Operations Guide - DOC. 6344 Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series •7

Touchpanel Media Centers Crestron Isys i/O™TPMC-15/17 Tilt Series
Specifications
The following provides a summary of specifications for the TPMC-15-CH/QM and
TPMC-17-CH/QM touchpanels.
Specifications for the TPMC-15-CH/QM and TPMC-17-CH/QM Touchpanels
SPECIFICATION DETAILS
Power Requirements 101 Watts (8.4 Amp @ 12 VDC)
From supplied power supply
Default Network ID 03
Timeout Adjustable from 0 to 120 minutes (Default = 15
min.)
Signal Join Maximums 4000 Digital, Analog, and Serial
Control System Update
Files1,2
2-Series Control System Version 3.137.CUZ or later
Video Inputs QM Version
(2) QuickMedia
channels over RJ-45
from a QM
transmitter. Supports
RGB (up to 1600 x
1200 @ 60 Hz),
YPRPB, S-video, and
composite, NTSC or
PAL. Delay
compensation (up to
22ns) on input
labeled QM1.
CH Version
(2) Balanced, analog,
RJ-45 video inputs
over CAT5 from
CNX-PVID (or
similar) device.
Supports YPRPB,
S-video, and
composite, NTSC or
PAL.
Audio Inputs QM Version
(2) QuickMedia
channels over RJ-45.
Each input carries
one pair of stereo
signals plus
microphone audio.
CH Version
(1) Balanced analog
RJ-45 audio input
over CAT5. Carries
audio from
CNX-BIPAD8 or other
line-level, balanced
audio source.
Video Outputs QM Version
(1) QuickMedia
channel over RJ-45.
Outputs RGB at
touchpanel’s native
resolution and aspect
ratio.
CH Version
N/A
Audio Outputs QM Version
(1) QuickMedia RJ-45
output over CAT5.
Carries Embedded
PC audio and
microphone audio.
CH Version
(1) Balanced
microphone RJ-45
audio output over
CAT5 to
CNX-BIPAD8.
Carries microphone
audio.
(continued on next page)
8 •Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series Operations Guide - DOC. 6344

Crestron Isys i/O™TPMC-15/17 Tilt Series Touchpanel Media Centers
Specifications for the TPMC-15-CH/QM and TPMC-17-CH/QM Touchpanels (continued)
SPECIFICATION DETAILS
General Audio QM Version
• Line level
microphone
output via RJ-45
QM output to QM
receiver
• Internal volume
control with
mono,
biamplified 2-way
speakers
• Built-in WAV file
(8 & 16 bit, 8kHz
to 44kHz
sampling rate,
mono or stereo,
PCM type) & key
click capability3
• Speaker
amplification: 5
Watts (HF) and 5
Watts (LF),
mono,
biamplified
• Stereo
headphone mini-
phone jack on
rear of unit, 105
mW per channel,
8 ohm load
CH Version
• Balanced line
level microphone
with AGC output
via RJ-45 output
to CNX-BIPAD8,
600 Ω
impedance.
• Maximum
Microphone
Output: 2 Vrms
• Balanced
(600 Ω) line level
stereo input
through RJ-45
input
• Maximum input
level, 4 Vrms with
internal volume
control and
mono,
biamplified 2-way
speakers
• Built-in WAV file
(8 & 16 bit, 8kHz
to 44kHz
sampling rate,
mono or stereo,
PCM type) & key
click capability3
• Speaker
amplification: 5
Watts (HF) and 5
Watts (LF),
mono,
biamplified
• Stereo
headphone mini-
phone jack on
rear of unit, 105
mW per channel,
8 ohm load
(continued on next page)
Operations Guide - DOC. 6344 Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series •9

Touchpanel Media Centers Crestron Isys i/O™TPMC-15/17 Tilt Series
Specifications for the TPMC-15-CH/QM and TPMC-17-CH/QM Touchpanels (continued)
SPECIFICATION DETAILS
General Video • Formats: composite, S-video, YPBPR, 480i,
480p, 576i, 576p, 720p, and 1080i
• NTSC and PAL supported
• Built-in time base correction for stable video
• Video signals can be displayed full screen or
in a window
• Supports still and full-motion video
• Brightness, contrast, hue and saturation
adjustments
Touchpanel Firmware TPMC_15_17.v1.04.00.csz or later
Memory
Installed
Maximum Project Size
512MB internal flash memory, expandable via
PCMCIA slot. 512MB of SDRAM
30MB using internal flash memory. Larger projects
can be run from a network drive or external flash
at the expense of slower processing speed.
Touchscreen Display
Display Type:
Size:
Aspect Ratio:
Resolution:
Brightness:
Contrast:
Illumination:
Viewing Angle:
Composition:
TFT Active matrix color LCD
TPMC-15: 15” (38.1 cm), 4:3 aspect ratio
TPMC-17: 17” (43.2 cm), 15:9 aspect ratio
TPMC-15: 4:3 XGA
TPMC-17: 15:9 WXGA
TPMC-15: 1024 x 768 pixels
TPMC-17: 1280 x 768 pixels
TPMC-15: 400 nits
TPMC-17: 450 nits
TPMC-15: 300:1
TPMC-17: 400:1
Back lit fluorescent
TPMC-15: H: ±170o, V: ±170o
TPMC-17: H: ±176 o, V: ±176 o
Resistive membrane
Graphic Engine 24 Bit non-palette graphics + 8 Bit alpha
(transparency) and video, 16.7 million colors,
Synapse image rendering algorithm
Buttons (4) Programmable hard keys + 1 reset button
USB Ports (2) USB Compliant
Expansion ports (2) PCMCIA card slots
Ethernet (1) 10BaseT/100BaseT Ethernet port (RJ-45)
Enclosure Black/silver molded plastic enclosure with integral
rear cover and cable strain relief
RS-232 RJ-11 connector for console
Default settings: 115200, 8 bit, parity none, stop
bit 1, XON/XOFF off, RTS/CTS off
CPU VIA Eden 667 MHz with 133 MHz FSB
Operating System Microsoft®Windows®XP; Embedded4
Cresnet Via rear panel; 24 VDC is not connected
(continued on next page)
10 •Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series Operations Guide - DOC. 6344

Crestron Isys i/O™TPMC-15/17 Tilt Series Touchpanel Media Centers
Specifications for the TPMC-15-CH/QM and TPMC-17-CH/QM Touchpanels (continued)
SPECIFICATION DETAILS
Operating Temperature
and Humidity
50º to 113º F (10º to 45º C),
10 to 90% Relative Humidity (non-condensing)
Dimensions and Weight Height: 14.17 in (35.99 cm)
Width: TPMC-15: 14.94 in (37.95 cm)
TPMC-17: 17.63 in (44.77 cm)
Depth: 13.74 in (34.90 cm)
Weight: TPMC-15: 15.8 lbs (7.1 kg)
TPMC-17: 19.4 lbs (8.8 kg)
1 The latest software versions can be obtained from the Crestron website. Refer to the NOTE
following these footnotes.
2 Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product
Catalog for a complete list of 2-Series control systems.
3 WAV files reside in the touchpanel’s Flash memory and will affect the amount of available space for
touchpanel screens.
4 Updates must be obtained from Crestron.
NOTE: Crestron software and any files on the website are for Authorized Crestron
dealers and Crestron Authorized Independent Programmers (CAIP) only. New users
may be required to register to obtain access to certain areas of the site (including the
FTP site).
Physical Description
The touch sensitive viewing screen is located on the front of the touchpanel. The
TPMC-15’s 15-inch (38.1 cm) screen has a 4:3 aspect ratio while the TPMC-17’s
17-inch (43.2 cm) screen has a 15:9 widescreen aspect ratio. The electronic hardware
is housed in a black molded plastic enclosure with silver accent as shown in the
following diagram. This touchpanel is designed for placement on a tabletop or other
flat surface. It has a hinged base that can tilt from 45 to 90 degrees. For additional
information on the hinged base, refer to “Tilt Angle Tension Adjustment” on page
20. All audio, RS-232, audio/video, network, and power connections are made at the
rear panel on the base of the unit. An integral cover and cable strain relief hide
connections to the touchpanel. A grille located on the front of the unit conceals two
speakers and the microphone is located at the top of the touchscreen.
Five pushbuttons are located on the top of the base. The leftmost button is recessed
and is a hard reset used to reboot the touchpanel. Four of the buttons are
programmable. Refer to “Pushbuttons” on page 19 for more information.
Operations Guide - DOC. 6344 Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series •11

Touchpanel Media Centers Crestron Isys i/O™TPMC-15/17 Tilt Series
TPMC-15, Front View
TPMC-17, Front View
12 •Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series Operations Guide - DOC. 6344

Crestron Isys i/O™TPMC-15/17 Tilt Series Touchpanel Media Centers
Physical Views of the TPMC-15 Touchpanel (Front and Back), Shown with Rear Connector Cover
14.94 in
(37.95 cm)
14.17 in
(35.99 cm)
11.94 in
(30.33 cm)
11.30 in
(28.70 cm)
Physical Views of the TPMC-17 Touchpanel (Front and Back), Shown without Rear Connector Cover
11.30 in
(28.70 cm)
11.94 in
(30.33 cm)
14.17 in
(35.99 cm)
17.63 in
(44.77 cm)
Operations Guide - DOC. 6344 Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series •13

Touchpanel Media Centers Crestron Isys i/O™TPMC-15/17 Tilt Series
Physical Views of the TPMC-15 & TPMC-17 Touchpanel (Side with Min. and Max. Angle)
13.74 in
(34.90 cm)
14.17 in
(35.99 cm) 12.40 in
(31.50 cm)
45°
Ports and Pushbuttons
All connections to the TPMC-15 and TPMC-17 are made through the ports on the
rear panel. Refer to the illustrations and descriptions that follow.
NOTE: An integrated cover and cable strain relief hide connections to the
touchpanel. For more information on the cover and strain relief, refer to “Cable
Management” on page 48.
NOTE: An interface connector for the NET port is provided with the TPMC-15 and
TPMC-17.
RS-232
This 6-pin RJ-11 connector mates with a 9-pin serial port of a PC. The connecting
cable is not supplied. Use this port to establish a direct connection between the
touchpanel and a PC without a control system or network connection. Once the direct
connection is established, touchpanel files and firmware updates can be uploaded to
the touchpanel. Additionally, the touchpanel’s diagnostic tools can be accessed over
the direct connection. In the event that modular cables or an RJ-11 to DB9F adapter
is not available, the following table and diagram provide information so that the cable
can be fabricated on site. Refer to “Touch Screen” on page 30 for RS-232 port
configuration settings.
14 •Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series Operations Guide - DOC. 6344

Crestron Isys i/O™TPMC-15/17 Tilt Series Touchpanel Media Centers
RS-232 Pinouts
PIN # DESCRIPTION
1 CTS
2 GND
3 RXD
4 TXD
5 RTS
6 N/C (Not connected)
16
16
Front
Top
PC to TPMC-15/17 Cable Specifications (Crestron Cable Number STCP-502PC)
ETHERNET
GREEN
LED
YELLOW
LED
PIN
1
PIN
8
One 8-wire RJ-45 connector with two LED indicators (green LED indicates network
speed, yellow LED indicates Ethernet activity). This connector provides an Ethernet
10baseT /100baseTX, full duplex, IEEE 802.3U compliant network connection.
Network Connector Pinout
PIN SIGNALS
1 TX +
2 TX -
3 RC+
4 N/C
5 N/C
6 RC -
7 N/C
8 N/C
USB
Two Universal Serial Bus (USB) “A” connectors provide a communications link to a
variety of third-party USB peripherals. USB is a connectivity specification developed
by the USB Implementers Forum that provides a single, simple, standardized way to
connect up to 127 devices to a computer. USB shielded cables contain two wires for
power +5 volts (red) and ground (brown) and a twisted pair of wires (yellow and
blue) that carry data. The USB standard supports data transfer rates of 12 Mbps
(megabits per second). USB devices can be connected or disconnected without
restarting the computer. USB connectors are used for touchpanels, storage devices
(PQI USB 1.1 Compact Flash Reader and Sandisk ImageMate USB 2.0
Operations Guide - DOC. 6344 Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series •15

Touchpanel Media Centers Crestron Isys i/O™TPMC-15/17 Tilt Series
Reader/Writer have been tested), USB mice (Gyration Ultra GT Cordless Optical
Mouse, Belkin, and Logitech USB mice have been tested) and keyboards. Additional
functionality/compatibility will be available in future firmware releases.
USB Type A Connector Pinout
PIN DESCRIPTION
1 +5 VDC
2 Data -
3 Data +
4 Ground
Pins 1 2 3 4
NOTE: Only standard Windows®XP embedded drivers are included. You cannot
load your own driver.
NOTE: The maximum length for a USB cable run is 16.4 feet (5.0 meters)
PWR
This female connector is used to supply 12 VDC power to the touchpanel from the
included external power pack.
CAUTION: Use only Crestron power supplies for Crestron equipment. Failure to
do so could cause equipment damage or void the Crestron warranty.
PHONE
Connect this standard mini phone jack (105 mW per channel, 8 ohm load) to the plug
of an external headphone set, not supplied.
PC CARD
Two Type II PCMCIA Card slots used for memory expansion up to 4GB or more,
VT Pro-e project uploads, or installation of a wireless network card. A cover is
secured over the slots to protect the electronics. Use a #1 Phillips screwdriver to
remove the cover. The plate can be flipped and secured if only one slot needs to be
accessed.
CAUTION: PCMCIA cards should be installed face down.
NET
The four-position mini-terminal block connector provides communication with a
Cresnet control network using three of the connecting pins. For additional details,
refer to “Network Wiring” on page 21.
NOTE: The TPMC-15 and TPMC-17 do not use, or supply power to the 24 VDC
Cresnet connection.
16 •Touchpanel Media Centers: Crestron Isys i/O™ TPMC-15/17 Tilt Series Operations Guide - DOC. 6344
