Crow SH-CRT-8F User manual

SH-CRT-8F/9F
TWO WAY WIRELESS
CURTAIN PIR MOTION DETECTOR
PRODUCT FEATURES DETECTOR OPENING BRACKET REMOVAL
The SH-CRT is an advanced, fully supervised low-current
wireless curtain motion detector that includes a FW2
transceiver for reliable system operation combined with the
most advanced Mirror Optics detection method.
•GFSK with 5 frequencies & LBT
•Ultra Low current consumption
•Powered by a 3V Type CR123A Lithium battery
•Motion Detection up to 12 meters
•Battery life up to 5 years
•APS Mode feature
•Immunity to attenuation feature
•Operating Frequencies: 868MHz / 916MHz
•Event Transmission:
Alarm
Tamper Open/Close
Supervision
Battery status
•Bi-Color LED indications
•Up to 500m transmission range in open space
•Remotely configurable
Figure 1
Pull up the screw cover
And unscrew the holding screw
Figure 2
Tilt out the detector from its bracket
INSTRUCTION MANUAL
P/N 7102393_C
BATTERY INSERTION DETECTOR MOUNTING DETECTION COVERAGE PAIRING PROCESS
Figure 3
The battery can be replaced by the user
Battery type: 3V Type CR123A Lithium
Direct flat on wall (Figure 4)
Avoid the following locations:
•Facing direct sunlight.
•Facing areas that may change temperature rapidly.
•Areas where there are air ducts or substantial airflows.
Recommended mounting height – 2.1m to 2.3m
This device detects or performs better when provided with
a constant and stable environment.
For pairing process, please refer to your control panel
instructions.
To pair your device with Shepherd™panel, please proceed
as follows:
1. Enter in installing mode via the "Installer Webpage"
2. Go to "Zones" and select the zone # you want to learn
3. Add Zone -(Reminder: insert Link Type “ISM”, device’s
ID, Device Type “Infrared motion detector”.
4. Set the Curtain PIR settings and save configuration.
5. Place Battery as instructed in Figure 3..
6. Verify Green & Red are blinking alternately, then the
LED will turn Green on for 3 sec. to indicate device
learned successfully
7. The device should register to the Control Panel.
8. If Green LED continues flashing more than 5 minutes
and stopped. Please check CRT PIR settings details,
remove battery and repeat step 5,6

DETECTOR TESTING BATTERY REPLACEMENT SPECIFICATION STANDARDS APPROVALS
After pairing and installing the detector, we recommend
performing walk and transmission tests.
Motion Transmission Test
Walk crossing in front of the detector from one side to the other
will cause motion alert transmissions. Verify receiving the
indication on your control panel. Pay attention that due to APS
feature it is required waiting 30 seconds between 2 consecutive
indications.
Walk Test
- Activate walk test mode via Web Installer (in the overview
level), for walk test institutions use Panel manual.
- Make few walk crossing in front of the detector and see results
in Overview display
Tamper Transmission Test
Changing the tamper switch state (by attaching / removing the
device to / from the Bracket) will cause tamper transmissions.
Figure 5
CAUTION
RISK OF EXPLOSION
IF BATTERY IS REPLACED BY DIFFERENT TYPE / MODEL.
DISPOSE USED BATTERY
ACCORDING TO ITS INSTRUCTIONS
Detection Method PYRO Element
Communication
Protocol
Freewave2™ Two Way ISM
GFSK with 5 frequencies & LBT
Operating
Frequencies 868-869MHz / 916-917MHz
Identification Unique ID serial number – 24 bit
Events Transmission Alarm, Tamper, Supervision,
Low Bat, Keep Alive.
Supervision Time 7 min by default
(configurable between 1 to 30 min)
Transmission Range 500m in open space
Battery 3V Type CR123A Lithium
Battery life Up to 5 years
Current
Consumptions
Standby ~11 µA
Receive mode ~24 mA
Transmit mode ~45 mA
Transmit power ~14dBm
Low Bat 2.8V
Cut Off 2.6V
Tamper Switch Front Cover Removal
Operating
temperature -10°C to +55°C
Dimensions 102mm x 30mm x 35mm
Weight (incl. battery) 110 gr.
The SH-CRT conforms to the essential requirements set out by:
•RTTE directive:1999/5/EC
•EMC directive: 2004/108/EC
•Low Voltage directive: 2006/95/EC
Harmonized Standards applicable to this products are:
•EN 50130-4
•EN 61000-6-3
•EN 301 489-1
•EN 301 489-3
•EN 300 220-1
•EN 300 220-2
•EN 60950-1
Additional Standards and Directives applicable to this product are:
•EN 50131-1
•EN 50131-2-2
•EN 50131-6
•EN 50131-5-3
•EN 50130-5
Security Grade2, Environmental Class II
Power supply Type C
Certification body: Telefication B.V.
EVENT TRANSMISSION
SUPERVISION – A periodical transmission (configurable)
indicating detector’s presence.
ALARM – Alarm transmission triggered by the device indicating
Motion detection. The Red LED will blink once.
LOW BAT – Whenever the battery reaches the low level
(2.8V), a Battery Low signal will be sent. When Battery level
drops below Cut Off level (2.6V) the device will stop functioning
and the Red LED will blink for 10 seconds and then turned Off.
TAMPER – Whenever the cover is removed from Bracket or
the device is tear off from the wall, a message will be
transmitted with “Tamper ON” signal. When cover will be
returned a “Tamper OFF” signal will be transmitted.
