cytiva AxiChrom User manual

AxiChrom wheel kits
Instructions
Original instructions
cytiva.com

Table of Contents
1Introduction ........................................................................................... 3
2 General precautions when moving columns ...................................... 4
3 AxiChrom 300-600 wheel kit ............................................................... 6
3.1 AxiChrom 300-600 wheel kit components ..................................................................... 7
3.2 Fitting an AxiChrom 300-600 wheel kit ............................................................................ 10
3.3 Removing an AxiChrom 300-600 wheel kit ..................................................................... 13
4 AxiChrom 800-1000 wheel kit ............................................................. 15
4.1 AxiChrom 800-1000 wheel kit components ................................................................... 16
4.2 Fitting an AxiChrom 800-1000 wheel kit ......................................................................... 18
4.3 Removing an AxiChrom 800-1000 wheel kit .................................................................. 22
5 AxiChrom 1200-1600 wheel kit .......................................................... 25
5.1 AxiChrom 1200-1600 wheel kit components ................................................................ 26
5.2 Fitting an AxiChrom 1200-1600 wheel kit ....................................................................... 29
5.3 Removing an AxiChrom 1200-1600 wheel kit ................................................................ 36
2 AxiChrom wheel kit Instructions 29145462 AB

1 Introduction
Purpose of this document
This document describes information that is supplementary to the instructions
provided in AxiChrom 300-1600 columns Operating Instructions (29065430) and in
AxiChrom 300-1600 columns User Manual (29099939).
This document only describes how to install and use a wheel kit on an AxiChrom™
column. For more information about AxiChrom columns please refer to the user
documentation provided with your column.
WARNING
Before installing, operating or maintaining AxiChrom
columns, all users must read and understand the entire
contents of AxiChrom 300-1600 columns Operating
Instructions (29065430) to become aware of the hazards
involved.
Scope
This document describes how to fit wheel kits to various sizes of AxiChrom columns so
that the columns can be moved, either using the trolley handle provided with the wheel
kit or by using moving equipment such as a MasterMover™ or PowerAttack™ connected
to an attachment coupling fitted to the wheel kit.
For information about moving equipment alternatives that can be used with an
AxiChrom wheel kit, but which must be ordered separately from the respective
supplier, refer to the AxiChrom product pages on the Cytiva website.
AxiChrom wheel kit Instructions 29145462 AB 3

2 General precautions when moving columns
This section provides general safety information that must be observed when moving
AxiChrom 300-1600 columns.
WARNING
Columns in swing-out or any kind of maintenance mode must not
be moved. This may cause personal injury or damage to the
column.
WARNING
Make sure that the wheels are immobilized when fitting a wheel kit,
so that the column cannot begin to roll away.
WARNING
Make sure never to place any body part between the column stand
and a wheel kit. Always use the handle to hold a trolley when fitting
it under the column stand.
WARNING
Maintain a safe distance when moving the column. Make sure
that no person is near the column when the column is in motion,
other than the personnel required to perform lifting and moving
procedures.
CAUTION
To avoid accidental collisions, use caution when moving columns
equipped with wheels by hand. Two or more people may be
required to move the column safely.
4 AxiChrom wheel kit Instructions 29145462 AB

NOTICE
To avoid damage to the wheels and possible tipping when the
column is moved, make sure that the wheels of the wheel kit do not
run into or over objects (for example doorway thresholds or
tubing).
NOTICE
The wheels must be removed and the column must be leveled
properly before the column is used.
NOTICE
While transporting a 300-600 column, do not pull the handle
upward, as the trolley knob may fall out of its position. Lifting the
handle will not work as a brake.
AxiChrom wheel kit Instructions 29145462 AB 5

3 AxiChrom 300-600 wheel kit
Introduction
This section describes how to fit a wheel kit for use with AxiChrom 300-600 columns.
In this chapter
Section See page
3.1 AxiChrom 300-600 wheel kit components 7
3.2 Fitting an AxiChrom 300-600 wheel kit 10
3.3 Removing an AxiChrom 300-600 wheel kit 13
6 AxiChrom wheel kit Instructions 29145462 AB

3.1 AxiChrom 300-600 wheel kit components
The following image illustrates the main components of the AxiChrom 300-600 column
wheel kit.
Wheel kit components
1 2
4
3
Part Function
1 Lever
2 Trolley
3 Trolley bar
4 Rear wheels
AxiChrom wheel kit Instructions 29145462 AB 7

Wheel and trolley fittings
FA
90-110 mm
Part Function
A Holes for fitting rear wheels
F Pins for locating trolley bar
Note: To be able to fit or remove the wheels of an AxiChrom 300-600 column
wheel kit, the distance between the floor and the column stand must be in
the range 90-110 mm.
Trolley and trolley bar
B
D C E
S
Part Function
B Bolts
C Height adjusting screw
8 AxiChrom wheel kit Instructions 29145462 AB

Part Function
D Trolley knob
E Slots
S Safety pin
AxiChrom wheel kit Instructions 29145462 AB 9

3.2 Fitting an AxiChrom 300-600 wheel kit
To be able to use the jack to assemble/disassemble the trolleys and fit or remove an
AxiChrom 300-600 column wheel kit the following requirements must be met.
•The distance between the floor and the column stand must be between 90-110 mm
for AxiChrom 300-600 columns.
•There must be adequate free surrounding space to be able to move the column (for
dimension information refer to AxiChrom 300-1600 columns Operating Instructions
(29065430)).
NOTICE
Do not perform any type of maintenance work on a column when it
is fitted with a wheel kit. Maintenance work may only be carried out
on AxiChrom columns when they are stably supported by the
column feet under the column stand.
Tip: If you intend to move the column back to the same position after it has been
moved, mark the position of the column feet on the floor before beginning to
fit the wheel kit. This will allow the column to be returned to exactly the
position after moving, without the need to level the column again.
10 AxiChrom wheel kit Instructions 29145462 AB

Step Action
1Place the lever close to one of the rear feet and lift the column by lowering
the lever arm. Screw the foot pads in completely.
If needed for work in restricted spaces, the lever can be mirrored by changing
the attachment of the lever arm.
2Fit the rear wheels in the hole in the column stand (A, Wheel and trolley
fittings, on page 8). Ensure that the washer and safety pin are correctly
placed, to secure the rear wheels.
3Lower the column by lifting the lever arm. Ensure that the column stands
firmly on the wheels before removing the lever.
4Fit the second pair of rear wheels on the other rear foot by repeating steps 1
to 3 above.
AxiChrom wheel kit Instructions 29145462 AB 11

Step Action
5Attach the trolley bar to the front of the column stand. Make sure that the
pins underneath the stand (F, Wheel and trolley fittings, on page 8 are
properly fitted into the slots E of the trolley bar (Trolley and trolley bar, on
page 8), before tightening the bolts B to the column stand.
6Place the trolley knob D (Trolley and trolley bar, on page 8) vertically under
the adjusting screw C, and adjust the height adjusting screw so it rests on the
trolley knob.
7When the height adjusting screw is adjusted, secure it with the safety pin S.
8Lift the front of the column by lowering the handle on the trolley. Turn the
trolley so it faces forward.
9Make sure that the column rests fully on the wheels. Screw the foot pads in
completely.
The column can now be moved.
12 AxiChrom wheel kit Instructions 29145462 AB

3.3 Removing an AxiChrom 300-600 wheel kit
When the column has been rolled into position at the intended location, remove the
wheel kit from the column as described below.
Step Action
1Adjust all feet until they have the same distance between the floor and stand,
90 to 110 mm.
2Turn the trolley to one of the sides as the following image shows.
Lower the front of the column, by raising the handle on the trolley. The handle
should now stand vertically.
3If necessary, remove the safety pin and loosen the height adjusting screw to
be able to relieve the weight from the trolley knob D. Remove the trolley.
B
D C E
S
4Unscrew the bolts B and remove the trolley bar from the front of the column
stand.
AxiChrom wheel kit Instructions 29145462 AB 13

Step Action
5Place the lever close to one of the rear feet and wheels, and lift the column by
lowering the lever arm. If needed in narrow spaces, the lever can be mirrored
by changing the attachment of the lever arm.
6Remove the washer and safety pin from the wheels, and disassemble the
wheels from the hole A in the column stand.
FA
90-110 mm
7Lower the column by lifting the lever arm. Remove the lever.
8Repeat steps 4 to 6 on the other rear foot.
9Make sure that the column stands firmly on all feet.
10 Make sure that the column is level before it is taken into operation.
14 AxiChrom wheel kit Instructions 29145462 AB

4 AxiChrom 800-1000 wheel kit
Introduction
This section describes how to fit a wheel kit for use with AxiChrom 800-1000 columns.
In this chapter
Section See page
4.1 AxiChrom 800-1000 wheel kit components 16
4.2 Fitting an AxiChrom 800-1000 wheel kit 18
4.3 Removing an AxiChrom 800-1000 wheel kit 22
AxiChrom wheel kit Instructions 29145462 AB 15

4.1 AxiChrom 800-1000 wheel kit components
The following images illustrate the main components of the AxiChrom 800-1000
column wheel kit.
Wheel kit components
D
C
E
B
K
J
Part Function
B Trolley bar top
C Lower part
D Slot
16 AxiChrom wheel kit Instructions 29145462 AB

Part Function
E Screw
J Jack
K Rear wheels
Wheel and trolley fittings
A
95-135 mm
Part Function
A Holes for fitting rear wheels
Note: To be able to fit or remove the wheels of an AxiChrom 800-1000 column
wheel kit, the distance between the floor and the column stand must be in
the range 95-135 mm.
AxiChrom wheel kit Instructions 29145462 AB 17

4.2 Fitting an AxiChrom 800-1000 wheel kit
To be able to use the jack to assemble/disassemble the trolleys and fit or remove an
AxiChrom 800-1000 column wheel kit the following requirements must be met.
•The distance between the floor and the column stand must be between 95-135 mm
for AxiChrom 800-1000 columns.
•There must be adequate free surrounding space to be able to move the column (for
dimension information refer to AxiChrom 300-1600 columns Operating Instructions
(29065430)).
NOTICE
Do not perform any type of maintenance work on a column when it
is fitted with a wheel kit. Maintenance work may only be carried out
on AxiChrom columns when they are stably supported by the
column feet under the column stand.
Tip: If you intend to move the column back to the same position after it has been
moved, mark the position of the column feet on the floor before beginning to
fit the wheel kit. This will allow the column to be returned to exactly the
position after moving, without the need to level the column again.
Note: The distance between the floor and the column stand is 122 mm when the
wheels are assembled.
A
95-135 mm
Figure 4.1:
Step Action
1Mount the wheels (2) on the underside of the wheel kit beam. Mount the
trolley handle.
18 AxiChrom wheel kit Instructions 29145462 AB

Step Action
2Use the handle on the trolley bar to steer it in between the front feet of the
column. The top B of the trolley bar should hang on the column stand when
positioned.
D
C
E
B
Part Function
B Trolley bar top
C Lower part
D Slot
E Screw
AxiChrom wheel kit Instructions 29145462 AB 19

Step Action
3Remove the rear wheels from the wheel kit frame.
Place the jack under the frame at position I, and use the jack to lever the front
of the column so that the wheel kit can be assembled and tightened using a
16 mm wrench underneath the trolley bar G.
I
4Place the bracket between the column stand and the trolley bar, as
illustrated in insert image H.
F
G
H
Steer the wheel kit with the trolley handle and lift up until part C reaches the
lower surface of the column stand. Make sure that the pin underneath the
stand fits inside the slot D of the trolley bar, then tighten the screw E in the
image in step 1. Make sure that both screws E are in the correct position.
20 AxiChrom wheel kit Instructions 29145462 AB
