DAELIM DELFINO User manual

OM67-0805-01E
HEAD OFFICE(FACTORY)
#58, SUNG SAN-DONG, CHANG WON, KYUNGNAM, KOREA
TEL: [phone] / FAX: [phone]
OWNER S MANUAL

2008. 05 PRINTED NO
COPY
WELCOME
Thank you for purchasing an Daelim vehicle. We hope you enjoy safe riding.
OPERATOR AND PASSENGER
This motorcycle is designed to carry the operator and one passenger.
Attempting to change the pre-set maximum speed may cause danger and will void the Daelim warranty.
ON-ROAD USE
This motorcycle is designed to be used only on the road.
READ THIS OWNER'S MANUAL CAREFULLY
Pay special attention to statements preceded by the following words:
Indicates a strong possibility of severe personal injury or death if instructions are not followed.
Indicates a possibility of personal injury or equipment damage if instructions are not followed.
Gives helpful information.
This manual is an important and integral part of your vehicle. keep it with your vehicle at all times, even though your vehicle is resold.
IMPORTANT NOTICE
WARNING
WARNING
CAUTION
NOTE
OWNER S MANUAL

SPECIFICATION
OPERATION INSTRUCTION
SAFETY PRECAUTIONS
PRIOR TO STARTING VEHICLE
OPERATION
CORRECT ATTIRE
CARGO
ATTACHMENT
MODIFICATION
MUFFLER
PARTS LOCATION
METER READING AND USAGE
METER
INDICATOR LAMPS
SWITCH OPERATION
MAIN SWITCH
START BUTTON
HEADLIGHT
WINKER SWITCH
HORN BUTTON
PASSING SWITCH
EQUIPMENT USAGE
STEERING STEM LOCK
SEAT LOCK
TRUNK
DOCUMENT STORAGE AREA
BAG HOLDER
CORRECT DRIVING OPERATION
STARTING THE ENGINE
IF ENGINE CANNOT BE STARTED
AFTER STARTING ENGINE
PROPER DRIVING METHODS
STOPPING
SELF INSPECTIONS BEFORE OPERATION
INSPECTION OF CONCERNED AREA
BRAKE INSPECTION
FUEL CHECK
TIRE INSPECTION
ENGINE OIL LEVEL CHECK
LIGHTS AND WINKER INSPECTION
BULB REPLACEMENT METHOD
REAR VIEW MIRROR
FUEL LEAK INSPECTION
1
CONTENTS
3
4
4
5
5
6
7
7
7
7
8
10
10
10
11
11
12
12
13
13
13
14
14
14
15
15
15
16
16
18
19
20
21
23
24
24
25
26
27
28
28
30
30

MAINTENANCE
MAINTENANCE SCHEDULE
MAINTENANCE PRECAUTIONS
BRAKES
THE ADJUSTMENT OF FREE PLAY OF REAR BRAKE LEVER
CHECKING THE REAR BRAKE SHOE
BRAKE HOSE, PIPE LEAKAGE, DAMAGE, ASSEMBLY STATE
BRAKE PAD WEAR
CHANGING ENGINE OIL
TRANSMISSION OIL INSPECTION
SPARK PLUG
BATTERY INSPECTION
FUSE REPLACEMENT
AIR CLEANER ELEMENT INSPECTION
SIDE STAND INSPECTION
CABLE RUBBER PART
CLEANING
GENERAL CLEANING
FRAME AND ENGINE NUMBER
SAFE DRIVING
DRIVING METHOD
DRIVING POSITION
TAKING POSE OF FELLOW PASSENGER
PRECAUTION WHEN DRIVING
STARTING
TURNING METHOD
PRINCIPLE OF TURN
EFFECT OF SPEED
3 POSITIONS OF TURNING
TURNING METHOD
PRECAUTION WHEN TURNING
BRAKING METHOD
BASIC PRINCIPLE OF BRAKE(FRICTION FORCE)
RESTRAINT OF BRAKING EFFECT (INERTIA)
BRAKING METHOD
COMPARISION OF BRAKING DISTANCE
IMPACT WHEN COLLISION
WIRING DIAGRAM
2
31
32
34
34
34
34
36
36
36
38
39
40
41
42
43
43
44
44
44
45
46
46
47
48
49
50
50
50
51
52
53
54
54
54
55
55
55
56

3
SPECIFICATION
LENGTH×WIDTH×HEIGHT(mm)
WHEEL BASE(mm)
SEAT HEIGHT(mm)
DRY WEIGHT(kgf)
PASSENGER
ENGINE TYPE
PISTON DISPLACEMENT(cc)
BORE AND STROKE(mm)
STARTING SYSTEM
1,830×655×1,127
1,290
777
109
2
AIR COOLED
4 STROKE SOHC 2VALVE
124.6
52.4×57
START MOTOR / KICK
IGNITION SYSTEM
BATTERY CAPACITY
C.D.I
12V8AH(MF TYPE)
110 / 70 - 12, 47J
120 / 70 - 12, 56J
TELESCOPIC
UNIT SWING OIL DAMPER
DISK BRAKE
DRUM BRAKE
P-RZ9HC
15
ITEM DATA ITEM DATA
FR.
RR.
FR.
RR.
FR.
RR.
SPARK PLUG
FUSE(A)
TIRE SIZE
SUSPENSION
BRAKE
FUEL CAPACITY(ℓ)
RESERVE FUEL CAPACITY(ℓ)
7.2
1.5
TRANSMISSION TYPE CVT

This manual describes matters pertaining to correct operation,
safe operation and simple maintenance of the vehicle you
purchased.
To ensure more comfortable and safer operation, make sure to
read this manual carefully prior to operation.
●The photographs and drawings shown in this manual may
differ from those of actual vehicles due to changes in vehicle
specifications and modifications made.
●This vehicle is designed for 2 riders including the operator.
●Careful driving and the wearing of proper attire and safety
equipment are the most important factors in the safe operation
of the scooter. Please obey traffic regulations and do not be
hurried and careless.
●Many new vehicle owners operate their newly purchased
vehicles with great care and attention to safety factors.
However, after becoming accustomed to the operations are
often discarded, which can lead to accidents. Please don't let
this happen to you and always approach the operation of your
vehicle with the safety considerations needed.
When operating the vehicle, always keep in mind and obey the
notes of precaution printed on the“Safety Precaution Label”
attached to the vehicle.
4
OPERATION INSTRUCTION SAFETY PRECAUTIONS
CAUTION
●Do not use polluted gasoline.
Using polluted gasoline will cause rust inside the fuel
tank, and will close the supply of fuel to the
carburetor, leading to an improper engine starting or
may cause serious damage to an engine.
●Do not use polluted or low-grade oil.
Always use genuine oil to protect and extend vehicle
performance and its life span.
●If any failure occurs due to the use of polluted gasoline
or oil, such failure will be excluded from being eligible
for repairs under the warranty.
●As far as any defect caused by contaminated gasoline or
oil, the warranty will be automatically invalidated.
●Be sure to wear helmet at all time.
●Be sure to put on gloves at all time.
●Observe the speed regulations.
●Beware of muffler affer driving as it is still hot to be
burnt.
Especially never children touch on it.
●For safety, do not change, alteration or modification the
vehicle.
●Regularly conduct specified maintenance inspections.
<Maintenance Inspection Points>
Brakes, Tires, Oil, Lights, Horn, Instruments

●Read user's manual carefully.
●Conduct maintenance checks prior to operation.
●Always maintain vehicle in clean status and carry out specified
maintenance checks.
●Make sure to stop engine and stay away from fire when
fueling.
●Exhaust gas contains harmful substance such as carbon
monoxide. Start engine in well-ventilated places.
●Operators should naturally fix bodies to keep smooth driving.
●Please check whether or not you are unnaturally strained and
strung up.
●Driving pose has a great influence on safe operation.
Please always maintain the center of your body in the middle of
seat. Especially do not sit at the rear seat because it may lessen
the weight of front wheel and cause trembling steering wheel.
●A passenger should hold on to the vehicle or the operator with
both hands and keep both feet on the pillion step bar.
●When wanting to turn, slightly lean to body toward the
direction of the turn. It is unsafe if the body is not moved in
union with the vehicle.
●Curvy roads and poor, unpaved roads constantly change in
surface quality. Driving on these roads can be unsafe if certain
safety precautions are not followed.
●In order to safely drive through these driving conditions,
anticipate coming road conditions, slow down to at least half
the normal speed, and relax your shoulders and wrists while
securely holding the handles.
5
PRIOR TO STARTING VEHICLE OPERATION

●Always make sure to wear helmet for safety. Wear gloves and
safety goggles.
●Do not wear uniforms which might hinder operation. It is
dangerous if the uniform is caught by brake lever or by the
rotating part of drive chain.
●Many automobile/motorcycle accidents happen because the
automobile driver does not “see” the motorcyclist.
Make yourself conspicuous to help avoid the accident that
wasn’t your fault :
- Wear bright or reflective clothing.
- Don’t ride in another motorist’s “blind spot”.
6
CORRECT ATTIRE
A helmet should always be
worn and the helmet chin
strap should be securely
fastened.
Always put on gloves.
Correct shirts or jackets with
tight-fitting sleeves should be
worn,
Shoes should fit properly, and shoes having little or
no heel should be worn.
WARNING
●Be sure you and your passenger always wear a helmet,
eye pretection and other protective apparel when you
ride.
●Not wearing a helmet increases the chance of serious
injury or death in a crash.

●When carrying cargo, you must keep in mind that operating the
motorcycle, especially when turning, will be different.
●Make sure not to overload the motorcycle with goods as this
can make the motorcycle unstable during operation.
●Except designated attachment by DAELIM MOTOR CO.,
LTD., don't attach any extra lighting device, because it may
cause an early discharging of battery.
●Modification of vehicle structure of function deteriorates
manipulatability or causes exhaust noise to become louder
shortening the vehicle life. These modifications are not only
prohibited by law but also are the acts harmful to other people.
Modifications are not covered by warranty.
●Pay particular attention to fellow passenger so that he/she can
prevent getting burnt by the hot muffler during travel.
7
CARGO
TRUNK MAXIMUM LOAD : 10kg
ATTACHMENT
MUFFLER
MODIFICATION
WARNING
●Overloading or improper loading can cause a crash and
you can be seriously hunt.
●Follow all load limits in this manual.
CAUTION
●Beware of muffler after driving as it is still hot to be
burnt. Especially never children touch on it. And pay
attention to park where pedestrian zoon.
●If haystack or vinyl is stuck to the muffler, it might be
fired.

8
FR. BRAKE DISK
PARTS LOCATION
PILLION STEP BAR BATTER COVER
MUFFLER
MAIN SEAT
SPEEDOMETER FR. BRAKE LEVER
FR. TIRE
RR. TIRE
FR. WINKER
RR. WINKER

9
PARTS LOCATION
HEADLIGHT
FR. FENDER
FR. CUSHION
RR. CUSHION
SIDE STAND MAIN STAND KICK START
BRAKE CALIPER
RR. BRAKE LEVER
MAIN SEAT
FUEL TANK LID
REAR COMBI.
LIGHT
RR. WINKER
AIR CLEANER

<SPEEDOMETER>
Indicates driving speed. Maintain legal
speed limits to ensure safe operation.
<ODOMETER>
Indicates total distance in kilometers
travelled by the vehicle.
<FUEL METER>
The fuel meter indicates the gasoline level
inside the fuel tank.
Gasoline should be put in the fuel tank as
soon as possible if the needle is resting in
the red area.
FUEL TANK MAXIMUM CAPACITY : 7.2ℓℓ
RESERVIOR CAPACITY : 1.5ℓℓ
<WINKER INDICATOR>
When the winker switch is operated,
the winker indicator flashes in union
with the flashing of the turn signals.
.
10
METER READING AND USAGE
METER
INDICATOR LAMPS
SPEEDOMETER FUEL METER
HEADLIGHT
HIGHBEAM
INDICATOR
WINKER
INDICATOR
WINKER
INDICATOR
WARNING
●To avoid running out of fuel,it might
cause severe injury due to engine
abruptly stop.
0
10
20
30
40 50
70
80
Mph
20
40
60 80
100
120
606060

1. ON.... Starts engine. Key can not be
pulled out.
2. OFF....Stops engine. Key can be
placed in or taken out of the
main switch.
3. LOCK....Locks handle bars. Key can be
placed in or taken out of the
main switch.
4. OPEN....When seat lock is released,
key returns to its original
position(OFF). Key can be
placed in or taken out of the
main switch.
11
CAUTION
●When you park the vehicle and
leave it, please lock handle bars and
take out the key.
●Rotate key smoothly without
pressing to turn to OPEN.
●The headlight will be on auto-
matically. when the key is on, so do
not remove this electric circuit
otherwise, it may cause severe injure
when driving in the night.
MAIN SWITCH
SWITCH OPERATION
KEY
ON
OFF
LOCK
MAIN SWITCH

The engine is started pressing this button
when pressed in a state where the main
switch key is placed to an ON position
and the brake lever is pulled.
<TURNING ON HEADLIGHT>
Put main switch key in “ON” position and
turn on headlight switch.
<DIMMER SWITCH>
High beam or low beam can be operated
by the use of dimmer switch.
HIGH BEAM
...... used when needing extra
light.
LOW BEAM
...... used when other vehicles
are present, in the city, etc.
12
HEADLIGHT
CAUTION
●The engine will not start if the brake
lever is not pulled.
●Do not hold the brake lever and
the throttle grip when the engine was
started. It may damage the engine.
CAUTION
●Use the high beam only in the
suburban road or when the usage of
the high beam not hinder the safe
driving of the car ahead.
START BUTTON
START BUTTON
SWITCH POSITION FUNCTION
Headlight, taillight,
position lamp and
meter lights on.
Position lamp, taillight,
and meter lights on.
Light turned off.
(OFF)
(P)
(H)
(LO)
D
(HI)
D
HEADLIGHT SWITCH
DIMMER SWITCH

If this switch is turned on when the main
switch is in an ON position, the winker will
operate.
⇨(R)....used when making a right turn.
⇦(L)....used when making a left turn.
The horn is sounded if the horn button is
pressed when the main switch is in an ON
position.
13
CAUTION
●The winker switch does not auto-
matically turn back to its original
position after completing the turn.
●Please set the switch back to its
center position after turning.
WINKER SWITCH HORN BUTTON
WINKER SWITCH HONE BUTTON

<LOCKING>
To lock the steering, turn the handlebars
all the way to the left, turn the key to
LOCK while pushing in. Remove the key.
<UNLOCKING>
To unlock the steering, turn the key to the
OFF position.
<LOCKING>
The seat automatically locks when the seat
is pushed in its downward position,
Lightly pull upward on the seat to make
sure the seat has been properly locked.
<UNLOCKING>
Turn the main switch key from OFF to
OPEN to open the seat.
14
STEERING STEM LOCK SEAT LOCK
EQUIPMENT USAGE
STEERING
STEM LOCK
KEY
WARNING
●Do not turn the key to LOCK while
riding the vehicle; loss of vehicle
control will result.
CAUTION
●
As the seat automatically locks, take
special care not to accidently leave the
key in the trunk.
●
Make sure that the seat is securely
locked after closing the seat.
Driving with unlocked seat lock may
cause danger.
●
When the seat lock is out of order, do
not operate it further and inspect it in
the closest authorized repair center.
STEERING
STEM LOCK
KEY

15
●There is a trunk under the seat.
●The seat is opened to gain access to the
trunk by using the main switch key on
the seat lock.
●The lamp inside the trunk will be turned
on if the seat is opened.
TRUNK MAXIMUM LOAD:10kg
●There is a document storage area on the
bottom of the seat.
●Store the owner’s manual and the
maintenance notebook in this area. ●For ease in carrying bags and similar
items, they should be hung from the
bag holder which is fitted for this
purpose.
●When using the bag holder, place it in
the open position and return it to the
normal position when not in use.
TRUNK DOCUMENT STORAGE AREA BAG HOLDER
CAUTION
●As water can enter the trunk when
washing, make sure to remove
articles that can be damaged by
water.
●Do not load uncloseable size of
helmet and thing in the tunk,
otherwise, the battery can be
discharged with the trunk lamp on.
CAUTION
●Do not attempt to carry very heavy or
bulky loads since this would affect the
stability and steering characteristics of
the scooter.
CAUTION
●The temperature inside the trunk
rises due to heat from the engine. Do
not place foodstuffs and other articles
that can be damaged easily by heat.
Also do not place flamm-able
materials in the trunk.
●Do not place valuable or fragile
goods in trunk.
BAG HOLDER
DOCUMENT STORAGE AREA
TRUNK

16
●Make sure to check the oil, gasoline,
etc., before starting the engine.
●Please ensure that the main stand is in a
down position when starting the engine.
●Drive with care for both safety reasons
and longer vehicle life.
●For 1 month (or 1,000km) after pur-
chasing the vehicle, drive moderatly
avoiding fast starts and fast acceleration
Always follow the proper starting
procedure described below.
●This motorcycle is equipped with a side
stand ignition cut-off system.
●The engine cannot be started if the side
stand is down.
●Always be ensure that you operate the
engine starting controls with the scooter
on its stand.
CORRECT DRIVING OPERATION
STARTING THE ENGINE
CAUTION
●Make sure that the rear wheel is
locked when starting the engine to
prevent an unexpected quick start of
the vehicle.
●Locking is not possible if the rear
wheel brake is not adjusted correctly.
WARNING
●Never run the engine in an enclosed
area. The exhaust contains
poisonous carbon monoxide gas that
can cause loss of consciousness and
lead to death.
●While the scooter is on its stand you
should NEVER apply full throttle:if
the rear wheel touches the ground
the scooter would set off at full
speed. (Remember that the scooter
has a centrifugal automatic speed
control)

17
Lock the rear wheel.
Turn the main switch to an ON
position.
Start engine with cell button.
<USING THE ELECTRIC START(CELL)>
●Press the starter button without rotating
the starter grip (opening the throttle).
●If the engine is hot and does not start
after pressing the starter button for 3~4
seconds, rotate the throttle grip to
1/8~1/4 of a rotation and try again. This
will allow easy starting
CAUTION
●Immediately release the starter button
as soon as the vehicle has started.
●Do not press the starter button when
the engine is running.
This can damage the starting motor.
1/41/8

●It is possible that starting will be more
difficult if the vehicle has not been used
for a long period of time or if the fuel
hole is plugged up(starting problems
even when there is sufficient fuel in the
fuel tank may be an indication of a
plugged fuel hole).
When this happens, do not rotate the
throttle grip and try the starter button a
few times.
When the engine is cold morning or
winter or the vehicle has not been used
for a long period of time, let the
engine idle for a short period allow the
engine to warm up.
If engine cannot be started or vehicle does
not move, check the followings.
●Is there fuel in fuel tank?
●Are you operating in accordance with
the instructions given in owner’s
manual?
●Is fuse not cut?
●Is starter motor running?
●If starter motor is not running due to
battery consumption, try starting motor
by using kick start technique.
18
IF ENGINE CANNOT BE STARTED
CAUTION
●Keep holding rear brake until start.
●Exhaust has contains harmful subs-
tance such as carbon monoxide.
Start engine in well-ventilated places.
CAUTION
●Do not keep the statter button pressed
for more than 5 seconds at a time.
Release the starter button for
approximately 10 seconds before
pressing it again.
