Myzone 3 Installation and
Configuration Manual
Reece Pty Ltd reserves the right to change or modify the design, specications, software, hardware,
rmware or Apps at anytime without prior written or oral notice. Images and functions in this manual
should be considered as indicative only and may differ from the actual Myzone touch screen or Apps

2
Table of Contents
General Installation Rules 6
General Installation Instructions 7
Unit Compatibility Form 8
System Design Considerations 9
Designing the Correct Constant Zone 9
Fixed Duct Constant and Standard Electronic Constant 11
Dedicated Electronic Constant and Bypass Electronic Constant 12
Myzone Wiring Layout 13
ON/OFF Zone Control Only (Max 8 Zones, Wi-Fi Optional) 13
Modulating Zone Control Only with Individual Wireless Zone Temperature Control (Max 8 Zones, Wi-Fi Optional) 14
A/C Unit Control and ON/OFF Zone Control (Max 8 Zones, Wi-Fi Optional) 15
A/C Unit Control and Modulating Zone Control with Individual Wireless Zone Temperature Control (Max 8 Zones, Wi-Fi Optional) 16
ON/OFF Zone Control Only (Max 14 Zones, Wi-Fi Optional) 17
Modulating Zone Control Only with Individual Wireless Zone Temperature Control (Max 14 Zones, Wi-Fi Optional) 18
A/C Unit Control and ON/OFF Zone Control (Max 14 Zones, Wi-Fi Optional) 19
A/C Unit Control and Modulating Zone Control with Individual Wireless Zone Temperature Control (Max 14 Zones, Wi-Fi Optional) 20
Stand Alone VAV Modulating Zone Control Only System (No Tablet) 21
A/C Unit Control & Modulating Zone Control with Wired Zone Temperature Controllers (Wi-Fi Optional) 22
A/C Unit Control and Modulating Zone Control with Wired iSense Zone Temperature Controllers (Wi-Fi Optional) 23
A/C Unit Control and Modulating Zone Control with Wired Touch Screen Zone Temperature Controllers (Wi-Fi Optional) 24
Multiple A/C Unit Control and ON/OFF Zone Control (Max 8 Zones, Wi-Fi Optional) 25
Optional Equipment for Hard Wired Wi-Fi Control of System 26
Myzone Wiring Connections to A/C Units 27
Myzone Wiring Connections to Actron Units 28
Myzone Wiring Connections to Braemar and Gree Units 29
Myzone Wiring Connections to Fujitsu Units 33
Myzone Wiring Connections to Daikin Units 34

3
Table of Contents
Myzone Wiring Connections to Mitsubishi Electric Units 35
Myzone Wiring Connections to MHI Units 36
Myzone Wiring Connections to Toshiba Units 37
Myzone Wiring Connections to Panasonic Units 38
Myzone Wiring Connections to Haier Units 39
Myzone Wiring Connections to Hitachi Units 40
Myzone Wiring Connections to Kaden Units 41
Myzone Wiring Connections to LG Units 42
Myzone Wiring Connections to Midea Units 43
Myzone Wiring Connections to Rinnai Units 44
Myzone Wiring Connections to Samsung Units 45
Myzone Wiring Connections to Temperzone Units 46
Myzone Wiring Connections to York Units 47
Myzone Wiring Connections to Universal Control Module 48
Gas Heating Thermostat Only 49
1 Stage Gas Heating + 1 x Fan Speed 50
1 Stage Gas Heating + 1 Stage Cooling + 1 x Fan Speed 51
2 Stage Gas Heating + 1 Stage Cooling + 1 x Fan Speed 52
2 Stage Gas Heating + 2 Stage Cooling + 1 x Fan Speed 53
1 Stage Reverse Cycle Heat Pump + 1 x Fan Speed 54
1 Stage Reverse Cycle Heat Pump + 3 x Fan Speed 55
1 Stage Reverse Cycle Heat Pump + Aux Heating + 1 x Fan Speed 56
2 Stage Reverse Cycle Heat Pump + Aux Heating + 1 x Fan Speed 57
System Initialisation 58
Changing the Orientation and Type of Graphic 59
Classic/Portrait 59
Modern/Portrait 60

4
System Configuration 61
Configuration Main Menu (Classic Display) 62
Number of Zones 63
Number of Constants 64
Zone Set Up 65
Sensor Configuration 67
Sensor Calibration 68
Pairing and Configuring Myzone RF Sensors 69
iSense Controller Configuration 70
A/C Unit Configuration 71
Select the Method of Controlling the AC Unit 71
Fan Auto Configuration 72
Fan Auto Zone Area Set Up 73
Unit Info and Master/Slave Setup 74
System Options (Display, Taglines and Filter Maintenance) 75
System Options (Locks and Non Standard Damper Motors) 76
Wi-Fi Bridge Set Up 77
Wi-Fi Bridge Configuration 78
Wi-Fi Manual IP Configuration 79
Configuration Main Menu (Modern Display) 80
Number of Zones 81
Number of Constants 82
Zone Set Up 83
Sensor Calibration 84
Air Balance 85
Table of Contents

5
Pairing and Configuring Myzone RF Sensors 86
A/C Unit Configuration 87
Controlling Sensor 87
Fan Auto 88
Fan Auto 89
Constant Control 90
Unit Auto-O 91
In-Duct Energy 92
Auto Deadband 93
A/C Unit Make 94
Fault History 95
Master/Slave 96
System Options 97
Installing the Myzone 3 App 100
Worldwide Service Registration 101
Home Automation Integration 102
Further Assistance 103
Table of Contents

6
General Installation Rules
1. The Myzone CPU (C225) and A/C Unit Module (C325) can be installed close or on the indoor fan coil unit.
2. Do NOT directly hardwire the 240V/24V transformer into the A/C units power supply. The transformer requires its own power supply.
3. Do NOT run the A/C unit control cables or RJ45 cables alongside 240V wiring.
4. Must use two-core, shielded data cable with a minimal thickness of 0.75mm for the A/C unit control cable.
5. Connect the Nexus or Nano touch screens to the Myzone net ports on the Myzone CPU using the supplied RJ45 cables.
6. When installing RJ45 cables down wall cavities or chasing through walls, protect the RJ45 connectors with tape to avoid damage, installation damage to cables is not
covered under warranty.
7. All zone motors used on a system must be the SAME brand.
8. Connect all zone damper motors using RJ12 cables.
9. Always install zones in consecutive ports starting at Zone 1. The Myzone CPU (C225) is marked with zone numbers.
10. If any zone is temperature controlled, connect a supply air in-duct temperature sensor to the CDTS port on the Myzone CPU (C225). Install the sensor into the supply air
plenum. Secure the sensor in place using reinforced aluminium tape.
11. When installing temperature controlled zones, ensure the sensor for the associated zone is installed in a location that is representative of the temperature in the room/
zone. The sensor should be installed at approximately 1600mm above the floor and should not be subject to draughts, direct sunlight or heat from equipment such as
computers, TV screens etc. The supply air outlets in the room must not blow conditioned air directly onto the sensor.
12. If any wireless sensor or wireless bridge is not within range then additional signal repeaters can be added to help relay the signal.
13. Myzone Wi-Fi Bridge Ethernet connection must be plugged directly into the customers modem/router.
14. Only connect power supply to Myzone CPU (C225) ater all components have been connected.

7
1. Install the ducted air conditioning unit, zone damper motors, flexible duct and grilles as per manufacturer’s instructions and in accordance with relevant
Australian Standards.
2. NOTE: For full wiring details, please refer to pages 13-27.
Hardware Installation
Connect the CPU (CM225) and the relevant A/C unit module together (Installation of the A/C unit module is only applicable to system set-ups that require A/C Unit
Control) (CM325# – Refer to module list for correct module). Take care ensuring that the A/C unit module pins are installed straight and direct.
3. Connect the supplied blue RJ45 cable to the “Myzone Net” port at the top of the Myzone CPU (CM225), run the other end of the cable to the Myzone Nexus/Nano Tablet.
4. Connect the blue RJ12 zone motor cables (sold separately) in consecutive ports starting at Zone 1 on the CPU (CM225) The CPU (CM225) is marked with zone numbers.
All zone motors must be the same brand.
5. Connect the red supply air sensor (CDTS) to the supply air temp. port on the Myzone CPU (CM225) and place the temperature sensor inside the supply air plenum/duct
and secure sensor with reinforced aluminium tape. NOTE: A supply air sensor is only required to be installed if there are individual temperature controlled zones. ON/OFF
zone control does NOT require a supply air temperature sensor.
6. Run twin-shielded data cable from the A/C unit control cable terminals on the Myzone CPU (CM225) to the A/C unit indoor board (see pages 28-43 for detailed wiring
instructions on A/C unit brands) Must use minimum 0.75mm signal cable. NOTE: Only run twin-shielded data cable if A/C unit control is required.
7. Plug the 240V power plug on the transformer into a power source. Plug in the 24V transformer plug into the side of the Myzone CPU (CM225) to provide power to the CPU.
Ensure to run a separate power supply for the 240V plug o the transformer. DO NOT take power from the A/C unit.
8. Ater System Initialisation has completed, configure the Myzone control to your application (see configuration instructions on pages (page 76).
9. Pair Wireless Sensors to the system as per instructions in configuration on page 81 and mount according to general installation rule 11.
10. Pair Wi-Fi Bridge to the system as per instructions in configuration on page 72.
The above general installation instructions are applicable to installation configurations pictured on pages 28-43, any other configurations will require dierent/extra
installation procedures (refer to installation wiring layout and index for assistance).
General Installation Instructions

8
Unit Compatibility Form
Brand Models Polarity RA Zones Master RF Specials
Actron LRE 71, 100, 130AS ✓✓✓✓✓
Braemar SHDV Inverter Series, Single Phase ✓ ✓ ✗✗✗
Carrier SHDV Series Only ✓✓✓✓✓
Daikin Must have P1/ P2 and Current Daikin Controller can run the unit ✗✓✓✓✓VRV requires set up
Fujitsu C325F2 = ARTC##LATU & ARTG##LHTA Series ✓✓✓✓✓
Gree GFH##K Inverter Ducted Series, Single Phase Only ✓ ✓ ✗✗✗
Haier ADH Series Only ✓ ✓ ✗✗✗
Hitachi RPI XX 1SQ & RPI XX 2SQ Series ✗✓✓✓✓
iZone AD Series ✓✓✓✓✓
Kaden KD Series ✓✓✓✓✓
LG B##AWN-7G6 Series. C325L2 Does NOT require the option card ✓✓✓✓✓
Midea DUCMI### Series ✓✓✓✓✓
Mitsubishi Electric PEA-M###GAA. ✗✓✓✓✓
Mitsubishi Heavy FDUA/FDUM Series ✗✓✓✓✓
Panasonic S-###PE1R5B – S Series Only ✗✓✓✓✓
Rinnai DINLR##Z72 Series Only. ✓✓✓✓✓
Samsung C325S = AC Series up to 14kw. C325SN = AC Series & AC###TNHDKG Series ✓✓✓✓✓
Temperzone Condenser must be fitted with a UC7 or higher board ✓✓✓✓✓
Toshiba RAV – SM ### 3DT – A Series only ✗✓✓✓✓
York 6850018, 6850038, 6850048 ✓✓✓✓✓
Requires special cable supplied by Controls manufacture.
See manual for details. Requires component from Unit manufacture. See manual for details. Requires Unit Manufacture A/C Unit control. See manual for details.

9
System Design Considerations
Designing the Correct Constant Zone
All ducted air conditioning systems should have a percentage of air passing over the indoor coil at all times. This is a safety mechanism to protect the
ductwork and the A/C unit.
There are several ways of achieving this when designing a ducted air conditioning system.
i. Fixed Ducted Constant Zone
A fixed duct constant zone requires the system to be designed with one zone that has no zone damper fitted to it. This is normally a large common area (e.g. main living area).
The downside with this configuration is that air will always be delivered to this area regardless of whether it is occupied or not. This reduces the eciency of the system and
does not allow for modulating temperature control in the zone.
ii. Electronic Constant Zone
This option requires the system to be designed with one zone that has a zone motor fitted to it, which will automatically open if all other zones are closed. With electronic
constants there are three options available as follows:
a. Standard electronic constant zone
Typically a zone damper would be fitted to the main living area in the home or a common area in an oce building. This zone can be used like any other zone but will be
automatically overridden open if required by the system to maintain the minimum airflow over the indoor coil. With a Myzone system you can select as many zones as
you need to be electronic constants and they will activate and deactivate progressively as required. Standard electronic constant zone is only Open/Closed.
b. Dedicated electronic constant zone
In this option an additional zone is installed into the system serving an unoccupied area such as a stairwell or hallway. This zone is let in the closed position and will
only open if required by the system. With a Myzone system you can select as many dedicated zones as you need. The benefit of the dedicated electronic constant zone is
that all occupied areas can have individual temperature control and if the electronic constant is required to operate it will not aect the comfort of the occupants.

10
iii. Bypass Electronic Constant Zone
In this option an additional zone is installed into the system looping from the supply air side of the A/C fan coil unit to the return air side of the A/C fan coil unit. This
bypass zone is let in the closed position and will only open if required by the system. The benefit of the Bypass electronic constant zone is that all occupied areas can
have individual temperature control and if the electronic constant is required to operate it will not aect the comfort of the occupants. No common areas are aected by
the operation of the bypass constant and there is no increase in noise when the bypass is operating. In addition to this, the use of the bypass option increases the system
eciency as any conditioned air is kept within the system reducing the load on the A/C unit and assisting to cycle the A/C unit o earlier. (If set up to control from the units
return air sensor).
We recommend that all systems with individual zone temperature controls are designed and configured with a bypass electronic constant zone and where possible control
the A/C unit from "Zones" (see Fig C04).
System Design Considerations
Designing the Correct Constant Zone

11
Fixed Duct Constant and
Standard Electronic Constant
Fig C02 – Standard Electronic ConstantFig C01 – Fixed Ducted Constant
For most accurate control when using
individual zone temperature control.
Set A/C unit to control from “Zones”.
For most accurate control when using
individual zone temperature control.
Set A/C unit to control from “Zones”.
Ensure doors
are let open
if there is no
return air grille
in the zone
Supply air sensor
installed here
Supply air sensor
installed here
Fixed Duct Constant
zone has no
temperature control
Ensure doors
are let open
if there is no
return air grille
in the zone
Standard Electronic
Constant zone. Can
only be set to “Open”
or “Closed”. It cannot
be temperature
controlled. Set this
as the constant zone
in Configuration
Menu –> Zone Setup

12
Dedicated Electronic Constant
and Bypass Electronic Constant
Fig C04 – Bypass Electronic ConstantFig C03 – Dedicated Electronic Constant
Ensure doors
are let open
if there is no
return air grille
in the zone
Use an unoccupied
area as the
dedicated Electronic
Constant zone. Can
be let in the closed
position.
For most accurate control when using
individual zone temperature control.
Set A/C unit to control from “Zones”.
For most accurate control when using
individual zone temperature control.
Set A/C unit to control from “Zones”.
Bypass supply
air into return air
duct. Electronic
constant zone
must be let in the
Closed position.
Ensure doors
are let open
if there is no
return air grille
in the zone
Supply air sensor
installed here Supply air sensor installed here

13
Myzone Wiring Layout
ON/OFF Zone Control Only
(Max 8 Zones, Wi-Fi Optional)
240V/24V
Zone 7
Zone 5
Zone 3
Zone 1
Zone 8
Zone 6
Zone 4
Zone 2
Wi-Fi Bridge
(205126)
240V/24V Transformer
(3205599)
Myzone 3 CPU
(3205598)
Nexus Tablet
(205295)
Zoneboss
Zone Motor
RJ12 Cable
(1609219) RJ45 Cable (3205601)

14
Myzone Wiring Layout
Modulating Zone Control Only with Individual Wireless Zone
Temperature Control (Max 8 Zones, Wi-Fi Optional)
240V/24V
Zone 7
Zone 5
Zone 3
Zone 1
Zone 8
Zone 6
Zone 4
Zone 2
Wi-Fi Bridge
(205126)
240V/24V Transformer
(3205599)
Myzone 3 CPU
(3205598)
Zoneboss
Zone Motor
Wireless
Zone Sensor
(1690067)
RJ12 Cable
(1609219)
Nexus Tablet
(205295)
RJ45 Cable
(3205601)

15
Myzone Wiring Layout
A/C Unit Control and ON/OFF Zone Control
(Max 8 Zones, Wi-Fi Optional)
240V/24V A/C Unit
Zone 7
Zone 5
Zone 3
Zone 1
Zone 8
Zone 6
Zone 4
Zone 2
Wi-Fi Bridge
(205126)
240V/24V Transformer
(3205599) Twin-Shielded Cable
Myzone 3 CPU
(3205598)
Zoneboss
Zone Motor
RJ12 Cable
(1609219)
Nexus Tablet
(205295)
RJ45 Cable
(3205601)

16
Myzone Wiring Layout
A/C Unit Control and Modulating Zone Control with
Individual Wireless Zone Temperature Control
(Max 8 Zones, Wi-Fi Optional)
240V/24V A/C Unit
Zone 7
Zone 5
Zone 3
Zone 1
Zone 8
Zone 6
Zone 4
Zone 2
Wi-Fi Bridge
(205126)
240V/24V Transformer
(3205599) Twin-Shielded Cable
Myzone 3 CPU
(3205598)
RJ12 Cable
(1609219)
Zoneboss
Zone Motor
Wireless
Zone Sensor
(1690067)
Nexus Tablet
(205295)
RJ45 Cable
(3205601)

17
Myzone Wiring Layout
ON/OFF Zone Control Only
(Max 14 Zones, Wi-Fi Optional)
240V/24V
Zone 7
Zone 5
Zone 3
Zone 1
Zone 8
Zone 6
Zone 4
Zone 2
Wi-Fi Bridge
(205126)
240V/24V Transformer
(3205599) Myzone 3 CPU
(3205598)
RJ12 Cable
(1609219)
Zoneboss
Zone Motor
Zone 13
Zone 11
Zone 9
Zone 14
Zone 12
Zone 10
RJ45 Cable
(3205601)
Nexus Tablet
(205295)

18
Myzone Wiring Layout
Modulating Zone Control Only with Individual Wireless Zone
Temperature Control (Max 14 Zones, Wi-Fi Optional)
240V/24V
Zone 7
Zone 5
Zone 3
Zone 1
Zone 8
Zone 6
Zone 4
Zone 2
Wi-Fi Bridge
(205126)
240V/24V Transformer
(3205599) Myzone 3 CPU
(3205598)
RJ12 Cable
(1609219)
Zone 13
Zone 11
Zone 9
Zone 14
Zone 12
Zone 10
RJ45 Cable
(3205601)
Zoneboss
Zone Motor
Nexus Tablet
(205295)

19
Myzone Wiring Layout
A/C Unit Control and ON/OFF Zone Control
(Max 14 Zones, Wi-Fi Optional)
240V/24V
Zone 7
Zone 5
Zone 3
Zone 1
Zone 8
Zone 6
Zone 4
Zone 2
Wi-Fi Bridge
(205126)
240V/24V Transformer
(3205599)
RJ12 Cable
(1609219)
Zone 13
Zone 11
Zone 9
Zone 14
Zone 12
Zone 10
RJ45 Cable
(3205601)
Zoneboss
Zone Motor
Twin-Shielded
Cable
A/C Unit
Myzone 3
CPU
(3205598)
Nexus Tablet
(205295)
Myzone 3
AC Unit
Module

20
Myzone Wiring Layout
A/C Unit Control and Modulating Zone Control with
Individual Wireless Zone Temperature Control
(Max 14 Zones, Wi-Fi Optional)
240V/24V
Zone 7
Zone 5
Zone 3
Zone 1
Zone 8
Zone 6
Zone 4
Zone 2
Wi-Fi Bridge
(205126)
RJ12 Cable
(1609219)
Zone 13
Zone 11
Zone 9
Zone 14
Zone 12
Zone 10
RJ45 Cable
(3205601)
240V/24V Transformer
(3205599) A/C Unit
Myzone 3
CPU
(3205598)
Twin-Shielded
Cable
Nexus Tablet
(205295)
Myzone 3
AC Unit
Module
