Dakota Digital VHX-53C User manual

Manual # 650408B
VHX-53C
Dakota Digital VHX Instrument Installation
For 1953-54 Chevy Car
Your new VHX-53C kit includes:
Installation
Control Box
(6) 10-24 x 3” Studs
and Hex Nuts
CAT5 Cable
Universal Sender
Pack
Installation Manuals
VHX Display
1. Remove the stock bezel, gauges, and the trim between the gauges from the dash. Also remove all
the studs so you have a bare bezel. The only item to be reused is the original front bezel.
ABS Back plate
(2) Mounting
Brackets
Switch Assembly

Manual # 650408B
2. Insert the six (6) supplied studs in the holes shown below. Thread them in until they stop; tighten
with pliers, taking care not to damage the end of the threads or twist them off.
3. Place the VHX display in the original bezel, using care to not scratch the lens.
4. Lay masking tape across the entire gauge location to mark the cut line using the VHX
gauge cluster as a template. Use the studs to align the VHX unit; be sure all six studs
are in their respective holes in the dash.

Manual # 650408B
5. With the cut lines marked, you can now cut the center of the dash out to fit the new VHX
display. Be sure to prep the rest of the car as needed to protect the interior and
especially glass from sparks and metal shards. Use the metal cutting tool of your choice
and work slowly as to not overheat the metal and damage the paint in a visible area.
6. Once the VHX display fits the new opening, place the ABS Back Plate over the four
center studs. These will help hold the display to the bezel. Then, secure the VHX
system to the dash with the two (2) provided mounting brackets on each end, with the
supplied 10-24 nuts. Before final tightening, double check alignment of display.
Mounting Brackets
ABS Back Plate

Manual # 650408B
WARNING: This product can expose you to chemicals including lead, which is known to the State of
California to cause cancer and birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov
8. Connect the CAT5 cable to the system and take care when routing this cable to the
control box. Refer to the main manual for wiring instructions to complete the VHX
installation.
7. Ensure the lens fits flush to the bezel and that the bezel itself fits snug against the
dash; there should be no gaps around the lens or where the bezel meets the dash.
