1 About this document
1.1 Validity
This document is valid for the Dallmeier electronic speed dome
DDZ3022A.
1.2 Documentation on the DDZ3022A
The document entitled „Installation and Configuration“ describes
installation, mounting, connection, start-up, configuration, testing
and assistance in case of faults.
Thetarget audience of this document isexclusivelyspecially trained
and authorized professionals („installers“).
Storing the documents
Store the documents near the product so that they are accessible.
Pass on all documents to each successive owner or user of the
dome.
1.3 Convention
Signs and symbols used
DANGER!
The DANGER warning identifies immediate danger which could
lead to death or severe injury if not avoided.
Electrical current in the unit can be potentially dangerous, e.g. in
cases where the power supply is damaged.
WARNING!
The DANGER warning identifies immediate danger which could
lead to death or severe injury if not avoided.

6
DDZ3022A
DallmeierelectronicGmbH&Co.KG
CAUTION!
The CAUTION warning identifies potential danger which could lead
to mild injury if not prevented.
CAUTION!
The CAUTION warning without a symbol warns you of potential
damage to property and unsafe actions.
The unit can be damaged or destroyed, for example, if liquid
penetrates it or if the ventilation slits are covered.
Attention!
Contains information on the prevention of damage and
malfunctions.
Note!
Contains information on limitations of properties or their
characteristics.
Tip!
Here you will find useful information on safe usage,
background information and recommendations.
Words in bold and italics generally refer to a button or a label on
the graphic interface (GUI).

7
DallmeierelectronicGmbH&Co.KG
2 For your safety
Only use the camera if it is in proper technical working condition,
for the intended purpose and while keeping safety and potential
dangers in mind. Observe the technical specifications and the
corresponding instructions and/or documentation. Have
malfunctions that could compromise safety eliminated immediately!
This applies especially for damage to the power supply.
!!
!!
!Use professionals
Installation, mounting, connection, start-up and configuration
of the DDF3000A may only be performed by trained and
authorized professionals (installers).
As far as not expressly specified otherwise, this specification
also applies for the maintenance, testing and repair of the
camera.
!!
!!
!Read and understand instructions
Read the documentation for the camera carefully and
completely before using the camera.
!!
!!
!Observe the rated voltage
The applied voltage must constantly match the rated voltage
of the camera (see technical data).
!!
!!
!Protection against condensation
Wait approx. 8 hours for the camera to reach room temperature
before starting it up.
!!
!!
!Expansion components/peripheral devices
Use only expansion components conforming with the technical
specifications.
!!
!!
!Connection of the camera
Connection of the camera to a recording system or control
panel may only occur while the camera is de-energized. Pull
the mains plug!
!!
!!
!Penetration of foreign bodies and liquids
The camera may not be subjected to moisture or rain. No
objects or liquids may penetrate into the camera.

8
DDZ3022A
DallmeierelectronicGmbH&Co.KG
!!
!!
!Danger when opening camera
If it is necessary that the camera be opened, unplug the power
plug before opening.
!!
!!
!ESD measures
Certain components of the camera may be damaged or
destroyed by electrostatic discharge, even while disconnected
from the
power supply. Carry out equipotential bonding. Carry out work
only with the appropriate ESD protective measures in place.
!!
!!
!Do not make modifications
Dallmeier electronic GmbH & Co.KG accepts no liability for
damage resulting from unauthorized or improper modifications
to the camera.
!!
!!
!Mount the camera securely
The camera must be mounted securely to prevent injury to
others (e.g. via falling camera) or damage to the camera.
!!
!!
!Observe regulations
Inform yourself on local regulations and requirements before
using the camera. Also observe the local laws regarding data,
working and environmental protection.
!!
!!
!Observe ratings
Ensure compliance with all technical ratings, operating
conditions (Appendix) and requirements at the installation site.
!!
!!
!Disposal
Disconnect the camera from the power supply. Remove the
power cable and all the expansion components / peripheral
devices.Return the camera to your respective sales partner.

9
DallmeierelectronicGmbH&Co.KG
3 General Information
3.1 Scope of delivery
Included in the scope of supply:
1 x DDZ3022A dome and camera
3 x screws and pins
2 x cable and plug (alarm input and AUX output)
1 x hook and screw (for optional outdoor housing)
3.2 Transportation and packaging
Store the original packaging for transportation at a later date.
Dallmeier electronic is not responsible for damage resulting from
unprofessional/improper transportation. Shipping should only occur
in the original packaging.
If the original packaging is no longer available, ensure that the
packaging used sufficiently protects the unit against damage,
moisture, heat and cold.
3.3 Approved use
The DDZ3022A is a Speed Dome Video Camera for color or b/w
imaging. It is designed for indoor and outdoor (optional housing)
use. It enables to combine camera, motorized auto focus zoom
lens, pan/tilt mechanism in a compact dome design.
3.4 Features
The DDZ3022Ais state of the art technologies of latest surveillance
systems. It delivers a number of advanced features like, 22x optical
auto focus zoom, 248 preset positions,8 privacy masking zones,
autoflip function, mechanical infrared cut filter removal and 4 record
240sec patterns which it makes this series is the new choice for
any high quality system integration. The 22x optical zoom lens will
allowan outstandingperformanceon auto focus tracking and preset
accuracyof lessthan0.1 °.These providefar advanced technologies
to high performance to most system integrators.

10
DDZ3022A
DallmeierelectronicGmbH&Co.KG
"Compact sized ø120mm diameter acryl dome sized all-in-one
color camera.
"Easy interface with multiple protocol and automatic dome
protocol detection
"IP67 environmental structure (optional outdoor housing)
"1/4" IT Super HAD CCD 410,000 pixels
"480 TV lines of horizontal resolution
"Outstanding auto focus tracking with 22x zoom lens (f=3.8 ~
95mm)
"High sensitivity with a minimum illumination 0.001lx (DSS,
black & white)
"RS-485 communication for long distance camera application.
"Max. 380°/sec panning speed (preset recall speed)
"Up to 248 programmable preset positions
"Up to 8 programmable tours
"4 memorized user control patterns up to 240 seconds (speed
and position, lens controls)
"Outdoorexternalpendant mounthousingwith heaterandblower
(optional)
"8 alarm inputs and 4 outputs can be programmed by user
"Program upgrade via RS-485 remote site
Tip!
For detailed information, please see chapter
Specifications.
3.5 Certificates
The following certifications were in effect for the DDF3022Acamera
at the time this document was produced:
"CE EMC, FCC CLASS A
3.6 Warranty
The warranty period is 36 months.
The terms and conditions valid at the signing of the contract apply.

11
DallmeierelectronicGmbH&Co.KG
4 Notes on operating the camera
!The camera uses a 24V AC / 1.5A supply.
!If the camera or the cable connected to the cable is located
near sources of strong radiation, the video picture may be
distorted.
!The quality of the video picture depends on the lens used, the
lighting and the monitor used to display the video picture.
!Automatic white balance depends on the lighting used and
can cause color distortions in artificial light.
!Poor lighting can lead to faulty white balance.

12
DDZ3022A
DallmeierelectronicGmbH&Co.KG

13
DallmeierelectronicGmbH&Co.KG
5 Installation
5.1 Requirements at the installation site
The DDZ3022A (without optional outdoor housing) is designed for
indoor use. Unfavorable local conditions may shorten the life of
the product or lead to malfunctions.
Do not install/operate the camera in places:
!with large scale dust and dirt
!with steam or oil vapors (e.g. kitchen)
!with direct sunlight
!with ambient temperature below 0 °C (32 °F) or above 50 °C
(122 °F).
!near sources of strong radiation, i.e. X-rays, radio transmitters
or magnetic fields
!with corrosive surroundings (e.g. gases or salt water)
5.2 Set Protocol and Termination
Before start up the dome camera, set the protocol and camera
address and termination set with dip-switches and clock-switches.
1. Preparation
#Separate the dome part and the
bottom plate.
#Turn the top counter-clockwise.
Fig. 5-1

14
DDZ3022A
DallmeierelectronicGmbH&Co.KG
2. Set the termination On / Off
Whether it is a dome camera or keyboard controller, the device
which is connected at the end of the line must have the cable
communication terminated by setting the appropriate DIP switch.
Without proper termination, there is potential for control signal
errors. Total length of the cable for communication should not
exceed 1.2Km.
1: ON / 2: ON............. Terminated
1: OFF / 2: OFF ......... Not terminated
3. Set the camera address (ID)
To prevent electrical damage, each dome camera must have a
unique address (ID).
Fig. 5-2
Fig. 5-3
SW1

15
DallmeierelectronicGmbH&Co.KG
S1 1-digit number of address (ID)
S2 10-digit number of address (ID)
S3 100-digit number of address (ID)
Example: If S3=1, S2=2, S1=8, then the ID number is 128
4 Set the details of the dome
S4 Video format, communication and camera setup
S5 Protocol select
S6 Baud rate and factory default
S4
2
on
off
Communication
RS-422
RS-485
S4
1
On
Off
Video Format
PAL
NTSC
Camera module
Autodetection
x27 Zoom Camera
Reserved
Reserved
S4
3
Off
On
Off
On
4
Off
Off
On
On

16
DDZ3022A
DallmeierelectronicGmbH&Co.KG
S6 Baud Rate
2400bps
4800bps
9600bps
19200bps
38400bps
57600bps
115200bps
230400bps
1
Off
Off
Off
Off
On
On
On
On
2
Off
Off
On
On
Off
Off
On
On
3
Off
On
Off
On
Off
On
Off
On
S6
4
On
Off
Extended ID
0-999
1000-3999
S5 Protocoll
Autodetection (No Parity)
Autodetection (Even Parity)
Autodetection (Odd Parity)
Reserved
HW
P-D
VCN
SNM
DNC
KTL
PS
SAE
SAT
VL
DMD
H/Wfactorydefault
1
Off
On
Off
On
Off
On
Off
On
Off
On
Off
On
Off
On
Off
On
4
Off
Off
Off
Off
Off
Off
Off
Off
On
On
On
On
On
On
On
On
2
Off
Off
On
On
Off
Off
On
On
Off
Off
On
On
Off
Off
On
On
3
Off
Off
Off
Off
On
On
On
On
Off
Off
Off
Off
On
On
On
On

17
DallmeierelectronicGmbH&Co.KG
5.3 Cable Connection
DANGER!
Danger of death from electric shock caused by lightning.
#Data transfer and video cables may not be connected or
detached during a storm.
1 RS-422/485 connection
The dome camera can be remotely controlled by an external device
or control system, such as a control keyboard or DVR, using RS485
half-duplex, RS422 duplex or simplex serial communications
signals.
Connect marked RX+, RX- to TX+ and TX- of the RS485 control
system. If control system is RS422, connect Rx+(TX+), Rx+(TX-) and
(RX+), (RX-) of the dome camera to TX+, TX- and (RX+), (RX-) of the
control device respectively.
Fig. 5-4

18
DDZ3022A
DallmeierelectronicGmbH&Co.KG
2 Video Output connection
Connect the video out (BNC) connector to the monitor or video
input.
3 Alarm connection
ALARM PIN DETAILS
ALARM 1 ALARM 2
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
COMA
NCA
NOA
GND
ALARM4
ALARM3
ALARM2
ALARM1
COMA
NC B
NO B
GND
ALARM8
ALARM7
ALARM6
ALARM5
4 Power connection
Connect the power of AC 24V, 1000mA to the dome camera.
Use certified / Listed Class 2 power supply transformer only.
Fig. 5-5

19
DallmeierelectronicGmbH&Co.KG
5.4 Surface Mount
#Make wiring and attach the bottom plate to the install area.
#Regarding the arrow mark, connect the dome part to the plate
by turning clockwise.
#After connection the dome system, fasten the safety screw.
Fig. 5-6
A
B

20
DDZ3022A
DallmeierelectronicGmbH&Co.KG
5.5 In-ceiling Mount
Note!
The in-ceiling housing is optional. Please ask your sales
partner if it is available.
#Make wiring and attach the bottom plate in the in-ceiling
housing.
#Regarding the arrow mark, connect the dome part to the plate
by turning clockwise.
#After connection the dome system, attach the deco-ring.
Fig. 5-7
