Dancover TITAN Arch 90 User manual

for
Greenhouse
TITAN Arch 90
Manual
26-02-2019

3 m
4 m
2,13 m

3
2
TECHNICAL CERTIFICATE/GREENHOUSE “TITAN Arch 90” TECHNICAL CERTIFICATE/GREENHOUSE “TITAN Arch 90”
DISCRIPTION
The greenhouse “TITAN Arch 90 ” is designed to create the climate, which is productive to
grow horticultural crops on the garden plots.
The greenhouse can be of different length depending on customer’s wish. Required length of
the greenhouse is provided with the purchase of added kits of stretching out blocks. Every block
stretches out the baseline model per 2 meters. The length of the baseline model is 4 m. The height
of the set up frame is 2.1 m.
The frame of the greenhouse is made of square galvanized pipe and it is assembled with the studs,
screws, nuts. The kit includes everything you need to fasten the covering. Assembling set of the
greenhouse covering is available on customer’s request. The baseline model needs 3 polycarbonate
sheets 2.1*6 m with 4mm gauge. Every block needs one polycarbonate sheet 2.1*6 m
Follow the greenhouse assembly instructions and use it in strict
accordance with the manual and operating rules stated in the technical
certificate. Please keep the technical certificate for further reference.
!
Operating rules
The greenhouse should be assembled and installed according the instruction. The buyer should
control the assembly quality if it is made by third person.
Do not install the greenhouse close to the houses or threes which can cause the snow or ice stiricide.
The recommended distance is no less than 2 meters long.
The greenhouse is designed to endure the wind of less than 24 m/s.
If the greenhouse in not looked after during winter, the customer should determine the possible
snow load or to skin the covering. The limit snow load takes place when the weight of the snow blanket
is 130 kg/1m2 of horizontal ground surface for the full optional frame (baseline model: arc interval is
1 m long). The limit snow load 200kg/1m2 is for the gained quantity of the arcs (the interval of the arc
is 0.65 m).
The manufacturer reserves the right for greenhouse engineering design changes.
Warranty
1. The manufacturer shall be responsible for completeness of the package.
2. The manufacturer shall be responsible for assemblability of the greenhouse in accordance with
the Assembly Instruction.
3. The manufacturer shall be responsible for structural integrity within the frames of the Operating
Rules.
4. The term for a claim is 24 months from the date of purchase.
Warranty liability
Cleaning and washing of the polycarbonate sheets
Warranty liabilities do not apply to cases of:
1. The greenhouse installation with violation of requirements of the manual
2. The violation of the operating rules.
3. Inappropriate use of the greenhouse.
4. The evidence that indicates corrosion on the cut of the details which do not influence the
operational characteristics of the construction.
5. The deformation of the greenhouse under the show due to operational characteristics
violation.
6. The deformation of the greenhouse due to soil movement.
7. Floods, hurricanes and other natural disasters.
1. Swill the sheets with warm water.
2. Wash the sheet with a solution of mild soap or household detergent and warm
water, using a soft cloth or sponge to remove dirt.
3. Swill with cold water and dry with soft rag.
Never use abrasives or highly alkaline cleaning compositions for cleaning polycarbonate
sheets. Dry rubbing of the surface will damage the protective layer of the cladding and shorten
its application time. Never rub the surface of polycarbonate sheets with brushes, metallic cloth
or other abrasive materials.
When disinfecting the greenhouse from pathogens causing fungal and bacterial diseases,
do not use “sulfur blocks” to avoid frame corrosion (blackening).

5
4
KITTING OF PARTS FOR ASSEMBLY. BASELINE MODEL. KITTING OF PARTS FOR ASSEMBLY. BASELINE MODEL.
BOX 1
5Door block ready-assembled х 2
6
Right side-frame of butt end
х 2
7
Left side-frame of butt end
х 2
8
Upwardmost arc ready-assembled
х 2
BOX 2
1
Package header
20x20 х 4
1-1
Package header
25x25 х 10
2Uppermost bearer х 12
2-1 Bottom bearer х 16
3
Mountain base х 14
4в
Uppermost arc х 3
4н
Bottom arc х 6

7
6
9Inner binder х 21
10 External binder х 21
11 End binder х 14
12 Uppermost strip belt-line х 5
13 Bottom strip belt-line х 10
14 End-most hold-down
L-1050 mm х 4
14-1 Hold-down
L-1000 mm х 4
15 Scotch tape х 1
16 Double-sided scotch tape х 1
KITTING OF PARTS FOR ASSEMBLY. BASELINE MODEL.
BOX 2
KITTING OF PARTS FOR ASSEMBLY. BASELINE MODEL.
BOX 2
17 Screw М4х8 х 56
18 Screw М4х25 х 16
19 Screw М6х50 х 4
20 Screw М6х60 х 10
21 Nut М4 х 72
22 Nut М6 х 14
23 Washer 5 х 164
24 Washer 6 х 20
25 Self reaming tapping screw 4,8x19 х 256
26
Locking set
(drop latches with nuts M5)
х 2
27
Door handle set
(lock catch, liner,
washer, squarely
mould core, two handles)
х 2

9
8
KITTING OF PARTS FOR ASSEMBLY. OPTIONAL FRAME.
BOX 1
1-1 package header 25x25 х 4
2Uppermost bearer х 6
2-1 Bottom bearer х 8
3Mountain base х 4
4в Uppermost arc х 2
4н Bottom arc х 4
Strips: added package (optional)
For the vent
2 pieces
У7
У7
У6 У5
For the door
2 pieces
У1
У2
У3
У4
9Inner binder х 14
10 External binder х 14
12 Uppermost strip belt-line х 2
13
Bottom strip belt-line х 4
14-1 Hold-down х 4
15 Scotch tape х 1
16 Double-sided scotch tape х 1
KITTING OF PARTS FOR ASSEMBLY. OPTIONAL FRAME.
BOX 1

11
10
KITTING OF PARTS FOR ASSEMBLY. OPTIONAL FRAME.
х4
3
1
1
2
430мм
430мм
х1
х1
BOX 1
17 Screw М4х8 х 28
18 Screw М4х25 х 8
20 Screw М6х60 х 4
21 Nut М4 х 36
22 Nut М6 х 4
24 Washer 6 х 8
25 Self reaming tapping
screw 4.8*19 х 22
х2
8

13
12
3
х1
М6
х1
M6x50
х1
х1
х2
х1
М6
х1
M6x50
х1
1
1
1-1
7
5
6
8
1

15
14
4
х4
х4
40 мм

17
16
х1
х2
5
430мм
430мм
40 мм
6
1-1
4в
4н 4н
х1
х1
х1
4н
4в 4в
4н
1-1
1-1

19
18
7
2055
390
900
1050
900
235
165
2100
900
1500
2055


The UV-resistant side of
polycarbonate sheets must
face outside (sunward). The
UV-resistant side is usually
indicated with notations on the
shipping plastic film. The film is
transparent on the back side of
the polycarbonate sheet. After
marking the polycarbonate sheets,
but prior to cutting it, mark the
UV-resistant side on every piece
of polycarbonate sheet: when the
shipping film is removed both sides
look similar. The shipping film is
removed from both sides shortly
before fastening the covering in the
frame.
Tape scotch on the cut sides of the
polycarbonate sheets.
!
2055
2100

21
20
х17
х17
8 9


х18
х18
Assembly
without using
the strips

23
22
х26
х26
х17
360 мм
У5
У6 У7
У7
910
Assembly using the
strips
Assembly
without using
the strips

25
24
х26
х6
У1 У2
У3 У4
10
Assembly using the
strips
11
х23
х23

27
26
12
2-1
2
M4
M4x8
х1 х1
13
M4 M4x8
х1
х1
х1

29
28
14
M4x8
х1 х1
2-1
215
STRETCHING OUT THE LENGTH OF THE
BASELINE MODEL WITH THE ADDITIONAL
BLOCKS
16
2000
M4
M4x8
х1 х1

31
30
17 18
L1=L2
!
L1
L2
L1
L2
L1=L2
!
INSTALLATION ON THE BASEMENT
INSTALLATION ON THE GROUND
1000
900
3000
4025
25

33
32
19
The UV-resistant side of polycarbonate sheets must face outside (sunward). The UV-
resistant side is usually indicated with notations on the shipping plastic film. The
film is transparent on the back side of the polycarbonate sheet. After marking the
polycarbonate sheets, but prior to cutting it, mark the UV-resistant side on every piece
of polycarbonate sheet: when the shipping film is removed both sides look similar. The
shipping film is removed from both sides shortly before fastening the covering in the
frame.
Tape scotch on the cut sides of the
polycarbonate sheets.
12000
2000
1000 1050
2100
х1
х2
L=1,05м
double-sided scotch
tape
Arrowed line on
the piece indicates
the butt end of the
greenhouse.
1050
21
20 !
Do not screw until tight.
х1
Scotch tape.
1050
M4x25
х2
M4
х2

35
34
22
23
M6x60
M6
х1 х1
х1
х2
1000
M4x25
M4
х2 х2
х1
1 м
24
