DANLERS TLSW 10 ILM Quick start guide

Installation notes
DANLERS Limited, Vincients Road, CHIPPENHAM, Wiltshire, SN14 6NQ, UK.
Telephone: [phone] Fax: [phone]
E-mail: [email protected] Web: www.danlers.co.uk
Company Registered Number 2570169 VAT Registration Number 543 5491 38
Products available from DANLERS
• PIRoccupancyswitches•Daylightlinkeddimmers•Manualhighfrequencydimmers
• Photocells • Radio remote controls • Time lag switches • Outdoor security switches
• Dimmers•Heating,ventilationandair-conditioningcontrols•Bespoke/O.E.M.products
Please call for more information or a free catalogue, or visit our website.
ThisproductconformstoBSEN60669-2-1.
Pleaseensurethemostrecenteditionoftheappropriatelocalwiringregulationsareobserved
andsuitableprotectionisprovidede.g.6ampsovercurrent,1kVovervoltage.Pleaseensure
thatthisdeviceisdisconnectedfromthesupplyifaninsulationtestismade.
Thisproductiscoveredbyawarrantywhichextendsto5yearsfromthedateofmanufacture.
Precautions and Warranty
Plated time lag switches (2-wire versions)
TLSW 10 TLSW 10 ILM
DANLERS2-wireplatedtimelagswitchesdonotneedaneutraland
aresuitableforreplacingstandardwallswitchesorpneumatictime
lagswitches.Thewallboxmustbeatleast16mmdeep.
Ashortpresswillswitchtheloadonanditwillswitchoffautomatically
afterthetimelagperiodhasexpired.Thetimelagcanbesetbetween
approximately 1 and 10 minutes.
Thebuttonontheilluminatedversion(TLSW10ILM)islituntilthe
buttonispressed.Itcomesbackonwhenthetimelaghaselapsed.
The load can be switched on from other locations by connecting
thesedevicesinparallelorbyconnectingDANLERSmatchingslave
switches,availableasbothaplatedsinglegangslave(SS1SL)and
atwogangslave(SS2SL).
Theseswitchesshouldonlybeconnectedto230V50HzAC.
Theycanswitchupto6amps(1500W)of:
• Fluorescentlamps,eitherhighfrequencyorswitchstart
•Incandescentormainshalogenlamps(recommendedwithintegralsafetyfuse)
•Electronicorwirewoundtransformers.
Theycanalsoswitchupto:
•2amps(500W)ofCompactuorescent,LEDand2Dlamps.
•1amp(250W)ofFansorMetalHalidelamps.
Largerloadscanbeswitchedviacontactor.(Alsoseebelow)
Because there is no neutral connection there is a minimum load
requirementof 40W RESISTIVE for eachTLSW10(ILM) in the circuit.
Iftheloadislessthanthisorisnottotallyresistive,i.e.acontactor,CFL,
LED, 2D lamps or emergency tting, then one power factor correction
capacitor, CAPLOAD, needs to be added across the load for each
TLSW10(ILM)incircuit,asshowninthewiringdiagramsoverleaf.
16/03/12 INS983 TLSW 10
Troubleshooting
Time lag switch can not be re-triggered instantly:
•Smallnon-resistiveload(Contactor,CFL,LEDor2Dlamps).
 AddoneCAPLOADperTLSW10(ILM)acrosstheload,
 asshowninwiringdiagrams.
Slave switch does not operate the time lag switch:
•EnsureonlyDANLERSslaveswitchesareused.
•Ensureslavewiringislessthan10mlong.
Does not work with existing 2-way switches:
•Timelagsandslavescanusethewiringof2-wayswitching
 circuits,butnotbemixedwith2-wayswitches.
Output always live:
•Timelagoperatedwithin30secondsofconnectingthesupply.
 Releaselatchedrelaywithrmsidewaysknocktoproductwitha
smallbluntobjectsuchasascrewdriverhandle. Loading
Minimum load

Installation procedure
1.Pleasereadthesenotescarefullybeforecommencingwork.
Incaseofdoubtpleaseconsultaqualiedelectrician.
Makesurethepowerisisolatedfromthecircuit.
Ifafourlugmetalbackboxisbeingusedthetopandbottomlugs
mustberemoved.
2.TheTLSW10(ILM)hastwoterminalblocksonthereverse,which
should be connected as:
 Block1 L Liveinput
 SL SwitchedLineoutput
 Block2 PushButton Forconnectiontoslaveswitch(es).†
Must not be connected to the mains.
3.Existingtwo-waystrapperlinescanusuallybeusedtoconnect
thesetimelagswitchesinparallelortoconnectslaveswitch(es),
asshowninthewiringdiagramsopposite.
4 Whenthesedevicesarewiredinparallel,dependantontheload,
it may not be possible to immediately re-trigger the time lag.
5.Thetimelagisadjustedviaaspindle(see
illustrationopposite)byinsertinganarrow
(at)screwdriverthroughtheholelocatedon
thebottomedgeofthedevice:
Notes:
Whenwiringhasbeencompletedandveried,switchonsupply,wait
for30seconds*andthentestoperation.
*Ifthisisnotobserved,seetroubleshootingsectionforremedy.
†ThetwoterminalsonDANLERSslaveswitchesarelabelledas:
 PlatedSlaveswitches: PushButton
 GridSlaveswitches: L,S
Ifgridslaveswitchesareusedwithplatedtimelagswitches,the
LandSterminalsmustbeconnectedonlytothePushButton
terminalsonthetimelagswitch,nottolive.
Typical wiring diagrams
1-way TLSW 10 (ILM)
load
L
N
230 VAC
SL
Push
Button
Optional CAPLOAD,
Power factor
correction capacitor.
See minimum load.
L
TLSW 10 (ILM)
TIME
1
min
10
mins
A
PPROXIMATE
SETTINGS
5 mins
Example of a typical 2-way circuit
load
LN
230 VAC
Multi-way TLSW 10 (ILM) with slave switches
LN
230 VAC
load
SL
L
Push button
Slave
SwitchSlave
Switch
TLSW 10
(ILM)
Unused existing wire
terminate safely
Push button SS 1SL
SS 1SL
Optional CAPLOAD
See minimum load
Multi-way TLSW 10 (ILM) in parallel
LN
230 VAC
load
SL
LL SLSL
L
Unused existing wire
terminate safely
Push buttonPush button Push button
Optional CAPLOAD(s)
See minimum load
TLSW 10
(ILM)
TLSW 10
(ILM) TLSW 10
(ILM)
