DANLERS ControlZAPP CZ CEFL Quick start guide

Installation notes
DANLERS Limited, Vincients Road, CHIPPENHAM, Wiltshire, SN14 6NQ, UK.
Telephone: [phone] Fax: [phone]
E-mail: [email protected] Web: www.danlers.co.uk
Company Registered Number 2570169 VAT Registration Number 543 5491 38
Products available from DANLERS
• PIR occupancy switches • Daylight linked dimmers • Manual high frequency dimmers
• Photocells • Radio remote controls • Time lag switches • Outdoor security switches
• Dimmers • Heating, ventilation and air-conditioning controls • Bespoke / O.E.M. products
Please call for more information or a free catalogue, or visit our website.
This product conforms to BS EN 60669-2-1, BS EN 55015 and BS EN 60730.
Please ensure the most recent edition of the appropriate local wiring regulations are observed
and suitable protection is provided (protected with the appropriate MCB) 1kV over voltage.
Please ensure that this device is disconnected from the supply if an insulation test is made.
This product is covered by a warranty which extends to 5 years from the date of manufacture.
Precautions and Warranty
08/09/16 INS013 CZ CEFL DALI VF
Variants
DANLERS design and manufacture other ControlZAPP CZCEFLP variants, coded
by the following order codes:
CZ CEFL Suitable for mains switching
CZ CEFL VF Suitable for mains switching, Volt Free contacts
CZ CEFL 10VDC Suitable for 1-10VDC ballasts
CZ CEFL 10VDC VF Suitable for 1-10VDC ballasts, Volt Free contacts
CZ CEFL DALI Suitable for DALI ballasts.
Troubleshooting
The output will not switch on:
•TheLUXsettingasspeciedbytheControlZAPPAppissettoolowandis
inhibiting the switch.
• The moving body is not emitting more IR than the background.
(Person wearing insulating clothing in a warm environment)
• Person is too far from the PIR switch, see detection diagram.
• Person is moving unusually slowly (perhaps when testing).
• The control unit battery is not engaged (ON).
Switch RED dip switch next to the telejack connector on the control
unit to the DOWN position.
The output switches on when nobody is present:
• Heater causing infra-red variations in a small cold room.
Resite the CZ CEFL DALI VF control away from heater.
• Please contact DANLERS for further technical support.
ControlZAPP Ceiling ush mounted switch
CZ CEFL DALI VF (with volt free output)
ControlZAPPceilingushpassiveinfra-redswitches(PIR)canbeushmounted
into suspended and plasterboard ceilings (diagram A).
These PIR switches incorporate a passive infra-red quad sensor to detect
movement of a warm body within their detection zone (diagram B) and a photocell
to monitor the ambient light level.
ALL adjustments are made via a freely downloadable ControlZAPP App
available from the DANLERS website.
If CZ CEFL DALI VF is set as PIR with LUX input, upon detecting movement, if
the ambient light is dark enough, the ControlZAPP device will turn the output ON.
The ambient threshold can be set to between approximately 30 lux to 1000 lux
andinnitelux(photocellinactive)viathe‘RespondtoDaylight’settingsonthe
ControlZAPP App.
If no more movement is detected within a pre-selected time as determined by the
ControlZAPPApp,thentheControlZAPPdevicewillturntheoutputoff.This‘Time
OffTimeout’ortimelagcanbesetviatheControlZAPPAppadjusterbetween
10sec and 23hrs 59min 59sec.
Loading /Output
CZ CEFL DALI VF is suitable for switching and dimming DALI ballasts (broadcast
only). CZ CEFL DALI VF can control up to 40mA, eg. 20 ballasts at 2mA (varies
according to make and model of ballasts).
IMPORTANT: To control DALI ballasts you will require a DALI Power Supply Unit.
Please refer to your ballast instructions.
DANLERS DALI Power Supply Unit (order code DALIPSU) is rated at 40mA (DALI
standard allows 250mA maximum). The controls interface of a DALI ballast normally
sources at 2mA.
CZ CEFL DALI VF can also switch up to:
• 10 amps (3000W) of resistive loads
• 6amps(1500W)uorescentlamps,highfrequencyorswitchstart,
incandescent or mains halogen lamps (recommended with integral safety fuse)
• 3 amps (750W) of electronic or wire wound transformers.
• 2 amps (500W) of low energy lamps: CFL, LED, 2D etc.
• 1 amp (250W) of fans or most metal halide lamps.
Start-up mode and Default settings
When the CZ CEFL DALI VF is powered up, it will take 1 minute for the circuitry to
stabilise(detectionLEDashing)andensuretheoutputisoff,theCZCEFLDALI
VF will then enter its Default Operating Mode.
Please Note: When in the Default Operating Mode the CZ CEFL DALI VF is set up
as an occupancy switch with a 20 minute turn OFF timeout (time lag) and photocell
disabled.

Installation procedure
1. Please read these notes carefully before commencing work. In case of doubt
pleaseconsultaqualiedelectrician.Ensurewiresandcablesaresecurelyheld
within the connection terminals.
IMPORTANT: The CZ CEFL DALI VF Control Unit clock battery must be
engaged (ON) prior to installation by switching the RED dip switch (see
diagram D) to the DOWN position.
2. POSITIONING: The CZ CEFL DALI VF switch should be installed to achieve
correct coverage of the area, see diagram B.
If the photocell override facility
(enabled via ControlZAPP app) is required, the switch must be located above
anareawheredaylightcangivegreaterilluminationthanthearticiallight.Avoid
locating this product where it is exposed to drafty conditions (exposed lobbies,
open ceiling voids or near fans) or near heat sources. To cover large areas PIRs
should be spaced in a 5 metre grid formation.
3. Disconnect the ControlZAPP device from the circuit before performing insulation
testing of the wiring circuit.
4. Do not connect on a circuit with large inductive loads, as induced spikes may
cause false triggering or damage the device.
5. CZ CEFL DALI VF must be connected to its ControlZAPP Power Supply via the
ControlZAPP communication cable provided, for wiring see diagram C.
NOTE: The use of non ControlZAPP connectors may damage the CZ CEFL DALI
VF device and will invalidate the warranty.
Settings and calibration
NOTE: ALL settings are adjusted by ControlZAPP App as specied in the
ControlZAPP App User Guide (downloadable from the DANLERS website)
including: MODE settings, SCHEDULER settings and photocell settings and
intelligent photocell calibration procedure.
MODE settings include: Detect Movement (enable or disable), Sensitivity, Short
Visit Mode (with timer), Turn ON automatically (Presence detection or Absence
detection), Turn OFF timeout (from10sec to 23hrs 59min 59sec), Respond to
Daylight (enabled or disabled) the calibration process must be run for the intelligent
photocell to work. Delay before ON or Delay before OFF timers, Scene Recall (ON
or OFF).
SCHEDULER settings include:
DAY TYPES(deningtimesforeachofthedifferentModestooccur).
WEEKLY SCHEDULE(deningwhichDayTypesareassignedtodifferentdaysof
the week).
EXCEPTIONS(deningexceptionstotheschedulesuchasholidays).
VIEW ON CALENDAR (overview of schedule).
C: Wiring diagram
Volt Free,
Normally
Open
Supply
Voltage
NO
L
N
VF1
VF2
Neutral
DALI Control Lines
A: Mounting diagram
B: Detection diagram
up to 5m
up to 7m
Strong detection zone
i.e. person moving arm
or walking towards PIR Secondary detection
zone i.e. person
walking perpendicular
to PIR
For optimum coverage
recommended
mounting height: 2.4 to 5m
CEILING VOID
(At least 78mm deep)
75mm circular hole
cut for PIR switch
VF 1
VF
2
L
N
Telejack connector Control Unit
Power Supply
Red dip switch (MUST be
switched DOWN (towards lens)
to engage clock battery ON)
IMPORTANT
DA
DA
D: Connector diagram
