Data Video TP-600 User manual

Prompter Kit for ENG Cameras
TP-600
Instruction Manual
Rev Date: 29/05/2013 P/N: TP-600_E1_A4
WWW.DATAVIDEO.COM

2
Contents
Warnings and Precautions.......................................................................................3
Warranty.....................................................................................................................4
Disposal.....................................................................................................................4
Packing List...............................................................................................................5
Product Overview......................................................................................................6
Features................................................................................................................................................6
Assembly...................................................................................................................7
Software Download from the App Store™............................................................11
Android App download from Google play™.........................................................11
Tablet / Device Settings..........................................................................................11
Prompter Application Set Up .................................................................................12
How to quickly add text into a DV Prompter document.......................................13
Using the optional wired Remote Control.............................................................14
Using the optional Bluetooth Remote Control .....................................................15
Cleaning the 60/40 Glass sheet..............................................................................17
Specifications..........................................................................................................19
Service and Support ...............................................................................................20
iPad, iTunes and App Store are trademarks of Apple Inc. Android and Google play are trademarks of Google Inc.
Disclaimer of Product and Services
The information offered in this instruction manual is intended as a guide only. At all times, Datavideo Technologies will try to
give correct, complete and suitable information. However, Datavideo Technologies cannot exclude that some information in this
manual, from time to time, may not be correct or may be incomplete. This manual may contain typing errors, omissions or
incorrect information. Datavideo Technologies always recommend that you double check the information in this document for
accuracy before making any purchase decision or using the product. Datavideo Technologies is not responsible for any
omissions or errors, or for any subsequent loss or damage caused by using the information contained within this manual.
Further advice on the content of this manual or on the product can be obtained by contacting your local Datavideo Office or
dealer.

3
Warnings and Precautions
1. Read all of these warnings and save them for later reference.
2. Follow all warnings and instructions marked on this unit.
3. Unplug this unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
4. Do not use this unit in or near water.
5. Do not place this unit on an unstable cart, stand, or table. The unit may fall, causing serious damage.
6. Slots and openings on the cabinet top, back, and bottom are provided for ventilation. To ensure safe
and reliable operation of this unit, and to protect it from overheating, do not block or cover these
openings. Do not place this unit on a bed, sofa, rug, or similar surface, as the ventilation openings on
the bottom of the cabinet will be blocked. This unit should never be placed near or over a heat register
or radiator. This unit should not be placed in a built-in installation unless proper ventilation is provided.
7. This product should only be operated from the type of power source indicated on the marking label of
the AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer or your
local power company.
8. Do not allow anything to rest on the power cord. Do not locate this unit where the power cord will be
walked on, rolled over, or otherwise stressed.
9. If an extension cord must be used with this unit, make sure that the total of the ampere ratings on the
products plugged into the extension cord do not exceed the extension cord rating.
10. Make sure that the total amperes of all the units that are plugged into a single wall outlet do not exceed
15 amperes.
11. Never push objects of any kind into this unit through the cabinet ventilation slots, as they may touch
dangerous voltage points or short out parts that could result in risk of fire or electric shock. Never spill
liquid of any kind onto or into this unit.
12. Except as specifically explained elsewhere in this manual, do not attempt to service this product
yourself. Opening or removing covers that are marked “Do Not Remove” may expose you to dangerous
voltage points or other risks, and will void your warranty. Refer all service issues to qualified service
personnel.
13. Unplug this product from the wall outlet and refer to qualified service personnel under the following
conditions:
a. When the power cord is damaged or frayed;
b. When liquid has spilled into the unit;
c. When the product has been exposed to rain or water;
d. When the product does not operate normally under normal operating conditions. Adjust only
those controls that are covered by the operating instructions in this manual; improper
adjustment of other controls may result in damage to the unit and may often require extensive
work by a qualified technician to restore the unit to normal operation;
e. When the product has been dropped or the cabinet has been damaged;
f. When the product exhibits a distinct change in performance, indicating a need for service.
GLASS - Handle with care
This product contains a sheet of 60/40 mirror glass please handle it with care.
To avoid a risk of damage or injury please follow this instruction manual and use
caution when transporting, un-packing, cleaning, assembling or dis-assembling this
part of the product.

4
Warranty
Standard Warranty
Datavideo equipment is guaranteed against any manufacturing defects for one year from the
date of purchase.
The original purchase invoice or other documentary evidence should be supplied at the time
of any request for repair under warranty.
Damage caused by accident, misuse, unauthorized repairs, sand, grit or water is not covered
by this warranty.
All mail or transportation costs including insurance are at the expense of the owner.
All other claims of any nature are not covered.
Cables & batteries are not covered under warranty.
Warranty only valid within the country or region of purchase.
Your statutory rights are not affected.
Two Year Warranty
All Datavideo products purchased after 01-Oct.-2008 qualify for a free one year extension to the
standard Warranty, providing the product is registered with Datavideo within 30 days of
purchase. For information on how to register please visit www.datavideo.com or contact your
local Datavideo office or authorized Distributors
Certain parts with limited lifetime expectancy such as LCD Panels, DVD Drives, Hard Drives are
only covered for the first 10,000 hours, or 1 year (whichever comes first).
Any second year warranty claims must be made to your local Datavideo office or one of its authorized
Distributors before the extended warranty expires.
Disposal
For EU Customers only - WEEE Marking
This symbol on the product indicates that it should not be treated as household
waste. It must be handed over to the applicable take-back scheme for the
recycling of Waste Electrical and Electronic Equipment. For more detailed
information about the recycling of this product, please contact your local
Datavideo office.

5
Packing List
Item
Description
Quantity
A
Main TP-600 ENG prompter rail
1
B
Smaller rail with spacer block for mounting bracket
1
C
¼” Screws Length 27mm secures item B to A
2
D1
Hex Tool (Black) for counter sunk Hex head screws
1
D2
Hex Tool (Silver) for Glass Frame Hex screws
1
E
¼” Screw Length 8mm secures item F to B
1
F
Adjustable Mounting Bracket with locking lever
1
G
Glass frame with 4 Velcro straps
1
H
Wing nut screws M6 Length 16mm secures item G to A
2
I
Cloth Snood/Hood with Velcro straps
1
J
60/40 Glass sheet with Green and Red stickers
1
K
Snood/Hood support wire
1
L
¼” Camera securing screws length 16mm
2
M
¼” Camera securing screws length 31mm
2
N
Camera riser block 15mm thick
1
O
Cloth case for Snood, Mirror Glass and Glass frame
1
P
Adapter screw to convert 3/8” hole to ¼” hole
1
Q
¼” Counter sunk hex head screw length 16mm
1
R
¼” Counter sunk hex head screw length 31mm
1
plus
Retail carton with protective foam packing
1 set
NOTE: Depending on your order, your TP-600 kit could have been supplied with one of the following
optional remote controls:
Wired remote for Android™or iOS™devices with a headset jack input.
Bluetooth Wireless remote for Android™or iOS™devices.
NOTE: The foam packing within the retail carton has been designed so that it can be easily
transferred to an optional hard case, called HC-600, for this kit.
Please speak with your supplier or dealer if you wish to purchase an optional remote control or the
HC-600 hard case for this prompter kit.
