Degelman STRAWMASTER 700 Series User manual

STRAWMASTER®700 NARROW
22’ & 30’
OPERATOR MANUAL
& PARTS CATALOG
DEGELMAN INDUSTRIES LP
BOX 830-272 INDUSTRIAL DRIVE,
REGINA, SK, CANADA, S4P 3B1
FAX [phone] PH 306.543.4447
1.800.667.3545 DEGELMAN.COM
142781 v1.2

DEGELMAN INDUSTRIES LP
BOX 830-272 INDUSTRIAL DRIVE,
REGINA, SK, CANADA, S4P 3B1
FAX [phone] PH 306.543.4447
1.800.667.3545 DEGELMAN.COM
IMPORTANT:
READ MANUAL
TABLE OF CONTENTS - OPERATORS SECTION
Introduction 1
Safety
Safety Information 2
Operation
Overview / Preparation 6
Hook-Up 8
Convert to Field Position 9
Suggested Tine Angle Settings 10
Height Adjustment 11
Transporting 12
Service & Maintenance
Service 13
Repair 15
Storage 19
Troubleshooting 20
TABLE OF CONTENTS - PARTS SECTION 21
Warranty 30

-1-
142781 - Strawmaster 700 Narrow (13-February-2020)
OPERATOR ORIENTATION - The directions left, right, front and rear, as mentioned throughout the manual,
are as seen from the tractor drivers’ seat and facing in the direction of travel.
Introduction
Left Side
Rear
Front
Right Side
CONGRATULATIONS on your choice of a Degelman Strawmaster®to complement your farming operation.
It has been designed and manufactured to shatter straw, control weeds, rake flax straw, and incorporate
seed and chemicals. Use this manual as your first source of information about this machine.
Safe, efficient and trouble free operation of your Degelman Strawmaster®requires that you and anyone
else who will be operating or maintaining it, read and understand the Safety, Operation, Maintenance and
Troubleshooting information contained within this manual.
Keep this manual handy for frequent reference and to pass on to new operators or owners. Call your
Degelman Dealer if you need assistance, information, or additional copies of the manual.

-2-
142781 - Strawmaster 700 Narrow (13-February-2020)
The Safety Alert Symbol identifies important safety
messages applied to the Strawmaster®and in this
manual. When you see this symbol, be alert to the
possibility of injury or death. Follow the
instructions provided on the safety messages.
The Safety Alert Symbol means:
ATTENTION!
BECOME ALERT!
YOUR SAFETY IS INVOLVED!
DANGER: Indicates an imminently hazardous situation
that, if not avoided, WILL result in death or serious injury
if proper precautions are not taken.
WARNING: Indicates a potentially hazardous
situation that, if not avoided, COULD result in death or
serious injury if proper precautions are not taken.
CAUTION: Indicates a potentially hazardous situation
that, if not avoided, MAY result in minor or moderate
injury if proper practices are not taken, or, serves as a
reminder to follow appropriate safety practices.
Why is SAFETY important to YOU?
3 BIG Reasons:
•Accidents Can Disable and Kill
•Accidents Are Costly
•Accidents Can Be Avoided
Note the use of the Signal Words: DANGER, WARNING, and CAUTION with the safety messages.
The appropriate Signal Word has been selected using the following guidelines:
SAFETY ALERT SYMBOL
SIGNAL WORDS
Safety
CAUTION
DANGER
WARNING

-3-
142781 - Strawmaster 700 Narrow (13-February-2020)
1. Read and understand the Operator’s
Manual and all safety signs before
operating, maintaining or adjusting
the Strawmaster®.
2. Install and properly secure all shields and
guards before operating. Use hitch pin with a
mechanical locking device.
3. Have a first-aid kit available for use
should the need arise and know
how to use it.
4. Have a fire extinguisher available
for use should the need arise and
know how to use it.
5. Wear appropriate protective gear. This list
includes but is not limited to:
• A hard hat
• Protective shoes with slip resistant soles
• Protective glasses or goggles
• Heavy gloves
• Wet weather gear
• Hearing protection
• Respirator or filter mask
6. Clear the area of people, especially small
children, and remove foreign objects from the
machine before starting and operating.
7. Do not allow riders.
8. Stop tractor engine, set park brake, remove
ignition key and wait for all moving parts to
stop before servicing, adjusting, repairing or
unplugging.
9. Review safety related items with all operators
annually.
YOU are responsible for the safe operation and
maintenance of your Degelman Strawmaster®.
YOU must ensure that you and anyone else who
is going to operate, maintain or work around
the Strawmaster®be familiar with the operating
and maintenance procedures and related SAFETY
information contained in this manual.
This manual will take you step-by-step through
your working day and alerts you to all good safety
practices that should be adhered to while operating
this equipment.
Remember, YOU are the key to safety. Good safety
practices not only protect you but also the people
around you. Make these practices a working
part of your safety program. Be certain that
EVERYONE operating this equipment is familiar
with the recommended operating and maintenance
procedures and follows all the safety precautions.
Most accidents can be prevented. Do not risk injury
or death by ignoring good safety practices.
• Strawmaster®owners must give operating
instructions to operators or employees before
allowing them to operate the Strawmaster®,
and at least annually thereafter per OSHA
regulation 1928.51.
• The most important safety device on this
equipment is a SAFE operator. It is the opera-
tor’s responsibility to read and understand
ALL Safety and Operating instructions in the
manual and to follow these. All accidents can
be avoided.
• A person who has not read and under-
stood all operating and safety instructions
is not qualified to operate the machine. An
untrained operator exposes himself and by-
standers to possible serious injury or death.
• Do not modify the equipment in any way.
Unauthorized modification may impair the
function and/or safety and could affect the
life of the equipment.
• Think SAFETY! Work SAFELY!
Safety
SAFETY GENERAL SAFETY

-4-
142781 - Strawmaster 700 Narrow (13-February-2020)
1. Review the Operator’s Manual and all safety
items before working with, maintaining or
operating the Strawmaster®.
2. Stop the tractor engine, set park brake, remove
ignition key and wait for all moving parts to
stop before servicing, adjusting, repairing or
unplugging.
3. Keep hands, feet, clothing and hair away from
all moving and/or rotating parts.
4. Clear the area of bystanders, especially
children, when carrying out any maintenance
and repairs or making any adjustments.
5. Place safety stands or large blocks under the
frame before removing tires or working beneath
the machine.
6. Be careful when working around or maintaining
a high-pressure hydraulic system. Wear proper
eye and hand protection when searching for
a high pressure hydraulic leak. Use a piece
of wood or cardboard as a backstop when
searching for a pin hole leak in a hose or a
fitting.
7. Always relieve pressure before disconnecting or
working on hydraulic system.
1. Read and understand the Operator’s Manual
and all safety signs before using.
2. Stop tractor engine, set park brake, remove
ignition key and wait for all moving parts to
stop before servicing, adjusting, repairing or
unplugging.
3. Keep hands, feet, hair and clothing away from
all moving and/or rotating parts.
4. Do not allow riders on the Strawmaster®or
tractor during operation or transporting.
5. Keep all shields and guards in place when
operating.
6. Clear the area of all bystanders, especially
children, before starting.
7. Do not operate machine on steep side hills or
slopes.
8. Be careful when working around or
maintaining a high-pressure hydraulic system.
Ensure all components are tight and in good
repair before starting.
9. Clean all reflectors, lights and the SMV sign
before transporting on a highway or public
road. Be sure to check with local highway
authorities and comply with their lighting
requirements.
Safety
OPERATING SAFETY MAINTENANCE SAFETY

-5-
142781 - Strawmaster 700 Narrow (13-February-2020)
1. Always place all tractor hydraulic controls in
neutral before dismounting.
2. Make sure that all components in the hydraulic
system are kept in good condition and are
clean.
3. Replace any worn, cut, abraded, flattened or
crimped hoses and metal lines.
4. Do not attempt any makeshift repairs to the
hydraulic lines, fittings or hoses by using tape,
clamps or cements. The hydraulic system
operates under extremely high-pressure.
Such repairs will fail suddenly and create a
hazardous and unsafe condition.
5. Wear proper hand and eye
protection when searching
for a high-pressure hydraulic
leak. Use a piece of wood
or cardboard as a backstop
instead of hands to isolate
and identify a leak.
6. If injured by a concentrated high-pressure
stream of hydraulic fluid, seek medical attention
immediately. Serious infection or toxic reaction
can develop from hydraulic fluid piercing the
skin surface.
7. Before applying pressure to the system, make
sure all components are tight and that lines,
hoses and couplings are not damaged.
• Think SAFETY! Work SAFELY
1. Read and understand ALL the information in the
Operator’s Manual regarding procedures and
SAFETY when operating the Strawmaster®in
the field/yard or on the road.
2. Check with local authorities regarding machine
transport on public roads. Obey all applicable
laws and regulations.
3. Always travel at a safe speed. Use caution
when making corners or meeting traffic.
4. Make sure the SMV (Slow Moving Vehicle)
emblem and all the lights and reflectors that are
required by the local highway and transport
authorities are in place, are clean and can be
seen clearly by all overtaking and oncoming
traffic.
5. Keep to the right and yield the right-of-way to
allow faster traffic to pass. Drive on the road
shoulder, if permitted by law.
6. Always use hazard warning flashers on tractor
when transporting unless prohibited by law.
7. Always use a pin with provisions for a
mechanical retainer and a safety chain when
attaching to a tractor or towing vehicle.
1. Failure to follow proper procedures when
mounting a tire on a wheel or rim can produce
a blow out which may result in serious injury or
death.
2. Do not attempt to mount a tire unless you have
the proper equipment and experience to do the
job.
3. Have a qualified tire dealer or repair
serviceman perform required tire maintenance.
Safety
HYDRAULIC SAFETY TRANSPORT SAFETY
TIRE SAFETY

-6-
142781 - Strawmaster 700 Narrow (13-February-2020)
The Strawmaster®harrow sections consist of four
rows each with six or eight tines per row which hold
the straw. As the tines drag along the ground, they
oscillate to build up a high frequency vibration and
provide a shattering action which breaks up the
straw allowing the residue to be spread evenly as it
is released. When stood vertically the tines will rake
flax residue.
PRINCIPLES OF OPERATION
Operation
The Degelman Strawmaster®is designed for
effective straw management, weed control,
herbicide application, raking flax residue and
following ground contour. The Strawmaster®
is fully adjustable from tine angle to operating
height with the use of gear driven jacks or
optional hydraulics. The harrow sections can
operate in a float position or under a variable
amount of pressure with the use of hydraulics and
spring bars.
It is the responsibility of the owner or operator
to read this manual carefully to learn how to
operate the machine safely, and how to set it to
provide maximum efficiency. Safety is everyone’s
business. By following safe operating practices, a
safe environment is provided for the operator and
bystanders.
The manual will take you step-by-step through
your working day. By following the operating
instructions in conjunction with a good
maintenance program your machine will provide
many years of trouble-free service.
TO THE NEW OPERATOR OR OWNER BRIEF OVERVIEW OF OPERATION
• Operating speed will depend on tractor
horsepower, environmental conditions and each
particular operation. A speed of 8 to 12 MPH.
(12 to 16 KPH) is suggested to efficiently shatter
and spread straw and residue.
• Operating height for the harrow will vary with
the length of the tines, and the angle that the
tines are set at. As the tines wear down, the
height of the machine from the ground will have
to be adjusted down proportionally. (Refer to
the Height Adjustments section)
• The harrow sections can be set in float position,
where the section drags the ground under its
own weight.
• Pressure can be applied using the hydraulics
to rotate the beam further back. The spring
bars will deflect to apply pressure to the
harrow section and the ground. The amount of
pressure to apply will depend
on the application,
and the operator’s
preference.
• Some suggested settings can be found in the
“Suggested Tine Angle Settings” section. As
there are only a few standard guidelines, feel
free to experiment with ground clearance, tine
angle and section pressure to obtain desired
results for each operation.
1
4
5
2
6
3
38’ Strawmaster Model
1. Trailer Frame
2. Center Frame
3. Left Wing Frame
4. Right Wing Frame
5. Wing Fold Cylinders
6. Auto-Fold Cylinders
7. 6’ Harrow Section
8. 8’ Harrow Section
7
7 (x2 - 30ft Model)
8 (x1 - 22ft Model)
-or-
7 (x2 - 30ft Model)
8 (x1 - 22ft Model)
-or-

-7-
142781 - Strawmaster 700 Narrow (13-February-2020)
Operation
Although there are no operational restrictions on
the Strawmaster®when it is new, there are some
mechanical checks that must be done to ensure
the long term integrity of the unit. When using the
machine for the first time, follow this procedure:
IMPORTANT:It is extremely important to follow
all of the Break-In procedures especially those
listed in the “Before using” section below to avoid
damage:
A. Before using:
1. Read Safety Info. & Operator’s Manual.
2. Complete steps in “Pre-Operation Checklist”.
3. Lubricate all grease points.
4. Check all bolt tightness.
B. After operating for 2 hours:
1. Check all hardware. Tighten as required.
2. Check all hydraulic system connections.
Tighten if any are leaking.
C. After operating for 8 hours:
1. Repeat Step B.
2. Re-torque all bolts on harrow sections and
mounting brackets.
3. Go to the service schedule as outlined in the
“Service & Maintenance” section.
BREAK-IN
Before operating the machine and each time there-
after, the following areas should be checked off:
1. Lubricate the machine per the schedule outlined in
the “Service & Maintenance Section”.
2. Use only a tractor with adequate power to pull
the Strawmaster®under ordinary operating
conditions:
Minimum Ideal
22’ model: 100 HP 150 HP
30’ model: 100 HP 150 HP
3. Ensure the Hitch Clevis is set at the correct height
for the tractor drawbar and trailer height. (Refer
to the “Height Adjustment” section for settings)
4. Ensure that the machine is properly attached to
the tractor using a drawbar pin with provisions
for a mechanical retainer. Make sure that a
retainer such as a Klik pin is installed.
NOTE: It is important to pin the draw bar in the
central location only.
5. Check tires and ensure that they are inflated to the
specified pressure.
6. Ensure that a safety chain on the hitch is installed.
7. Check oil level in the tractor hydraulic reservoir.
Top up as required.
8. Inspect all hydraulic lines, hoses, fittings and
couplers for tightness. Tighten if there are leaks.
Use a clean cloth to wipe any accumulated
dirt from the couplers before connecting to the
tractor’s hydraulic system.
9. Check all the machine settings, refer to the
Adjustment section. Perform adjustments as
necessary.
10. Check tines, remove entangled debris. Replace
damaged tines. If tines are 16 in. or less in
length, they should be replaced. (New tine
length: 26 in.) See section on Tine Replacement.
PRE-OPERATION CHECKLIST
It is important for both personal safety and
maintaining the good mechanical condition of
the machine that this pre-operational checklist be
followed.
OPERATING SAFETY
• Read and understand the Operator’s Manual
before starting.
• Lower to ground, stop engine, place all controls
in neutral, set park brake and remove ignition
key before servicing, adjusting or repairing.
• Keep hands, feet, hair and clothing away from
all moving and/or rotating parts.
• Do not allow riders.
• Clear the area of bystanders, especially small
children.
• Stay well back from machine when operating.
Keep others away.

-8-
142781 - Strawmaster 700 Narrow (13-February-2020)
The Strawmaster®should always be parked on a
level, dry area that is free of debris and foreign
objects. Follow this procedure to hook-up:
1. Clear the area of bystanders and remove
foreign objects from the machine and working
area.
2. Make sure there is enough room to back the
tractor up to the trailer hitch.
3. Start the tractor and slowly back it up to the
hitch point.
4. Stop the tractor engine, place all controls in
neutral, set park brake and remove ignition key
before dismounting.
5. Use the trailer jack to raise or lower the hitch to
align with the drawbar.
6. Install a drawbar pin with provisions for a
mechanical retainer such as a KLIK pin.
Install the retainer.
7. Install a safety chain between the tractor and
the hitch.
8. Connect the hydraulics. To connect, proceed as
follows:
• Use a clean cloth or paper towel to clean the
couplers on the ends of the hoses. Also clean
the area around the couplers on the tractor.
Remove the plastic plugs from the couplers and
insert the male ends.
• Be sure to match the pressure and return line to
one valve bank.
9. Raise the hitch jack and rotate it 90º to place in
its stowed position.
10. When unhooking from the tractor, reverse the
above procedure.
Operation - Hook-Up
HOOK-UP / UNHOOKING

-9-
142781 - Strawmaster 700 Narrow (13-February-2020)
Operation - Convert to Field Position
TO CONVERT TO FIELD POSITION
1. Disengage the hydraulic transport lock. 3. Extend the Wing Fold Cylinders to completely
open both wing sections.
4. With wings fully opened, lower harrow sections
to the ground by extending the auto-fold
cylinders.
2. Raise the harrow sections part way up by
extending the Auto-Fold Cylinders. This is to
clear the wing support stands on the trailer
frame when opening the wing sections.
IMPORTANT:Ensure there is lots of room
behind and to the sides.
1
4321
4
3
2

-10-
142781 - Strawmaster 700 Narrow (13-February-2020)
Operation - Suggested Tine Angle Settings
The following lists suggested tine angle settings. Since
there are no standard angles for running the tines,
the operator may adjust the tine angles as required to
achieve desired results.
REMEMBER:
• actual settings will vary with tine wear.
• ensure trailer and frame are leveled properly.
(Refer to the “Height Adjustment” section.)
REMEMBER WHEN OPERATING:
• straw should be dry.
• if machine leaves
clumps of straw,
apply slight
down pressure
by extending
hydraulic lift
cylinders.
• Begin operating Strawmaster®
with the lift hydraulics in float
position, if more compaction is
required, rotate center beam by
extending main lift cylinders.
• To avoid deep ridges in your
field, reduce down pressure and operate at lower
speeds; 5 - 6 mph.
• If packing is done after seeding, make sure to
check that seed is not being disturbed.
• To prevent tine damage, avoid tight turning.
FIELD PACKING
BREAKING & SPREADING STRAW
• For best results operate at
10 - 12 mph
• The straw built up in the harrow
sections helps to achieve maximum
rub action to break down straw.
TOUGH STRAW
• Advance the tine angle to a more aggressive
setting. This will hold straw for a longer period
of time, allowing for a more even distribution of
residue. REMEMBER: Breaking down straw is much
more effective in dry conditions.
• A second pass may be required in extremely
heavy straw conditions. (Work the second pass at
a 45 degree angle to how it was worked the first
time).
• Increasing downward pressure
will help break the soil crust and
place the granule in contact with
moist soil.
• Avoid straw build up in the first two rows of tines.
This makes for a more even granule or seed
broadcast.
IMPORTANT:Always follow label directions for
chemical herbicides.
• Valmar Airflow offers all the necessary hardware
required to neatly install their applicator on the
Strawmaster®700. The Valmar Airflow Model
1655 can be used with the 22’ & 30’ models.
CHEMICAL INCORPORATION
THE FIELD
• Work the field at 45 degrees to
the seeding line.
• In order to rake flax straw some
down pressure is required.
• Before built-up straw starts to spill out the back
of the machine dump straw load by lifting harrow
sections.
RAKING 4321
4321
4321 4321

-11-
142781 - Strawmaster 700 Narrow (13-February-2020)
Operation - Height Adjustment
Tine angle adjustment should be made with the
machine in field position. For suggested initial
settings with new tines, refer to the “Suggested Tine
Angle Settings” section.
To adjust tine angle: Rotate the sidewind jacks
located on each harrow section. Start at one end,
set as desired. Set all the other sections to the same
setting.
TINE ANGLE ADJUSTMENT
The trailer
frame
hitch
should be parallel
to the ground when operating. It will
be necessary to adjust the hitch clevis
height each time the trailer height is
adjusted due to tine wear.
To adjust the hitch clevis location, hook-up the
tractor to the trailer hitch, following the procedure
in the section “Hook-up/Unhooking”. Stand back
and check to see if the trailer hitch is parallel to the
ground. If not, use the sidewind jack to raise the
trailer hitch and centre the clevis to the drawbar.
Remove hitch mounting bolts and move the clevis up
or down as required. Re-install the hitch mounting
harware. Lower the trailer hitch.
Stand back to check if the trailer hitch is level. If
not, repeat procedure.
HITCH CLEVIS ADJUSTMENT
Trailer height will require adjustment as the tines
wear down, or as the tine angle is increased.
Trailer height is adjustable manually with the use of
two ratchet jacks, each located on the trailer wheel
arms.
To adjust
trailer height:
Begin with the
machine in
field position.
Make sure
the tine angle
has been set,
if necessary.
Use the ratchet
jack handle for adjustment. Adjust ratchet jacks
evenly until tines are set to a desired height. If
trailer frame cannot be lowered any further, replace
tines or check tine angle.
When adjustments are complete, check that the
trailer frame is parallel to the ground. If not, adjust
clevis height and re-check. Repeat if necessary.
TRAILER HEIGHT ADJUSTMENT
NOTE: Stawmasters can have either manual or hydraulic adjustment. Trailer
height & tine angle are set by either ratchet/sidewind jacks or hydraulics.
If trailer height is set correctly it will
be even with harrows and...
Front & back tines apply equal pressure Front tines not applying pressure Front tines applying too much pressure
If trailer is too high... If trailer is too low...

-12-
142781 - Strawmaster 700 Narrow (13-February-2020)
4. Engage the transport lock by closing the
hydralic valve.
Operation
Follow this procedure when preparing to transport:
IMPORTANT:Clear the area of bystanders,
especially small children, before converting into
transport configuration.
1. Retract the “Auto-Fold Cylinders” to raise the
harrow sections to about 3/4 of the way up.
2. Fully retract the “Wing Fold Cylinders” to fold
the wing sections.
3. Continue to retract the “Auto-Fold Cylinders” to
lower the wing sections onto the wing support
stands located on the trailer assembly.
TRANSPORT
RIDERS
TRANSPORT SAFETY
• Use only a drawbar pin with a mechanical
retainer, and a safety chain.
• Clean the SMV sign, lights and reflectors before
starting.
• Always use hazard flashing lights on tractor
unless prohibited by law.
• Travel at a safe speed. Slow down when
cornering on rough roads, and pull off to the
side of the road when meeting traffic.
• Under no circumstances should
there ever be riders while the
Strawmaster®is in transport.
4
1 432
1
2
3
TO CONVERT TO TRANSPORT POSITION

-13-
142781 - Strawmaster 700 Narrow (13-February-2020)
Service & Maintenance
GREASING
Use an SAE multipurpose grease with extreme
pressure (EP) performance. Also acceptable is an
SAE multipurpose lithium base grease.
1. Use only a hand-held grease gun for all
greasing.
2. Wipe grease fitting with a clean cloth before
greasing, to avoid injecting dirt.
3. Replace and repair broken fittings immediately.
4. If fittings will not take grease, remove and clean
thoroughly. Also clean lubricant passageway.
Replace fitting if necessary.
5. Inject grease until you see grease being
expelled from the bearing or bushing areas.
SERVICE
Maintenance Checklist
Dailly - 8 Hours
• Hydraulic Fluid Leaks
• Damaged Hoses
• Tire Pressure
Weekly - 25 Hours
• Working Points & Pins
• Tine Wear
• Safety Signs Clean
Annually - 200 Hours
• Bolt Tightness
• Wheel Bearings TORQUE
all hardware
MAINTENANCE SAFETY
• Stop tractor engine, set park brake and remove
ignition key before servicing, adjusting,
repairing or maintaining.
• Be careful when working around or maintaining
a high pressure hydraulic system. Wear
the proper hand and eye protection when
searching for a pin hole leak in a hose or
fitting.
• Place safety stands or large blocks under the
frame before removing the tires or working
beneath the machine.
Sidewind Jacks
Harrow Sections
Auto-Fold
Cylinders (x2)
Wing-Fold
Cylinders (x2)
Hub - Trailer
Wheel (x2)
Ratchet
Jacks (x2)
Center Frame
& Wing
Joint Pins
CHECK TIRE PRESSURE
Cart/Trailer Tires:
12.5L x15 - 12 PLY 90 PSI (620 kPa)
Previous Tire:
12.5L x15 - 8 PLY 32 PSI (220 kPa)

-14-
142781 - Strawmaster 700 Narrow (13-February-2020)
Service & Maintenance
TORQUE SPECIFICATIONS
CHECKING BOLT TORQUE
The tables shown below give correct torque values
for various bolts and capscrews. Tighten all bolts to
the torques specified in chart unless otherwise noted.
Check tightness of bolts periodically, using bolt torque
chart as a guide. Replace hardware with the same
strength (Grade/Class) bolt.
IMPERIAL TORQUE SPECIFICATIONS
(based on “Zinc Plated” values)
SAE-5 SAE-8
Size Grade 5 Grade 8
lb.ft (N.m) lb.ft (N.m)
1/4” 7 (10) 10 (14)
5/16” 15 (20) 20 (28)
3/8” 25 (35) 35 (50)
7/16” 40 (55) 60 (80)
1/2” 65 (90) 90 (120)
9/16” 90 (125) 130 (175)
5/8” 130 (175) 180 (245)
3/4” 230 (310) 320 (435)
7/8” 365 (495) 515 (700)
1” 550 (745) 770 (1050)
1-1/8” 675 (915) 1095 (1485)
1-1/4” 950 (1290) 1545 (2095)
1-3/8” 1250 (1695) 2025 (2745)
1-1/2” 1650 (2245) 2690 (3645)
METRIC TORQUE SPECIFICATIONS
(based on “Zinc Plated” values)
8.8 10.9
Size Class 8.8 Class 10.9
lb.ft (N.m) lb.ft (N.m)
M6 7 (10) 10 (14)
M8 16 (22) 23 (31)
M10 30 (42) 45 (60)
M12 55 (75) 80 (108)
M14 90 (120) 125 (170)
M16 135 (185) 195 (265)
M18 190 (255) 270 (365)
M20 265 (360) 380 (515)
M22 365 (495) 520 (705)
M24 460 (625) 660 (895)
M27 675 (915) 970 (1315)
M30 915 (1240) 1310 (1780)
M33 1250 (1695) 1785 (2420)
M36 1600 (2175) 2290 (3110)
Wheel Tightening Procedure
1. Install and hand tighten nuts/bolts.
2. Tighten to approx 20% Torque value using the
10 Bolt Star or CrissCross pattern shown above.
3. Tighten to Full Torque value using the Star or
CrissCross pattern.
4. If applicable, install Rear Locknuts using Wheel
Torque Values.
Wheel Nut/Bolt Torque
Size lb.ft (N.m)
9/16 120-130 (165-175)
5/8 185-190 (250-260)
BOLT PATTERNS
2
1
6
53
4
6 BOLT PATTERN
2
1
34
57
8
8 BOLT PATTERN
1
2
34
5
5 BOLT PATTERN
1
2
3
46
5
79
10 8
10 BOLT PATTERN
WHEEL NUT & WHEEL BOLT TORQUE
Tightening Flare Type Tube Fittings
1. Check flare and flare seat for defects that might
cause leakage.
2. Align tube with fitting before tightening.
3. Lubricate connection and hand tighten swivel
nut until snug.
4. To prevent twisting the tube(s), use two
wrenches. Place one wrench on the connector
body and with the second tighten the swivel nut
to the torque shown.
Hydraulic Fitting Torque*
Size lb.ft (N.m)
1/2 34 (46)
3/4 75 (100)
7/8 90 (122)
* The torque values shown are based on
lubricated connections as in reassembly.
HYDRAULIC FITTING TORQUE
HARDWARE/HOSE SPECIFICATIONS
Unless otherwise stated:
• Hardware - Hex, Plated GR5 UNC or P8.8 (metric)
• Hydraulic Hoses - 3/8 & 1/2, ends come with
3/4 JIC female swivel.
TORQUE
all hardware

-15-
142781 - Strawmaster 700 Narrow (13-February-2020)
Service & Maintenance
WHEEL HUB REPAIR
WHEEL NUT / BOLT TORQUE
1. The Recommended 9/16 wheel nut/bolt torque for
this implement is 120-130 lb.ft (165-175 N.m)
2. When attaching the wheel, tighten to this
specifications. Check again after approximately
500 revolutions and re-tighten as required.
3. Check wheel bolts twice annually to ensure proper
bolt torque.
Spindle
Inner Cone
Valve Stem
Wheel Nuts
Rim
Tire
Inner Cup
Hub
Dust Seal
Outer Cone
Outer Cup
Cotter
Pin
Slotted Nut
Washer
Dust Cap
COMMON WHEEL AND
HUB COMPONENTS
CHECK TIRE PRESSURE
Cart/Trailer Tires:
12.5L x15 - 12 PLY 90 PSI (620 kPa)
Previous Tire:
12.5L x15 - 8 PLY 32 PSI (220 kPa)
ASSEMBLY
1. If cups need replacing, be
careful to install them gently
and evenly into hub until they
are fully seated.
2. Apply a thick wall of grease
inside hub. Pack grease in cones.
3. Install dust seal as illustrated, and inner cone.
4. Position hub onto spindle and fill surrounding
cavity with grease.
5. Assemble outer cone, washer and nut.
6. Tighten nut while rotating hub until there is a
slight drag.
7. Turn nut back approximately 1/4 turn to
align cotter pin hole with notches on nut.
Note: Hub should rotate freely. If not, repeat
step 6.
8. Install cotter pin and bend legs sideways over
nut.
9. Fill dust cap half full of grease and gently tap
into position.
10. Pump grease into hub through grease fitting
until lubricant can be seen from dust seal.
IMPORTANT:Be sure to block up unit
securely before removing tires.
DISASSEMBLY
1. Carefully pry off dust cap.
2. Remove cotter pin from nut.
3. Remove nut and washer.
4. Pull hub off spindle.
5. Dislodge the inner cone
bearing and dust seal.
6. Inspect cups that are press
fitted into hub for pits or
corrosion and remove if
necessary.
7. Inspect and replace defective
parts with new ones.
Previously
Wheel Bolts
& Lock Nuts

-16-
142781 - Strawmaster 700 Narrow (13-February-2020)
Service & MaintenanceService & Maintenance
5
HYDRAULIC CYLINDER REPAIR
c) Use a screwdriver or a finger to hold one end
of the ring in the groove while fitting the other
end of the ring into the groove. The tips should
snap in together. Ensure it is secure and fully
seated before the next step.
IMPORTANT: It is important to ensure the
removal ring is completely in the groove
before pulling the rod out. If the ring sticks out
it will get stuck between the head and tube.
Note: Excessive force will not overcome a
jammed ring and could damage the cylinder.
b) Completely remove rod and head from tube.
6. a) Extend the rod to pull head out of tube. If the
rod does not pull out easily, push the head back
in and ensure the ring is properly in the groove.
Replace ring if necessary.
7
7. Remove plastic removal ring from the cylinder
tube.
6
Plastic Ring
Inner Wire Ring
5. Take the plastic removal ring from the seal kit:
a) Straighten the ring and remove any kinks or
excessive curl to make installation easier and
prevent it from falling out.
b) Insert the removal ring into the internal
groove with the feathered
end pointing into the tube.
1. Retract the rod assembly.
2. Remove the external steel wire ring.
REPAIRING A WIRE RING CYLINDER
3. Remove any dirt that may have accumulated on
the cylinder head.
4. Using the mallet and punch, push the head
into the cylinder tube until the
internal tube groove
is fully exposed.
This will also move the
internal wire ring into
its removal position.
4
2
External Ring
Inner Ring
Initial Ring Positions
4
Internal Groove
Inner Ring
Outer
Wire Ring
(Removed)
v1.0
Set Screw
Locking Ring
Wire Ring
Threaded
Head
Threaded
Head
Types of Cylinders
(Wire Ring / Threaded Head)
PREPARATION
When cylinder repair
is required, clean off
unit, disconnect hoses
and plug ports before
removing cylinder.
When removed, open
the cylinder ports and
drain the cylinder's
hydraulic fluid.
Examine the type of
cylinder. Make sure
you have the correct
tools for the job.
You may require the
following tools:
• Proper Seal Kit
• Rubber Mallet
• Screwdriver
• Punch
• Pliers
• Emery cloth
• Torque Wrench
