MERIDIAN SERIES® HEATED ROLL-INS
Project __________________________
Item____________________________
Quantity _________________________
CSI Section 11400
MERIDIAN SERIES®
Heated Roll-Ins
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.deleld.com
Phone: [phone]
Fax: [phone]
Email: info@deleld.com
Approval _________________
Date____________________
MHRI2-G
SPECIFICATIONS
Exterior: Cabinet front and shroud shall be 22-gauge
stainless steel. Exterior sides shall be aluminum. Facing
of shroud shall be easily removable without the use of
tools.
Cabinet interior shall be anodized aluminum. Bottom
& top of liner shall be die-stamped to provide radius
corners and a recessed bottom. Cabinet shall be
fully insulated with high-density foamed in place
polyurethane.
Doors: Solid doors shall have a 22-gauge stainless steel
exterior & anodized aluminum interior liner. Doors shall
be fully insulated with high density foamed in place
polyurethane. Each door shall have two self-closing,
cam-lift style hinges. Doors shall be easily removable
without use of tools. Door gaskets shall be magnetic
snap-in style to allow simple replacement. Door handles
shall be recessed.
Glass doors shall be constructed with a combination of
extruded aluminum and PVC and are provided with a
magnetic gasket and shall utilize insulated double-pane
construction. Glass doors shall be provided with self-closing,
cam-lift style hinges, and shall be easily removable without
the use of tools. Mechanical controls shall be located behind
a removable shroud facing.
Dual Voltage Models Only: Electrical connections shall
be 115/208-240 volt, 60 hertz, single phase, and must be
hard-wired to the junction box located on top of the unit.
Heating Assembly: Cabinets to be designed to maintain
temperature up to 200ºF. Fin strip heating element. High
speed blower to provide uniform airow in cabinet 3ºF
variability. Removable/replaceable heating system. No
exposed elements inside cabinet. Fan and heating elements
service accessible without tools. Temperature to be
controlled by an adjustable electronic thermostat. Night
switch in front.
NOTES: Bottom to be reinforced with 14-gauge
channels. All units to be supplied with easily attachable
16-gauge stainless steel ramps, one per door opening.
Wiper gasket shall be provided on bottom of door for
seal to ramp.
MODELS:
 MHRI1-S Single section  MHRI2-S Two section
Solid full height door Solid full height doors
 MHRI1-G Single section  MHRI2-G Two section
Glass full height door Glass full height doors
STANDARD FEATURES
• Built in door locks
• Durable stainless steel doors and shroud, for lasting good
looks
• New high-density foam insulation cuts energy costs
• Big, easy grip handles are easy to nd, don’t intrude into
kitchen trafc
• Attractive aluminum side panels are easy to clean and
corrosion resistant
• Heavy-duty hinges with stay open feature
• Heating system is located outside the food zone, more
space for product storage
• Easy to read dial thermometer
• Tri seal door gaskets lower energy costs with a unique
insulating design
• Aluminum interior stands up to food acids without
corroding
• Lots of interior storage space for the money
OPTIONS AND ACCESSORIES
 Stainless steel exterior sides
 Stainless steel interior
 Door and end laminate
 Stainless steel exterior back
 Digital thermometer
 220/50/1 electrical

Meridian Series® Heated Roll-Ins
Model #__________
CSI Section 11400
Printed in the USA.
01/04
DSMRIH
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.deleld.com
Phone: [phone]
Fax: [phone]
Email: info@deleld.com
MECHANICAL DATA
CU. FT. SHELVES # of RACK UNIT BTU/HR CAB BTU/HR SHIP NEMA
MODEL VOLTAGE AMPS STORAGE SQ. FT. SHELVES CAP. H.P. LOAD SYSTEM CAP WEIGHT PLUG
STAINLESS
MHRI1-S 120/208-240 9.0 36.15 NA NA 1 NA NA NA 434 NA
MHRI2-S 120/208-240 16.0 74.72 NA NA 2 NA NA NA 616 NA
GLASS
MHRI1-G 120/208-240 9.0 36.15 NA NA 1 NA NA NA 449 NA
MHRI2-G 120/208-240 16.0 74.72 NA NA 2 NA NA NA 676 NA
PLAN VIEW MHRI1-S PLAN VIEW MHRI2-S
34”
86.4cm
34”
86.4cm
34”
86.4cm
66”
167.6cm
ELEVATION VIEW MHRI2-S
ELEVATION VIEW MHRI1-S
32.25”
81.9cm
END/SECTION VIEW
ALL MODELS
89”
226.1cm
89”
226.1cm
12.14”
30.8cm
70.75”
179.1cm
28.20”
71.6cm
73.28”
186.1cm
34”
86.4cm
PERSPECTIVE
VIEW
ALL MODELS
29.12”
74cm
Ramp Width
3.80”
9.7cm
29.75”
75.6cm
37.68”
95.7cm
DOOR CLEARANCE DETAIL
ALL MODELS
MECHANICAL DETAIL
Ramp dimensions
see below
5.92”
15.04cm
1.06”
2.69cm
RAMP DIMENSIONS
(Not to scale)
