Delta VIS100-30G12D User manual

i
VIS100 Operating Manual V1.0
Table of Contents
Chapter 1: Components and Specifications
1.1 Packaging and Optional Parts ..........................................................................................1-1
1.2 Sensor Unit .........................................................................................................................1-2
1.2.1 Specifications .............................................................................................................1-2
1.3 Camera and Lens Selections ............................................................................................1-3
Chapter 2: Input and Output Interface
2.1 Input/Output (I/O) Terminal Block .....................................................................................2-1
2.2 Grounding and Installation ................................................................................................2-2
2.2.1 Grounding ..................................................................................................................2-2
2.2.1 Installation .................................................................................................................2-2
Chapter 3: Basic Operation
3.1 Application Names and Functions .....................................................................................3-1
3.2 GUI .......................................................................................................................................3-3
3.2.1 Main Page .................................................................................................................3-4
3.3.2 Menu Page..................................................................................................................3-5
3.3.3 Language ...................................................................................................................3-8
3.3.4 Information Page.........................................................................................................3-9
3.3.5 Statistics Page.............................................................................................................3-9
Chapter 4: Inspection Setting Process
4.1 Getting Start .........................................................................................................................4-1
4.1.1 Camera Default IPAddress .......................................................................................4-1
4.1.2 Open the Application...................................................................................................4-1
4.1.3 Log in to the Application ............................................................................................4-2
4.1.4 Basic Operation...........................................................................................................4-2
4.2 Configuration .......................................................................................................................4-3
4.2.1 Camera ......................................................................................................................4-3
4.2.2 Communication ...........................................................................................................4-4
4.2.3 Account .....................................................................................................................4-6
4.2.4 Mode .........................................................................................................................4-7
4.2.5 Camera IP .................................................................................................................4-8
4.2.6 Export/Import Settings ...............................................................................................4-8

ii
Chapter 5: Inspection tools
5.1 Region of Interest (ROI) .....................................................................................................5-1
5.2 Filters ...................................................................................................................................5-2
5.3 Barcode ...............................................................................................................................5-3
5.3.1 1D Barcode ................................................................................................................5-3
5.3.2 Data Matrix Code (DMC) .............................................................................................5-4
5.3.3 QR Code ....................................................................................................................5-6
5.3.4 Micro QR Code ..........................................................................................................5-7
5.4 Blob ......................................................................................................................................5-9
Chapter 6: Troubleshooting
6.1 Troubleshooting Steps .....................................................................................................6-1

Foreword
VIS100 Vision Sensor Operating Manual
Thank you for your purchase of the high performance Delta Vision Sensor VIS100 from Delta Electronics
Inc. This operating manual covers the component description, installation, operation, troubleshooting,
peripherals, and maintenance.
To guarantee proper installation and operation of the system, please carefully read this operating manual
and safe keep it for future reference.
Precautions
1. Please check the signal connections, for example input voltage and polarity, before powering on to
prevent damages due to an incorrect voltage input level.
2. Please check that system power is turned off before inspecting the input power source or connecting
the wires. Do not touch the terminals or connect the wires while system power is turned on; as this runs
the risk of electric shock.
3. Please do not disassemble or modify the internal components of the controller.
4. Keep away from interference sources such as high voltage and high frequency noise during
installation.
5. Avoid system operation under the following situations:
(a) Excessive dust and corrosive gasses; (b) high temperature, high humidity, and high levels of
radiation; (c) shock and impact; (d) exposure to direct sunlight
6. Check the ground terminal to the power source for proper connection. Check the terminals for secure
connection.
7. Only use the blower to remove dust from the camera sensor or lens. Do not blow using the mouth to
avoid getting moisture on the components.
8. Gently wipe dust off of the lens using a lens cloth to remove attached dirt. Using excessive force or
inappropriate materials may scratch the lens.

Chapter 1 Components and Specifications
VIS100 Vision Sensor Operating Manual
1-1
Chapter 1
Components and Specifications
1.1Packaging and Optional Parts
A complete vision system requires the following basic components:
1) Vision sensor unit and 0.4 m cable
2) Lens (optional, first set is included with the 8mm lens)
1.1.1 Unit Packaging
The following is included:
1) 0.3M (640 x 480 pixels) Vision sensor: VIS100-30G12D / VIS100-30GBLD
2) 0.4 m TCP/IP cable: VIS-CA04S

Chapter 1 Components and Specifications
VIS100 Vision Sensor Operating Manual
1-2
1.2 Sensor Unit
1.2.1 Specifications
General Specifications
Input power DC 9~30 Voltage
Operation voltage 90%~110% of rated voltage
Power consumption Less than 0.2A
Ingress Protection Rating IP55
Operating temperature -20°C ~+5°C
Functional Specifications
Camera
Type Mono
Resolution 0.3M pixel: 640(Horizontal) * 480(Vertical)，90fps
Exposure 200~65535 (us)
Lens mount M12
Memory DDR3 512MB & 4GB Flash
Inspection
window
Inspection
item Code Reader、Blob
ROI Type Rectangle、Circle
Pre-processing Total 5 pcs per each inspection tools
Mode Gauss, Erosion, Dilation, Mean, Median, Range, Mirror, Rotate, Invert,
Opening, Closing, Sharpen, Correction, Binary, Histo-Equalization.
Communication port Ethernet(10BASE-T)
Display
Monitor
screen Browser (PC or Smart phone)
Operating
language Simplified Chinese, English, Japanese, Korean
Flashlight control Internal trigger

1章部件名稱及規格
VIS100 Vision Sensor Operating Manual
1-3
1.3 Camera and Lens
VIS100 Sensor includes 0.3M pixel CMOS sensor, lens is the 8mm (M12, C mount) specification.
Before selecting the lens, please confirm the field of view and working distance between the lens and test
object. Refer to the table below for a suitable lens.
Field of view
(mm)
Horizontal
(H)*Vertical (V)
Focal
length
8mm
Focal
length
12mm
Focal
length
16mm
Focal
length
25mm
Focal
length
35mm
Focal
length
50mm
Resolution
um/pixel
Dis. R Dis. R Dis. R Dis. R Dis. R Dis. R
640
* 480
1024
* 768
1000(H)*750(V) 1667 0 1562 977
800(H)*600(V) 1333 0 2013 0 1250 781
600(H)*450(V) 1000 0 1513 0 2015 0 938 586
500(H)*375(V) 833 0 1263 0 1683 0 781 488
400(H)*300(V) 667 0 1013 0 1348 0 2181 0 625 391
350(H)*263(V) 583 0 888 0 1181 0 1906 0 547 342
300(H)*225(V) 500 0 763 0 1014 0 1631 0 2253 0 469 293
250(H)*188(V) 417 0 638 0 847 0 1356 0 1878 0 391 244
225(H)*169(V) 375 0 575 0 764 0 1218 0 1690 0 352 220
200(H)*150(V) 333 0 513 0 681 0 1081 0 1503 0 2241 0 313 195
175(H)*131(V) 292 0 450 0 597 0 943 0 1315 0 1963 0 273 171
150(H)*113(V) 244 0 389 0 514 0 806 0 1128 0 1686 0 234 146
140(H)*105(V) 228 0 362 0 480 0 751 0 1053 0 1575 0 219 137
130(H)*98(V) 210 0 334 0 444 0 696 0 978 0 1464 0 203 127
120(H)*90(V) 193 0 307 0 407 0 641 0 903 0 1353 0 188 117
110(H)*83(V) 175 0 280 0 371 0 586 0 828 0 1242 0 172 107
100(H)*75(V) 158 0 253 0 336 0 532 0 753 0 1131 0 156 97
90(H)*68(V) 142 0 227 0 300 0 477 0 678 0 1020 0 141 88
80(H)*60(V) 124 0 200 0 265 0 423 0 603 0 909 0 125 78
75(H)*56(V) 115 0.5 183 0 247 0 397 0 565 0 853 0 117 73
70(H)*53(V) 107 0.5 176 0 230 0 370 0 528 0 798 0 109 68
65(H)*49(V) 98 0.5 160 0 212 0 344 0 490 0 742 0 102 63
60(H)*45(V) 90 0.5 147 0 193 1 316 0 453 0 687 0 94 59
55(H)*41(V) 81 0.5 133 0.5 175 1 290 0 417 0 631 0 86 54
50(H)*38(V) 72 1 120 0.5 158 1 262 0 378 0 576 0 78 48.8
45(H)*34(V) 63 1 106 0.5 142 1.5 235 0 341 0 520 0 70 43.9
40(H)*30(V) 55 1 93 1 123 1.5 208 0 304 0 465 0 63 39.1
35(H)*26(V) 47 1 79 1 108 1.5 183 1 268 0 409 0 55 34.2
32.5(H)*24.4(V) 42 1 72 1 99 2 168 2 247 0 382 0 51 31.7
30.0(H)*22.5(V) 37 1.5 66 1.5 89 2 153 2 229 0 354 0 46.9 29.3

Chapter 1 Components and Specifications
VIS100 Vision Sensor Operating Manual
1-4
Field of view
(mm)
Horizontal
(H)*Vertical (V)
Focal
length
8mm
Focal
length
12mm
Focal
length
16mm
Focal
length
25mm
Focal
length
35mm
Focal
length
50mm
Resolution
um/pixel
Dis. R Dis. R Dis. R Dis. R Dis. R Dis. R
640
* 480
1024
* 768
27.5(H)*20.6(V) 33 1.5 58 1.5 80 2 139 2 211 0 325 0 43.0 26.9
25.0(H)*18.8(V) 28 1.5 53 2 72 2 126 2 189 5 298 0 39.1 24.4
22.5(H)*16.9(V) 23 2 45 2 111 5 170 5 272 0 35.2 22.0
20.0(H)*15.0(V) 19 2 40 2 94 5 153 5 243 0 31.3 19.5
18.0(H)*13.5(V) 16 2 33 2 87 5 137 5 221 0 28.1 17.6
17.0(H)*12.8(V) 14 2 81 5 130 5 210 5 26.6 16.6
16.0(H)*12.0(V) 40 5 76 6 122 5 199 5 25.0 15.6
15.0(H)*11.3(V) 36 5 70 6 116 5 189 5 23.4 14.6
14.0(H)*10.0(V) 23 5 32 5 64 7 106 10 177 5 21.9 13.7
13.0(H)*9.8(V) 21 5 29 6 59 7 99 10 166 5 20.3 12.7
12.0(H)*9.0(V) 18 5 25 6 54 8 92 10 153 10 18.8 11.7
11.0(H)*8.3(V) 15 5 23 7 49 9 85 15 145 10 17.2 10.7
10.0(H)*7.5(V) 13 5 19 8 44 10 77 15 133 10 15.6 9.77
9.0(H)*6.75(V) 11 6 16 9 39 11 68 15 122 15 14.1 8.79
8.0(H)*6.00(V) 8 7 13 10 34 13 63 20 111 20 12.5 7.81
7.5(H)*5.63 (V) 8 7 10 10 31 14 58 20 104 20 11.7 7.32
7.0(H)*5.25(V) 7 11 27 16 53 20 99 25 10.9 6.84
6.5(H)*4.88(V) 25 18 51 25 92 25 10.2 6.35
6.0(H)*4.50(V) 23 20 46 25 88 30 9.38 5.86
5.5(H)*4.13(V) 21 22 44 30 84 35 8.59 5.37
5.0*H)*3.75(V) 17 24 39 30 76 40 7.81 4.88
4.5(H)*3.38(V) 14 26 35 35 72 45 7.03 4.39
4.0(H)*3.00(V) 12 30 33 40 66 50 6.25 3.91
3.5(H)*2.63(V) 9 34 27 45 60 60 5.47 3.42
Dis. is the working distance and R is the size of the extension circle.
When the depth of field increases, the range of focus also increases. The following conditions will affect the
depth of field.
The longer the extension ring, the shallower the depth of field will be; thus the depth of field will
increase when the shorter extension ring is used.
Longer working distance results in a deeper depth of field.
Smaller aperture results in a deeper depth of field.
Shorter focal distance of the lens results in a deeper depth of field.

Chapter 2Input and Output Interface
VIS100 Vision Sensor Operating Manual
2-1
Chapter 2
Input and Output Interface
VIS100 input and output interfaces include the following:
1) I/O
2) Ethernet
The pins and wiring connections are defined and detailed below.
2.1 Input / Output (I/O) Terminal Block
Wiring the Sensor:
Connect and secure the I/O Cable to the I/O Cable connector located on the bottom of the Vision Sensor.
The following table lists the I/O Cable signal connections.
Serial No. Color Signal Description
1
Red
24V
Voltage Supply Positive Pole
2
Yellow
0V
Voltage Supply Negative Pole
3
Black
COMM
Common contact
4
Grey
IN1
Input 1
5
Brown
IN2
Input 2
6
White
OUT1
Output 1
7
Green
OUT2
Output 2
8
Orange
GND
ISO_GND

Chapter 2 Input and Output Interface
VIS100 Vision Sensor Operating Manual
2-2
Input circuit diagram Output circuit diagram
2.2 Grounding and Installation
2.2.1 Grounding
Precautions
Do not connect or disconnect the wires while system is powered on.
The grounding wire should be at minimum length using the regulated wire gauge. The grounding
resistance must be under 100Ω.
Please ground the grounding terminal using the third method. Do not directly connect to other power
devices.
2.2.2 Installation
Please reserve at least 50mm above and 30mm left/right of the controller for proper ventilation. Excessive
operating temperature due to insufficient cooling will damage the sensor.

Chapter 3 Basic Operation
VIS100 Vision Sensor Operating Manual
3-1
Chapter 3
Basic Operation
3.1 Application Names and Functions
You can remotely setup and configure your 1D/2D reader or Absence/Presence Checker on your PC or
mobile device via Wi-Fi using the web browser. This allows you to see the inspection process in real-times
and adjust the parameters anywhere in your factory.
General Functions
Icon
Name
Function
Login Logs into the software to operate the camera with this application.
Information Displays basic camera information with application version, camera
ID, and license type for this application and manufacture date.
Statistics Displays statistics for the total camera triggered times, total code read
times, total code unread times, total pass verification and failed
verification times.
Home Returns to Main page from any page.
Return Returns to the previous page.
Menu (*1) Opens the application menu for configuration. The top icon appears
on a Smartphone, and the bottom icon appears on a PC.
Run repeat (*1) Runs repeatedly with the current settings.
Run once (*1) Runs once with the current settings.
Stop (*1) Stops the running process. This function stops the next process to
execute.
Live cam (*1) Shows the live image with camera capture.
Save (*1) Saves all the settings except the camera IP and account
name/password. The camera IP and account name/password are
saved in the Configuration function.
Clear statics (*1) Clears all statistics.

Chapter 3 Basic Operation
VIS100 Vision Sensor Operating Manual
3-2
Inspection Tools
Icon
Name
Inspection Tool
Filter (*1)(*2) Filter Tool. Uses one or more filters to process the image for better
results.
Barcode (*1)(*3) Barcode reader tool for reading barcodes.
Data Matrix (*1)(*4) Data Matrix code reader tool for reading data matrix codes.
QR Code (*1) (*4) QR code reader tool for reading QR codes.
Micro QR Code
(*1) (*4) Micro QR code reader tool for reading micro QR codes.
Blob (*1) (*5) Blob/Object count tool for counting the total number of blobs.
Matching (*1)(*5) Pattern Matching tool for matching a pre-defined pattern.
Mapping (*1)(*8) Mapping tool for mapping the image with a checkerboard pattern.
Configuration Functions
Icon
Name
Inspection Tool
Camera settings
(*1) Configures camera image size, light, gain, exposure, and hardware
trigger.
Communication
settings (*1) Configures I/O and network communications.
User account
settings (*1) Adds/deletes/changes username and password.
Mode selector
(*1)(*6) Switches between code reading and blob detection.
IP address
settings (*1) Configures camera IP address, mask, gateway, and DNS.
Import/Export
settings & image
(*1)(*7)
Imports settings or exports images and settings.
Camera settings
(*1) Configures camera image size, light, gain, exposure, and hardware
trigger.
Communication
settings (*1) Configures I/O and network communications.

Chapter 3 Basic Operation
VIS100 Vision Sensor Operating Manual
3-3
(*1) You must log in to operate.
(*2) You need a license for this function.
(*3) You need a Complete license or 1D license or 1D/2D license for this function.
(*4) You need a Complete license or 2D license or 1D/2D license for this function.
(*5) You need a Complete license or Absence/presence license for this function.
(*6) The mode appears according to your license.
(*7) Export settings are available for PC browsers which support HTML5 API BLOB.
(*8) You need a Complete license or Alignment license for this function.
3.2 GUI
Both Smartphones and PCs show the application Main page after you enter the camera IP address in the
browser. You can view only basic information (Statistics, Camera Information and Main page information)
without logging in.
The following lists the differences in the user interface between the Smartphone and the PC Main
pages.
Smartphone: Menu and Statistics appear on two separate pages.

Chapter 3 Basic Operation
VIS100 Vision Sensor Operating Manual
3-4
PC: The user interface has three appearances depending on the browser window width. Window
width below 1000 px shows only part of the page and hides both Menu and Statistics. Window width
between 1000 px and 1300 px shows the Menu on the left side. Window width larger than 1300 px
shows the Menu on the left and Statistics on the right of the window.
3.2.1 Main Page
The information showing under the “Delta” logo in the Main Page
Name : Name of the camera (set in Camera Setting)
Result:Result of the inspection
Cycle Time: Time from after an image is captured to the end of the process

Chapter 3 Basic Operation
VIS100 Vision Sensor Operating Manual
3-5
3.2.2 Menu Page
After you log in with username and password, the menu or menu button will show on.
PC
1) The menu is on the left side of the screen when the browser is in full screen width
2) The menu contains inspection tools that you can use in the process according to your license. To
activate a tool, select the check box next to the tool (check barcode as shown).
PC menu (Configuration)

Chapter 3 Basic Operation
VIS100 Vision Sensor Operating Manual
3-6
3) The Configuration page contains all the camera settings.
Smartphone
1) To access the menu, tap the top left button (left figure) on the screen, and the menu (right figure) wikk
be shown.
PC menu (Application)

Chapter 3 Basic Operation
VIS100 Vision Sensor Operating Manual
3-7
2) The Application menu contains the inspection tools that you can use to process an image according to
your license. To activate an application, select the check box next to the tool (check barcode as
shown).
3) The Configuration page contains all the camera settings.

Chapter 3 Basic Operation
VIS100 Vision Sensor Operating Manual
3-8
3.2.3 Language
The application supports four languages: Simplified Chinese, English, Japanese, Korean.
PC: You change the language by clicking the Language button at the top left of the menu page
Smartphone: You can change the language by tapping the Language button in the Main page.

Chapter 3 Basic Operation
VIS100 Vision Sensor Operating Manual
3-9
3.2.4 Information Page
The Information page contains the following basic information.
1) Version: Application version.
2) ID: Camera identification number.
3) License: Application license type.
4) Date: Manufacture date (DD/MM/YYYY format).
3.2.5 Statistics Page
The Statistics page contains the following information.
1) Total Triggered: Total number of times the camera is triggered.
2) Total Read: Total number of times the code is read successfully.
3) Total Unread: Total number of times the code isn’t read successfully.
4) Pass Verification:Total number of times for passed verification.
5) Fail Verification: Total number of times for failed verification.
6) : Resets all statistics to zero.

Chapter 4 Inspection Setting Process
VIS100 Vision Sensor Operating Manual
4-1
Chapter 4
Inspection Setting Process
4.1 Getting Start
4.1.1 Camera Default IP Address
The following table lists the default camera IP address (for camera from Inspiraz Technology).
Name Address
IP 192.168.1.10
Mask 255.255.255.0
Gateway 192.168.1.1
DNS 192.168.1.1
4.1.2 Open the Application
You must use a web browser to open this application. Google Chrome is the recommended browser.
Open the web browser and enter the camera IP address to open the application.
(Recommend version：Chrome v.58、Firefox v.51 above)

Chapter 4 Inspection Setting Process
VIS100 Vision Sensor Operating Manual
4-2
4.1.3 Log in to the Application
You must log in to change the camera settings.
1) Open the application on your Smartphone’s or PC’s web browser.
2) Click to open the login page.
3) Enter the Username and Password.
4) Click Login.
Default Username: admin; Default Password: admin
4.1.4 Basic Operation
Live camera
Start: Click once to run the live camera.
Stop: Click again or click the stop button to stop the live camera.
Run
Start: Click to run all the selected inspection tools with the current settings.
Stop: Click to stop the inspections.
Run once
•Start: Click to run all the selected inspection tools and settings once.
