Denver MDA-270 User manual

MDA-270
denver.eu
2022

Please read the safety instructions carefully before using the
productforthefirsttimeandkeeptheinstructionsforfuture
reference.
1. This product is not a toy. Keep it out of reach of children.
2. Keep product out of the reach of children and pets to
avoid chewing and swallowing.
3.Productoperatingandstoragetemperatureisfrom0degree
Celsiusto40degreeCelsius.
Underandoverthistemperaturemightaffectthefunction.
4. Never open the product. Touching the inside electrics can cause
electricshock.Repairsorserviceshouldonlybeperformedby
qualifiedpersonnel.
5.Donotexposetoheat,water,moisture,directsunlight!
6.Pleaseprotectyourearsagainstloudvolume.Loudvolumecan
damageyourearsandriskinhearingloss.
7. Bluetooth wireless technology operates within a range of about
10m(30feet).Themaximumcommunicationdistancemayvary
depending on the presence of obstacles
(people,metalobjects,walls,etc.)ortheelectromagneticenvironment.
8.MicrowavesemittingfromaBluetoothdevicemayaffectthe
operationofelectronicmedicaldevices.
9.Theunitisnotwaterproof.Ifwaterorforeignobjectsentertheunit,
itmayresultinfireorelectricshock.Ifwateroraforeignobjectenters
theunit,stopuseimmediately.
10.OnlychargewithsuppliedAdaptor.Thedirectplug-inadapteris
usedasdisconnectdevice,thedisconnectdeviceshallremainreadily
operable.So,makesurethereisspacearoundthepoweroutletfor
easy access.
11. Do not use non original accessories together with the product as
thiscanmaketheproductfunctionalityabnormal.
Safety information
ENG 1

MICRO SYSTEM MDA-270
LOCATION OF CONTROLS
1. LCD DISPLAY
2. REMOTE SENSOR
3. CD DOOR
4. AUX IN
5. 3.5MM HEADPHONES JACK
6. POWER / STANDBY
7. USB PORT
8. SPEAKER
9. VOLUME +/-
10. SOURCE
11. MENU / INFO
12. MODE / PROG
13. FOLDER
14. STOP / ENTER
15. TUNE - / SKIP -
16. PLAY / PAUSE / SCAN / PAIR
17. TUNE + / SKIP +
18. OPEN / CLOSE
19. DC IN (9V 2A)
20. SPEAKER SOCKET “R”
21. SPEAKER SOCKER “L”
22. ANTENNA
ENG 2
12
4 5 6
7
8
3
9
10
11 12 13 14 15 16 17
18
19 20 21
22

ENG 3
25
23 24 26
27
28
29
30
31
32
33
34
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
35
59 60
52
53
54
55
56
57
58
61
REMOTE CONTROL
23. POWER /STANDBY
24. 2
25. 3
26. SOURCE
27. 1
28. 4
29. 7
30. 0
31. FOLDER +
32. FOLDER –
33. INFO
34. SKIP - (BT)
35. OPEN / CLOSE
36. EQUALIZER
37. X-BASS
38. SLEEP
39. MONO / ST
40. TUNE + / SKIP +
(RADIO, CD, USB)
41. RANDOM
42. MUTE
43. VOLUME +
44. VOLUME -
45. 5
46. 8
47. MEMORY
48. TUNE - / SKIP -
(RADIO, CD, USB)
49. REPEAT
50. SCAN
51. SKIP + (BT)
52. 6
53. 9
54. CH+
55. ENTER
56. CH-
57. MENU
58. PLAY / PAUSE (BT)
59. STOP (CD, USB)
60. PLAY / PAUSE (CD, USB)
61. BATTERY COMPARTMENT
1 x 3V size “CR2025” (Battery included)

POWER SUPPLY - Connect the power cord to DC IN on the device.
Connect the power adapter to a suitable household power outlet.
Press the “POWER” button to turn the appliance On or Standby.
Press the “SOURCE” button to enter DAB, FM, Bluetooth, CD or USB mode
VOLUME - Adjust the volume level with the “VOLUME” control.
SETTING THE CLOCK - Date and Time is automatically set once the unit
receives DAB radio broadcast signals (and when such info is available).
DISPLAYING TIME OR DATE INFORMATION
Press the “INFO” button in DAB, FM, Bluetooth, CD or USB modes
DAB OR FM RADIO
1. Press the “SCAN” button for automatic scan; radio stations with suitable
signal strength are automatically saved. After the search is complete,
thefirstsavedstationisplayedautomatically.
2. Press or press and hold the “TUNE+/-” button to select the station.
*If the signal is weak or distorted, try to align the telescopic antenna
vertically.
RDS INFORMATION
Press the “INFO” button to display the following information
(if Radio Data System “RDS” is available).
- Radio Text
- Program Type (such as NEWS, SPORT, POP M)
- Name
- Mono
- Time
- Date
DISPLAYING DAB INFORMATION
Press the “INFO” button to display the following information (if available).
- Frequency
- Ensemble Name
- Time
- Date
STORING PRESET STATIONS - 30 memory presets for DAB/FM
1. Press the “TUNE+/-” button to select DAB or FM radio mode.
2. Press and hold the “PROG” button to enter preset mode.
3. Press the “SKIP+/-” button to select the preset number.
4. Press “ENTER” button to save the desired instruction.
Repeat steps 1 - 4 to save more preset stations.
ENG 4

RECALL PRESET STATIONS
1. Press the “PROG” button to enter preset recall mode.
2. Press the “SKIP+/-” button to select the preset station.
3. Press the “ENTER” button to recall the preset station.
DAB MENU
Press and hold the “MENU” button.
Press the “SKIP+/-” button to select the desired information.
Press “ENTER” button to save the desired instruction.
(*The asterisk behind the option indicates the current setting.)
1. Full Scan
2. Manual Tuning
3. DRC (Dynamic Range Control) - off / low / high
DRC On or Off allow for a degree of compensation for the differences
in the dynamic range between radio stations.
4. Prune - No: Return to the previous menu / Yes: Remove invalid
stations form the station list
5. System
Sleep - 15, 30, 45, 60, 90 minutes or off
Alarm
Alarm 1 or 2
Hour
Minute
Duration 15, 30, 45, 60 or 90
Source: BUZZER, DAB, FM, CD or USB
Daily, Once, Weekends or Weekdays
Volume level
Alarm On or Off
When the alarm setting is active, the corresponding alarm icon will be
displayed. After the set time has expired the device will sound an alarm
and light up.
Time - Set Time/Date
Auto Update - Update from DAB, FM or no update
Set 12/24 hour - Set 12/24 hour format
Set Date format - DD-MM-YYYY / MM-DD-YYYY
Backlight
Timeout (10, 20, 30, 45, 60, 90, 120 180 seconds or On)
On level (High, Medium or Low)
Dim level (High, Medium or Low)
Language – English – German – Italian - French
Factory Reset - Yes / No
SW Version - Check the version
ENG 5

FM MENU
Press and hold the “MENU” button.
Press the “SKIP+/-” button to select the desired information.
Press “ENTER” button to save the desired instruction.
(*The asterisk behind the option indicates the current setting.)
1. Scan setting - All Stations: Regardless of the signal strength
/ Strong station only
2. Audio setting - Stereo allowed / Forced mono
3. System - Same as DAB MENU
BLUETOOTH
Turn on the Bluetooth function of your device and
pair “DENVER MDA-270” from the device list.
1. Bluetooth Connected will be shown on the display once successfully
connected.
2. Press and hold the “PAIR” button to disconnect.
During Playback
1. Press the “PLAY/PAUSE” button to play or pause the track.
2. Press the “SKIP+/-” button to skip to the next or previous track.
*Change the volume level on this unit or on your Bluetooth device.
CD and USB playback
1. Insert a CD or connect a USB stick.
2.Theunitautomaticallyreadsandplaysfromthefirsttrack.
3. Press the “PLAY/PAUSE” button to play or pause the track.
4. Press the “SKIP+/-” button to skip to the next or previous track.
5. Press and hold the “SKIP+/-” button to search a position inside the track.
6. Press the “STOP” button to stop playback.
REPEAT (CD / MP3 and USB)
Press the “MENU” button during playback.
Repeat one track
Repeat DIR (Folder)
Repeat all tracks
Intro
Normal Playback (DISC or USB display on)
FOLDER - Press the “FOLDER” button select a folder.
ENG 6

PROGRAM PLAYBACK (CD, CD MP3 or USB)
CD = max 20 tracks
CD MP3 or USB = max 99 tracks
1. Press the “STOP” button.
2. Press the “PROG” button, P01 will show on the display.
3. Press the “SKIP+/-” button too select a track.
4. Press the “PROG” button again to save the selected track.
5. Repeat the steps to program further tracks.
6. Press the “PLAY” button to playback the programmed track list
(“MEM” is shown on the display).
7. Press the “STOP” button twice to cancel the programmed track list
*The repeat function is available for programmed track list.
Aux-in
1. Use a 3.5mm Aux In cable (not included) to connect the Aux in jack
and an external audio player.
2. Control the playback from the external audio player.
3. Adjust the volume level on this unit or on the external audio player.
HEADPHONES JACK - Once connecting headphones to the
3.5mm headphone jack, then the sound from the speakers will be
muted automatically.
ENG 7

Please notice - All products are subject to change without any notice.
We take reservations for errors and omissions in the manual.
ENG 8
Electric and electronic equipment and included batteries contains
materials, components and substances that can be hazardous to your
health and the environment, if the waste material (discarded electric
and electronic equipment and batteries) is not handled correctly.
Electric and electronic equipment and batteries is marked with the
crossedouttrashcansymbol,seenabove.Thissymbolsignifiesthat
electric and electronic equipment and batteries should not be disposed
of with other household waste, but should be disposed of separately.
As the end user it is important that you submit your used batteries to the
appropriate and designated facility. In this manner you make sure that
the batteries are recycled in accordance with legislature and will not
harm the environment.
All cities have established collection points, where electric and electronic
equipment and batteries can either be submitted free of charge at
recycling stations and other collection sites, or be collected from the
households. Additional information is available at the technical
department of your city.
ALL RIGHTS RESERVED, COPYRIGHT DENVER A/S
denver eu.

Hereby, Denver A/S declares that the radio equipment type MDA-270
is in compliance with Directive 2014/53/EU. The full text of the
EU declaration of conformity is available at the following internet address:
denver.eu and then click the search ICON on topline of website.
Write model number: MDA-270. Now enter product page,
and RED directive is found under downloads/other downloads.
Operating Frequency Range:
FM 88-108 MHz
DAB/DAB+ 174.928 - 239.200 MHz
Bluetooth Frequency 2.4GHZ
Max Output Power: 2 x 50 W / 2 x 5 W RMS
