Arthritis rollator
User manual
Version 1.0.0 DE

2
TOMTAR / Bedienungsanleitung Rollator FAKTO+ Arthritis / Version 1.0.0 DETOMTAR / User manual FAKTO+ Arthritis / Version 1.0.0 DE / EN
NOTE
For better visibility find our user
manual also online under
www.dietz-reha.de
as PDF file with zoom function.
USER MANUAL
Thank you for purchasing a
FAKTO+ Arthritis Rollator from DIETZ.
Please read this user manual carefully before rst using the new FAKTO+
Arthritis. It contains important safety instructions and valuable tips on
correctly using and caring for the FAKTO+ Arthritis rollator. If you have any
questions or require additional information, please contact the specialist
retailer which supplied the wheelchair to you.
These operating instructions contain all of the instructions necessary for
adjusting and operating the FAKTO+ Arthritis rollator.

01 Important Information
General information . . . . . . . . . . . . . . . . . . . .4
intended use . . . . . . . . . . . . . . . . . . . . . . . . . .4
Indication . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Contraindication . . . . . . . . . . . . . . . . . . . . . . .4
Signs and symbols . . . . . . . . . . . . . . . . . . . . .5
02 Product description
Scope of delivery . . . . . . . . . . . . . . . . . . . . . . .5
Set up Rollator . . . . . . . . . . . . . . . . . . . . . . . .6
03 Build up the rollator
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Unfolding the rollator . . . . . . . . . . . . . . . . . . .7
Fitting the armrests . . . . . . . . . . . . . . . . . . . . .7
Adjusting armrests & handles . . . . . . . . . . . . .8
Checking for correct assembly . . . . . . . . . . . .8
04 Using the rollator
Folding mechanism . . . . . . . . . . . . . . . . . . . . .9
Brake and parking brake . . . . . . . . . . . . . . . . .9
Readjusting the brakes . . . . . . . . . . . . . . . . . .9
Readjusting the brakes at the cable . . . . . . . .10
05 Accessories/Add ons
Basket (tted as standard) . . . . . . . . . . . . . .10
Rack (tted as standard) . . . . . . . . . . . . . . . .10
Tray (tted as standard) . . . . . . . . . . . . . . . .11
Single hand brake (optional) . . . . . . . . . . . . .11
Add-ons & Accessories of Third-partys . . . . . .11
06 Safety instructions
Safety instructions. . . . . . . . . . . . . . . . . . . . .12
07 Instructions for general use
Servicing / maintenance. . . . . . . . . . . . . . . . .14
Maintainance schedule . . . . . . . . . . . . . . . . .15
Fault-nding and rectication . . . . . . . . . . . .17
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Desinfection . . . . . . . . . . . . . . . . . . . . . . . . .18
Forwarding and reusing. . . . . . . . . . . . . . . . .18
Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Product labelling . . . . . . . . . . . . . . . . . . . . . .19
08 Vendor declarations
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Lifetime. . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Liability. . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
09 Technical data
Dimensions and technical data . . . . . . . . . . .22
Product tests. . . . . . . . . . . . . . . . . . . . . . . . .23
Environmental conditions . . . . . . . . . . . . . . .23
Capture identication data . . . . . . . . . . . . . .23
3
EN
FR
IT
NL
EN
USER MANUAL CONTENTS

GENERAL INFORMATION
This user manual is intended provide all users
and support staff with a basis for ensuring the
safe use of the FAKTO+ Arthritis.
The manual contains information on the prepa-
ration, use, maintenance and servicing of your
rollator. In order to make the most of the device
in a sensible manner and to maintain handling
reliability, you should always comply with the
specied handling instructions. Make sure that
the user manual can always be accessed by the
user.
This user manual is included in the scope of de-
livery. We reserve the right to make changes to
the versions shown in this manual as a result of
technical further development. Reprints, trans-
lations and reproductions of this manual in any
form, in whole or in part, require the written
approval of DIETZ GmbH.
The copyright is owned by the manufacturer.
This user manual is not subject to an updating
service. You can nd out the latest status by
contacting DIETZ GmbH.
INTENDED USE
The FAKTO+ Arthritis is designed for persons
with restricted mobility - especially rheumatism
and arthritis patients - with a maximum body
weight of 120 kg for use as a walking aid and,
to a limited extent, as a seating device for tem-
porary rest.
It is used both domestically as well as in hospi-
tals and is designed exclusively for use on solid
and level indoor surfaces.
The intended use may differ for products which
were manufactured as custom-made device
and which have been labelled as such. In this
case, please refer to the documentation sup-
plied with the product.
INDICATION
The use of the FAKTO+ Arthritis is indicated for:
c Restricted mobility due to a restriction of
the active or passive musculoskeletal
system
c Coordination problems when walking
c Reduced load-bearing capacity
c Rheumatism and Arthirits
CONTRAINDICATION
The use of FAKTO+ Arthritis is unsuitable in the
case of
c Perception disorders
c Extreme imbalance
c with a body weight above 120 kg
The FAKTO+ Arthritis may not be used as a
climbing aid, transport aid for heavy loads or
for similar purposes.
For children FAKTO + Arthritis is not suitable.
4
TOMTAR / Bedienungsanleitung Rollator FAKTO+ Arthritis / Version 1.0.0 DETOMTAR / User manual FAKTO+ Arthritis / Version 1.0.0 DE / EN
01 IMPORTANT INFORMATION

SIGNS AND SYMBOLS
These symbols indicate passages of text that
are helpful for using and operating the product
in every day life.
WARNING
It is mandatory to observe and comply with
warnings.
They inform you of circumstances that could re-
sult in injury and/or damage to the rollator or
surroundings if the warnings are not observed.
NOTE
Tips and advice to simplify using the func-
tions.
SCOPE OF DELIVERY
The scope of delivery of FAKTO+ Arthritis
consist of:
c FAKTO+ Arthritis rollator
c Basket
c Tray
c User manual
c Rack
Optional Accessories:
c One-handed brake
Art. 290107 (left)
Art. 290108 (right)
On reception of your new rollator please check
the delivery for completeness and damage. If
damage is evident, please contact your seller
immediately.
WARNING
Keep foil away from children, there is danger of
suffocation!
WARNUNG
Do not burn the foil! Toxic gases may develop
when burning.
5
EN
FR
IT
NL
EN
01 IMPORTANT INFORMATION 01 IMPORTANT INFORMATION 02 PRODUCT DESCRIPTION

NOTE
The image above is designed to help you clearly
identify the individual components of your
FAKTO+ Arthritis. Therefore, please always refer
to it when reading the user manual.
Grip handle
Armrest
Clamp lever
Locking lever
Brake pads
Front wheel (swivel wheel)
Basket
Main frame
Push handle
T-tube armrest
Seat
Adjusting screw brake
Adjusting screw cable
Brake cable
Brake lever
Rack, plastic
Basket hooks
Type label / Warning notice
Star knob screw for hight adjustment
6
TOMTAR / Bedienungsanleitung Rollator FAKTO+ Arthritis / Version 1.0.0 DETOMTAR / User manual FAKTO+ Arthritis / Version 1.0.0 DE / EN
SET UP ROLLATOR FAKTO+ ARTHRITIS
02 PRODUCT DESCRIPTION

ASSEMBLY
Place the individual parts of your rollator on the
oor. The handlebars are already connected to
the main frame by the brake cables. Place them
to the right and left of the main frame.
Unfolding the rollator
Hold the main frame by the seat's grip hole (1,
pic. 1) and position it on the oor with the front
wheels (swivel wheels). The grip hole must be
on the side facing away from you.
Bend over the main frame and grip the part of
the frame that faces away from you to unfold
the frame (2, pic. 1).
Now you can place the rollator with all four
wheels on the oor and fully unfold it by press-
ing on the seating surface.
1
2
pic. 1
To lock the folding mechanism, fold down the
lever until it engages rmly in the guide (1,
pic. 2).
1
pic. 2
NOTE
To use FAKTO+ Arthritis correctly, it must be ad-
justed to your individual size. You should have
an employee of your medical supply store or
another trained person do this.
Fitting the armrests
Loosen the star screws of the two T-pipes. The
T-pipes can now be inserted into the vertical
tubes of the frame (1, pic. 3).
The clamping levers (3, pic. 3) at the upper end
of the T-pipes must point in the direction of the
front wheels.
Now insert the handlebars into the horizontal
element of the T-pipes from the front (2) so that
the side with the handle and the brakes points
upwards in the direction of travel and x the
clamping lever (3, pic. 3).
Now apply the parking brake by pushing the
brake lever away from you. (See "Brake and
parking brake" chapter)
7
EN
FR
IT
NL
EN
02 PRODUCT DESCRIPTION 03 BUILD UP THE ROLLATOR

In order not to impaire the stability of the rolla-
tor, the end of the handle tubes (8, pic. 4) must
not disappear in the T-tube!
Now tighten the clamping lever (3, pic. 3) and
adjust it so that the lever points in the opposite
direction to the direction of travel.
8
9
pic. 4
Checking for correct assembly
Now check that the rollator has been correctly
assembled:
c The rollator must stand securely on all
four wheels.
c The clamping levers and clamp levers must
be securely tightened..
c The handle tubes and the T-tubes with the
armrests must be assembled so that they
are not able to rotate.
If you are unsure as to whether the rollator is
assembled correctly, please contact your medi-
cal supply store or an authorised specialist re-
tailer.
1
2
3
4
6
7
5
pic. 3
Adjusting armrests & handles
Now adjust the correct height of the armrests
and the position of the handles.
Insert the hexagonal screw (4, pic. 3) from the
inside of the main frame through the borehole.
Now guide the curved washer over the screw
thread. Ensure that the hexagonal head of the
screw is seated in the "hexagonal cut-out" of
the frame tube (5, pic. 3). This allows you to
tighten the star screw without the need for
tools (6, pic. 3).
Now check the position of the handlebars. The-
se can be adjusted in depth to the length of your
forearms.
Make sure that the handle tubes are only xed
inside the corrugated area (7, pic. 3) of the
T-tubes.
8
TOMTAR / Bedienungsanleitung Rollator FAKTO+ Arthritis / Version 1.0.0 DETOMTAR / User manual FAKTO+ Arthritis / Version 1.0.0 DE / EN
03 BUILD UP THE ROLLATOR

USING FAKTO+ ARTHRITIS
Make yourself sufciently familiar with your
FAKTO+ Arthritis before using it for the rst time
so that you feel condent when handling it.
Folding mechanism
1
2
pic. 5
The folding mechanism must be locked after
each unfolding. Always ensure that the unlo-
cking lever is properly engaged in the lower
position (1, pic. 5).
First remove the tray and basket before unlo-
cking and folding. Now press the unlocking le-
ver upwards (1, pic. 5) and push the front and
rear parts of the main frame together (2, pic. 5).
Please also refer to the "Unfolding the rollator"
chapter.
WARNING
Take care of your hands, ngers clothes and when
operating the folding lock and when unfolding or
folding up the rollator! Risk of clamping!
Brake and parking brake
The brakes are operated using the brake han-
dles mounted on the handles.
To brake while moving, pull the two brake han-
dles towards you evenly (1, pic. 6).
1
2
pic. 6
To brake the rollator safely and indenitely
when stationary, for example to sit, push the
brake handle rmly away from you (2, pic. 6).
The brake handle engages securely and audibly
in this position. Pull the brake handle towards
you to release it. You can clearly notice that the
brake is released.
WARNING
If problems occur when adjusting the brakes,
please contact an authorised specialist retailer!
This is the only way of ensuring the safe use of
the rollator.
Readjusting the brakes
The adjusting screw for the brake cables can
be found on the brake handles. Unscrew (coun-
ter-clockwise) to increase the tension and re-
duce the actuation travel of the brake lever (1,
pic. 7). The screw is counter-locked with a nut
9
EN
FR
IT
NL
EN
03 BUILD UP THE ROLLATOR 04 USING THE ROLLATOR

(2, pic. 7). You must always tighten this counter
nut after adjustment to prevent the brake ca-
bles from loosening unintentionally.
1
2
3
pic. 7
Readjusting the brakes at the cable
The brakes can also be readjusted using the
cable (3, pic. 7). This can be useful if the bra-
ke lever adjustment described in the previous
paragraph is no longer effective. Here, too, you
must tighten the counter nut after adjustment
has been completed.
WARNING
Never fully unscrew the screw, otherwise the
brake will no longer work.
ACCESSORIES / ADD ON
Only original accessories from DIETZ are to be
used. Only then the conformity and the safety
of the product is guaranteed.
Basket (tted as standard)
The wire basket suspended underneath the seat
is designed for the storage and transportation of
larger goods or items up to a maximum of 5 kg.
To remove the basket, lift if off the hooks un-
derneath the seat. The hook can now be folded
upwards so that you can pick up the basket.
To attach the basket to the rollator, simply t it
back onto the hooks.
Make sure that the basket is securely attached
before placing items inside.
Rack (tted as standard)
The plastic rack underneath the basket is de-
signed for the storage and transportation of
larger items such as shopping bags, up to a
maximum of 7 kg.
If you wish to clean the rack, you can remove it
upwards by detaching the retaining clips that
grip around the frame tube.
To re-attach the rack, push the clips back onto
the frame tube and check that the rack is se-
curely in place.
10
TOMTAR / Bedienungsanleitung Rollator FAKTO+ Arthritis / Version 1.0.0 DETOMTAR / User manual FAKTO+ Arthritis / Version 1.0.0 DE / EN
04 USING THE ROLLATOR 05 ACCESSORIES / ADD ONS

Tray (tted as standard)
The tray is designed for the transportation of
small items up to a maximum of 5 kg.
Place this on the seat. There are four pins on
the bottom of the tray that can be positioned
into the four holes in the seat.
WARNING
Do not use the tray to transport hot items or hot
drinks.
Single hand brake (optional)
If one of your hands does not have enough
strength to safely apply the brake, the Fakto+
Arthritis can be equipped with a single hand
brake. This will need to be attached to the rolla-
tor by an authorised specialist retailer.
c Attaching a single hand brake to your rol-
lator requires you to have sufficient
strength in the hand that applies the
brake so as to ensure safe handling.
c The same usage and maintenance in-
structions apply as for the version with
brakes on both handlebars.
ADD-ONS & ACCESSORIES OF
THIRD-PARTYS
In general, only original accessories from DIETZ
GmbH may be used. If third-party products are
installed on the rollator, responsibility for the
safety of the product passes to the person who
installs the accessories or carries out the instal-
lation. The conformity of the combination of ac-
cessories or add-ons and product is then new
to be explained by the person who attaches it.
The conformity declared by DIETZ according to
MDR 2017/745, Annex II expires.
WARNING
The safety of the product cannot be guaranteed
if add-ons or accessories are used that are not
sold by DIETZ.
WARNING
If accessories or add-ons are combined with the
rollator, then the safety instructions in the user
manual for the accessories or add-on must be
observed.
11
EN
FR
IT
NL
EN
05 ACCESSORIES / ADD ONS

SAFETY INSTRUCTIONS
By observing the intended use and following the safety instructions, there is no danger of using the
FAKTO+ Arthritis rollator.
WARNING
Follow all safety instructions, otherwise there
may be a risk of injury!
c The rollator may only be used indoors and
on level, rm ground.
c The rollator must be securely upright on all
four wheels.
c Before each use of the rollator, check that all
attached parts are properly fastened, that
the brakes are working and that the folding
mechanism is locked.
c Always lock both brakes before sitting on
the rollator's seat.
c The rollator’s seat is only designed to be
used for short periods, such as when
taking a break when walking!
c Attention: Please note that a shift of bal-
ance due to body movements may in-
crease the risk of the rollator tipping over.
c Do not hang any bags on the handles or
other parts of the rollator, as this will
increase the risk of it tipping over!
c There is a generally higher risk of tipping
over when standing and moving with the
rollator due to the high armrests. There-
fore, always ensure that the load on the
rollator is even!
c Pay attention to the neighbouring compo-
nents when operating the folding lock
(unlocking lever). There is a risk of en-
trapment if handled improperly!
c Never exceed the maximum combined
load of 120 kg for user and load!
c Avoid exposing the wheelchair to direct
sunlight/low temperatures for long
periods of time as parts of the product
(e.g. frames, footrests, brakes and side
panels) may b come very hot (> 41°C) or
very cold (<0°C) and this may cause skin
injuries.
c Ensure that the rollator is not parked in
direct vicinity of emergency exits and
escape routes and blocks them.
c Never use the rollator under the influence
of alcohol or other substances that can
negatively affect your attention and reac-
tion ability!
c Only ever use the rollator in accordance
with its intended use! When using the
rollator, never approach obstacles such as
steps or curbs without applying the
brakes.
12
TOMTAR / Bedienungsanleitung Rollator FAKTO+ Arthritis / Version 1.0.0 DETOMTAR / User manual FAKTO+ Arthritis / Version 1.0.0 DE / EN
06 SAFETY INSTRUCTIONS

c The rollator must not be left to children to
play and must not be subjected to im-
proper use!
c When sitting on the rollator, you must not
walk with your feet or be pushed by other
persons! This is an injury risk and may
cause damage to the product!
c Observe the road traffic regulations on
public road traffic.
c Wherever possible, wear light, eye-catch-
ing clothing. This will allow you to be
seen more easily by other road users.
c Never use the rollator as a seat in a
vehicle or on public transport. This poses
an increased risk of falling!
c Never use escalators. The risk of falling
and injury is very high!
c Stairs must only be negotiated with the
help of accompanying persons if no ele-
vators or ramps are present.
c The wheel bearings can be damaged by
sand, seawater and road salt. Clean the
rollator thoroughly if it has been exposed
to conditions such as these.
c If they cannot be bypassed, ruts, rails or
similar obstacles must always be crossed
at right angles (90°).
c The rollator must not be used to transport
heavy loads. Items must only be
transported using the rack, basket or tray,
as described in the “Accessories” section.
c Serious incidents that occur in relation to
the rollator must be reported to the
manufacturer and the responsible
authorities!
c If you notice any limitations in the
functioning of your rollator, please take it
to your authorised specialist retailer for
repair immediately.
c If your product is a custom-made device
(see section entitled "Product label-
ling"), attention must be paid not only
to the latest operating instructions, but
also the additional documentation
including all safety instructions.
13
EN
FR
IT
NL
EN
06 SAFETY INSTRUCTIONS

SERVICING / MAINTENANCE
We recommend performing the inspections listed in the maintenance schedule at regular intervals
to ensure that the rollator is always safe to use.
Defective or neglected care and maintenance of the rollator limits liability.The maintenance schedule
does not give any information concerning the amount of work actually required on the rollator.
NOTE
As the user, you will be the rst to notice possi-
ble damage. If you notice a fault as described in
the maintenance schedule or further defects
and functional impairments, contact an autho-
rised specialist dealer immediately.
NOTE
The inspections and measures stipulated in the
maintenance schedule must be performed by
the user or assistant if not otherwise stated.
WARNING
Repairs on the rollator must only be performed
by specialist shops using DIETZ original spare
parts to maintain the operational safety of the
rollator. The relevant spare parts catalogue can
be found on our website in the information of
the product in question.
NOTE FOR SPECIALIST DEALERS:
If the user indicates abnormalities on the rol-
lator, check all the inspection points listed in
the maintenance schedule on the rollator. The
checks must also be performed before putting
the rollator back into operation and after lon-
ger storage periods (> 4 months).
14
TOMTAR / Bedienungsanleitung Rollator FAKTO+ Arthritis / Version 1.0.0 DETOMTAR / User manual FAKTO+ Arthritis / Version 1.0.0 DE / EN
07 INSTRUCTIONS FOR GENERAL USE

MAINTENANCE SCHEDULE FAKTO+ ARTHRITIS
What Description
Brakes/parking
brakes:
Function
The rear wheels must not turn when the brake handles are pushed or
locked (parking brake) or when the brake handles are actuated (service
brake).
The brakes must be re-adjusted following a replacement of the
bowden cables or the rear wheels. This must only be carried out by
an authorised specialist retailer.
x
Push handles and
armrests:
Stability
1. It must be possible to securely lock the clamping levers of the push
handles/armrests and star screw of the T-tubes.
2. The armrests and push handles must not wobble.
x
Folding lock and folding
mechanism:
Function & safety
1. It must be possible to operate the lever on the folding lock without any
issues.
2. It must be possible to connect and detach the two parts of the frame
without any issues. When doing so, it must be possible to push
the horizontal bar on the rear part of the frame into the runners on the
front part of the frame without any issues.
3. It must be possible to engage the lever right at the bottom in order to
lock it.
x
Screw connections:
Securely fastened
All screw connections must be securely fastened.
Repeated loosening and re-tightening causes self-locking nuts
and screws to lose their effectiveness. These must therefore be
replaced by a specialist retailer if they have become loose.
x
Steering and running
wheels:
Mobility, function &
damage
1. The wheels must run in a straight line and must not wobble.
2. The wheels must move easily and quietly during travel.
3. Please clean the wheel hub if it is dirty or if uff has accumulated.
4. The wheels must not be damaged.
x
Steering and running
wheels:
Mobility, function
& damage
1. The wheels must not be damaged and must run quietly, in a straight
line and without wobbling.
2. Please clean the wheel hub if it is dirty or if uff has accumulated.
x
Armrests:
Stability & damage
1. The armrests must not be damaged or wobble. Check if the clamp
levers of the T-tubes are xed tight and if the armrests are xed tight
with the T-tubes.
2. The pad of the armrests must not be damaged.
before use
monthly
15
EN
FR
IT
NL
EN
07 INSTRUCTIONS FOR GENERAL USE

What Description
Push handles:
Stability &
damage
1. The handles and brake handles must be securely in place.
2. The push handles must not have any external damage or distortion,
and must not wobble.
3. It must be possible to securely lock the clamping levers.
x
Seat:
Contamination &
damage
1. The seat must be securely connected to the frame.
2. If the seat is dirty, clean in accordance with the cleaning instructions.
2. If damaged, have the seat replaced.
x
Frame, complete:
Function &
damage
1. The two parts of the frame must not be damaged or cracked.
2. Functional or surface damage must be rectied. x
Visual inspection:
Loose parts, fractures,
corrosion or other
damage
If this type of damage is detected, the rollator must
no longer be used, as safe operation is no longer guaranteed! x
Contamination:
Rollator, complete
The entire rollator must be cleaned in line with the level of contamination,
but at least once a month (see “Cleaning” section). x
vor Fahrtbeginn
monatlich
16
TOMTAR / Bedienungsanleitung Rollator FAKTO+ Arthritis / Version 1.0.0 DETOMTAR / User manual FAKTO+ Arthritis / Version 1.0.0 DE / EN
07 INSTRUCTIONS FOR GENERAL USE

FAULT-FINDING AND RECTIFICATION
What Possible causes Measures
The front wheels do not
run in a straight line.
The wheel bearings are defective or
the wheel suspension is no longer
correctly attached.
Consult an authorised specialist
retailer.
The rollator is hard to
push.
The wheel axles/wheel hubs are dirty. Remove the dirt.
The brakes are incorrectly adjusted.
Consult an authorised specialist
retailer.
The wheel bearings are defective or
the wheel suspension is no longer
correctly attached.
The brake function is
insufcient or uneven.
The brakes are incorrectly adjusted or
the brake pad has worn out.
Consult an authorised specialist
retailer.
The seat is positioned at
an angle or is not securely
attached to the rollator.
The rollator is not fully unfolded. Fully unfold the rollator and engage
the folding lock.
The seat is defective or is incorrectly
screwed onto the rollator. Consult an authorised specialist
retailer.
The hinges on the folding mechanism
or the folding lock are defective.
The rollator does not
provide secure support or
does not stand reliably.
The armrests or push handles are not
xed in place properly or have been
incorrectly adjusted for the user.
Check the position of the armrests and
push handles.
Check whether the clamping levers
on the push handles are securely
tightened.
The rollator has not been fully
unfolded and the folding lock has not
been engaged.
Fully unfold the rollator and engage
the folding lock.
The rollator frame or the push handles
are damaged.
Consult an authorised specialist
retailer.
Squeaking or grinding
noises Various causes Consult an authorised specialist
retailer.
17
EN
FR
IT
NL
EN
07 INSTRUCTIONS FOR GENERAL USE

Please only use the following disinfectants; use
of other chemicals might damage the rollator:
c Aldehyde-free disinfectants based on
alcohol (max. 70% propylalcohol)
c Aldehyde-based disinfectant
WARNING
Observe the use and processing instructions is-
sued by the cleaning agent/ disinfectant manu-
facturer.
FORWARDING AND REUSING
Your product is suitable to be passed on to oth-
er parties / for reuse, unless it is labelled as a
custom-made device.
The number of times the rollator can be reused
depends on the material wear conditions and
the functional capabilities of the respective
product.
If the rollator is passed on to a new user or
specialist dealer for reuse, please remember
to hand over all technical documents that are
necessary for safe usage. The rollator must be
cleaned and disinfected, and must be checked
for damage and approved by the specialist re-
tailer. To do so, please check all the inspection
points listed in the maintenance schedule on
the rollator.
CLEANING
c Regularly clean the rollator by wiping
with a damp cloth.
c In the event of heavier contamination, use
a mild cleaning agent and warm water.
c The wheels can be cleaned using a damp
brush with soft plastic bristles
c Remove dirt and fluff from the wheel
hubs.
c After cleaning, ensure that all materials are
completely dried in order to preserve their
quality.
c Only ever use standard mild cleaning and
disinfection products to clean the rollator.
Detailed information on disinfection can
be found in the following section.
WARNING
Do not use high-pressure cleaners, strong, cor-
rosive chemicals or scouring agents for cleaning
purposes.
DESINFECTION
When manually reconditioning a used aid for
reuse, all of the aid’s components must be thor-
oughly treated/wiped with a disinfectant. Take
particular care to disinfect surfaces that come
into frequent contact with hands/skin, such as
handles.
18
TOMTAR / Bedienungsanleitung Rollator FAKTO+ Arthritis / Version 1.0.0 DETOMTAR / User manual FAKTO+ Arthritis / Version 1.0.0 DE / EN
07 INSTRUCTIONS FOR GENERAL USE

STORAGE
To store the rollator, ensure that it is stored in a
dry place protected against direct, strong sun-
light and at a temperature of 0 °C to +45 °C.
Do not activated the locking brakes. Secure the
rollator against rolling away unintentionally.
After longer periods of storage (> 4 months),
please check all the inspection points on the
rollator listed in the maintenance schedule
before reusing/redeploying it.
WARNING
Do not store the rollator near a heat source or
store objects on it.
DISPOSAL
If you no longer need the rollator, please con-
tact your specialist dealer. They will then pick
up the rollator and either dispose it properly or
make further use of it. If this is not possible,
please take the wheelchair to your local recy-
cling facility.
PRODUCT LABELLING
Type and warning signs must always be kept
legible. With the FAKTO+ Arthritis, these are at-
tached to the horizontal connecting bar of the
main frame.
Please have unreadable or missing signs/stick-
ers replaced immediately by your specialist
dealer. This includes the reector stickers.
This information/warning sign is located next to
the type plate:
Gehhilfe für Innenbereich
Achtung: Nur auf ebenem Untergrund verwenden!
Walking aid for indoor use
Attention: Use on flat and firm terrain only!
The following section explains the symbols and
information on the type plate in detail. The type
plate also contains the serial number of your
rollator.
DIETZ GmbH
Reutäckerstraße 12
76307 Karlsbad D
2019
- 09
580 mm
(01)04260241688597
(10)1900XXX
(21)358000XXX
347NPU
Fakto+ Arthritis
120 kg
1155 mm -
1325 mm
trademark, brandname or
product brand
Type
REF = Article number
19
EN
FR
IT
NL
EN
07 INSTRUCTIONS FOR GENERAL USE

Products with the following designation are
custom-made devices:
SONDERANFERTIGUNG
CUSTOM-MADE DEVICE
Custom-made devices are products which are
customised for a particular user. The type plate,
warnings, and where applicable the intended
use differ in this case. Please pay attention to
the additional documentation!
UDI = Unique Device Identifer
(01) UDI-DI
(10) Order number
(21) serial number
manufacturer / manufacturer
sign / contact adress
maximum user weight incl.
load
Manufacturing date
Total width rollator
Total hight rollator
(min.- max.)
Rollator for indoor use
Follow the user manual
Attention - Please note the
safety instructions in the
operating instructions!
Medical Device
CE mark
20
TOMTAR / Bedienungsanleitung Rollator FAKTO+ Arthritis / Version 1.0.0 DETOMTAR / User manual FAKTO+ Arthritis / Version 1.0.0 DE / EN
07 INSTRUCTIONS FOR GENERAL USE
