Displays2go LECTFLCHW User manual

1. Reading Top
2. Base
3. Body
4. Shelf
6. Flat Head Screws (4)
6. Flat Head Screws (4)
5. Shelf Supports (4)
6. Flat Head Screws (8)
7. Phillips Head Screwdriver (Not Shown)
Lectern Parts: Hardware:
1. Reading Top
2. Base
3. Body
4. Shelf
5. Shelf Supports
Figure 1

Attaching the Base to the Body
1. Position the Base and Body on a clean flat surface.
2. Align the pre-drilled holes in the Body with the threaded
inserts in the Base.
3. Using the provided screwdriver, attach the Body to the
Base with (4) Flat Head Screws as illustrated in Figure 2.
Tip: Do not fully tighten these screws until the unit is
otherwise fully assembled.
Figure 2
Figure 3
Attaching the Reading Top
1. Position the Reading Top over the Body as illustrated
in Figure 3.
2. Align the pre-drilled holes in the Body with the threaded
inserts in the Reading Top.
3. Using the provided screwdriver, attach the Reading Top
to the Body with (4) Flat Head Screws as illustrated
in Figure 3.
Tip: You should now fully tighten all 8 Flat Head Screws.

Figure 5
Installing the Optional Shelf
1. Insert 1 Shelf Support into each of the four pre-drilled
locations identified in Figure 4.
Shelf Support installation locations
2. Remove the protective film from the Shelf.
3. Place the Shelf onto the Shelf Supports to complete your
LECTFLCHW assembly.
Shelf
Figure 4
