INSTALLATION AND PROGRAMMING GUIDE
7300 Series Thinline™
Icon Keypad

TABLE OF CONTENTS
About the Keypad ...................................... 1
Features.............................................................................. 1
Card Reader ...................................................................... 1
Keypad Layout ............................................2
Card Reader ..................................................................... 3
Two-Button Panic Keys................................................ 3
Install the Keypad.......................................4
Remove the Cover ......................................................... 4
Wire the Keypad............................................................. 5
When Using an Auxiliary Power Supply .................... 5
Mount the Keypad ......................................................... 7
Program the Keypad ..................................8
Reading the Display...................................................... 8
User Options.................................................................... 8
Installer Options ............................................................10
Access Installer Options ................................................ 10
Configure Panics and User Code Digits ....................11
Run Keypad Diagnostics ................................................12
LCD Segment Test ............................................................12
Test Individual Keys and Card Reads.........................12
Exit Installer Options ....................................................... 12
Reference................................................... 13
End User Training .........................................................13
Shortcut Keys .................................................................13
Programming Menus Items .......................................14
Panic Keys........................................................................14
Icons...................................................................................15
Display Codes.................................................................16

Compliance Requirements...................... 17
Wiring Specifications ..................................................17
Compatibility ............................................ 18
Panel Models...................................................................18
Credentials.......................................................................18
Product Specifications ............................ 19
Certifications............................................ 20
Intertek (ETL) Listed...................................................20
FCC Information ....................................... 21
Industry Canada Information..................22

7300 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 1
ABOUT THE KEYPAD
The DMP 7300 Series Thinline™ Icon Keypads provide an easy to understand icon display
to assist users when arming and disarming an All/Perimeter or Home/Sleep/Away system
or using any of the standard system features. The icons provide immediate recognition of
any system alarm as well as system status.
7300 Series keypads are compatible with XT Series control panels.
Features
All 7300 Series models provide three 2-button Panic keys, a backlit keyboard with easy-
to-read lettering, and an internal speaker. Additionally, the model 7363 keypad provides a
built-in proximity reader designed to read standard HID proximity credentials.
Card Reader
When a proximity credential is presented to the internal reader, a beep tone is heard to
provide an audible acknowledgment of the credential read.

Digital Monitoring Products, Inc | 7300 Series Installation and Programming Guide2
KEYPAD LAYOUT
A
C
B
D
F
E
G
I
H
J
L
K
V
X
W
S
U
T
P
R
Q
M
O
N
Y
Z
E
N
T
E
R
B
A
C
K
ALL RESET HOME
CHIME
ZONE
PERIM SLEEP EXIT
INSTTESTOUTPUT
CODE
1 2 3 4
5 6 7 8
9 0 CMD
Proximity
Credential Reader
and Backlit Logo
Keypad Display
Select Keys
Panic Keys
Command
(CMD) Key
Back Arrow Key
143
2
Figure 1: 7300 Series Thinline Keypad

7300 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 3
Card Reader
When a proximity credential is presented to the keypad’s backlit logo, a beep tone is
emitted to provide an audible acknowledgment of the credential read.
Two-Button Panic Keys
All keypads oer a panic key function that allows users to send panic, emergency, or
fire reports to the central station in an emergency. Panic keys are enabled in the Installer
Options. Place the icon stickers below the top row select keys as shown in Figure 1.
Note: By default, all 7300 keypads send address 8 to the central station for panic
alarms.

Digital Monitoring Products, Inc | 7300 Series Installation and Programming Guide4
INSTALL THE KEYPAD
Remove the Cover
The keypad housing is made up of two parts: the cover,
which contains the circuit board and components, and
the base.
To separate the keypad cover from the base, insert a
flathead screwdriver into one of the slots on the bottom
of the keypad and gently lift the screwdriver upward.
Repeat with the other slot. Gently separate the cover
from the base and set the cover containing the keypad
components aside. See Figure 2.
1
Figure 2: Separate the
Keypad Housing
Cover
Base

7300 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 5
Wire the Keypad
The 7360 and 7363 keypads are supplied with a 4-wire harness for panel keypad bus
connection. Refer to the following table for wire colors and connections:
WIRE COLOR CONNECT TO PANEL PURPOSE
Red Terminal 7 DC Power
Yellow Terminal 8 Send Data
Green Terminal 9 Receive Data
Black Terminal 10 Ground
When Using an Auxiliary Power Supply
If the current draw for all keypads exceeds the panel output, provide additional
current by adding a Model 505-12 auxiliary power supply:
1. Connect all keypad Black ground wires to the power supply negative terminal.
2. Run a jumper wire from the power supply negative terminal to the panel
common ground terminal.
3. Connect all keypad power (+12 VDC) wires to the power supply positive
terminal.
4. Do not connect the power supply positive terminal to any panel terminal.
For more information, refer to the 505-12 Power Supply Installation Guide (LT-0453).
2

Digital Monitoring Products, Inc | 7300 Series Installation and Programming Guide6
Black – Ground
Green – Receive Data
Yellow – Send Data
Red – Keypad Power
Reference Card
Guide Tabs
Surface and Backbox Mounting Holes
Combined 4-square and 3-gang Switch Box Mounting Holes
Keypad Back
Figure 3: Mounting Holes and Wiring Harness

7300 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 7
Mount the Keypad
All DMP keypads are designed to install on any desk stand, 4” plastic square box,
3-gang plastic switch box, or a flat surface. Refer to Figure 3 when mounting the
keypad.
Insert the included screws into the mounting holes and secure the keypad to the wall.
Insert the included system information reference card into the card slot. The reference
card has user code instructions on one side and write-in zone number and names on
the other.
3

Digital Monitoring Products, Inc | 7300 Series Installation and Programming Guide8
PROGRAM THE KEYPAD
Reading the Display
For programming options, the display shows an identifier
followed by a value. The identifier represents the menu option
and the value represents the currently-programmed value. For
options that can be turned o or on, the values are binary where
0 = o and 1 = on.
For more information, refer to each of the following sections or
Reference.
User Options
To access User Options, hold down the back arrow and CMD keys for two seconds. Press
CMD to display the next option or press the Back Arrow to exit the User Options menu.
Brightness
Set the brightness of the display, keyboard, and logo backlighting
by selecting a level between 0 (o) and 8 (max). The default is 8.
The brightness level increases to maximum intensity when a key is
pressed. If no activity occurs for 30 seconds, brightness returns to
the programmed level.
Brightness = 8
Panic Key = On
Identifier Value
Examples

7300 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 9
Speaker Tone
Set the keypad internal speaker tone from the range of 1 to8. The
default is 5.
Volume Level
Set the keypad internal speaker volume level for key presses and
entry delay tone conditions from the range of o (0) to maximum
(8). The default is 8.
During alarm and trouble conditions, the volume reverts to
maximum level.
Firmware Version
The LCD displays the 3-digit firmware version of the keypad.
Version 100 is shown in the example.
Keypad Model
The LCD displays the model number of the keypad.
• 60 - Model 7360
• 63 - Model 7363
Note: To continue to the Installer Options menu, enter 3577+CMD at the Firmware
Version or Keypad Model screens.

Digital Monitoring Products, Inc | 7300 Series Installation and Programming Guide10
Installer Options
All models provide a Keypad Option and Diagnostic menu to allow installing and service
technicians to configure and test keypad operation. Because all 7300 Series keypads
operate together on the Keypad bus using the same address, there is no address option to
set.
ACCESS INSTALLER OPTIONS
The Installer Options Menu can only be accessed from User Options at Firmware Version
or Keypad Model. When either is displayed, enter 3577(INST) and press CMD.

7300 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 11
Panic Key
Configure the two left Select keys as 2-button Panic. The display
shows the current setting as a binary value. To turn on the panic
key operation, enter 1. To turn o the panic key, enter 0. The default
is 0(o).
Emergency Key
Configure the two middle Select keys as 2-button Emergency. The
display shows the current setting as a binary value. To turn on the
panic key operation, enter 1. To turn o the panic key, enter 0. The
default is 0(o).
Fire Key
Configure the two middle Select keys as 2-button Fire. The display
shows the current setting as a binary value. To turn on the panic
key operation, enter 1. To turn o the panic key, enter 0. The default
is 0(o).
Number of User Code Digits
Enter the user code digit length used by the panel. Range is 4 to 6.
The default is 4.
CONFIGURE PANICS AND USER CODE DIGITS

Digital Monitoring Products, Inc | 7300 Series Installation and Programming Guide12
RUN KEYPAD DIAGNOSTICS
LCD Segment Test
At diagnostics startup the keyboard is backlit at maximum brightness and all the icons
flash on and then o as a group. The keypad alternates between these two states for
approximately two minutes. Press the Back Arrow to return to the Panic Keys option. Press
CMD at any time to continue to the next test.
Test Individual Keys and Card Reads
When a top row select key is pressed, the corresponding Cancel, Bypass, Extend, or
Verify option is displayed. When keys 0-9 are pressed, the number of the selected key is
displayed in the 3-digit display. If a proximity credential is presented during the key test,
the keypad beeps once for a successful read.
EXIT INSTALLER OPTIONS
Press CMD to end Installer Options. Press the Back Arrow key to return to the LCD
Segments test.

7300 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 13
End User Training
For the 7300 Series keypad user guide, refer to the Thinline™ Series Icon Keypad User
Guide (LT-0956).
Shortcut Keys
KEY # SHORTCUT LABEL PURPOSE
1 ALL Arm All or arm Away
2 RESET Reset sensors
3 HOME Arm Home
4 CODE Access user codes menu
5 CHIME Activate or deactivate chime
6 PERIM Arm Perimeter
7 SLEEP Arm Sleep
8 EXIT Use easy exit (Start countdown and exit
without disarming)
9 ZONE Check zones
10 OUTPUT Turn outputs on or o
←TEST Perform a communication test
CMD INST Arm Instant during a countdown
REFERENCE

Digital Monitoring Products, Inc | 7300 Series Installation and Programming Guide14
Programming Menus Items
MENU ITEM IDENTIFIER VALUE RANGE DEFAULT VALUE
Brightness b 0 to 8 8
Speaker Tone S 1 to 8 5
Volume Level L 0 to 8 8
Keypad Firmware Version none 3 digits n/a
Model Number (7360) none 60 n/a
Model Number (7363) none 63 n/a
Panic Key P 0 or 1 0
Emergency Key E 0 or 1 0
Fire Key F 0 or 1 0
User Code Digits U 4 to 6 4
Panic Keys
PANIC TYPE SELECT KEYS ZONE NUMBER
Panic 1 and 2 (left two keys) 19
Emergency 2 and 3 (center two keys) 29
Fire 3 and 4 (right two keys) 39
Panic
Press and hold for 2 seconds to activate.
Emergency Fire

7300 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 15
Icons
AC Power
Steady = OK, Pulsing = Fault
System Ready
Ready to arm
Battery Power
Steady = OK, Pulsing = Fault
System Not Ready
Not ready to arm
Disarmed
System is fully disarmed
Burglar Alarm
Burglary with area number
Armed
Some or all areas are armed
Fire Alarm
Fire with area number
Armed Instant
Some or all areas armed Instant
Bypass Option
Bypass faulted zones
Chime
Keypad chime is on
Extend Option
Extend schedule
Dialer Communication
Steady = OK, Pulsing = Error
Cancel Option
Cancel a false alarm
Network Communication
Steady = OK, Pulsing = Error
Verify Option
Verify a real alarm

Digital Monitoring Products, Inc | 7300 Series Installation and Programming Guide16
Display Codes
Armed
The system is armed all or away
Alarm Canceled
Alarm was canceled by disarm
Perimeter
The system is armed Perimeter
RF Alarm
Wireless receiver detected interference
Home
The system is armed Home
RF Jammed Trouble
Wireless receiver detected interference
Sleep
The system is armed Sleep
RF Receiver Trouble
Wireless receiver is not operating properly
Closed
Schedule closed, system armed
Test
System is being tested
Busy
The system is busy
Test - Minutes Left
The number of minutes left in the test
Reset Panel
Panel must be reset
Transmit Good
Communication test success
Aborted Alarm
Alarm was canceled manually
Transmit Failed
Communication test failed
