AIR CONDITIONERS
COOLAIR
SPX1200I
Rear panel evaporator unit
Installation Manual . . . . . . . . . . . . . . . . . . 3
Rückwandverdampfereinheit
Montageanleitung . . . . . . . . . . . . . . . . . .16
Unité d'évaporateur pour paroi
arrière
Instructions de montage. . . . . . . . . . . . . 30
Evaporador para la pared trasera
Instrucciones de montaje . . . . . . . . . . . . 44
Unidade de evaporação para a
parede traseira
Instruções de montagem . . . . . . . . . . . . 58
Unità di evaporazione per parete
posteriore
Indicazioni di montaggio . . . . . . . . . . . . 72
Achterwandverdampereenheid
Montagehandleiding . . . . . . . . . . . . . . . 86
Bagvægsfordamperenhed
Monteringsvejledning . . . . . . . . . . . . . . 100
Bakväggsförångarenhet
Monteringsanvisning . . . . . . . . . . . . . . . 113
Fordamperenhet for bakvegg
Monteringsanvisning . . . . . . . . . . . . . . . 126
Takaseinähaihdutinyksikkö
Asennusohje . . . . . . . . . . . . . . . . . . . . . . 139
Блок испарителя на задней
стенке
Инструкция по монтажу . . . . . . . . . . . . 152
Jednostka parownika tylnej ścianki
Instrukcja montażu . . . . . . . . . . . . . . . . . 167
Jednotka výparníka určená na
zadnú stenu
Návod na montáž . . . . . . . . . . . . . . . . . . 181
Výparníková jednotka na zadní
stěně
Návod k montáži. . . . . . . . . . . . . . . . . . . 194
Hátfalrögzítésű párologtató
egység
Szerelési útmutató . . . . . . . . . . . . . . . . .207
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

3
EN
CoolAir SPX1200I
Original instructions
Contents
1 Symbols and formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Using the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.2 Handling electrical cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Conventions in this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.1 General information on the installation manual. . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.2 Target group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.1 Prescribed installation method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.2 Notes on installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6.3 Determining the installation position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6.4 Installing the evaporator unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.5 Sealing and attaching the hood. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
6.6 Routing supply lines to condenser unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
6.7 Connecting condenser unit to evaporator unit. . . . . . . . . . . . . . . . . . . . . . . . . . .11
6.8 Installing the electrical connection lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7 Configuration of unit software . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.1 Entering and exiting configuration mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7.2 P.01: Low voltage shut-down. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7.3 P.02: Unit for temperature display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7.4 P.05: Tilt sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
8 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

EN
Symbols and formats CoolAir SPX1200I
4
1 Symbols and formats
!
!
A
I
2 Safety instructions
The manufacturer accepts no liability for damage in the following cases:
• Faulty assembly or connection
• Damage to the product resulting from mechanical influences and incorrect
connection voltage
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in the operating manual
2.1 Using the device
• The freedom of movement of semi-trailers (of the outer edges of the semi-
trailer when turning or jackknifing) and other vehicle attachments must not be
restricted.
• Only use the parking cooler for the purpose specified by the manufacturer
and do not make any alterations or structural changes to the device.
• Only operate the parking cooler if you are certain that the housing and the
cables are not damaged.
• Installation, maintenance and repair work may only be carried out by
qualified personnel from a specialist company who are familiar with the
risks involved and the relevant regulations.
• Do not use the parking cooler near flammable fluids or in closed rooms.
• Do not reach into air grilles or ventilation nozzles or insert any foreign objects
in the system.
WARNING!
Safety instruction: Failure to observe this instruction can cause death or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair the
function of the product.
NOTE
Supplementary information for operating the product.
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

5
EN
CoolAir SPX1200I Conventions in this manual
•Donot open the system in the event of a fire. Use approved extinguishing
agents instead. Do not use water to extinguish fires.
• Switch off the parking cooler before using automatic washing equipment
(automatic car washes etc.) to clean the vehicle.
• Disconnect all connections to the power supply when carrying out work on
the device.
• The system must be switched off before you tilt the cab.
2.2 Handling electrical cables
• The electrical cables might be laid over sharp edges. Use ducts or tubes to
prevent damage.
• Do not lay loose or bent cables next to electrically conductive materials
(metal).
• Do not pull on the cables.
• Attach and lay the cables in such a manner that they cannot be tripped over
or damaged.
• The electrical power supply may only be connected by a specialist work-
shop.
• Fit a fuse of 25 A to the connection to the vehicle's power supply.
• Never lay power supply lines (battery leads) in the vicinity of signal or control
cables.
• Where neeeded, secure cables with cable binders.
3 Conventions in this manual
3.1 General information on the installation manual
This installation manual contains the essential information and instructions for
installing the parking cooler. The information is intended to be read by the
installation personnel of the parking cooler.
The following instructions are intended to help you use the installation manual
properly:
• The installation manual is part of the scope of delivery and should be stored
carefully.
• The installation manual provides you with important information on the
installation of the device and can also be used as a reference material in the
event of repairs.
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

EN
Proper use CoolAir SPX1200I
6
• The manufacturer assumes no liability for non-observance of this installation
manual. Any claims are excluded in this case.
3.2 Target group
The installation and configuration information in this manual is intended for
qualified installation personnel who are familiar with the guidelines and safety
precautions to be applied during the installation of lorry accessory parts.
4Properuse
The CoolAir SPX1200 parking cooler is designed for supplying the cab of a lorry
with cooled and dehumidified air. It can be used while driving.
The CoolAir SPX1200I rear panel evaporator unit (ref. no. 9105305612) can only
be operated in combination with a CoolAir SPX1200C condenser unit. Both
components together form the CoolAir SPX1200 parking cooler.
A
I
NOTICE!
• The CoolAir SPX1200 parking cooler is not suitable for installation in agri-
cultural machines and construction machines or similar equipment. It does
not work properly in the event of strong vibrations and exposure to dust.
• Operating the SPX1200 parking cooler with voltages other than those
specified can result in damage to the device.
NOTE
The SPX1200 parking cooler is only designed for ambient temperatures of up
to 52 °C.
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

7
EN
CoolAir SPX1200I Scope of delivery
5 Scope of delivery
6 Installation
A
6.1 Prescribed installation method
The parking cooler consists of the following components (fig. 3):
• CoolAir SPX1200C condenser unit (2)
• CoolAir SPX1200I rear panel evaporator unit (1) with connecting line (3)
The condenser unit (2) is attached to the firm and straight rear panel of the cab or
by means of a firm fastening frame. The evaporator unit (1) is fitted on the inside
of the rear panel of the cab.
Item in
fig. 1Part designation Quantity
.Evaporator unit with connecting cable 1
3Insulating plate 1
$Edge protection Ø 13 mm 1
/Edge protection Ø 36 mm 1
1Clip 4
4Screw M6 x 10 mm 4
2Cover for clip 4
(Hood for rear panel 1
,Self-tapping screw 3.5 x 9.5 mm 4
"Plastic spacer L = 25 mm 4
0Hexagon screw M6 x 40 4
#Plastic spacer L = 40 mm 8
%Hexagon screw M6 x 110 4
&Washer M6 (d1 = 6.4 mm, d2 = 20 mm) 8
– Remote control (incl. type CR2025 battery) 1
– Evaporator unit installation template 1
NOTICE!
• The parking cooler may only be installed by qualified personnel from a
specialist company. The following information is intended for specialists
who are familiar with the guidelines and safety precautions to be applied.
• The evaporator unit must be installed in an upright position (fig. 2).
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

EN
Installation CoolAir SPX1200I
8
I
6.2 Notes on installation
!
!
I
You should always read this installation manual all the way through before
installing the parking cooler.
You should always observe the following tips and information when installing the
parking cooler:
• Please consult the manufacturer of your vehicle with regard to the following.
– is the cab's rear panel a suitable location for attaching the unit?
– is the body designed to bear the static weight and loads occasioned by
the parking cooler in a moving vehicle?
• Check the dimensions of the unit (fig. 2).
• Always check before installation of the unit whether any vehicle components
could be damaged, deformed or impaired in terms of their functionality as a
result of the installation.
• Avoid any unnecessary and frequent mechanical stress to the supply line
between the evaporator unit and the condenser unit. Damage can result in
the loss of refrigerant and impair the performance of the unit.
NOTE
The connection line (3) can only be installed after fitting the evaporator unit and
the condenser unit.
WARNING! Danger of electrocution!
• Detach all connections to battery before starting installation of parking
cooler.
• Make sure that all electrical components are electrically discharged before
carrying out work on them.
CAUTION!
Improper installation of the air conditioning roof unit can result in irreparable
damage to the device and put the safety of the user at risk.
The manufacturer will not be held liable for claims if the air conditioning roof
unit is not installed according to this installation manual. That applies to
malfunctions and the safety of the air conditioning roof unit, in particular to
injuries and damage to property.
NOTE
• The manufacturer strongly recommends the use of a vehicle-specific
fastening frame for an optimum installation procedure for the SPX1200C
condenser unit on the rear panel of the cab.
• Following installation of the unit, the specified unit software parameters
must then be checked (chapter “Configuration of unit software” on
page 12).
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

9
EN
CoolAir SPX1200I Installation
• The supplied assembly parts must not be modified during installation.
• The ventilation slots (grill) may not be covered (minimum distance from other
attachment parts: 10 cm).
• You can connect the unit to the battery via the lorry's terminal block or
directly. The terminal block is to be preferred for the connection. On some
vehicles, larger consumers connected to the terminal block are switched off
after a short while if the power requirement is too high. Ask your vehicle
manufacturer for the specifications of the terminal block.
• Observe the body manufacturer's guidelines with regard to installation of the
unit and its electrical connection.
6.3 Determining the installation position
The system's installation position must meet the following criteria:
• All maintenance work must be easy to perform.
• Sufficient space must be available for the refrigerant line.
• The refrigerant line must be long enough (approx. 2.1 m) for connection of
the condenser and evaporator unit. The line must not be routed under
tension (fig. 3).
• The fastening surface should be as flat as possible. Use spacer sleeves for
uneven surfaces. If spacer sleeves are used, appropriately longer fastening
screws with sufficient tensile strength (not included in the assembly set) must
then be used.
INOTE
The fastening screws M6 x 40 mm included are designed for use with the
spacer sleeves, l = 25 mm, (e.g. MAN TGX).
The fastening screws M6 x 110 mm included are designed for use with the
spacer sleeves, l = 40 mm, (e.g. Volvo FH as of construction year 2013) (two
spacer sleeves for each screw).
By combining the spacer sleeves, different distances between the rear wall of
the cab and inner trim can be achieved.
The screw overhang beyond the nut must not exceed 15 mm.
If spacer sleeves are not to be used or if other ones are to be used, the fastening
screws have to then be adapted to match them. Otherwise the unit housing
may be damaged.
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

EN
Installation CoolAir SPX1200I
10
6.4 Installing the evaporator unit
The evaporator unit is fitted horizontally on the cab's rear panel, near the bunk.
➤Find a suitable fastening position in the cab that allows sufficient air
circulation.
A
➤Drill the holes for mounting the evaporator unit (fig. 5).
I
➤Drill the hole for the connection line (Ø 30 mm) (fig. 6).
➤Drill the hole for the condensation line (Ø 13 mm) (fig. 6).
A
➤Carefully unwind the connection line.
➤Fit the evaporator unit (fig. 7).
➤Fasten the evaporator unit from the outside (fig. 8).
NOTICE!
• Make sure that the drill template included is not upside down when
positioned.
• You can position the drill template from the inside or from the outside onto
the cab. Make sure that the following holes are used for the connecting and
condensation line:
– from inside: holes that bear the inscription “Inside”
– from outside: holes that bear the inscription “Outside”
NOTE
If the space between the interior trim and the cab's rear panel is large, the hole
(Ø 15 mm) for the inclined condensation line must be drilled slightly lower than
specified on the template. For a distance for the interior trim to the cab's rear
panel of approx. 25 mm the hole (Ø 15 mm) should be drilled approx. 5 mm
lower to ensure that the condensation drainage process functions.
NOTICE!
Make sure that the coupling half with the thin, capillary tube is not twisted or
kinked.
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

11
EN
CoolAir SPX1200I Installation
6.5 Sealing and attaching the hood
A
I
➤Mount one clip (fig. 9).
➤Mount the hood (fig. 9).
6.6 Routing supply lines to condenser unit
I
➤Shorten any supply line which is not needed by bending a curve.
➤Fasten the supply lines to the cab's rear panel using the clips (fig. 0).
6.7 Connecting condenser unit to evaporator unit
➤Route the connection cable in a curve out through the opening in the floor of
the condenser unit.
➤Fasten the connection cable as shown (fig. aand fig. b).
NOTICE!
When bending the supply line make sure that the radius is not too narrow. Use
a suitable round object with a shim as a bending aid.
A radius which is too narrow will kink the refrigerant line, and this will prevent
the parking cooler from operating.
NOTE
If you wish to avoid damaging the cab's rear panel (drilling a hole), you can also
fix the hood in place using a suitable adhesive. Observe the instructions
provided by the adhesive manufacturer.
NOTE
• The installation manual for the SPX1200C condenser unit should also be
observed.
• Mount the SPX1200C condenser unit first to enable the exact position of
the condenser unit to be determined. This will save you bending the cop-
per pipe several times to make it fit.
• Make sure that the maximum length of the supply lines does not exceed
2.1 m.
• Avoid any narrow radiuses when routing and bending supply lines. Use a
suitable round object with a shim as a bending aid. A radius which is too
narrow will kink the refrigerant line, and this will prevent the parking cooler
from operating.
• If you wish to avoid damaging the cab's rear panel, you can also fix the clip
inplace using asuitableadhesive. Observe theinstructionsprovided by the
adhesive manufacturer.
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

EN
Configuration of unit software CoolAir SPX1200I
12
6.8 Installing the electrical connection lines
!
A
I
You can connect the unit to the battery via the lorry's terminal block or directly.
The terminal block is to be preferred for the connection. Ask your vehicle manu-
facturer for the specifications of the terminal block.
➤Lay the connection line.
➤Connect it to the vehicle (fig. c).
7 Configuration of unit software
Before the system is first put into operation, the control unit settings can be
adjusted to suit the various installation conditions. Those adjustments must be
made by the installer (fig. 4).
WARNING!
• The electrical power supply may only be performed by qualified personnel
with specialist knowledge.
• Make sure there is no voltage present on electrically operated components
before carrying out work on them.
NOTICE!
• Fit a fuse of 25 A to the connection to the vehicle's power supply.
• The battery must be able to supply the required current and voltage
(chapter “Technical data” on page 15).
NOTE
The unit is equipped as standard with a 4 m long cable with a cross-section of
8mm
2. If longer cable lengths are required, then the cable cross-section must
be increased by an authorised specialist workshop:
In this case, extend the cable using a 16 mm² cable. Make a professional
connection.
The 16 mm² cable must not be longer than 8 m.
Display
indication Parameter Meaning Factory setting
P.01 Low voltage
shut-down
The battery monitor shuts down the
system at the voltage defined here.
22.8 V
P.02 Unit for tempera-
ture display
The temperature can be displayed in
°C or °F.
°C
P.05 Tilt sensor The tilt sensor can be adjusted to the
inclination of the vehicle roof.
–
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

13
EN
CoolAir SPX1200I Configuration of unit software
I
7.1 Entering and exiting configuration mode
➤Press and hold the button.
➤Press and hold the button for longer than 3 s.
✓The display shows the symbol .
✓The parking cooler switches to configuration mode.
✓The display shows “P.01” and the symbol flashes.
➤Scroll through the menu by pressing the or button to select the
desired menu item.
➤Press the button to open the desired menu item.
➤Press and hold the button for longer than 3 s to exit configuration mode.
7.2 P.01: Low voltage shut-down
The battery monitor protects the battery against discharging excessively.
A
If only the power supply voltage specified here is available to the parking cooler,
the system is switched off.
➤Switch to configuration mode (chapter “Entering and exiting configuration
mode” on page 13).
✓The display shows “P.01” and the symbol flashes.
➤Press the button to change the setting.
✓The current setting is displayed.
➤Use the or button to select the voltage level for low voltage shut-
down.
The low voltage shut-down setting can be adjusted in 0.1 V increments from
20.0 V to 23.5 V.
NOTE
Configuration mode can still be activated if the low voltage cut-out has
switched off the system and only residual voltage is available.
NOTICE!
If the unit is switched off by the battery monitor, it means the battery charge
level is low. Avoid repeated starting or using electrical equipment. Make sure
that the battery is recharged. As soon as the required voltage is available again,
the system can be operated again.
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

EN
Configuration of unit software CoolAir SPX1200I
14
I
➤Press the button to save the setting.
✓The set value is saved and is then applied when the system is restarted.
✓You are then returned to the menu and can select another menu item by
pressing the or button.
7.3 P.02: Unit for temperature display
The system can display the room temperature in °C or °F. This parameter can be
configured:
➤Switch to configuration mode (chapter “Entering and exiting configuration
mode” on page 13).
✓The display shows “P.01” and the symbol flashes.
➤Press the or button to select the menu item P.02.
✓The display shows “P.02” and the symbol lights up.
➤Press the button to change the setting.
✓The code for the current setting is displayed:
– 0: °C
– 1: °F
➤Use the or button to select the desired temperature unit.
➤Press the button to save the setting.
✓The set value is saved and is then applied when the system is restarted.
✓You are then returned to the menu and can select another menu item by
pressing the or button.
NOTE
The level for the low voltage shut-down should not be set any lower than the
minimum battery voltage required to be able to start the engine under any
conditions.
As a rule that should be no less than 22 V.
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

15
EN
CoolAir SPX1200I Technical data
7.4 P.05: Tilt sensor
The electronics of the system prevents that the system is switched on when the
vehicle is parked at a slope. Since some vehicles‘ roof already is tilted, the tilt
sensor has to calibrated to the zero setting before first use.
➤Park the vehicle on a level place.
➤Switch to configuration mode (chapter “Entering and exiting configuration
mode” on page 13).
✓The display shows “P.01” and the symbol flashes.
➤Press the or button to select the menu item P.05.
✓The display shows “P.05”.
➤Press the button to change the setting.
✓The code for the current setting is displayed.
➤Use the or button to select “1”.
➤Press the button to save the setting.
✓The set value is saved and is then applied when the system is restarted.
✓You are then returned to the menu and can select another menu item by
pressing the or button.
8 Technical data
CoolAir SPX1200 parking cooler
with SPX1200I rear panel evaporator unit
Cooling capacity: 1200 W
Rated input voltage: 24 Vg
Input voltage range: 20 Vg– 30 Vg
Operating temperature range: +5 to +52 °C
Current consumption: 12 – 22 A
Low-voltage cut-off: Configurable
Dimensions (W x H x D): Condenser unit 346 x 560 x 156 mm
Evaporatorunit648x278x144mm
Weight: Evaporator unit 15 kg
(including connection lines)
Condenser unit 21 kg (without fastening frame)
Inspection/certification:
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

DE
CoolAir SPX1200I
16
Original-Betriebsanleitung
Inhaltsverzeichnis
1 Erklärung der Symbole. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2 Sicherheitshinweise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.1 Umgang mit dem Gerät. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
2.2 Umgang mit elektrischen Leitungen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
3 Handbuchkonventionen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.1 Allgemeine Informationen zur Einbauanleitung. . . . . . . . . . . . . . . . . . . . . . . . . .19
3.2 Zielgruppe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
4 Bestimmungsgemäße Anwendung . . . . . . . . . . . . . . . . . . . . . . . 19
5 Lieferumfang . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.1 Vorgeschriebene Installationsweise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
6.2 Hinweise zur Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
6.3 Anbauposition bestimmen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.4 Verdampfereinheit einbauen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.5 Abdichtung und Anbringen der Abdeckhaube. . . . . . . . . . . . . . . . . . . . . . . . . 24
6.6 Versorgungsleitungen zur Kondensatoreinheit verlegen . . . . . . . . . . . . . . . . . 25
6.7 Kondensatoreinheit mit der Verdampfereinheit verbinden. . . . . . . . . . . . . . . . 25
6.8 Elektrische Anschlussleitungen verlegen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7 Konfiguration der Anlagen-Software . . . . . . . . . . . . . . . . . . . . . . 26
7.1 Einstellungsmodus starten und beenden. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.2 P.01: Unterspannungsabschaltung. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.3 P.02: Anzeige Temperatureinheit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7.4 P.05: Neigungssensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
8 Technische Daten . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

17
DE
CoolAir SPX1200I Erklärung der Symbole
1 Erklärung der Symbole
!
!
A
I
2 Sicherheitshinweise
Der Hersteller übernimmt in folgenden Fällen keine Haftung für Schäden:
• Montage- oder Anschlussfehler
• Beschädigungen am Produkt durch mechanische Einflüsse und falsche
Anschlussspannung
• Veränderungen am Produkt ohne ausdrückliche Genehmigung vom
Hersteller
• Verwendung für andere als die in der Anleitung beschriebenen Zwecke
2.1 Umgang mit dem Gerät
• Die Bewegungsfreiheit von Aufliegern (die äußeren Kanten des Aufliegers
beim Einlenken oder Einknicken) und anderen Fahrzeuganbauten darf nicht
eingeschränkt werden.
• Benutzen Sie die Standklimaanlage nur für den vom Hersteller angegebenen
Verwendungszweck und führen Sie keine Änderungen oder Umbauten am
Gerät durch.
• Wenn die Standklimaanlage sichtbare Beschädigungen aufweist, darf Sie
nicht in Betrieb genommen werden.
• Die Installation, Wartung und etwaige Reparatur dürfen nur durch einen
Fachbetrieb erfolgen, der mit den damit verbundenen Gefahren bzw. ein-
schlägigen Vorschriften vertraut ist.
WARNUNG!
Sicherheitshinweis: Nichtbeachtung kann zu Tod oder schwerer Verletzung
führen.
VORSICHT!
Sicherheitshinweis: Nichtbeachtung kann zu Verletzungen führen.
ACHTUNG!
Nichtbeachtung kann zu Materialschäden führen und die Funktion des
Produktes beeinträchtigen.
HINWEIS
Ergänzende Informationen zur Bedienung des Produktes.
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU

DE
Sicherheitshinweise CoolAir SPX1200I
18
• Setzen Sie die Standklimaanlage nicht in der Nähe von entflammbaren
Flüssigkeiten und Gasen oder in geschlossenen Räumen ein.
• Greifen Sie nicht in Lüftungsgitter oder Lüftungsdüsen, und stecken Sie keine
Fremdgegenstände in die Anlage.
• Im Falle von Feuer öffnen Sie die Anlage nicht, sondern verwenden Sie
zugelassene Löschmittel. Verwenden Sie kein Wasser zum Löschen.
• Schalten Sie die Standklimaanlage aus, bevor Sie automatische Wasch-
einrichtungen (automatische Waschanlage usw.) zum Reinigen des Fahr-
zeugs verwenden.
• Lösen Sie bei Arbeiten (Reinigung, Wartung usw.) an der Standklimaanlage
alle Verbindungen zur Stromversorgung.
• Schalten Sie vor dem Umklappen des Fahrerhauses die Anlage aus.
2.2 Umgang mit elektrischen Leitungen
• Müssen Leitungen durch scharfkantige Wände geführt werden, so ver-
wenden Sie Leerrohre bzw. Leitungsdurchführungen.
• Verlegen Sie keine losen oder scharf abgeknickten Leitungen an elektrisch
leitenden Materialien (Metall).
• Ziehen Sie nicht an Leitungen.
• Befestigen und verlegen Sie Leitungen so, dass keine Stolpergefahr entsteht
und eine Beschädigung des Kabels ausgeschlossen ist.
• Der elektrische Anschluss darf nur von einem Fachbetrieb durchgeführt
werden.
• Sichern Sie den Anschluss ans Netz im Fahrzeug mit 25 A ab.
• Verlegen Sie niemals die Spannungsversorgungsleitung (Batteriekabel) in
räumlicher Nähe zu Signal- oder Steuerleitungen.
• Sichern Sie die Kabel durch Kabelbinder wenn erforderlich.
63;,,VERRN6HLWH)UHLWDJ6HSWHPEHU
