Dometic Go Power! GP-1750HD User manual

MODIFIED SINE
WAVE INVERTER
User Manual
GP-1750HD
GP-3000HD
GP-5000HD
© 2021 Go Power!
Worldwide Technical Support and Product Information gpelectric.com
Go Power! | Dometic
201-710 Redbrick Street Victoria, BC, V8T 5J3
Tel: [phone]
80691_MANUAL_GP-1750-3000-5000-HD_RevC

[page 2] | gpelectric.com
1. CONTENTS
2. GENERAL INFORMATION.................................................3
2.1 CAUTIONS / WARNINGS ......................................................................3
2.2 DISCLAIMERS ......................................................................................9
2.3 MODIFIED HD FEATURE .....................................................................10
3. SPECIFICATIONS............................................................12
4. INSTALLATION ..............................................................15
4.1 INSTALLATION PRECAUTIONS............................................................15
4.2 INVERTER SHUTDOWN16 ......................................................................
4.3 WHERE TO INSTALL ...........................................................................16
4.5 INSTALLATION AND TESTING.............................................................17
4.6 BATTERY PRECAUTIONS.....................................................................19
4.7 DC WIRING SIZING ............................................................................20
4.8 DC GROUNDING................................................................................21
5. OPERATION..................................................................22
5.1 OPERATING PRECAUTIONS ................................................................22
5.2 CONNECTING AC LOADS....................................................................23
5.3 CONTROLS AND INDICATORS ............................................................23
5.4 OPTIONAL ON/OFF REMOTE...............................................................23
5.5 POWER OUTPUT................................................................................24
5.6 INPUT VOLTAGE.................................................................................25
5.7 OVERTEMP ........................................................................................25
5.8 OVERLOAD ........................................................................................ 25
6. TROUBLESHOOTING ......................................................26
6.1 TROUBLESHOOTING GUIDE................................................................26
7. MAINTENANCE ............................................................27
7.1 SERVICING PRECAUTIONS..................................................................27
7.2 MAINTENANCE.................................................................................. 27
8. WARRANTY RETURN PROCEDURE ................................28
9. END OF LIFE - RECYCLING ............................................29
CONTENTS

gpelectric.com | [page 3]
2.1 CAUTIONS / WARNINGS
This document contains important safety instructions for the products produced by Go Power!
Read all instructions and cautionary markings on the product and on any accessories or
additional equipment included in the installation. Failure to follow these instructions could result
in severe shock or possible electrocution. Use extreme caution at all times to prevent accidents.
All electrical work must be performed in accordance with local and national electrical codes.
These instructions are for use by qualied personnel who meet all local and governmental code
requirements for licensing and training for the installation of electrical power systems with AC
and DC voltage up to 600 volts.
Installation, maintenance, and connection of inverters must be performed by qualied personnel,
in compliance with local electrical standards, wiring rules, and the requirements of local power
authorities and/or companies.
Safety regulations relevant to the location shall be followed during installation, operation and
maintenance. Improper operation may have a risk of electric shock or damage to equipment and
property.
2. GENERAL INFORMATION
2. GENERAL INFORMATION

[page 4] | gpelectric.com
General Safety
WARNING!
Limitations on Use
CAUTION!
Equipment Damage
This equipment is NOT intended for use with life support equipment
or other medical equipment or devices.
This product is designed for indoor/compartment installation. It must
not be exposed to any liquids, moisture of any type.
Only use components or accessories recommended or sold by Go
Power! or its authorized agents.
IMPORTANT
Do not attempt to install this equipment if it appears to be damaged
in any way. See the Warranty section for instructions on returning the
equipment.
WARNING!
Hazard to Human Life
This type of notation indicates that the hazard
could be harmful to human life.
WARNING!
Shock Hazard Danger of shock or electrocution.
WARNING!
Burn / Fire Hazard Danger of hot surface and/or re.
CAUTION!
Hazard to Equipment
This type of notation indicates that the hazard may
cause damage to the equipment.
IMPORTANT
This type of notation indicates that the information
provided is important to the installation, operation
and/or maintenance of the equipment. Failure to
follow the recommendations in such a notation
could result in annulment of the equipment
warranty.
i
GENERAL INFORMATION

gpelectric.com | [page 5]
Personal Safety
WARNING!
Personal Injury
Use safe lifting techniques when lifting this equipment as
recommended by the Occupational Safety and Health Association
(OSHA) or other local codes.
Use standard safety equipment when working on this equipment, such
as safety glasses, ear protection, steel-toed safety boots, safety hard
hats, etc.
Use standard safety practices when working with electrical equipment.
(Remove all jewelry, use insulated tools, wear cotton clothing, etc.)
Never work alone when installing or servicing this equipment. Have
someone nearby that can assist if necessary.
Ensure that children, pets, and other animals are kept away from the
inverter, solar arrays, battery bank, and utility grid components.
If the equipment is used in a manner not specied by the
manufacturer, the protection provided by the equipment may be
impaired.
People with pacemakers should consult their physician(s) before use.
Electromagnetic elds in close proximity to heart pacemakers could
cause pacemaker interference or pacemaker failure.
The brass components of this product contain lead, a chemical known
to the State of California to cause birth defects or other reproductive
harm.
This product contains or, when used, produces a chemical known
to the State of California to cause cancer and birth defects or other
reproductive harm.
The warnings, precautions, and instructions in this manual cannot
cover all possible conditions and situations that may occur. It must
be understood by the operator that common sense and caution are
factors which cannot be built into this product, but must be supplied
by the operator.
GENERAL INFORMATION

[page 6] | gpelectric.com
Equipment Safety
WARNING!
Lethal Voltage
Review the system conguration to identify all possible sources
of energy. Ensure ALL sources of power are disconnected before
performing any installation or maintenance on this equipment.
Conrm that the terminals are de-energized using a validated
voltmeter (rated for a minimum 1000 VAC and 1000 VDC) to verify
the de-energized condition.
Do not perform any servicing other than that specied in the installation
instructions unless qualied to do so, or have been instructed to do so
by Go Power! Technical Support personnel.
To avoid electric shock, disconnect the DC input and AC input of
the inverter at least 5 minutes before performing any installation
or maintenance.
Do not tighten the AC and DC terminals or pull on the AC and DC wiring
when the inverter is running.
WARNING!
Fire Hazard
Do not keep combustible or ammable materials in the same room with
the equipment. Some products contain relays with moving parts and
are not ignition-protected.
Ensure AC, DC, and ground cable sizes conform to local codes. See
product manuals for minimum size requirements.
Ensure all conductors are in good condition.
Do not operate the unit with damaged or substandard cabling.
CAUTION!
Equipment Damage
When connecting cables from the inverter to the battery terminals,
ensure the proper polarity is observed. Connecting the cables
incorrectly can damage or destroy the equipment and void the
product warranty.
Thoroughly inspect the equipment prior to energizing. Verify that no
tools or equipment have been inadvertently left behind.
Keep all vents clear of obstructions that can prevent proper air ow
around, or through, the unit.
CAUTION!
Equipment Damage
Static electricity may damage electronic components. Take appropriate
steps to prevent such damage to the inverter; otherwise the warranty
may be annulled.
GENERAL INFORMATION

gpelectric.com | [page 7]
Battery Safety
WARNING!
Explosion, Electrocution, or
Fire Hazard
Ensure the cables (conductors) are properly sized.
Ensure clearance requirements are strictly enforced around the batteries.
Ensure the area around the batteries is well ventilated and clean
of debris.
Never smoke, or allow a spark or ame near, the batteries.
Always use insulated tools. Avoid dropping tools onto batteries or
other electrical parts.
Never charge a frozen battery.
Never use old or untested batteries. Check each battery’s label for age,
type, and date code to ensure all batteries are identical.
If a battery must be removed, always remove the grounded terminal
from the battery rst. Make sure all devices are de-energized or
disconnected to avoid causing a spark.
GENERAL INFORMATION

[page 8] | gpelectric.com
IMPORTANT
Use the battery types recommended by Go Power! Follow the battery
manufacturer’s recommendations for installation and maintenance.
Insulate batteries as appropriate against freezing temperatures. A
discharged battery will freeze more easily than a charged one.
If a remote or automatic generator control system is used, disable the
starting circuit and/or disconnect the generator from its starting battery
while performing maintenance to prevent accidental starting.
Wear complete eye and clothing protection when working with
batteries. Avoid touching bare skin or eyes while working
near batteries.
Keep plenty of fresh water and soap nearby in case battery acid
contacts skin, clothing, or eyes.
If battery acid contacts skin or clothing, wash immediately with soap
and water. If acid enters the eye, immediately ood it with running
cold water for at least 20 minutes and get medical attention as soon
as possible.
CAUTION!
Equipment Damage
When connecting cables from the inverter to the battery terminals,
ensure the proper polarity is observed. Connecting the cables
incorrectly can damage or destroy the equipment and void the
product warranty.
Thoroughly inspect the equipment prior to energizing. Verify that no
tools or equipment have been inadvertently left behind.
Ensure clearance requirements are strictly enforced.
Keep all vents clear of obstructions that can prevent proper air ow
around, or through, the unit.
CAUTION!
Equipment Damage
Static electricity may damage electronic components. Take appropriate
steps to prevent such damage to the inverter; otherwise the warranty
may be annulled.
i
GENERAL INFORMATION

gpelectric.com | [page 9]
2.2 DISCLAIMERS
IMPORTANT: Please follow installation and wiring instructions exactly as outlined to ensure
safety. We recommend installation by an RV/marine technician or professional electrician to
ensure adherence to relevant electrical codes. We have made every reasonable effort to ensure
the accuracy of the instructions in this manual, but Go Power! does not guarantee that the
information is error free, nor do we make any other representation, warranty or guarantee that
the information is accurate, correct, reliable or current. The specications in this manual are for
reference purposes only and are subject to change without notice. For additional information
please see www.gpelectric.com.
DISCLAIMER: Go Power! disclaims liability for any direct, indirect or incidental damages caused
by, or in case of, installation not performed following the instructions and cautions in this
manual. Go Power! will refuse requests for exchanges or returns, resulting from the purchase
and installation of items which do not comply with local codes. To avoid such concerns Go
GENERAL INFORMATION

[page 10] | gpelectric.com
Remote port - Use this port to connect the optional remote control unit to the Inverter.
USB port - Use this port to connect a USB device.
Standard outlet - Use these sockets to connect AC loads to the Inverter.
Digital display - This display shows battery voltage and wattage.
ON / OFF - Use this button to turn the inverter ON or OFF.
Function LED - A single LED indicates Power (green) or Fault Condition (red).
2.3 MODIFIED HD FEATURES
D
E
F
C
B
A
NOTES
1 TYPE YOUR NOTES IN HERE
2 FEEL FREE TO MOVE/RESIZE THIS TABLE
REV ECO # DESCRIPTION DATE DRAWN BY
MATERIAL
FINISH
FINISH
SPEC
COLOR
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE
B
1:8
-
INVERTER, MSW, 5000W
1 OF 1
79227
SHEET
SIZE REVISION
SCALE
DRAWING NO
CAD REFERENCE
Carmanah Technologies Corp.
250 Bay Street
Victoria, BC Canada V9A 3K5
Tel [250] 380-0052
Fax [250] 380-0062
CHANGES SHALL BE INCORPORATED
ELECTRONICALLY BY THE DESIGN AUTHORITY
PDM MAINTAINED DATA
COPYRIGHT © 2012 BY
Carmanah Technologies Corp. Victoria, BC, Canada
ALL RIGHTS RESERVED. NO PART OF THIS
DOCUMENT MAY BE REPRODUCED STORED IN A
RETRIEVAL SYSTEM, OR TRANSMITTED IN ANY
FORM, WITHOUT THE WRITTEN PERMISSION OF
Carmanah Technologies Corp.
PROPRIETARY
ORIGINALLY DESIGNED BY
ORIGINALLY DRAWN BY
CHECKED BY DATE
DATE
DATE
Ben Jolie
Ben Jolie
12/13/2016
01/04/2017
UNLESS OTHERWISE SPECIFIED
DO NOT SCALE DRAWING
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.100-2000
TOLERANCES APPLY AS SHOWN BELOW
DECIMALS SURF FINISH ANGLES
.X
.XX
.XXX
.XXXX
± .1
± .01
± .005
± .0005
63 1
INCHES
THIRD ANGLE PROJECTION
DOC # DATE
21/12/11 57012 B
DOC REVISION
79227
ALL COMPONENTS AND PROCESSES TO BE ROHS COMPLIANT, CERTIFICATE REQUIRED WITH INITIAL SHIPMENT
NOTES
1 TYPE YOUR NOTES IN HERE
2 FEEL FREE TO MOVE/RESIZE THIS TABLE
REV ECO # DESCRIPTION DATE DRAWN BY
MATERIAL
FINISH
FINISH
SPEC
COLOR
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE
B
1:4
-
INVERTER, MSW, 3000W
1 OF 2
79222
SHEET
SIZE REVISION
SCALE
DRAWING NO
CAD REFERENCE
Carmanah Technologies Corp.
250 Bay Street
Victoria, BC Canada V9A 3K5
Tel [250] 380-0052
Fax [250] 380-0062
CHANGES SHALL BE INCORPORATED
ELECTRONICALLY BY THE DESIGN AUTHORITY
PDM MAINTAINED DATA
COPYRIGHT © 2012 BY
Carmanah Technologies Corp. Victoria, BC, Canada
ALL RIGHTS RESERVED. NO PART OF THIS
DOCUMENT MAY BE REPRODUCED STORED IN A
RETRIEVAL SYSTEM, OR TRANSMITTED IN ANY
FORM, WITHOUT THE WRITTEN PERMISSION OF
Carmanah Technologies Corp.
PROPRIETARY
ORIGINALLY DESIGNED BY
ORIGINALLY DRAWN BY
CHECKED BY DATE
DATE
DATE
Ben Jolie
Ben Jolie
12/13/2016
01/04/2017
UNLESS OTHERWISE SPECIFIED
DO NOT SCALE DRAWING
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.100-2000
TOLERANCES APPLY AS SHOWN BELOW
DECIMALS SURF FINISH ANGLES
.X
.XX
.XXX
.XXXX
± .1
± .01
± .005
± .0005
63 1
INCHES
THIRD ANGLE PROJECTION
DOC # DATE
21/12/11 57012 B
DOC REVISION
79222
ALL COMPONENTS AND PROCESSES TO BE ROHS COMPLIANT, CERTIFICATE REQUIRED WITH INITIAL SHIPMENT
NOTES
1 TYPE YOUR NOTES IN HERE
2 FEEL FREE TO MOVE/RESIZE THIS TABLE
REV ECO # DESCRIPTION DATE DRAWN BY
MATERIAL
FINISH
FINISH
SPEC
COLOR
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE
B
1:4
-
INVERTER, MSW 1750W
1 OF 1
79228
SHEET
SIZE REVISION
SCALE
DRAWING NO
CAD REFERENCE
Carmanah Technologies Corp.
250 Bay Street
Victoria, BC Canada V9A 3K5
Tel [250] 380-0052
Fax [250] 380-0062
CHANGES SHALL BE INCORPORATED
ELECTRONICALLY BY THE DESIGN AUTHORITY
PDM MAINTAINED DATA
COPYRIGHT © 2012 BY
Carmanah Technologies Corp. Victoria, BC, Canada
ALL RIGHTS RESERVED. NO PART OF THIS
DOCUMENT MAY BE REPRODUCED STORED IN A
RETRIEVAL SYSTEM, OR TRANSMITTED IN ANY
FORM, WITHOUT THE WRITTEN PERMISSION OF
Carmanah Technologies Corp.
PROPRIETARY
ORIGINALLY DESIGNED BY
ORIGINALLY DRAWN BY
CHECKED BY DATE
DATE
DATE
Ben Jolie
Ben Jolie
12/13/2016
01/04/2017
UNLESS OTHERWISE SPECIFIED
DO NOT SCALE DRAWING
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.100-2000
TOLERANCES APPLY AS SHOWN BELOW
DECIMALS SURF FINISH ANGLES
.X
.XX
.XXX
.XXXX
± .1
± .01
± .005
± .0005
63 1
INCHES
THIRD ANGLE PROJECTION
DOC # DATE
21/12/11 57012 B
DOC REVISION
79228
ALL COMPONENTS AND PROCESSES TO BE ROHS COMPLIANT, CERTIFICATE REQUIRED WITH INITIAL SHIPMENT
GP-1750HD GP-3000HD
GP-5000HD
B
F
D
B
F
D
C
C
C
E
E
E
A
D
F
A
8888
8888
8888
B
A
GENERAL INFORMATION

gpelectric.com | [page 11]
DC input connector - Use these connection points to secure the battery bank negative and
positive cables to the Inverter. Always ensure the DC terminal covers are used to protect the
terminals.
Chassis ground - Use this connection to ground the exposed chassis of the inverter to the
chassis ground.
NOTES
1 TYPE YOUR NOTES IN HERE
2 FEEL FREE TO MOVE/RESIZE THIS TABLE
REV ECO # DESCRIPTION DATE DRAWN BY
MATERIAL
FINISH
FINISH
SPEC
COLOR
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE
B
1:8
-
INVERTER, MSW, 5000W
1 OF 1
79227
SHEET
SIZE REVISION
SCALE
DRAWING NO
CAD REFERENCE
Carmanah Technologies Corp.
250 Bay Street
Victoria, BC Canada V9A 3K5
Tel [250] 380-0052
Fax [250] 380-0062
CHANGES SHALL BE INCORPORATED
ELECTRONICALLY BY THE DESIGN AUTHORITY
PDM MAINTAINED DATA
COPYRIGHT © 2012 BY
Carmanah Technologies Corp. Victoria, BC, Canada
ALL RIGHTS RESERVED. NO PART OF THIS
DOCUMENT MAY BE REPRODUCED STORED IN A
RETRIEVAL SYSTEM, OR TRANSMITTED IN ANY
FORM, WITHOUT THE WRITTEN PERMISSION OF
Carmanah Technologies Corp.
PROPRIETARY
ORIGINALLY DESIGNED BY
ORIGINALLY DRAWN BY
CHECKED BY DATE
DATE
DATE
Ben Jolie
Ben Jolie
12/13/2016
01/04/2017
UNLESS OTHERWISE SPECIFIED
DO NOT SCALE DRAWING
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.100-2000
TOLERANCES APPLY AS SHOWN BELOW
DECIMALS SURF FINISH ANGLES
.X
.XX
.XXX
.XXXX
± .1
± .01
± .005
± .0005
63 1
INCHES
THIRD ANGLE PROJECTION
DOC # DATE
21/12/11 57012 B
DOC REVISION
79227
ALL COMPONENTS AND PROCESSES TO BE ROHS COMPLIANT, CERTIFICATE REQUIRED WITH INITIAL SHIPMENT
NOTES
1 TYPE YOUR NOTES IN HERE
2 FEEL FREE TO MOVE/RESIZE THIS TABLE
REV ECO # DESCRIPTION DATE DRAWN BY
MATERIAL
FINISH
FINISH
SPEC
COLOR
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE
B
1:4
-
INVERTER, MSW, 3000W
1 OF 2
79222
SHEET
SIZE REVISION
SCALE
DRAWING NO
CAD REFERENCE
Carmanah Technologies Corp.
250 Bay Street
Victoria, BC Canada V9A 3K5
Tel [250] 380-0052
Fax [250] 380-0062
CHANGES SHALL BE INCORPORATED
ELECTRONICALLY BY THE DESIGN AUTHORITY
PDM MAINTAINED DATA
COPYRIGHT © 2012 BY
Carmanah Technologies Corp. Victoria, BC, Canada
ALL RIGHTS RESERVED. NO PART OF THIS
DOCUMENT MAY BE REPRODUCED STORED IN A
RETRIEVAL SYSTEM, OR TRANSMITTED IN ANY
FORM, WITHOUT THE WRITTEN PERMISSION OF
Carmanah Technologies Corp.
PROPRIETARY
ORIGINALLY DESIGNED BY
ORIGINALLY DRAWN BY
CHECKED BY DATE
DATE
DATE
Ben Jolie
Ben Jolie
12/13/2016
01/04/2017
UNLESS OTHERWISE SPECIFIED
DO NOT SCALE DRAWING
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.100-2000
TOLERANCES APPLY AS SHOWN BELOW
DECIMALS SURF FINISH ANGLES
.X
.XX
.XXX
.XXXX
± .1
± .01
± .005
± .0005
63 1
INCHES
THIRD ANGLE PROJECTION
DOC # DATE
21/12/11 57012 B
DOC REVISION
79222
ALL COMPONENTS AND PROCESSES TO BE ROHS COMPLIANT, CERTIFICATE REQUIRED WITH INITIAL SHIPMENT
NOTES
1 TYPE YOUR NOTES IN HERE
2 FEEL FREE TO MOVE/RESIZE THIS TABLE
REV ECO # DESCRIPTION DATE DRAWN BY
MATERIAL
FINISH
FINISH
SPEC
COLOR
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE
B
1:4
-
INVERTER, MSW 1750W
1 OF 1
79228
SHEET
SIZE REVISION
SCALE
DRAWING NO
CAD REFERENCE
Carmanah Technologies Corp.
250 Bay Street
Victoria, BC Canada V9A 3K5
Tel [250] 380-0052
Fax [250] 380-0062
CHANGES SHALL BE INCORPORATED
ELECTRONICALLY BY THE DESIGN AUTHORITY
PDM MAINTAINED DATA
COPYRIGHT © 2012 BY
Carmanah Technologies Corp. Victoria, BC, Canada
ALL RIGHTS RESERVED. NO PART OF THIS
DOCUMENT MAY BE REPRODUCED STORED IN A
RETRIEVAL SYSTEM, OR TRANSMITTED IN ANY
FORM, WITHOUT THE WRITTEN PERMISSION OF
Carmanah Technologies Corp.
PROPRIETARY
ORIGINALLY DESIGNED BY
ORIGINALLY DRAWN BY
CHECKED BY DATE
DATE
DATE
Ben Jolie
Ben Jolie
12/13/2016
01/04/2017
UNLESS OTHERWISE SPECIFIED
DO NOT SCALE DRAWING
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.100-2000
TOLERANCES APPLY AS SHOWN BELOW
DECIMALS SURF FINISH ANGLES
.X
.XX
.XXX
.XXXX
± .1
± .01
± .005
± .0005
63 1
INCHES
THIRD ANGLE PROJECTION
DOC # DATE
21/12/11 57012 B
DOC REVISION
79228
ALL COMPONENTS AND PROCESSES TO BE ROHS COMPLIANT, CERTIFICATE REQUIRED WITH INITIAL SHIPMENT
GP-1750HD GP-3000HD
GP-5000HD
1
2
2
1
2
1
1
1
1
2
1
GENERAL INFORMATION

[page 12] | gpelectric.com
ELECTRICAL SPECIFICATION ITEM MODEL NO.
GP-1750HD
INPUT
CHARACTERISTICS
VOLTAGE RANGE 10.5 - 16 VDC
INPUT OVER VOLTAGE PROTECTION 16.5 VDC
INPUT UNDER VOLTAGE PROTECTION 10 ± 0.5 VDC
NO LOAD CURRENT ≤1 A
OUTPUT
CHARACTERISTICS
CONTINUOUS OUTPUT WATTAGE 1750 W
MAXIMUM SURGE RATING 3500 W
FREQUENCY 60 HZ ± 3 HZ
OUTPUT VOLTAGE 120 VAC RMS +5/-15
EFFICIENCY ≥80%
SHORT-CIRCUIT PROTECTION SYSTEM SHUTDOWN
USB OUTPUT VOLTAGE 4.75 - 5.25 VDC / 2.1 A
OUTPUT WAVEFORM MODIFIED SINE WAVE
AC OUTPUT CONNECTIONS 3 STANDARD NORTH AMERICAN OUTLETS
USB CONNECTIONS 1 USB PORTS
SIGNAL AND CONTROL REMOTE CONTROLLER PANEL UNIT GP-REMOTE (OPTIONAL)
PROTECTION
INPUT PROTECTION OVER / UNDER VOLTAGE
AC OUTPUT PROTECTION SHORT-CIRCUIT, OVERLOAD
OTHERS OVER / UNDER TEMPERATURE PROTECTION
ENVIRONMENT
OPERATING TEMP. 32° F - 104° F (-0° C - 40° C)
STORAGE TEMP. 14° F - 122° F (-10° C - 50° C)
STORAGE TEMP. & HUMIDITY 10 - 95% RH
DIMENSION (L X W X H) 8.07” X 8.86” X 3.50”
(205 MM X 225 MM X 89 MM)
WEIGHT 6.42 LBS (2.91 KG)
Cooling THERMOSTATICALLY CONTROLLED FAN
3. SPECIFICATIONS

gpelectric.com | [page 13]
ELECTRICAL SPECIFICATION ITEM MODEL NO.
GP-3000HD
INPUT
CHARACTERISTICS
VOLTAGE RANGE 10.5 - 16 VDC
INPUT OVER VOLTAGE PROTECTION 16.5 VDC
INPUT UNDER VOLTAGE PROTECTION 10 ± 0.5 VDC
NO LOAD CURRENT ≤1.2 A
OUTPUT
CHARACTERISTICS
CONTINUOUS OUTPUT WATTAGE 3000 W
MAXIMUM SURGE RATING 6000 W
FREQUENCY 60 HZ ± 3 HZ
OUTPUT VOLTAGE 120 VAC RMS +5/-15
EFFICIENCY ≥85%
SHORT-CIRCUIT PROTECTION SYSTEM SHUTDOWN
USB OUTPUT VOLTAGE 4.75 - 5.25 VDC / 2.1 A
OUTPUT WAVEFORM MODIFIED SINE WAVE
AC OUTPUT CONNECTIONS 4 STANDARD NORTH AMERICAN OUTLETS
USB CONNECTIONS 1 USB PORTS
SIGNAL AND CONTROL REMOTE CONTROLLER PANEL UNIT GP-REMOTE (OPTIONAL)
PROTECTION
INPUT PROTECTION OVER / UNDER VOLTAGE
AC OUTPUT PROTECTION SHORT-CIRCUIT, OVERLOAD
OTHERS OVER / UNDER TEMPERATURE PROTECTION
ENVIRONMENT
OPERATING TEMP. 32° F - 104° F (-0° C - 40° C)
STORAGE TEMP. 14° F - 122° F (-10° C - 50° C)
STORAGE TEMP. & HUMIDITY 10 - 95% RH
DIMENSION (L X W X H) 11.41” X 9.92” X 4.13”
(290 MM X 252 MM X 105 MM)
WEIGHT 10.54 LBS (4.78 KG)
Cooling THERMOSTATICALLY CONTROLLED FAN
SPECIFICATIONS

[page 14] | gpelectric.com
ELECTRICAL SPECIFICATION ITEM MODEL NO.
GP-5000HD
INPUT
CHARACTERISTICS
VOLTAGE RANGE 10.5 - 16 VDC
INPUT OVER VOLTAGE PROTECTION 16.5 VDC
INPUT UNDER VOLTAGE PROTECTION 10 ± 0.5 VDC
NO LOAD CURRENT ≤1.2 A
OUTPUT
CHARACTERISTICS
CONTINUOUS OUTPUT WATTAGE 5000 W
MAXIMUM SURGE RATING 10000 W
FREQUENCY 60 HZ ± 3 HZ
OUTPUT VOLTAGE 120 VAC RMS +5/-15
EFFICIENCY ≥80%
SHORT-CIRCUIT PROTECTION SYSTEM SHUTDOWN
USB OUTPUT VOLTAGE 4.75 - 5.25 VDC / 2.1 A
OUTPUT WAVEFORM MODIFIED SINE WAVE
AC OUTPUT CONNECTIONS 4 STANDARD NORTH AMERICAN OUTLETS
USB CONNECTIONS 1 USB PORTS
SIGNAL AND
CONTROL REMOTE CONTROLLER PANEL UNIT GP-REMOTE (OPTIONAL)
PROTECTION
INPUT PROTECTION OVER / UNDER VOLTAGE
AC OUTPUT PROTECTION SHORT-CIRCUIT, OVERLOAD
OTHERS OVER / UNDER TEMPERATURE PROTECTION
ENVIRONMENT
OPERATING TEMP. 32° F - 104° F (-0° C - 40° C)
STORAGE TEMP. 14° F - 122° F (-10° C - 50° C)
STORAGE TEMP. & HUMIDITY 10 - 95% RH
Dimension (L x W x H) 18.50” X 9.92” X 4.13”
(470 MM X 252 MM X 105 MM)
WEIGHT 15.65 LBS (7.10 KG)
COOLING THERMOSTATICALLY CONTROLLED FAN
SPECIFICATIONS

gpelectric.com | [page 15]
4.1 INSTALLATION PRECAUTIONS
1. Do not install the Inverter into a building’s electrical system. The Inverter is a vehicu-
lar accessory. It is not designed to be safely used in a building’s electrical system and
has not been evaluated to meet building wiring codes. Improper application may
create a re or electric shock hazard.
2. To allow proper cooling, install in an indoor well-ventilated area and do not cover ventila-
tion openings or cooling fans. Do not install in engine compartment. Avoid placing the
Inverter on carpets and rugs; they are not only ammable, but they also obstruct
vents underneath the Inverter.
3. Keep combustible materials and gases away from the Inverter. The Inverter produces sparks
and heat during operation and could start a re.
4. Connect to a 12 VDC power supply only. A power supply with lower voltage will not oper-
ate the Inverter correctly, and higher voltage could damage the Inverter.
5. Connect input polarity properly. Incorrect connection will damage the Inverter and void
warranty.
6. Keep the Inverter dry and clean. Do not expose to rain, snow, spray, bilge water, or dust.
7. Use cables that are the appropriate size. The more power (amps) or the longer the cables,
the thicker they need to be to prevent overheating and re. See section 4.7 DC WIRING SIZE.
8. Install the Inverter as close to the DC source as possible, but not in a closed area with vent-
ed lead-acid batteries. Vented lead-acid batteries release explosive hydrogen gas that can
be ignited by the Inverter.
9. Mount the Inverter horizontally.
10. Verify that the installation surface has no hidden utility lines before drilling or driving
screws.
11. This product is not a toy. Keep it out of reach of children.
12. Do not use with positive ground electrical systems (most automobiles, trucks, and RVs have
negative ground systems).
4. INSTALLATION

[page 16] | gpelectric.com
4.2 INVERTER SHUTDOWN
The Inverter has a number of shutdown points, for the safety of the operator, the Inverter, and
the devices being used with it.
• If the DC input voltage drops too low, the alarm on the Inverter will sound. If the input
voltage drops further, the Inverter will shut down automatically to prevent permanent
battery damage. Recharge the battery as soon as possible.
• If the DC input voltage exceeds 16 VDC, the Inverter will shut down automatically.
• If the output load power rises higher than the rating power of the Inverter, the Inverter
may shut down automatically.
• The Inverter may automatically shut down if its internal temperature gets too high.
Note: even though this Inverter has built-in mechanisms to minimize damage, these situations
should be avoided because they can still damage the Inverter or battery.
4.3 WHERE TO INSTALL
Your Inverter should be installed in a location that meets the following requirements:
1. Dry: do not allow water to drip or splash on the Inverter.
2. Cool:ambient air temperature should be between 0°C and 40°C (the cooler the better).
3. Ventilated: allow at least two inches of clearance around the inverter for airow. Ensure
the ventilation openings on the rear and bottom of the unit are not obstructed.
4. Safe: do not install the Inverter in the same compartment as batteries or in any compart-
ment capable of igniting ammable liquids such as gasoline.
5. The Inverter should be located within 10 feet of the batteries.
INSTALLATION

gpelectric.com | [page 17]
4.5 INSTALLATION AND TESTING
Battery Type Selection:
•
Use only deep-cycle lead-acid batteries with this Inverter, such as 12 volt marine/RV
deep-cycle batteries. Do not use automotive, engine starting (SLI), or maintenance-free
wet cell batteries with this Inverter; they are designed for repeated, shallow discharge
and will wear out quickly.
•
Gel and AGM (Absorbed Glass Mat) batteries can be used with this Inverter, but they
require special charging procedures. Refer to battery supplier’s instructions.
1. Unpack and inspect the Inverter, and make sure the power switch is in the OFF position.
Note: we recommend using Go Power! DC Install Kits when installing a Go Power! Inverter
(sold separately). Check section 4.7 DC WIRING SIZE to determine what Install Kits works
for your Inverter.
2. Connect the DC Inverter cables into the power input terminals on the back of the Invert-
er. Remember, the (+) terminal is positive and the (-) terminal is negative. Place the lug
connector between the washers and tighten the terminal screw or nut to clamp the wires
securely. Ensure connections are tight.
3. Connect the ground cable to the appropriate location; see section 4.8 GROUNDING.
4. First, connect the DC Inverter cables from the negative terminal of the Inverter to the nega-
tive terminal of the battery. Make sure the connection is secure.
5. Before proceeding further, carefully check that the cable you just connected is going from
the negative terminal of the Inverter to the negative output terminal of the battery.
6. Install the Inverter fuse into the positive lead. The fuse should be located within 12” (31
cm) of the battery. Ensure all connections are tight and secure.
7. Connect the cable of the positive terminal of the Inverter to the positive terminal of the
battery. Make a secure connection. Check your polarity
CAUTION! Equipment Damage.
Loose connections result in excessive voltage drop and may cause
overheated wires and melted insulation. Ensure connections are tight.
INSTALLATION

[page 18] | gpelectric.com
CAUTION! Equipment Damage.
This Inverter cannot supply power to any AC distribution wiring or AC
loads in which the neutral and ground are connected (bonded). Doing
so will destroy the unit and void the warranty. If you do not understand
neutral to ground bonding, please have a professional install your
system for you. See section 4.8 GROUNDING for more information.
WARNING! Fire/explosion Hazard.
You may observe a spark when you make the nal battery connection
since current may ow to charge capacitors in the Inverter. Do not make
this connection in the presence of ammable fumes, as explosion or re
may result.
8. Set the power switch to the ON position. Check the meters and indicators on the front
panel of the Inverter. The Function LEDs should be green showing the Inverter is ON. If it
does not, check your battery bank and the connections to the Inverter. The other indicators
should be OFF.
9. Set the Inverter switch to the OFF position. The indicator lights may blink and the internal
alarm may sound momentarily. This is normal. Plug the test load into the AC receptacle on
the front panel of the Inverter.
10. Set the Inverter switch to the ON position and turn the test load on; the Inverter should
supply power to the load. If you plan to measure the output voltage of the inverter, a true
RMS meter must be used for accurate readings.
INSTALLATION

gpelectric.com | [page 19]
4.6 BATTERY PRECAUTIONS
1. Wear splash-resistant ANSI-approved safety goggles and electrically-insulated gloves
while working near batteries.
2. Charge, store, and maintain batteries according to supplier’s instructions.
3. Locate batteries in a clean, well-ventilated area, away from ignition sources and ammable
materials. Vented lead-acid batteries release explosive hydrogen gas while charging.
4. Only connect similar batteries together. Do not connect old and new batteries together,
ooded and gel cells together, or batteries of different capacities together.
5. Only connect this Inverter to a 12V nominal battery bank. Do not attempt to connect
the Inverter to any other power source other than a battery with a nominal output
voltage of 12 volts or damage to the Inverter may occur and will void the warranty.
6. Connect batteries in parallel ONLY (negative terminals together to one cable; positive
terminals together to the other cable).
The following points must be observed for the DC Wiring.
•
The DC positive and negative cables connected to the Inverter from the battery bank
should be linked together with zip ties or electrical tape every 6”. This helps to reduce
radio frequency interference and reduces the effects of inductance both of which improve
the Inverter waveform and reduces the wear of the Inverters lter capacitors.
• To ensure optimum Inverter performance the number of connections between the battery
bank and the Inverter unit should be minimized except from the over-current and battery
disconnect devices. All additional connection points will cause extra voltage drops.
•
The Battery bank voltage must match the DC voltage required by the Inverter, which is 12V.
• All DC cable wire terminations should use a crimped and sealed copper ring terminal lugs.
• Make sure all cables have a smooth bend radius and no kinks are present.
• Colour code all DC Cables coming to/from the battery bank. Use coloured electrical tape
or heat shrink tubing. Red for positive (+), Black for negative (-) and Green for DC ground.
INSTALLATION

[page 20] | gpelectric.com
12 V
Lead-acid
Battery
OUTPUT
(to Inverter
Negative
Terminal)
OUTPUT
(to Inverter
Positive
Terminal)
12 V
Lead-acid
Battery
To increase
capacity,
connect
additional
12 V
Lead-acid
batteries
4.7 DC WIRING SIZING
The distance between the battery bank and the Inverter should be as short as possible to
achieve maximum efciency and to reduce re hazards. The gauge of the cable should be
sized appropriately to limit the voltage drop to less than 2% when carrying the maximum input
current to prevent frequent low-input voltage warnings and shutdown. Only use high quality
copper wire.
The cables should be as short as possible and the overall length of both cables added together
should be less than 10 ft (3 m) to comply with code requirements. Keeping your wire runs as
short as possible helps to prevent: low voltage shutdowns and nuisance tripping of the DC
breaker because of increased current draw. The table below shows the recommended DC cable
size, fuses/circuit breakers and DC grounding cable sizes for the Inverter (note: these values are
correct for cables in free air, not conduit).
MODEL WIRE AWG INLINE FUSE / CIRCUIT BREAKER
GP-1750HD #2 F-200
GP-3000HD 4/0 F-400
GP-5000HD 4/0 F-400
INSTALLATION
