Dometic SINEPOWER MSI 412 User manual

ENERGY & LIGHTING SINEPOWER
MSI412
EN Sine wave inverter
Installation and Operating Manual

EN 2
MSI
Please read this instruction manual carefully before installation and first use,
and store it in a safe place. If you pass on the product to another person, hand
over this instruction manual along with it.
Contents
1 Explanation of symbols................................................................................... 2
2 Safety instructions.......................................................................................... 3
3 Scope of delivery ............................................................................................ 5
4 Intended use .................................................................................................. 5
5 Technical description...................................................................................... 6
6 Fastening the inverter .................................................................................... 8
7 Connecting the inverter................................................................................ 10
8 Using the inverter......................................................................................... 11
9 Cleaning and caring for the inverter ............................................................. 12
10 Rectifying faults ........................................................................................... 12
11 Guarantee..................................................................................................... 14
12 Disposal ....................................................................................................... 14
13 Technical data.............................................................................................. 14
Explanation of symbols
1 Explanation of symbols
!
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal
or serious injury.

MSI
EN 3
!
A
I
2 Safety instructions
The manufacturer accepts no liability for damage in the following cases:
•Faulty assembly or connection
•Damage to the product resulting from mechanical influences and excess
voltage
•Alterations to the product without express permission from the manufacturer
•Use for purposes other than those described in the operating manual
2.1 General safety
WARNING!
•Electronic devices are not toys!
Keep electrical appliances out of reach from children or infirm persons. Do not
let them use the appliances without supervision.
•Persons (including children) whose physical, sensory or mental
capabilities or lack of experience and knowledge prevents them
from using the appliance safely should not use this appliance
without initial supervision or instruction by a responsible person.
•Use the device only as intended.
•Do not operate the device in a damp or wet environment.
Safety instructions
•Maintenance and repair work may only be carried out by qualified
personnel who are familiar with the risks involved and the relevant
regulations.
CAUTION! Safety instruction: Failure to observe this instruction can
lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and
impair the function of the product.
NOTE Supplementary information for operating the
product.
!

MSI
4 EN
2.2 Safety when installing the device
WARNING!
Take the precautions necessary to ensure that children cannot interfere with
operation.
Dangerous situations may occur which cannot be recognised by
children!
CAUTION!
Ensure the device is standing firmly.
The device must be set up and fastened in such a way that it cannot tip over or
fall down.
NOTICE!
Do not expose the device to a heat source (such as direct sunlight or heating).
Avoid additional heating of the device in this way.
Electrical cables
CAUTION!
•Lay the cables so that they cannot be tripped over or damaged.
•All the wiring must comply to AS3000 and AS3001.
NOTICE!
•If cables have to be fed through metal walls or other walls with sharp
edges, use ducts or wire bushings to prevent damage.
•Do not lay cables which are loose or bent next to electrically
conductive material (metal).
•Do not pull on the cables.
•Do not lay the 230 V mains cable and the 12 V DC cable in the same
duct.
•Fasten the cables securely.
•The electrical power supply may only be connected by a qualified
electrician.
Scope of delivery
!
!
A
!
A

MSI
EN 5
2.3 Operating the appliance safely
WARNING!
•Operate the device only if you are certain that the housing and the
cables are undamaged.
•Even after the fuse triggers, parts of the inverter remain live.
•Always disconnect the power supply when working on the device.
NOTICE!
•Make sure the air inlets and outlets of the device are not covered.
•Ensure good ventilation.
•Do not connect the 230 V output of the inverter (1) to a different
230 V source.
3 Scope of delivery
•Sine wave inverter
•4 holders
•Instruction Manual
Intended use
4 Intended use
The SinePower inverters are used to convert a direct current of 12 V into a 230 V
AC supply of 50 Hz.
!
A

MSI
6 EN
Rechargeable devices with USB interface can be charged via the USB port (5 V,
2000 mA).
This device is exclusively intended for vehicle use.
5 Technical description
The inverters can be used anywhere where there is a 12 Vg voltage source. The
inverters are connected to:
• Vehicle battery: MSI412 (12 Vg)
Devices MSI412 can be switched on and off optionally using an external switch.
The devices are additionally cooled with a load and temperature-dependent fan
(1).
The maximum constant output for the devices MSI412 is 350 W.
Never connect devices that have a higher power requirement.
I
Technical
description
NOTE
Note when connecting devices with an electrical drive (such as
power drills and refrigerators), that they often need more power
than is stated on the type plate.

MSI
EN 7
If the system has a short circuit, the device switches off.
If the voltage is too high, the device switches off and must be restarted manually.
If the input voltage is too high or too low or the system overheats, the device
switches off and then on again after a short while.
The inverter has the following connections, displays and control elements:
Pos.
Element
1
Switches
0: device is switched off
I: device is switched on
2
Green Status LED: lights up when inverter is in operation
3
Red Status LED: indicates malfunction
4
USB port
5
Connection for external switch
6
230 Vwsafety socket
7
Holders

MSI
8 EN
Pos.
Element
1
Connection cable for direct current
2
Fan
6 Fastening the inverter
You can fasten the inverter using the four holders supplied.
When selecting the installation location, observe the following instructions:
•The inverter can be mounted horizontally or vertically.
•The inverter must be installed in a place that is protected from moisture.
•The inverter may not be installed in the presence of flammable materials.
•The inverter may not be installed in a dusty environment.
•The place of installation must be well-ventilated. A ventilation system must be
present for installations in small, closed spaces. The minimum clearance
around the inverter must be at least 25 cm.
•The air intake on the underside or the air outlet on the back side of the inverter
must remain clear.

MSI
EN 9
Connecting the inverter
•For ambient temperatures higher than 40 °C (such as in engine or heating
compartments, or direct sunlight), the heat from the inverter under load can
lead to the automatic shut-off of the inverter.
•The installation surface must be level and sufficiently strong.
A
➤Clip two holders on the lower left bar and two on the right.
You can move the holders as required.
➤Fasten the inverter by screwing one screw through each hole in the holders.
NOTICE!
Before drilling any holes, ensure that no electrical cables or other
parts of the vehicle can be damaged by drilling, sawing and filing.

MSI
10 EN
7 Connecting the inverter
A
Make sure that a professional fuse is installed between the positive pole (+) and
the inverter. Mind the following values:
• MSI412: 40 A
Connecting the inverter
A
➤To set
up the
inverter, connect the red cable to the positive pole (+) of the vehicle battery
and the black cable to the negative pole (–) of the vehicle battery. Make sure
the vehicle battery terminals are clean when connecting them.
Connecting the external switch contact to the inverter
NOTICE!
The cable between the battery and the inverter may not exceed a
maximum length of 2 m.
NOTICE!
•If no sufficient, professional fuse is installed, the inverter could
be damaged and the gaurantee is invalidated.
•Do not reverse the polarity. Reversing the polarity of the
connections will cause a great spark and the internal fuses will
melt. These fuses should only be replaced by a qualified
electrician.
