Dormakaba Saffire LX-D User manual

WARNING
DO NOT REMOVE TAPE
12
3
DO NOT REMOVE TAPE
SLOT AT THE BOTTOM
14
2X
13 OR 2X FOR STEEL DOOR
A
2 1/8" (54mm) Hole saw
1" (25mm)
For maximum
security, install
reinforcing
plate.
Install long screws
in door stop side
Door stop
11
8
9
10
12
14
6
15
5
16
19
4
2
1
3
7
13
20
21
24
22
25
HORIZONTAL MOUNTING
OPTION
INSIDE TRIM
23
Saffire LX-D Installation Guide for door thickness
1 3/8" to 2 1/8"
Please read and follow all directions carefully. 1.
This lock is not designed to be used on emergency exit doors .2.
Carefully inspect glass, door frame, door, etc. to ensure the recommended procedure will not cause damage. 3.
dormakaba standard warranty does not cover damages caused by installation.
Wear safety glasses when making the holes. 4.
All the following operations and testing of the lock are to be done with door open. 5.
ADJUST BACKSET OF DEADBOLT 2.
INSTALL DEADBOLT IN DOOR 3.
Safety glasses •
1/2” (13mm) Chisel •
1/8” (3mm) Drill Bit •
5/32” (4mm) Drill Bit •
1” (25mm) Drill Bit or Hole Saw •
2 1/8” (54mm) Drill Bit or Hole •
Saw
Drill •
Awl or Center Punch •
Screwdriver, 1/8" Slotted •
Philips Screwdriver #2 •
Adjustable Square •
Tape Measure •
1C - DOOR PREPARATION
TOOLS REQUIRED
DEADBOLT IS PRE-SET AT 2 ¾" (70mm) BACKSET. PROCEED
AS SHOWN TO CHANGE TO 2 ⅜" (60mm) BACKSET, IF
REQUIRED.
Determine which template fits your Saffire LX-D lock installation, either 1.
2 3/8" (60mm) or 2 3/4" (70mm) backset.
Place appropriate template onto door and mark holes. 2.
Drill holes as per dimensions on the template. The 1" (25 mm) hole to 3.
be on the center line of door thickness.
Mortise door edge for dead bolt face plate. 4.
Drill 2 1/8" from both sides of the door to prevent unsightly damage. 5.
A = Backset = 2.3/4"(70mm) or 2 3/8" (60mm)
PART LIST & LOCK DIAGRAM
1B - INSTALL STRIKE ON STEEL FRAME
1A - INSTALL STRIKE ON WOOD FRAME
Please continue on next page.
For thicker door, please see order guide.
PK3705 - Rev 3
dormakaba Canada inc.
7301 Boul Décarie
Montréal QC H4P 2G7
Canada
1-877-468-3555
www.dormakaba.us
FOR DOOR THICKNESS BETWEEN 2-1/4" AND 2-1/2" PLEASE ORDER
HARDWARE KIT 062-515846.
ITEM
NO.
QTY. DESCRIPTION
1 1 FRONT LOCK HOUSING ASSEMBLY
2 1 GASKET FRONT LOCK HOUSING
3 1 TAIL PIECE
4 1 INSIDE TRIM ASSEMBLY
5 1 INSIDE TRIM COVER ASSEMBLY
6 1 DEADBOLT
7 1 STRIKER PLATE
8 1 DUST BOX
9 1 REINFORCING PLATE
10 2 PHILLIPS, 8 X 1" WOOD SCREW
11 2 PHILLIPS, 8 X 3" WOOD SCREW
12 2 PHILLIPS, 8-32 X 7/32" FLAT HEAD SCREW
13 4 PHILLIPS, 8-32 X 1/2" FLAT HEAD SCREW
14 2 PHILLIPS, 8 X 1" WOOD SCREW
15 1 6-32 X 3/16" PAN DEAD SCREW
16 3 PHILLIPS, 10-24 X 1-1/4" PAN HEAD SCREW
17 1 MESSENGER CABLE (OPTIONAL)
18 1 POWER CABLE
19 3 AA BATTERY
ITEM
NO.
QTY. DESCRIPTION
20 1 FIRE PLATE
21 1 BASE PLATE
22 1 COVER PLATE
23 1 LOCATING POST
24 3 FLAT HEAD SCREW
25 3 BUTTON HEAD SCREW

OUTER CAM GROOVE AT 12 O'CLOCK
INNER CAM
LEFT HAND (LH)
1- HOLD TO PREVENT ROTATION.
2- ROTATE TO CHANGE
FROM LH TO RH.
GROOVE AT 6 O'CLOCK
RIGHT HAND (RH)
TAIL PIECE SHALL BE "SNAP" IN PLACE WITH
WIRE RING OPENING ROTATED AT 6 O'CLOCK.
STEP 2
STEP 1
REMOVE TAPE
CONNECT V1 TO
V2 (POWER) CONNECT W1 TO W2
(COMMUNICATION
IF APPLICABLE)
AFTER CONNECTION, 6.
CABLES SHALL BE ROUTED
AROUND THE CLIPS
WARNING
ALIGN STUD AND TAIL PIECE
GENTLY INTO DEAD BOLT
TAIL PIECE MUST BE BELOW
DEADBOLT CENTER LINE
F
F
2
1
3
STEP 3
STEP 2
A
A
2
1
3
C
SECTION A-A
SCALE 1 : 4
DETAIL C
SCALE 1 : 1.5
TAB
STEP 4
STEP 5
GAP
KEEP CLEARANCE TO MINIMUM
TO FACILITATE INSTALLATION
OF COVER
G
SECTION F-F
SCALE 1 : 4
TAIL PIECE SHALL BE IN VERTICAL
POSITION & KNOB IN HORIZONTAL
POSITION.
STEP 1
KNOB
LH INSTALLATION
RH INSTALLATION
STEP 1
9. INSTALL INSIDE COVER
5. ASSEMBLE TAIL PIECE
6. REMOVE INSIDE
COVER
7. ASSEMBLE OUTSIDE HOUSING
4. ADJUST LOCK HANDING ON OUTSIDE HOUSING ASSEMBLY
8A - INSTALL INSIDE TRIM ASSEMBLY (VERTICAL MOUNTING ONLY) - FOR HORIZONTAL MOUNTING SEE 8B - SHEET 3 THEN
PROCEED WITH SECTION 9.
INSTALL INSIDE TRIM ON DOOR AS SHOWN BELOW, RUNNING CABLES THROUGH INSIDE TRIM BACKPLATE LOWER SLOT. 1.
CABLE SHALL BE PULL GENTLY TO ACCUMULATE ALL EXCESS WITHIN INSIDE TRIM.
INSTALL MOUNTING SCREW, 3X. 2.
BEFORE TIGHTENING THE SCREWS, DEADBOLT FUNCTIONALITY SHALL BE VALIDATED BY ROTATING TAIL PIECE FROM 3.
INSIDE. DEADBOLT SHALL MOVE SMOOTHLY.
ALL SCREWS SHALL BE TIGHTENED PROPERLY. 4.
INSTALL BATTERIES AFTER TIGHTENING ALL SCREWS AND CONNECTING WIRING V1 & V2 AND W1 & W2 IF APPLICABLE. 5.
HOLD INNER CAM IN PLACE, INNER CAM GROOVE ORIENTED AT 12 O'CLOCK. 1.
FOR RH LOCK, ROTATE OUTER CAM COUNTERCLOCKWISE UNTIL OUTER CAM GROOVE IS ORIENTED AT 6 O'CLOCK. 2.
FOR LH LOCK, ROTATE OUTER CAM CLOCKWISE UNTIL OUTER CAM GROOVE IS ORIENTED AT 12 O'CLOCK. 3.
STEP 2: MOVE THE COVER UPPWARD. TAIL PIECE MUST REMAIN
ENGAGED IN TURN KNOB.
STEP 3 : ENGAGE COVER'S TAB WITH BACK PLATE HOOK.
STEP 4: CLOSE COVER'S BOTTOM.
STEP 5: INSTALL SCREWS.
PK3705 - Rev 3
STEP 6: PROTECTIVE PLASTIC FILM SHALL BE REMOVED FROM
THE COVER, BOTH SIDE.
STEP 1: ENGAGE TAIL PIECE

CABLES SHALL BE PULLED GENTLY THROUGH INSIDE 1.
TRIM'S BACKPLATE TO ACCUMULATE ALL EXCESS
CABLES WITHIN THE INSIDE TRIM.
LH MOUNTING
INSTALL INSIDE COVER 10.
1
COVER PLATE AND INSIDE TRIM ASSEMBLY SHALL BE INSTALLED AS SHOWN WITH 3X SCREWS, ITEM 25.
LH
RH
CABLES SHALL BE PULLED GENTLY THROUGH INSIDE 1.
TRIM'S BACKPLATE TO ACCUMULATE ALL EXCESS
CABLES WITHIN THE INSIDE TRIM.
RH MOUNTING
CONNECT V1 TO
V2 (POWER)
8B - INSTALL INSIDE TRIM ASSEMBLY HORIZONTAL MOUNTING OPTION (IF APPLICABLE)
BEFORE TIGHTENING THE SCREWS VERIFY FUNCTIONALITY BY EXTRACTING AND RETRACTING THE DEADBOLT. DEADBOLT SHALL 1.
MOVE SMOOTHLY.
ALL SCREWS SHALL BE THIGHTEN PROPERLY. 2.
CONNECT BATTERIES AFTER TIGHTENING ALL SCREWS AND WIRING W1 & W2. 3.
POWER AND COMMUNICATION CABLES SHALL BE
CONNECTED AND ROUTED AS SHOWN.
LOCATING POST AND MOUNTING SCREWS SHALL BE
INSTALLED AS SHOWN.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.”
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.”
PK3705 - Rev 3
CONNECT W1 TO W2
(COMMUNICATION
IF APPLICABLE)

F
F
2
1
3
STEP 3
STEP 2
A
A
2
1
3
C
SECTION A-A
SCALE 1 : 4
TAB
HOOK
STEP 4
STEP 5
GAP
KEEP CLEARANCE TO MINIMUM
TO FACILITATE INSTALLATION
OF COVER
G
SECTION F-F
SCALE 1 : 4
TAIL PIECE SHALL BE IN VERTICAL
POSITION & KNOB IN HORIZONTAL
POSITION.
DETAIL A
STEP 1
KNOB
LH INSTALLATION
RH INSTALLATION
STEP 1
INSIDE TRIM COVER INSTALLATION, FOR MORE DETAIL PLEASE SEE SAFFIRE LX-D INSTALLATION GUIDE
STEP 2: MOVE THE COVER UPPWARD. TAIL PIECE MUST REMAIN ENGAGED IN TURN KNOB. SEE
DETAIL A & B
STEP 3 : ENGAGE COVER'S TAB WITH BACK PLATE HOOK.
STEP 4: CLOSE COVER'S BOTTOM.
STEP 5: INSTALL SCREWS.
PK3705B - Rev 1
STEP 6: PROTECTIVE PLASTIC FILM SHALL BE REMOVED FROM THE
COVER, BOTH SIDE.
STEP 1: ENGAGE TAIL PIECE
DETAIL B
