Doro MATRA 25 User manual

AFTI/MATRA 25
English
French
User Guide
Manuel d'utilisation
Telephone with Caller ID
Monobloc avec Présentation du
Numéro

1 Earpiece Volume Control
2 Talk Button
3 Recall (R) Button
4 Scroll (Up) Button and *
5 Scroll (Down)Button and #
6 OK Button
7 Menu Button
8 Delete/Disconnect Button
9 Line/Ringer Signal Indicator
English (see page 4-16)
Français (voir pages 17-27)
1 Réglage du volume
2 Touche décrocher
3 Touche R
4 Touche de délement et *
5 Touche de délement et #
6 Touche conrmation
7 Menu
8 Touche effacer/raccrocher
9 Indicateur de
communication/sonnerie

English
4 www.doro.com
Installation
Batteries
To ensure the display, memories, Caller ID, clock and other
functions operate, three good quality AAA 1.5V alkaline batteries
must be installed. When the batteries are running low, the
symbol will be visible in the display. Replace the batteries as soon
as possible! The battery compartment is located on the back of the
handset.
1. Ensure the telephone line cord is disconnected from the
telephone network wall socket.
2. Remove the battery cover.
3. Install the batteries ensuring correct battery polarity is observed.
4. Replace the battery cover.
Connection
Once the batteries have been installed.
1. Connect the telephone line cord to the telephone network wall
socket.
2. A click will be heard when the modular plug is correctly in place.
3. Press o and listen for the dial tone. Your telephone is now
operational.
4. Press l to terminate the call.
5. To set the time and date please refer to page 12.
Wall Mounting
1. Secure two screws, vertically positioned 100 mm apart.
2. Position the wall mount bracket on top of the screws and slide
it downward into place.
The telephone can now be placed in the wall socket after terminating
the call using l.

English
www.doro.com 5
Operation
Making a Call
1. Enter the required telephone number. Mistakes can be erased
using l.
2. Press o, and the displayed number will be dialled.
3. Press l to terminate the call.
Receiving a Call
1. Wait for the handset to ring, remove the handset from the wall
bracket.
2. Press o to answer the call.
3. Press l to terminate the call.
Volume Control
The earpiece volume may be adjusted (low, medium and high) during
a call using located on the side of the handset.
Timer
Approximately 5 seconds after dialling, a timer will be shown on the
display. The timer helps you keep track of how long the call lasts.
Mute Button
The handset microphone can be disabled during a call.
1. Press w repeatedly until MUTE ? is displayed. Press 0.
2. The display will show UNMUTE ? and z will ash so long as
the function is active.
3. Press 0 again to re-activate the microphone.

English
6 www.doro.com
Menu
Menu Description
The telephone has a menu system with display texts, controlled by
the following buttons:
W Access and scroll through the main menus
v/V Used to scroll through some submenus.
0 Conrms selected option.
l Delete/Correct, and to select standby mode.
The menu system will automatically time out after several seconds
if no buttons are pressed.
The menu contains the following main headings:
PHONEBOOK (VIP) Allows telephone numbers stored in the
phone book to be dialled or deleted
CALLER ID Displays a list of the most recently received
numbers.
REDIAL Displays a list of the most recently dialled
numbers.
STORE Allows numbers/names to be stored in the
phone book.
SETTINGS Set date/time, ringer signal and the text
language

English
www.doro.com 7
Caller Identication
Explanation of Caller ID
Caller ID allows you to see who is calling before you answer a
call, and see who has called in your absence. If a name is attached
to the telephone number and stored in the phone book, the name
will be shown while the phone is ringing. Received calls are stored
chronologically. The call log will store up to 30 telephone numbers.
When the log is full, the oldest number will be deleted automatically,
as the new call is logged.
IMPORTANT!
In order for numbers to be shown, the Caller ID service must be provided by your
network operator and a current subscription in place.
Contact your operator for more information.
Retrieving and Dialling Incoming Numbers.
1. Press w repeatedly until CALLER ID ? is displayed. Press 0.
2. Scroll to the required telephone number using v/V.
3. Press 0 to dial the number or l l to return to standby
mode.
Erasing Numbers
1. Press W repeatedly until CALLER ID ? is displayed. Press 0
2. Scroll to the required telephone number using v/V.
3. Press l. The display will show CLEAR ?
4. Press 0 to conrm.
Erasing all numbers
1. Press W repeatedly until CALLER ID ? is displayed. Press 0
2. Scroll to any telephone number using v/V.
3. Press and hold l until CLEAR ALL ? is displayed
4. Press 0 to conrm.

English
8 www.doro.com
Caller Identication
Transferring Numbers to the Phone Book
1. Press W repeatedly until CALLER ID ? is displayed. Press. 0
2. Scroll to the desired telephone number using v/V.
3. Press w. STORE ?will be displayed. Press 0.
4. For name registration please refer to page 10.
Messages
Besides showing telephone numbers, the display may also show a
number of messages:
NUM. UNKNOWN It is an International call or a call from a
PBX (no information received)
NUM. BLOCKED The call comes from a blocked number or
a PBX.
5 Message indication (sent from your network
operator).
Several calls have been received from this
particular phone number.
This number has not been detected before.
Redial
The ve most recently dialled numbers can easily be redialled.
1. Press w repeatedly until REDIAL ? is displayed. Press 0.
2. Scroll to the desired telephone number using v/V.
3. Press 0 to dial the displayed number or l to return to
standby mode.

English
www.doro.com 9
Phone Book
Using the Phone Book
The phone book will store 10 telephone numbers (20 digits
maximum) and names (13 characters maximum), this allows the
stored number to be dialled using fewer button presses than if dialled
manually. The phonebook is stored according to position (01-10).
Letters
Each number key has been allocated certain letters.
Button Letters/symbols
1.......................................... [Space character] . , ? ! - " ` ( ) 1
2.......................................... A B C 2
3.......................................... D E F 3
4.......................................... G H I 4
5.......................................... J K L 5
6.......................................... M N O 6
7.......................................... P Q R S 7
8.......................................... T U V 8
9.......................................... W X Y Z 9
0.......................................... 0
* .......................................... Delete/move back
#.......................................... Move forward
Dialling Numbers from the Phone Book
1. Press w repeatedly until VIP ? is displayed. Press 0.
2. Scroll to the required telephone number using v/V.
3. Press o, to dial the displayed number.

English
10 www.doro.com
Phone Book
Storing Phone Numbers and Names
1. Press w repeatedly until STORE ? is displayed. Press 0.
2. Enter the telephone number, including the area code. Use l
to delete entries or make changes.
3. Press 0.
4. Enter a name by pressing the corresponding number button until
the required letter is displayed, please refer to the table on the
previous page. Press l to delete or make changes. Once the
rst letter has been entered wait a second or two and repeat this
procedure until all you have entered the entire name required.
5. Press 0.
6. Enter memory position ( 0-9).
7. Press 0 to conrm.
Please note!
If the next letter is not on the same button, you can immediately press the button
containing the required letter, without waiting.
If you need to change the phone number, store the new number in the same
location as the old one.
Erasing Phone Numbers/Names
1. Press w repeatedly until VIP ? is displayed. Press 0.
2. Memory location 01 is displayed.
3. Scroll to the desired location using v/V.
4. Press l. CLEAR ? will be displayed.
5. Press 0 to conrm.
