Dräger Alcotest 6510 User manual

Dräger Alcotest®6510 - Dual Limit Breath Alcohol Screening Device
Approved by the Medical Bureau of Road Safety (MBRS)
Instructions for Use
i

Dräger Alcotest 6510 3
Content
Content
1 For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Product overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.1 Measuring device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.1 Inserting the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.2 Batteries to be used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.3 Fixing the hand strap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.4 Fitting the mouthpiece . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.5 Switching on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Performing the measurement . . . . . . . . . . . . . . . . . . . . . 8
5.1 Requirements of the person to be tested . . . . . . . . . . . . . . 8
5.2 Automatic measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.3 Error in delivering the breath sample . . . . . . . . . . . . . . . . 10
5.4 Removing the mouthpiece. . . . . . . . . . . . . . . . . . . . . . . . . 11
6 Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.1 Activation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.2 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.3 Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.1 Testing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.2 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.3 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.4 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7.5 Changing the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
8 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8.1 Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8.2 Batteries/Rechargeable batteries . . . . . . . . . . . . . . . . . . . 14
9 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4Dräger Alcotest 6510
For your safety
1 For your safety
Follow the instructions for use
Any use of the device requires understanding and observation of these
instructions.
The device is only to be used for the purposes specified herein.
Maintenance
Maintenance must only be performed by experts.
All repairs are carried out byDräger or the Medical Bureau of Road Sa-
fety (MBRS).
Only authentic spare parts may be used for maintenance.
Liability for proper function or damage
The device is not to be serviced or repaired by any person not employ-
ed or authorised by the MBRS.
Dräger cannot be held responsible for damage caused by non-
compliance with the recommendations given above.
The warranty and liability provisions of the terms of sale and delivery
of Dräger are likewise not modified by the recommendations given
above.
Dräger Safety AG & Co. KGaA
2 Intended use
The Alcotest®65101) is an apparatus for indicating the presence of al-
cohol in the breath. The Dual Limit Dräger Alcotest 6510 device was
approved by the MBRS on 9th December 2010. For mobile use with
batteries.
2.1 Preparation
The Alcotest 6510 is supplied calibrated to the MBRS by the manufac-
turer. If the calibration date exceeds 6 months arrange to have the de-
vice calibrated by the MBRS. The date of the last calibration can be
found in the menu (page 11).
1) Alcotest is a registered trademark of Dräger.
00123840.eps
OK
Alcotest 6510
M

Dräger Alcotest 6510 5
Product overview
3 Product overview
3.1 Measuring device
1 Display
2 Menu button "UP"
Selection of menu functions
3 "OK" button
Confirms entries or selected functions.
Button to switch device on and off.
4 Menu button "DOWN/MENU"
Entering menu functions
Selection of menu functions
5 Socket – not for use by operator
6 Lamp red/green
7 Mouthpiece receptacle
00223840.eps
OK
Alcotest 6510
M
1
2
3
4
6
7
5

6Dräger Alcotest 6510
Preparation
4 Preparation
4.1 Inserting the batteries
Upon initial operation or if the bat-
tery symbol on the display indi-
cates "empty".
1.
00423840.eps
Gently press onto the lock of
the battery compartment and
remove cover.
2. Observe correct polarity when
inserting the batteries!
3. Close battery cover.
4.2 Batteries to be used
2 each 1.5 V Type Alkaline
(Mignon, LR6, AA)
or
rechargeable battery 2*1.2 V NiMH
Battery symbol
Indicates the battery charging status:
Full battery
50 % battery capacity
Empty battery
02023840.eps
NOTICE
Charging batteries while in the device will cause damage to
the device.
00523840.eps
+ +
i
i

01223840.eps
Dräger Alcotest 6510 7
Preparation
4.3 Fixing the hand strap
1.
00923840.eps
OK
Alcotest 6510
Insert the smaller loop into the
hole in the housing.
2. Thread the longer loop
through the eyelet and pull
through.
4.4 Fitting the mouthpiece
1.
01023840.eps
Open packaging. To keep
the mouthpiece hygienic,
retain the part to come in
contact with the mouth co-
vered by the wrapping until
the mouthpiece is correctly
fitted to the device.
2.
01123840.eps
With the grooved markings
facing up, press the mouth-
piece into mouthpiece
receptacle until a click
sound confirms correct en-
gagement.
3.
00723840.eps
OK
Alcotest 6510
M
Remove packaging com-
pletely and commence
breath test.
zMouthpiece can be used
with orientation to right or
left side.
NOTICE
The symbols under the battery flap mean: Attention! Please
consult the user instructions!
Before changing batteries, please read the instructions. The
service socket is not for charging. Never insert a power cable.
i
i

8Dräger Alcotest 6510
Performing the measurement
4.5 Switching on and off
4.5.1 Switch on
02123840.eps
Alcotest 6510
zOK Keep - button pressed for
approx. 1 second until start
window is displayed.
4.5.2
shut-down in 2 sec.
Alcotest 6510
02223840.eps
Switch off
zOK Keep - button pressed.
The device displays the shut down
time.
4.5.3 Automatic
switch off
auto - shut-down
Alcotest 6510
02323840.eps
The device switches off automati-
cally 4 minutes after the last use.
When the batteries are discharged
the device switches off automati-
cally.
5 Performing the measurement
Conditions
zA new mouthpiece is to be used for every person tested.
zDo not apply too high alcohol concentrations on to sensor, e.g. by
rinsing the mouth with high-grade alcohols shortly before the
measurement. By doing so the sensor service life is reduced.
5.1 Requirements of the person to be tested
zAt least 20 minutes should elapse between the persons last drink
and before using the device.
Residual alcohol in the mouth can distort the measurement.
Aromatic drinks (e.g. fruit juice), mouth sprays containing alcohol,
medicines can interfere with measurements. Rinsing the mouth
with water or non-alcoholic drinks does not reduce this waiting
period!
zBefore sampling the person to be tested must breathe normally.
Quick inhaling and exhaling through the mouth must be avoided.

Dräger Alcotest 6510 9
Performing the measurement
5.2 Automatic measurement
zThe sampling is activated automatically. There is no provision for
manual sampling.
5.2.1 Preparation
02123840.eps
Alcotest 6510
1. Insert new mouthpiece in the
holder (page 7).
2. Switch device on (page 8).
z
02423840.eps
WAIT
After 2 seconds "WAIT" is indi-
cated on the display.
z
02523840.eps
Persons
Driver
Specied
After approx 8 seconds the
choice of person screen is dis-
played. Use the Mand
buttons to choose person and
the OK -button to confirm.
z
02623840.eps
READY
Test No. 00140
After approximately 6 seconds
"READY" is displayed and a
short audible signal is given.
zAt the same time the current
test number is indicated. A
green light flashes.
zThe device is ready for
measurement.
5.2.2 Performing the measurement
1.
02723840.eps
Blow
Ask the test subject to blow
evenly into the mouthpiece
without interruption. A suffici-
ent flow is indicated by a conti-
nous tone and a green light.
zWhilst the subject is blowing
the display shows: "Blow".
2.
02823840.eps
Analyzing
WAIT
When the sampling is suc-
cessful the green light will
cease and the continuous tone
will stop. Instruct the subject to
stop blowing.
The display shows: "WAIT
Analyzing".

10 Dräger Alcotest 6510
Performing the measurement
5.2.3 Test result
The breath alcohol value is measured in µg/100 mL. The result is dis-
played as "PASS" or "FAIL".
PASS
Driver ≤22 μg/100 mL
Specified ≤9 μg/100 mL
FAIL
Driver > 22 μg/100 mL
Specified > 9 μg/100 mL
zPress the OK - button to re-
turn to the Persons screen.
5.3 Error in delivering the breath sample
If the sampling volume is too low
or the sampling time is too short,
the display shows: "Insufficient
Volume".
zThe beep sounds briefly and a
red light flashes.
zTo repeat press the OK - button.
z
02523840.eps
Persons
Driver
Specied
Use the
M
and buttons to
choose person and the
OK -button to confirm.
The device is ready for
measurement after 4 seconds.
If the subject exhales incorrectly
e.g. by abruptly stopping or
sucking at the end of sampling, the
display shows either "Blow Inter-
ruption" or "Insufficient Volu-
me".
zThe beep sounds briefly and a
red light flashes.
zTo repeat press the OK - button. The device is ready for measure-
ment after 4 seconds.
z
02523840.eps
Persons
Driver
Specied
Use the Mand buttons to
choose person and the
OK -button to confirm.
The device is ready for
measurement after 4 seconds.
02923840.eps
PASS
03023840.eps
FAIL
03123840.eps
OK
Volume
Insucient
NOTICE
Switching the device off in the meantime does not reduce the
waiting period!
03223840.eps
OK
Interruption
Blow
i
i

Dräger Alcotest 6510 11
Menu
5.4 Removing the mouthpiece
z
00823840.eps
OK
Alcotest 6510
M
Push the mouthpiece out of
the mouthpiece holder.
zDispose of the mouth piece
properly.
6Menu
6.1 Activation
1. Switch device on. When "READY" appears on the display the me-
nu functions can be called up.
2. For menu press button
M
briefly.
6.2 Operation
zSelect functions using Mand buttons.
zThe selected function is highlighted.
zActivate the selected function by pressing OK - button.
zSelecting "Back to measurement" and pressing the
OK - button brings the device into the measuring mode.
If no button is pressed within 120 seconds, the device automatically re-
turns to the measuring mode.
6.3 Menu
Last test
Back to measurement
Accuracy check
Set contrast
Last cal. date
03323840.eps
Last test
Display of the last test.
Back with OK - button.
Accuracy check
Confirm proper measuring operati-
on.
Last cal. date
Display of last calibration date.
Back with - button.
Set contrast
Change by pressing and . Back with - button.
OK
MOK

12 Dräger Alcotest 6510
Maintenance
6.3.1 Procedure for carrying out an accuracy check
1. From the Menu select "Accuracy check" and press the
OK - button.
{The display shows the calibration check gas to be used.
{"Next" is automatically highlighted at the bottom of the
screen.
2. Press the OK - button.
{After a short period, "Supply gas" is displayed.
3. Fit a clean dry mouthpiece to the device.
4. Connect the outlet from the check gas cylinder to the mouthpiece
and allow gas to flow through the mouthpiece by pressing the val-
ve on top of the gas cylinder.
{A Beep is heard, followed by an audible click, when the device
has sampled the gas and "Remove gas, Analysing" is dis-
played momentarily.
5. Stop the flow of gas by releasing the valve at the top of the gas cy-
linder.
{The Check value and the Result of the check are displayed
and "Next" is highlighted at the bottom of the screen.
{The result should be between 19 to 24.9 μg/100 mL.
6. Record the result on the record sheet provided for that purpose. If
the result lies outside this range contact the MBRS.
7. Press the OK - button to return to menu.
{The display may show the recovery time counting down to
zero.
8. Scroll up to "Back to measurement".
9. Press the OK - button.
{The device returns to the Ready mode.
7 Maintenance
The operator may change the batteries as required (see page 13).
7.1 Testing
It is advisable that an accuracy check is carried periodically, i.e. on a
monthly basis (see page 12).
7.2 Calibration
The device should be returned to the MBRS for recalibration at 5-7
month intervals.
7.3 Storage
zThe Alcotest®6510 consumes a small amount of current even
when switched off. Therefore remove the batteries from the device
during long periods without use.
zThe Device should not be stored under extremes of temperature.
zOnly dispose of as special waste in accordance with local waste
disposal regulations.
zFor more information about suitable waste disposal companies
please contact the local authorities for environmental protection.
NOTICE
Accuracy checks may be carried out in either the "Specified
"option or "Driver" option.
i
i
CAUTION
Used alkaline batteries must not be thrown into open fire, be
recharged or opened by exerting force. Danger of explosion!
NOTICE
In case of long storage periods
Remove batteries from device, if the device is not used for
more than 6 months to avoid damage to the device caused by
leaking battery acid.
!
i
i

Dräger Alcotest 6510 13
Maintenance
7.4 Cleaning
z
00423840.eps
Do not submerge in liquid –
liquid must not enter the
sockets!
To clean:
zWipe with a disposable tissue.
zDo not use cleaning agents
containing alcohol or solvents.
7.5 Changing the bat-
teries
If the battery symbol on the display
indicates "empty" , change the bat-
teries.
zGently press onto the lock of
the battery compartment and
remove cover.
zRemove used batteries and in-
sert new ones – consider cor-
rect polarity.
zClose battery cover.
7.5.1 Required batteries:
2 each 1.5 V Type Alkaline (Mignon, LR6, AA)
or
rechargeable battery 2*1.2 V NiMH
zFor continuity of use it is recommended always to have replace-
ment batteries or an additional battery supply available.
00523840.eps
+ +
CAUTION
Used batteries
zdo not expose to fire,
zdo not recharge,
zdo not force open. Danger of an explosion!
!

14 Dräger Alcotest 6510
Disposal
8 Disposal
8.1 Devices
8.2 Batteries/Rechargeable batteries
EC-wide regulations for the disposal of electrical and electronic
equipment, which have been defined in the EU Directive
2002/96/EC and in national laws, have been effective since
August 2005 and apply to this device. Common household
appliances can be disposed of using special collecting and
recycling facilities. However, as this device has not been
registered for household usage, it must not be disposed of
through these means. The device can be returned to your
national Dräger Sales Organization for disposal. Please do not
hesitate to contact Dräger if you have any further questions on
this issue.
Only dispose of as special waste, in accordance with local waste
disposal regulations. Information can be obtained from
environmental agencies and from waste disposal companies.

Dräger Alcotest 6510 15
Troubleshooting
9 Troubleshooting
Symptom Fault Remedy
Device switches off automatically. Batteries discharged. Replace batteries.
Device has been left ready for measurement
for more than 4 minutes.
Switch device on again.
Device leaves menu mode automatically and
shows measuring mode.
Device automatically switches to measuring
mode after 120 seconds.
Re-select menu.
Device cannot be switched on. Batteries discharged. Replace batteries.
Insuffient volume, Blow interruption. Subject not blowing hard or evenly enough. Instruct the subject to blow in the correct man-
ner.
Breath alcohol concentration exceeds the
measuring limit.
Contact MBRS.
Display shows "Internal System Error". Device Error. No measuring function possible. Contact MBRS.
Display shows “Low Temperature
Warm up Device Error ID 600”.
Device is too cold. Warm up Device.
Display shows “High Temperature
Cool down Device Error ID 600”.
Device is too warm. Cool down Device.

90 23 840 - GA 4754.500
© Dräger Safety AG & Co. KGaA
Edition 04 - October 2011 (Edition 01 - April 2005)
Subject to alteration
Dräger Safety AG & Co. KGaA
Revalstraße 1
23560 Lübeck, Germany
Tel [phone]
Fax [phone]
www.draeger.com
