Dreame DreameBot D10 Plus User manual

De afbeeldingen in deze handleiding zijn alleen ter referentie. Zie het eigenlijke product.
D10 Plus
Robotstofzuiger en -dweil met
automatisch ledigen
Gebruiksaanwijzing

Contents
User Manual
Manuel d'utilisation
1
25
EN
FR

1
EN
Usage Restrictions
Safety Information
·This product should not be used by children younger than 8 years old
nor persons with physical, sensory, intellectual deficiencies, or limited
experience or knowledge without the supervision of a parent or guardian
to ensure safe operation and to avoid any risks. Cleaning and maintenance
shall not be performed by children without supervision.
·Children shall not play with this product. Ensure children and pets are kept
at a safe distance from the robot while it is operating.
·This product is for floor cleaning in a home environment only. Do not use it
outdoors, on non-floor surfaces, or in a commercial or industrial setting.
·Do not use the robot in an area suspended above ground level without a
protective barrier.
·Do not place the robot upside down. Do not use the LDS cover, robot cover, or
bumper as a handle for the robot.
·Do not use the robot at an ambient temperature above 40° C or below 0° C
or on a floor with liquids or sticky substances.
·Pick up any cables from the floor before using the robot to prevent it from
dragging them while cleaning.
·Remove fragile or small items from the floor to prevent the robot from
bumping into and damaging them.
·Keep hair, fingers, and other body parts away from the suction opening of
the robot.
·Keep the cleaning tool out of reach of children.
Read this manual carefully before use and keep it for future reference.

2
EN
Batteries and
Charging
·Do not use any third-party battery or auto-empty base. Use only with RCS7
supply unit.
·Do not attempt to disassemble, repair, or modify the battery or auto-
empty base on your own.
·Do not place the auto-empty base near a heat source.
·Do not use a wet cloth or wet hands to wipe or clean the base's charging
contacts.
·Do not improperly dispose of old batteries. Unneeded batteries should be
discarded at an appropriate recycling facility.
·If the power cord becomes damaged or broken, stop using it immediately
·Do not place children, pets, or any item on top of the robot regardless of
whether it is stationary or moving.
·Do not use the robot to clean any burning objects.
·Do not vacuum hard or sharp objects.
·Make sure the robot is turned off and the auto-empty base is unplugged
before cleaning or performing maintenance.
·Do not use a wet cloth to wipe or any liquid to rinse the robot and base.
Washable parts must be dried completely before installing and using
them.
·Please use this product in accordance with the instructions in the User
Manual. Users are responsible for any loss or damage that arise from
improper use of this product.
Usage Restrictions
Safety Information

3
EN
Hereby, Dreame Trading（Tianjin）Co., Ltd. declares that the radio equipment type RLS3D is in compliance with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following internet address: https://global.dreametech.com
For detailed e-manual, please go to https://global.dreametech.com/pages/user-manuals-and-faqs
Batteries and
Charging
Safety Information
and contact after-sales service.
·Make sure the robot is turned off when being transported and kept in its original
packaging if possible.
·If the robot will not be used for an extended period, fully charge it, then turn
it off and store in a cool, dry place. Recharge the robot at least once every 3
months to avoid over-discharging the battery.
·This product contains batteries that can only be replaced by qualified technicians
or after-sales service.
·The lithium-ion battery pack contains substances that are hazardous to the
environment. Before disposing of the robot vacuum, please first remove the
battery pack, then discard, or recycle it in accordance with local laws and
regulations of the country or region it is used in.
·When removing the batteries from the product, it is better to use up the batteries
and make sure your product is disconnected from power. Uninstall the screw on
the bottom, then remove the cover.
·Unplug the battery connector, then remove the batteries. Do not damage the
battery case to avoid any risk of injuries.
·Return the batteries to a professional recycling organization.
Laser Safety
Information
·The laser distance sensor complies with the IEC 60825-1:2014 standard for
Class 1 laser products and does not generate dangerous laser radiation.

4
EN
Accessories
Pre-Installed Accessories
Other Accessories
Product Overview
Water Tank Side Brush
Cleaning Tool
Main Brush Dust Bin
Power Cord
Mop Pad
Dust Collection Bag ×2
(1 pre-installed)

5
EN
Robot
Product Overview
Power/Clean Button
·Press and hold for 3 seconds
·Press to begin cleaning after the robot is powered on
Dock/Spot Clean Button
·Press to send the robot back to the base
·Press and hold for 3 seconds to start Spot Clean Mode
Status Indicator
·White: Cleaning or cleanup is completed
·Blinking Orange: Error
·Breathing White: Robot is charging when the battery
power is not low
Cover

6
EN
Reset Button
• Press and hold for 3
seconds to restore the
robot to factory settings
Wi-Fi Indicator
Cleaning Tool
Air Outlet/Speaker
Robot
Robot Sensors
Product Overview
Laser Distance Sensor
Bumper
Return-to-Base Sensor
Cli Sensors
Main Wheel
Cli Sensors
Cli Sensors
Main Wheel
Main Brush
Charging Contacts
Brush Guard Clips
Dust Intake
Universal Wheel
Side Brush
Charging Contacts

7
EN
Auto-Empty Base Open the upper cover
Bottom
Back
Product Overview
Upper Cover
Status Indicator
White: The base is plugged in
Breathing White: Robot is charging
Blinking Orange: Dust collection
bag is full/Dust collection bag not
installed/Error
Dust Bag Slot
Air Duct Cover
Mounting Screw
Filter
Signaling Area
Charging Contacts
Dust Intake
Cord Storage Slot
Power Cord Socket

8
EN
Dust Bin Mopping Module
Dust Collection Bag
Product Overview
Water Tank
Water Inlet
Attaching Area
Slot
Water Tank Release Clip
Mop Pad
Filter
Dust Bag Handle
Dust Intake
Bin Cover Release Clip
Bin Clip
Note: Due to the factory setting, a new dust collection bag has been installed inside already.
