DREAMS Calvert Bed King User manual

015-00134(Solid slats)
Calvert Bed King 015-00079(Sprung slats)
Assembly Instructions
1. We suggest you spend a short time reading through this leaflet and then follow
the simple step by step instructions.
2. If you follow the instructions carefully the end result should be worth the effort.
3. Do not discard any of the packaging until you have checked that you
have all the parts and the pack of fittings.
4. Assemble this product on a carpet.
5. To ensure an easier assembly, we strongly advise that all fittings are only
finger tightened during initial assembly. Only upon completion of the assembly
should all fixing points be fully tightened.
6. We recommend a periodic check on all fixing points to make sure they remain
fully tightened.
7. Keep glue and fittings out of children’s reach.
In the unlikely event that this product has missing or damaged parts, please call
0344 292 0000 to obtain spares
spare
Before you
Start, here
are some
helpful
advices.
Revision number 1/1

M6× 20mm x 8pcs
M6× 35mm x 6pcs
M6 × 6pcs
Metal Washer x 14 pcs
Plastic Washer x 8 pcs
Allen key × 2pcs
Screw x50mmx 1pcs
Revision number 1/1
PARTS Fittings
NO. PART LIST QTY
(1) Headboard 1
(2) Footboard 1
(3) Side Rails 2
(4) Support Leg 1
A
B
D
C
E
F
G

ASSEMBLY
Revision number 1/1
STEP1
(1) Use bolt A, washer D and
plastic washer E to fix the side
rail (3) onto headboard (1) and
footboard (2) by using Allen
Key (F).

ASSEMBLY
STEP 2
Revision number 1/1
NOTE: You have bought your bed,
choosing one of two slat options;
either solid or sprung. Although
both assembly options are explained
here only one will apply to you.
Please follow the correct procedure
for the slat system which you have
chosen.
Both slats on "step 2" and "step 3"
can be assembled to the bedstead.
you can make a choice between the
two slats.
OPTION"A": DREAMS FIXED
WOOD SLATS
（1）Carefully locate the slats
onto the unit,as step 2:
Use bolt (B) ,washer D and
JCN nut (C) to fix the unit
using Allen Key (F)
(2) Fit the adjustable support
wooden leg(4) to the centre
slat (there is a pre-dnlled hole
on the centre slat) as shown

ASSEMBLY
STEP 3
OPTION"B": DREAMS
SPRUNG SLATS
(1) Use the bolt to fix support
leg onto the slat frame.
Please note that these bolts are
to be found inside the slat
frame box.
(2) Carefully locate the slats
onto the unit.
(3) Use bolt (B) and JCN nut
(C) to fix the unit using Allen
Key (F).
Revision number 1/1
