DREAMS Yardley User manual

Yardley Ottoman
Single
Two person
assembly
1/2 hour approx
assembly time

Yardley Ottoman Single - Assembly Guide - Page 2
Important Ottoman
Safety Warnings
• IMPORTANT – READ CAREFULLY – RETAIN FOR FUTURE REFERENCE
• You must ensure that the mattress is on the bed frame before operating the lift
mechanism – Failure to do so could result in injury.
• Keep hands clear of the mechanism when opening or closing the ottoman.
• Beware of entrapment – Never reach in through the mechanism to access the
storage area.
• Always ensure that the ottoman is FULLY opened before accessing the storage area.
• Do not exceed the maximum weight as specified in the table below:
Bed Bed Size
Piston
Strength
(N/M)
Min Mattress
Weight (kg)
Max Mattress
Weight (kg)
Single 350 10 25
Double 450 15 35
Yardley

Thank you
Hello, thanks for choosing to purchase your bed from our company- you're now on your way to
creating a practical and stylish solution for your room. Before you begin building your bed,
please take a moment to read through the instructions and make sure that you've got all the
relevant parts listed on the following pages.
Assembly tips
Before you begin, it’s best to identify all parts and fittings to build your bed.
We advise laying these out on the floor to check you have everything, and
familiarising yourself before building.
We recommend that you build your new bed in the room you’d like it to
be located - this will help prevent any risk of damage to your newly built
sofa bed whilst moving it.
Top tip
Safety and care
It’s really important to ensure children and animals are kept away from the
assembly area, as there are small components used in this bed which could
present a choking hazard. All plastic and wrapping materials should also be
To keep your little ones busy, there is a colouring page inside the back cover.
Yardley Ottoman Single - Assembly Guide - Page 3
Recycling
Please ensure that packaging is disposed of in a safe and environmentally
friendly way, and recycle where possible. Our assembly instructions are
printed on recycled paper. Please keep your assembly instructions safe
to refer back to in the future.
Help and support
At Dreams, it’s our mission to give the whole nation a great night’s sleep - this
means that the quality of our products is of utmost importance to us. If there
are any issues with your product or any missing parts, please contact our Help
Centre on 0800 652 6750, where a member of our team will be happy to help.
(For customers based in Northern Ireland, please call 028 9050 8300)

Parts
1. Headboard x 1 pc □5. Fabric base x 1 pc □
Parts list
Yardley Ottoman Single - Assembly Guide - Page 4
2. Footboard x 1 pc □6. Metal slats frame x 1 pc □
3. Left siderail x 1 pc □7. Gas piston x 2 pcs □
4. Right siderail x 1 pc □
01
02
03
04
05
07
06
x2
Before assembly the bed, please open
the zipper at the back of headboard and
find footboard(02),bottom cover(05) here.

Fittings
Please check you have all the parts listed below with your product:
Yardley Ottoman Single - Assembly Guide - Page 5
0 1 2 3 4 5 6 7 8 9 1010 11 12 13 14 15 16 17 18 19cm
Tools required
Please check you have all these below:
Allen Key
Cx 1
Spanner (M8)
Ax 1
Metal Bracket
Dx 2
Black Soft Mat
Ix 2
Assembly
Scissors
Tape measure
Bolt (M8 x 20mm)
Bx 16
Bolt (M8 x 45mm)
Ex 8
Flat Washer
Fx 16
Nut (M8)
Gx 4
Nut (M8)
Hx 8

Assembly
BED FRAME ASSEMBLING
Loosely insert bolts (B) into
each side of headboard (1)
and foot board.
Note: Do not tighten fully
but leave 10mm protruding.
1
20 21 22 23 24
Yardley Ottoman Single - Assembly Guide - Page 6
Assembly
Attach the side rails to the
headboard and footboard.
Make certain the bed is
squared up, then tighten
all bolts fully.
Attach the corner brackets
to the headboard and footboard.
Stick the black soft mat on
the corner brackets.
2
Turn the bed on its side
and attach the fabric base
to the bottom of the side rails,
headboard and footboard.
Note: Make sure the fabric
is fixed evenly all around.
3
01
02
B
B
B
B
C
D
01
02
02
02
03
04
04
04
B
B
I
05

NOTE: When fully assembled and the mattress is
in position, please raise and lower the ottoman 4-5 times.
To ensure the gas pistons are fully lubricated.
6
Assembly
Put the slat frame on the lift mechanism,
use four sets of bolts (E), flat washers (F)
and nuts (H) to loosely fit the slat frame
to the first four holes on each side
of the lift nearest to the headboard,
finger tight.
4
Lift up the slat frame, use the locking
nut (G) to fit the pistons to
the lift mechanism.
Note: A small gap is left so stem can
move freely. This is normal,
See the sketch.
5
Yardley Ottoman Single - Assembly Guide - Page 7
Assembly
E
A
F
F
Tighten all the bolts after confirming
the metal frame is in correct position.
Frame must be in the center of bed in
length & width.
SMALL GAP
G
G
07
When fully assembled and the
mattress is in position,
please raise & lower the
ottoman 4-5 times
To ensure the gas pistions are
fully lubricated
Lift up the slat frame by one person with two hands.
Another one assemble the gas lift with nuts.
Don't over tighten, a small gap is left so stem can
move freely.
H

Yardley Ottoman Single - Assembly Guide - Page 8
How to use Ottoman Support Bar
Before accessing the ottoman storage area,
always ensure the ottoman support bar is engaged.
When engaging the ottoman support bar,
ensure the slat frame/ platform base is raised to
the maximum opening extension point i.e.
the uppermost height.
Locate the support bar from the inside of
slat frame / platform base.
Put the support bar into the bracket
fixed to the bed frame fully.
When you are ready to close the ottoman,
carefully locate the support bar and lift it
upwards out of the bed frame bracket and
guide it back to inside of the slat frame and secure it.
Slowly close the ottoman slat frame / platform
base using the handle provided.
2
1
• Recommended mattress weights - do not exceed the maximum relevant weight specified on the Assembly Instruction.
• Ottoman support bar - always engage the support bar when accessing the ottoman storage area.
• Read all instructions provided before using your Ottoman bedframe. Please save and retain the instructions
for future reference.

Yardley Ottoman Single - Assembly Guide - Page 9
Warnings
• You must ensure that the mattress is on the bed frame before operating the lift
mechanism – Failure to do so could result in injury.
• Keep hands clear of the mechanism when opening or closing the ottoman.
• Beware of entrapment – Never reach in through the mechanism to access the
storage area.
• Always ensure that the ottoman is FULLY opened before accessing the storage area.
• Do not exceed the maximum weight as specified in the table below:
• Use caution when operating, always use the handle when lifting
• Note: This bed uses a pressurised mechanism.
• To be operated by adults only
• Please ensure that children and pets are kept away from the bed when operating
the lift mechanism.
• Keep children and pets away from the storage area.
• Do not overload the internal storage base.
• Do not stand inside the internal storage area of the bed
• Before removing the mattress secure the frame to ensure it does not open unexpectedly.
• Do not attempt to lie on the mattress when the ottoman is in the raised position.
• When lifting the ottoman remove all bedding except the fitted sheet.
Bed Bed Size
Piston
Strength
(N/M)
Min Mattress
Weight (kg)
Max Mattress
Weight (kg)
Single 350 10 25
Double 450 15 35
Yardley

Yardley Ottoman Single - Care and maintenance - Page 9
Care and maintenance
Here are some tips to keep your new bed in tip-top condition
Cleaning
To clean your new bed, we'd advise using a warm damp cloth - please do not
use abrasive chemicals or bleach as this may damage the product.
Fabric
Please note depending on the lighting, positioning and surroundings of your
period of time, the colour might lighten or fade slightly due to light exposure.
Wood
Please note each of our wooden pieces are unique, meaning that markings and
shade can vary slightly between beds. Over a period of time, the wood might
lighten or fade slightly due to light exposure.
Metal
Metal tends to be more resilient to everyday wear and tear. We recommend to
gently dust your metal furniture and keep it dry to maintain its look.
Periodically we recommend you check that the screws or fixtures haven't been
become loose, over time. To move your new bed, we recommend lifting it where
possible, as dragging or pushing it could cause damage to your flooring.
Checking and moving
Thank you for shopping with us - we hope you have
a great night's sleep
