DXV D35403.410 User manual

- 1 -
INSTALLATION INSTRUCTIONS
SAVE FOR FUTURE USE
ROUGHING-IN DIMENSIONS:
• For reference
RECOMMENDED TOOLS AND MATERIALS
M965555 Rev. 1.1
In the United States:
DXV by American Standard
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: [phone]
www.DXV.com
In Canada:
DXV by American Standard
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: [phone]
www.DXV.ca
In Mexico:
DXV by American Standard
Via Morelos 330
Col. Santa Clara Coatitla
Ecatepec, Estado de México 55540
Toll Free: 01-800-8391200
www.DXV.mx
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing,
supply stores. It is essential that the tools and materials be on hand before work is begun.
Fresno™Single Control Bar Faucet
with Pull Down Spray
Model D35403.410
Thank you for selecting DXV by American Standard.
To ensure that your installation proceeds smoothly,
please read these instructions carefully
before you begin.
Adjustable WrenchChannel Locks Basin Wrench Plumbers' Putty or Caulking
Phillips Screwdriver
Regular Screwdriver
7-7/16"
(188mm)
5-5/16"
(135mm)
12-7/16"
(315mm)
6"
(153mm)
2"
(51 mm) 28-1/2"
(723mm)
3/8" (10mm) COMPRESSION
FLEXIBLE SUPPLIES
1-3/8" to 1-1/2"
(33 to 38mm)
DIA. MOUNTING HOLE
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2013

- 2 - M965555 Rev. 1.1
1
1
3
5
7
6
8
9
10
11
2
4
RECESS
SCREWDRIVER
12
CAUTION
INSTALL FITTING Turn off hot and cold water supplies before beginning.
• Make certain the O-RING SEAL (1) is properly seated in recess of faucet body.
• Insert supply HOSES (2), SHANK (3) and SPRAY HOSE (4) through center hole of sink or mounting surface.
• Assemble RUBBER WASHER (5), PLASTIC WASHER (6), RUBBER & METAL “C” WASHERS (7) and long LOCKNUT (8)
onto SHANK (3) from underside of sink. Hand tighten LOCKNUT (8) and check that faucet is centered.
• Tighten LOCKNUT (8) with WRENCH (12) supplied. Insert screwdriver into hole in WRENCH (12) and tighten.
• Feed HOSE END (9) through HOSE GUIDE (10). Slide other side of HOSE GUIDE (10) onto SHANK (3) and secure with
LOCK NUT (11). Do not over tighten!

- 3 - M965555 Rev. 1.1
Figure 2
SEAL
WASHER
SEAL
WASHER
2
1
3
5 7
64
Figure 1
UNDER SIDE
OF MOUNTING
SURFACE
18"
(457mm)
CONNECT HOSE SPRAY and INSTALL WEIGHT
• Check that seal washers are installed in both ends of SPRAY HOSE ADAPTER (1).
Thread SPRAY HOSE ADAPTER (1) onto faucet SHANK (2). Tighten with adjustable wrench. Figure 1.
• Thread HOSE END (3) into bottom of SPRAY HOSE ADAPTER (1). Tighten with adjustable wrench.
Make sure all connections are tight. Figure 1.
• Install RUBBER BUSHING (4) onto SPRAY HOSE (5). Install WEIGHTS (6) onto HOSE (5) using two screws (7). Locate
WEIGHTS (6) 18" from underside of mounting surface on HOSE (5). Tighten SCREWS (5) firmly. Figure 2.
3
MAKE WATER SUPPLY CONNECTIONS
• Turn off hot and cold water supplies before beginning.
• Connect FLEXIBLE SUPPLIES (1, 2) directly to wall supplies.
Connection on fitting supplies are 3/8" (10mm) compression. Connect
left supply (Marked with a Red Stripe) to Hot and right supply
(Marked with Blue Stripe) to Cold wall supply. Use adjustable
wrench to tighten connections. Do not over tighten.
• Faucet supplies are 27-1/2" (699mm) long from faucet base.
• Note: If additional supply length is required, installer must
purchase additional parts separately.
• Important: If SUPPLY HOSES (1, 2) are too long, loop as
illustrated to avoid kinking.
2
RED
STRIPE
BLUE
STRIPE
1
2
COLD
HOT

- 4 - M965555 Rev. 1.1
• Loosen and remove LEVER HANDLE (1). Loosen HANDLE SCREW (2)
with 2.5mm Hex Wrench and then pull HANDLE BASE (3) off.
• Unscrew ESCUTCHEON CAP (4). Unscrew theCARTRIDGE NUT (5).
• Remove CARTRIDGE (6). Clean inlets of CARTRIDGE (6) and MANIFOLD (7).
• Reassemble CARTRIDGE (6). Replace CARTRIDGE NUT (5), CAP (4) and
HANDLE assembly, check ow.
• Clogged CARTRIDGE outlets or inlets may cause reduced flow.
To clean, rst turn off water supply then:
• If SPOUT (7) leaks at swivel point the O-RINGS (8) need to be replaced. To remove SPOUT (7):
• Loosen the SPOUT SET SCREW (9) with a 3mm Hex wrench.
• Rotate the SPOUT (7) side to side while pulling upward to remove SPOUT (7) from faucet body.
• Replace the defective parts, grease O-RINGS (8) then push SPOUT (7) back into position. Tighten SET SCREW (9).
• Check that SPOUT (7) rotates freely and does not leak at the swivel point.
SERVICE
2
3
1
4
5
6
7
CLEAN
93mm HEX WRENCH
5
TEST INSTALLED FAUCET
• Unthread SPRAY HOSE (3) from SPRAY (2).
• Turn on water supplies and check connections for leaks.
• Hold HOSE END (3) in sink and operate HANDLE (1) on and off,
hot and cold to ush water lines thoroughly. Replace SPRAY (2).
• Pull SPRAY (2) out and check hose and supply connections
for leaks. Check that SPRAY HOSE (3) and WEIGHT (4) slide
up and down freely and do not interfear with supplies or waste
outlet plumbing.
• Check all drain connections for leaks.
• Move HANDLE (1) to "off" position.
• Move HANDLE (1) into "off" position.
3
4
HOT & COLD
SUPPLIES
4
8
1
2
3
REMOVE
INSTALL
7

- 5 - M965555 Rev. 1.1
Single Control Bar Faucet
with Pull Down Spray
Fresno™
MODEL NUMBER
D35403.410
M962650-0070A
HOSE WEIGHTS
M962648-0070A
SPOUT BUSHING
& O-RING KIT
M962690-0070A
CARTRIDGE NUT
M962652-0070A
SPOUT SET SCREW
M962691-YYY0A
CARTRIDGE COVER
M964406-0070A
CARTRIDGE
M964722-YYY0A
HANDLE KIT
M964748-YYY0A
SPOUT KIT
M962659-0070A
MOUNTING KIT
M962660-0070A
HOSE GUIDE
M962661-0070A
MOUNTING NUT
100
355
Replace the "YYY" with
POLISHED CHROME
ULTRA STEEL
M964724-YYY0A
PULL DOWN SPRAY
M962759-0020A
SPRAY HOSE
WITH SEALS
M964725-YYY0A
PEDESTAL
M962662-0070A
SPRAY HOSE ADAPTER
