Dynojet PCIII USB User manual

i511-411 www.powercommander.com 2005 Triumph Daytona 650 - PCIII USB - 1
2005 Triumph Daytona 650
Installation Instructions
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89031 [phone] www.powercommander.com
Parts List
1Power Commander
1USB Cable
1CD-ROM
1Installation Guide
1Power Adapter
2Power Commander Decals
2 Dynojet Decals
2 Velcro®Strip
1Alcohol Swab
1Dynojet O2 controller
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
The ignition must be turned off before installation.
After turning off the ignition make sure not to dis-
connect anything for at least one minute. If some-
thing is disconnected while the CDI is powering
down a check engine light may be indicated. Also
do not turn on the ignition while one of the electri-
cal connectors is unplugged. If a check engine
light is indicated the code can only be cleared by
a Triumph dealer.
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Button Adjustment Display
Faceplate Buttons
Expansion Port USB Port

1 Remove the seat.
2Remove the fuel tank
Note: The fuel tank does not need to be
removed to perform the install
but it will make it easier.
3Unplug the connector from the
throttle bodies to the wiring har-
ness (Fig. A).
4Plug the connectors from the
Power Commander in-line of the
stock connector (Fig. B).
5Route the Power Commander
wiring harness along the left
side of the frame (Fig C).
6Connect the ground wire from
the Power Commander to the
negative side of the battery
(Fig. C).
Fig. AFig. BFig. C
i511-411 www.powercommander.com 2005 Triumph Daytona 650 - PCIII USB - 2
Unplug this connector
PCIII connectors
Stock connector
Ground wire
PCIII harness

7Install the Power Commander in
the tail section. Make sure to
use the supplied alcohol swab to
clean the inner rear fender
before attaching the Power
Commander. Use the supplied
velcro to secure the unit to the
inner rear fender (Fig. D).
Fig. D
i511-411 www.powercommander.com 2005 Triumph Daytona 650 - PCIII USB - 3
8Unplug the stock O2 sensor
from the wiring harness. This
connector is located underneath
the fuel tank next to the regula-
tor/rectifier (Fig. E).
9Plug the Dynojet O2 controller
into the stock wiring harness.
Fig. E
10 Install the O2 controller to the
right side of the inner rear fend-
er (Fig. F) using the supplied
velcro.
11 Reinstall fuel tank and seats.
Fig. F
Unplug harness
O2 controller
