Dynojet Power Commander III 718-411 User manual

1997-1998 Moto Guzzi Centauro - PCIII USB - 1i718-411
1997-1998 Moto Guzzi Centauro
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 [phone] www.powercommander.com
Installation Instructions
Parts List
1 Power Commander
1 USB Cable
1 CD-ROM
1 Installation Guide
1 Power Adapter
2 Power Commander Decals
2 Dynojet Decals
1 Velcro®Strip
1 Alcohol Swab
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
The ignition MUST be turned
OFF before installation!
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Button Adjustment Display
Faceplate Buttons
Expansion Port USB Port

1 Remove seat assembly.
2 Place the PCIII in the tail section tem-
porarily.
3 Route the wiring harness from the
PCIII towards each cylinder. Route
the harness between the battery and
the frame going under the frame rails.
NOTE: It does not matter which lead
goes to which injector.
4 Unplug the stock wiring harness from
the injector (Fig. A).
5 Plug the connectors from the PCIII in-
line of the stock connectors (Fig. B).
6 Repeat steps 4 and 5 for the other
injector.
7 Unplug the Throttle Position Sensor
connector from the TPS on the right
hand side of the bike (on top of the
throttle body) (Fig C).
Fig. AFig. B
Fig. C
1997-1998 Moto Guzzi Centauro - PCIII USB - 2i718-411 www.powercommander.com
PCIII Connectors
Stock Connector
Stock Connector
Stock Connector

8 Plug the TPS connectors from the
PCIII in-line of the stock connectors
(Fig. D).
9 Ground the wire from the PCIII to the
negative side of the battery (Fig. E).
10 Mount the PCIII in one of two places.
Either in the tool tray area or between
the frame and the battery.
Fig. DFig. E
1997-1998 Moto Guzzi Centauro - PCIII USB - 3i718-411 www.powercommander.com
PCIII Connectors
Stock Connector
Ground wire from PCIII
